Onix ATP-014 User manual

Model Number: ATP-014
Heavy Duty Mobile Phone
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS

2
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
Welcome
Congratulations on choosing to buy an ONIX product.
All products brought to you by ONIX are manufactured to the highest standards
of performance and safety and, as part of our philosophy of customer service
and satisfaction, are backed by our comprehensive 1 Year Warranty. We hope
you will enjoy using your purchase for many years to come.

3
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
Contents
Welcome 2
General Safety Instructions 4
Product Overview 6
Getting Started 8
Instructions 9
Specifications 19

4
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
General Safety Instructions
Read this manual thoroughly before first use and keep it in a safe place for
future reference, along with the completed warranty card, purchase receipt
and carton. The safety precautions enclosed herein reduce the risk of fire,
electric shock and injury when correctly adhered to.
• Environment:Do not use this product where it is excessively hot, cold
or humid, or where it is exposed to strong magnetic fields, mechanical
vibrations or long periods of sunshine.
• Heat:Do not leave the unit near any heat sources, stoves, ovens or other
appliances (including amplifiers) that produce heat.
• Interference:Do not use the product near other electronic devices that
use radio frequency signals. Do not use it in hospitals or near medial
equipment. Avoid using the product within a 15cm range of a pacemaker.
• Batterycharger:Only use the charger provided with this product. Do not
touch the USB cable of the battery charger with wet hands. Do not bend
or damage the cable. Do not use the charger if the cable or power plug are
damaged. Do not drop or cause an impact to the charger. Do not use the
charger if it is damaged.
• Damage: Do not use the charger if the USB cable or plug are damaged. In
case of damage, contact the after sales support line for advice.
• Disconnect: Grip the plug when disconnecting the charger; do not pull on
the cable.
• Personalusage:This product is intended for personal use only; it is
not suitable for commercial use. Do not use it for anything other than its
intended purpose, and only use it as described in this manual.
• Restrictedusage:The product is not intended for use by persons
(including children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the equipment by a person
responsible for their safety.
• Children:This product is not a toy. Keep it away from young children.
Close supervision is necessary when the product is used by or near
children.

5
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
General Safety Instructions (Cont.)
• Repair:The product has no user-serviceable parts contained inside. Do not
attempt to repair, disassemble or modify it. Any modifications could void
your warranty.
• Packaging: Plastic packaging materials can present a suffocation hazard
for young children and babies. Keep all packaging materials out of
children’s reach to ensure they do not play with these.
• Thunderstorm: Do not use the product and its charger during a
thunderstorm to prevent malfunction and lower the risk of electric shock.
• Explosiveenvironments: Turn off the phone in potentially explosive
environments (such as at a petrol station or other refuelling points).
• Aircraft: Turn off the phone when boarding an aircraft.
• Roadsafety: Do not use the phone while driving a vehicle. Keep your
hands free to operate the vehicle at all times. Obey all local laws that apply
to mobile phone usage in your country.
• Batteryhandling:Do not expose the battery to high temperatures. Never
dispose of the battery in a fire. Observe local regulations for the disposal of
batteries.
• Flashlight: Do not use the flashlight close to the eyes of people or pets.
• Storage: Do not store your mobile phone near metal objects such as
coins, keys or jewellery that could scratch the product. Do not store it near
magnetic fields.
• Memorycards: Always handle the phone’s memory card(s) with care.
Protect the card(s) from static electricity and strong shocks.
• Disposal: When discarding this device, observe local regulations and
dispose of it appropriately for recycling. Contact your local authorities for
advice on facilities.
• Noncompliance:We accept no liability for any damage caused by
noncompliance with these instructions or any other improper use or
mishandling.

6
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
Product Overview
1 Earpiece
2 Micro USB socket
3 Display screen
4 Left selection button
5 Right selection button
6 Enter / Select button
7 Call button
8 End / Power button
9 Numbers buttons (keyboard)
10 Microphone
1
9
8
76
54
3
2
10

7
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
11 Rear camera
12 Loudspeaker
13 Battery bay (600mAh battery supplied,
but not pictured)
14 Micro SD slot
15 SIM card 2 bay
16 SIM card 1 bay
17 Charging adaptor (not pictured)
18 Micro USB cable (not pictured)
19 Earphones with microphone (not pictured)
Product Overview (Cont.)
11
12
14 15 16
13

