OneTech 2Z-ATK-6M User manual

Automatic Tyre Kille
2Z-ATK-6M
r Manual

Warning
Automatic tyre killer is a type of complicate equipment.
For to prevent product structure damage, forbid disassemble
equipment.
This product used with hazardous voltage, whole system need
periodically inspect, prevent personal injury.
Correct wiring connection according to directions, to prevent
equipment damage.
Please turn off power immediately when encounter any
abnormalities in commissioning.

Product Profile
Introduction
Tyre killer, also known as broken tyre device, the original intention of
tyre killer is to prevent vehicles escape from toll stations. The product
can be operated by manual buttons and remote control. Tyre killer can
slow down vehicle and has puncture tire functions, it is the essential
special facilities to prevent vehicles forcibly passed. Ensure the people's
life and property Safety.
Tyre killer main framework is composed of A3 steel plate (shape similar
like deceleration belt) and steel plate blade, adopts
electronic-mechanical integrated control device. It is an advanced device
that intercepts unauthorized vehicles and terrorists, has easy to operate,
reliable and safe advantages.
Features
1. The structure has sturdy and durable, stable speed, low noise
advantages, can adapt to a variety of working environment.
2. Mechanical hydraulic drive, simple installation, easy maintenance,
high safety performance, long service life.
3. Can be combined with other traffic control system to achieve linkage
control.
Technical Parameters
1. Input Voltage: 220V
2. Rated Power: 550w
3. Lifting Time: 1~2s
4. Load capacity(t):≤80
5. Operation Method: Wire Control/Remote Control
6. Working Temperature: -40～70℃

Installation
Materials Preparation
1. Cutting machine (for to break road);
2. Excavator with a broken hammer (for to break road);
3. Level ruler(equipment leveling);
4. Electric concrete vibrator;
5. C30 concrete;
6. Wire trunking, impact drill, drill (Φ6), Φ8 expansion screw (for to
fix indoor circuit and control box);
7. Φ50PVC pipe, T-pipe, straight PVC tube, elbow;
8. Φ32PVC pipe, T-pipe, straight PVC tube, elbow;
9. 8 * 0.75 cable(8 cores ,Φ0.75mm line);
3 * 2.5 cable(3 cores Φ2.5mm line);
2 * 1.5 cable(2 cores ,Φ1.5mm line);
All cable upon are RVV line.
10. Wire stripper;
11. Screwdriver and wrench;
12. Set of hex wrenches;
Installation Steps
1. Well prepared,clear the order and location of the various parts of the
installation, excavate foundation .
Note:
Depth of foundation=Tyre killer height(H)+Concrete thickness(300mm)
Length=Tyre killer length(L1)+Watering concrete(400mm)
Width=Tyre killer width(W1)+Watering concrete(400mm)
And one spare pit with for tyre killer hydraulic station, hydraulic station
pit depth is hydraulic station height(H1)+Concrete thickness(300mm),
set drainage for hydraulic station, method same to tyre killer as
following showed.
Above are recommend dimensions. Could make adjustments according
specific construction site.

2. Setφ75mm PVC pipeline as drainage, connect with drainage well.
Drainage well depth have to over 2m. If have municipal drainage
around, could connect equipment drainage pipe to municipal
drainage directly. Use anti-taste drain.
3. Set the electronic control system in the control room.
4. Pour 300mm depth C30 concrete over drainpipe, at least have 3
T-pipe orifices of the drainpipe averagely be set upon concrete level.
after concrete pouring, stir it with electric concrete vibrator. Have to
choose C30(Or higher mark concrete) to guarantee the foundation
strength, if customer request, could reinforce steel bar inside
foundation concrete. Concrete solidification time is about 24 hours.

5. When concrete completely solidified, use crane to hang tyre killer
into the foundation. Level the device with level ruler. Tyre killer
should 1mm higher than road surface. Equipment bottom gaps need
be filled and smoothed by concrete, prevent concrete flow into
equipment. (Attention: Be sure the tyre killer rising direction)
6. Connect tyre killer wire to electronic control system.
7. Secondary evenly pouring concrete around the equipment, prevent
concrete entering the equipment. Shake concrete with electric
concrete vibrator to reduce the gap. If the equipment changes
position when pouring , have to promptly adjusted. After the
adjustment, continue to construction and finish the second pouring
work.
8. Connect button panel.
9. According to the scene to restore the area.
Operation
Remote Controller
Switch is on the side of remote control.
Total four buttons on remote controller. A(Up), B(Down), C(Stop),
D(Spare Key).

Button Box
Three buttons on button box, Up; Down; Stop.
Up button rise tyre killer; Down button fall tyre killer; Stop button stop
running tyre killer.
Note
1. During operation MUST pay attention to pedestrian and traffic
safety.
2. Ensure the equipment has returned to its original position before
vehicle access.
3. Forbid people stand on tyre killer when equipment be operating.
4. Maintenance and repair should be under in the case of power cut.
5. Non-professionals are not free to disassemble the various
components of equipment to change the working environment of
the device, or working voltage.
6. If the system fails, notify company; forbidden to handle the
situation by clients without technique support, so as to avoid
unnecessary losses.
7. Forbidden to move the dedicated button box at will, to prevent
loosening of internal wiring.
8. When not using remote control, should be properly placed, turn off
the remote control switch to prevent misuse.
9. It is strictly forbidden to prevent mud and sand debris to fill the
equipment gaps, so as not to affect the equipment normal lifting.

Regular inspections and maintenance are the basis for ensuring that the
equipment works at optimum efficiency. Please pay attention to the
following points when performing equipment maintenance:
1. The electrical power should be cut off during electrical maintenance,
and the maintenance and inspection signs should be hung in a
prominent position.
2. Check the operation of switches, buttons, etc. once a month.
3. Check the screws on each terminal and each electrical component
loosely every month.
4. Regularly perform dust removal and maintenance on the surface of
the equipment and the electrical control system.
5. Screw the gear mechanism and mechanical fixing mechanism of the
equipment regularly.
6. Regularly clean up the internal debris of the equipment. Once per
month.
7. Clean the environment around the equipment every day, and clean
up the equipment as soon as debris enters the equipment.
8. Wipe the mechanical structure of the equipment with lubricating oil
every month.
9. Rise and fall at least 2 times a day to keep the equipment running
properly
