Onezili OZL-800 User manual

1
FEATURES
Digital control
42KHz for intensive rinse
1~30 minutes working time
Die casting stainless steel tank
Thank you for purchasing this ultrasonic cleaner. Please take some time to read these operating instructions before use
and keep them for future reference. Failure to follow these instructions may lead to serious artificial damages to the
product.
ULTRASONIC CLEANER OZL-800
USER MANUAL

2
ULTRASONIC PRINCIPLE
SAFETY PRECAUTIONS
● Make sure the voltage value is within the default voltage range.
● Don’t remould this machine.
● Please prevent the control panel from being eroded by detergent, acid or alkali solution
etc.
● Make sure the ground wire is well-connected with the machine before using the machine.
APPLICATIONS
This list is almost endless. Provided the product is non porous and can normally be
immersed in water, they can be thoroughly cleaned. Here are some examples:
Jewelry especially gold, silver & platinum
Watchstraps
Coins and other collectibles
Small PCB Boards
Toothbrushes & Dentures
Electrical components
Make-up cases
Tattoo needles
Knives, bayonets and other militaria
Ultrasonic cleaning is not recommended to be used to clean the following gemstones:
Opal, Pearl, Emerald, Tanzanite, Malachite, Turquoise, Lapis and Coral.
Ultrasonic cleaning is based on the cavitation effect caused by
high frequency ultrasonic wave vibration signal in the fluid.
Microscopic bubbles are formed, and then implode violently
causing the cavitation which create an intense scrubbing action
on the surface of the item being cleaned. The bubbles are small
enough to penetrate microscopic crevices, cleaning them
thoroughly and consistently.
Ultrasonic cleaning is extremely effective at removing dirt and
grime which would normally require tedious manual cleaning by
hand. It has been used to clean a wide variety of instruments and
mechanical parts such as carburetors, returning them to almost
“like new” condition without damage to delicate parts.

3
OPERATION
1. Fill at least 2/3 of the stainless steel tank with a cleaning solution. Based on cleaning
requirements, a small amount of cleaning solution is recommended because it will
help to increase the cleaning performance.
2. Dismantle the spare parts to be cleaned as possible as you can, and remove the dirt,
oil contaminants, carbon deposit etc with a high-pressure jet, wire brush,scraper
knife or other tools so as to prolong the service life of the cleaning solution and
ensure the cleaning speed and performance.
3. Put the spare parts to be cleaned into the tank and make them fully-immersed, but
not overlapped as possible as you can.
4. Start ultrasonic cleaning:
A. Connect the power socket on the back to a power with the power cord (the red
indicator will turns on and the LED screen will display “180”.)
B. Press the “TIME” button to switch the cleaning time in the following time
circulation: 90→ 120→ 150→ 180→ 210→ 240→ 270→ 300→ 330→ 360→ 540→
720→ 900→18. →21. →24. →27. → 30.→ 90 (18 cleaning time in total).
C. Press “ON/OFF” button once to make the machine start cleaning. The blue ultrasonic
indicator turns on, the setting time starts counting down. When the time reaches “886”,
the machine stop working automatically. Besides, the ultrasonic cleaning can also be
stopped by pressing “ON/OFF” once again.
D. Unplug the power cord, pour the cleaning solution, clean the tank and the housing
with a clean cloth.
5. In order to enhance the cleaning effect, you can add appropriate amount of detergent
into the cleaning solution or prolong the cleaning time.
6. The machine will stop working after 45 minutes continuous work, and can started
working again after 4 minutes’ break.

4
Specifications
Ultrasonic frequency
42KHz
Tank
SUS304 stainless steel
Housing
Stainless steel
capacity
800ml
Time control
0-30 minutes,18 cleaning time optional, digital control
Input voltage
AC100-120V,50/60Hz OR AC 220-240,50/60HZ
Ultrasonic Power
35W
Dimension
Tank: 154*88*65mm
Overall: 180*110*128mm
Package: 235*170*180mm
Weight
N.G. :1 kg G.W. :1.3kg
Removal of common fault
No.
Problems
Reasons
Solutions
1
Ultrasonic cleaning
does not work
A. The power lord is
not connected;
B. The fuse is burned;
C. High frequency wire
is disconnected or not
well-connected;
D. The circuit problem
of transducers;
E. Other reasons.
A.Check the power connection and plug
the power lord;
B.Change the burned fuse with a good
one of the proper voltage;
C.Connect or change the high
frequency wire;
D.Check the circuit or consult our
after-sale service department;
E.Find out the defective component,
replace it or ask our after-sale service
department for a new circuit board.
2
The time setting
does not work
A.The timer is broken;
B.Other reasons
A. Reset the power;
B. Change the timer or digital control
panel;
C. Consult the after-sale service
department;
3
Bad cleaning effect
A. Prolong the cleaning time;
B. Adjust the cleaning solution to a
best cleaning level;
C. Choose the right detergent;
4
Leakage of the
electricity
A. Ensure that the ground wire is
well-connected;
B. Check whether the ground wire is
loose and make it well-connected.
5
Other problems
Consult the after-sale service
department