8
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
Getting Started
Beforerstuse
• Unpack the product but keep all packaging materials until you have
made sure your new mobile phone is undamaged and in good working
order. Plastic wrapping can be a suffocation hazard for babies and young
children, so ensure all packaging materials are out of their reach.
• Unwind the USB cable to its full length and inspect it for damage. Do not
use the charger if it or the USB cable are damaged. In case of damage,
contact our after sales support line for advice,
• Read this manual to familiarise yourself with all the features and operating
principles of your new mobile phone.
InsertingtheSIMcard(s)andbattery
• Unscrew the two screws at the back of the phone and open the cover.
• If the battery is in place, remove it (refer to page 7).
• Insert your SIM card(s) and micro SD card in the dedicated space(s). First
insert the micro SD card, then insert a SIM card and, if you want to use two
SIM cards, insert the second SIM card on top, as marked on the housing
(see also page 7).
• Once the memory and SIM cards are securely in place, insert the battery
(supplied) into the phone, making sure to align the pins with the contacts.
• Reinstall the back cover and tighten the screws.
Chargingthebattery
The battery has been partially charged at the factory. To perform all functions,
we recommend you fully recharge it as follows:
• Connect the smaller end of the USB cable to the data connection of the
mobile phone (see pages 6-7) and the larger end to the battery charger.
• Insert the plug of the battery charger into an electrical outlet and switch on
power to the outlet.
• When the phone indicates a full charge (the battery status icon is located
in the top right corner of the display), switch off power to the charger and
disconnect the charger from the power point and the USB cable from the
device.
Follow the above charging procedure whenever your device indicates a low
battery charge.

9
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
Instructions
Basicoperations
Turningon
• Press and hold the End/Powerbutton to turn on the mobile phone.
Displayscreen
• A few moments after it is turned on, the screen
will display several icons indicating signal
strength, SIM card(s) in use, sound mode,
Bluetooth connection, keypad lock, battery
status, date, time etc., as illustrated on the right.
• The screen will turn off automatically after some
time of inactivity. Press any button to illuminate
the screen again.
Keypadlock
• When the keypad is locked, “Unlock” appears in
the bottom left corner of the display.
• To unlock the keyboard, press theLeftselection button, then press[*].
• To lock the keyboard in standby mode, press the End/Powerbutton.
Silentmode
• Press and hold the [# ]Hashbutton to turn the phone to silent; press this
button again to restore normal indoor mode.
DualSIMoperation
• This phone can be operated with two SIM cards. If you have two SIM cards
inserted, you will be prompted to choose a SIM card before you make a
call or send a message. You will also have to choose on which SIM card to
store messages and/or other data.
Dateandtimesetting
• See page 17 for how to set the date and time.
Menu
• Press the Leftselectionbutton to access the menu (menu operation
instructions start on page 11).
Names
• Press the Rightselectionbutton for a shortcut to the phone book.

10
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
Instructions (Cont.)
Makingacall
Use the numberbuttons to enter the number you want to call (including country
and area code, if necessary), then press the Callbutton (If you have two SIM
cards activated, you will be prompted to select the appropriate card first).
Answeringacall
When the phone rings, press the Callbutton to answer it.
Ending/rejectingacall
• Press the End/Powerbutton to end or reject a call.
Hands-freeoperation
• Plug the earphones and microphone cable into the Micro USB socket. The
ring tone will now be emitted through the earphones.
• Press the Callbutton to answer a call, then speak into the microphone.
Press the End/Power button to end a call. Alternatively, use the button on
your headphone to answer or end a call.
Viewingamissedcall
• When you have missed a call, the missed call icon will appear.
• To view the missed call, press the Leftselectionbutton to display the
number of the missed call. Press the button again to select OPTIONS
to view the call details, call back the caller, send a text message, send a
multimedia message, save to phone book or delete the number.
Calldivert
• When you inform the service provider to activate call divert, you can
forward all incoming calls to another number even though your phone is off
or has no reception (changes may apply) (see page 17).
Callbarring
• This feature must be supported by your service provider. When the call
barring function is activated, you can answer or make a call according to
your choice of barring mode. Access this feature via the menu, Call Centre,
then choose SIM1 or SIM2, Call barring (see page 17).
Callwaiting
• This is a network dependent feature. After this function is activated, your
phone notifies you when there is an incoming call during a call (changes
may apply) (see page 17).

11
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
Instructions (Cont.)
Menuoperation
When the screen is unlocked, “Menu” will be shown in the bottom left corner
of the display screen and “Names” in the right corner.
• Press the Leftselectionbutton to display your menu options: Messaging,
Phone book, Call Centre, Setting, Fun & Games, Multimedia, Services,
Tools and Profiles.
• Press the appropriate section of the Left/Right/Up/Downnavigation
ringto select a menu option, then press the Leftselectionbutton to
select OK and enter the menu.
• Press the Rightselectionbutton to select Back and go to the previous
menu screen.
Messages
Settings
Services
Tools
Call Centre
Profiles
Multimedia
Phonebook
Fun & Games

12
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
Instructions (Cont.)
CallCentre
Your phone keeps lists of incoming and outgoing calls, even for calls that did
not connect. The most recent calls are listed first.
Callhistory
• Enter the “Call Centre” menu in the main menu and then choose Call
History. Choose from the following call history options: missed calls, dialled
calls, received calls. You can also delete call logs of missed, dialled and
received calls, and examine call times, costs and use of messages.
Callsettings
• Here you can check or activate features such as call waiting, call divert,
call barring, call time reminders, auto redial, and answer mode. (Some
options may incur a fee from your service provider/s).
Multimedia
Enter the “Multimedia” menu and choose from the following options: audio
player, camera, image viewer, video player, video recorder, FM radio, sound
recorder.
• Audioplayer
Select this option to use the audio player to play music.
• Camera
Select this option to take photos with your mobile phone. The image to be
captured will be displayed on the screen.
Press the Enter/Selectbutton to take the photo, the picture just taken
will be displayed. You can send it via multimedia message, or via Bluetooth
wireless technology, or delete it (under Option), or go back to using the
Camera menu.
The camera options menu includes settings for photos (view the pictures
taken and stored), camera settings (anti-flicker, delay timer) and image
settings (size and quality), switch to video recorder, scene mode (auto or
night mode) and an option to restore factory default settings.
Important: When restoring factory default settings, be aware that you
will lose all user installed applications and data. We therefore strongly
recommend that you back up important data first.

13
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
Instructions (Cont.)
• Imageviewer
Select this menu item, then choose the submenu Options to view the
following options:
View View captured images and open them with the selection key
Useas Use the current photo for the wallpaper list, power on/off
display list, Bluetooth or MMS
Rename Change the name of the photo
Delete Delete the photo
Send Send via Bluetooth or via MMS
More
information
View more information of the image such as resolution, size
and creation date
• Videoplayer
Select this menu item to open the video player and view all recorded video
files. Then choose in the submenu from options to play, send, rename or
delete the video file.
• Videorecorder
Select this menu item to open the video recorder. Move the phone and
view the footage to be recorded on the screen. Press the Enter/Select
button to start recording the video footage, press it again to stop recording
(and again to resume, and so on). When you have finished recording, select
Stop to save the footage.
Enter the Options submenu to select appropriate camcorder settings.
• FMradio
Select this menu item to enter the FM radio application. You will be
prompted to connect earphones. On first use, press the Leftselection
button to choose Options, then select Auto search. Select Yes when
prompted to search and save channels. The radio application will search
for all available FM channels and store them in the Channel list. Select
Manual input to fine tune, if necessary. Choose Settings to set Background
play and Loudspeaker to on or off.
In the Channel list, choose Play to play the station, delete it or edit the
channel name.

14
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
• Soundrecorder
Select this menu item to open the sound recorder and view the sound files.
In the Options menu, select New Record (to start recording), play and list.
Select the settings option to choose your preferred recording audio quality.
Phonebook
• Enter the “Phonebook” menu to add a new contact or view your existing
contacts on your SIM cards and phone storage. Choose the Options
submenu on existing contacts to access the following options:
• View, Send text message, Send multimedia message, Call, Edit, Delete,
Copy or Phone book settings.
Userproles
In the “User profiles” menu you can activate or customise the following user
profiles: General, Silent, Meeting and Outdoor. In each profile you have options
for tone setting, volume, alert type, ring type, extra tone and answer mode.
Messaging
Enter the “Messaging” menu to exchange messages with other mobile phone
users and to manage your voice mail box.
Instructions (Cont.)
• Writemessage
Enter this submenu item directly to write a new text message (SMS) or
multimedia message (MMS). First select Text Message, then select Options
to select the recipient of the message, change input method, save the
draft message, and advanced options such as to add the name or number
into your template use, PHB (phone book) number and input method (for
example, by capital letter, small letter, numeric etc.).
• The Inboxholds received messages, the Outbox saved messages. Saved
messages are stored in Drafts.
• Messagesettings:This menu item contains the following options:
TextMessage Option to set up SIM1 and SIM2 settings in
addition to Save Sent Message options
MultimediaMessage Option to set up multimedia messages
ServiceMessage Option to enable/disable push and service
loading
PreferredStorage Phone or SIM card(s)

15
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
Instructions (Cont.)
• MMS
NewMMS:Enter details (phone number or email address) for the recipient
of the message, copy and blind copy, subject and message content. Once
you have entered the message, select Done and choose the send option
(send, send and save, save to drafts, or exit).
The Inboxholds all your received messages, the Outbox holds your saved
messages, sent messages are stored in the Sent box and draft messages
in the Draft box.
Messagesettings:This menu item provides options for setting your server
profile, compose (message signature), send and retrieval options and
memory status.
Aboutus:Here you can view details about the MMS software version.
NOTE:Before using multimedia messaging (MMS), please note that you will
have to enter your network settings. To do so, go to MMS Message
settings, Server profile and then select your service provider. If yours
is not listed, please ask your service provider for the required settings.

16
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
Tools
The “Tools” menu contains various tools: Bluetooth Wireless Technology
Setting, Alarm, Calendar, Calculator, File Manager and World Clock.
• Bluetooth®WirelessTechnology
This phone supports Bluetooth wireless technology. Enter this submenu
to connect the phone to other Bluetooth enabled devices. First set the
Bluetooth connection to “On” (Power) and then go to the My Device
submenu to search for devices or view paired and connected devices.
In the Visibility submenu you can set visibility options for the Bluetooth
enabled device; in the My Name submenu you can change the name of the
Bluetooth enabled device.
• Alarm
The Alarm function lets you set three different alarms. Select an Alarm and
then chose Edit to set it to on or off, set the time and repeat and snooze
options.
• Calendar
Enter the Calendar submenu and select Options. Enter Jump to date and
use the navigationringand numberbuttonsto go to the desired date
(year - month - day), then press OK.
• Calculator
Enter the Calculator submenu and then use the numberbuttons to enter
numeric values and the navigationring to select the function.
• Filemanager
Use this menu to access and manage your files on the memory card.
Options include: copy, move, delete, send via MMS or Bluetooth, rename,
and other actions through the Options submenu.
• Worldclock
Use this to check the time around the world.
Instructions (Cont.)
The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.,
and any use of such marks by Hands (IP) Holdings Pty Ltd is under license. Other trademarks
and trade names are those of their respective owners.

17
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
Settings
Enter the “Settings” menu to set your preferred settings. Submenu items
include Phone settings, Dual SIM settings, Network settings, Security
settings, and Restore settings to factory default.
• Phonesettings
Here you can set the current date and time, display language, preferred
input method, display options, dedicated keys, flight mode, screen auto
lock and miscellaneous settings. Just select the appropriate submenu item
and follow the prompts to adjust to your preference.
• DualSIMsettings
Enter this submenu to select which SIM card you want to use. You can
enable one SIM card only or both. When you have both enabled, you will
be prompted to select an appropriate SIM card when you are making a call
or sending a message.
• Networksettings
Enter this submenu to set up your network settings. When dual SIM
mode is activated, you can perform the network setup for SIM1 and SIM2
separately.
• Securitysettings
Enter this submenu to set security settings (SIM card lock, phone lock,
password) to on or off. The default phone lock code is 0000. (Contact your
service provider(s) for SIM lock codes.)
• Restorefactorysettings
Enter this submenu to restore factory settings for wallpaper, screen saver,
ring tone etc. You will need to enter the phone lock code (default: 0000).
Instructions (Cont.)

18
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
Fun&Games
Enter the “Fun & Games” menu to play the “Snake” game. Select Game
Settings to set the audio to on or off.
Services
Enter the “Services” menu to connect to the internet.
NOTE:Contentsandoptionsdependonyourserviceprovider. For more
detailed information, please consult your service provider.
• Internetservice
Your phone is equipped with a browser for connection to the internet. Once
in the Internet service menu, you can access the following submenus:
Homepage:Select Home page to connect to the home page you have
set. If no home page has been set, the phone will connect to the default
website set by the network operator.
Bookmarks: You can add favourite websites to the Favorites list for quick
reference.
SearchorInputURL:Input the URL (web address) of the internet service
you want to visit, tap the option button and select Go.
Settings:Here you can check your data accounts and set up browser
options and preferences.
• Dataaccounts
Consult the service provider for the required settings. Enter the settings
provided by your service provider for MMS and internet access.
Instructions (Cont.)

19
1300 886 649 Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
AUS
Display 1.77” QCIF display
Resolution 128 x 160
Internalmemory 32MB
Battery 600mAh
Bluetooth Version 2.0
SIM Dual SIM
Frequency 2G: 850 / 900 / 1800 / 1900 MHz
With support of WAP and GPRS
Camera VGA 0.08MP
Weather-and
DustproofRating
Complies with IP67
MicroSD Up to 4GB
Dataport Micro USB
Specications

Model: ATP-014 Product Code: 47427 10/2014
www.tempo.org
1300 886 649
AUS
Warrantyreturns
Should you for any reason need to return this product
for a warranty claim, make sure to include all accessories
with the product.
Productdoesnotwork?
If you encounter problems with this product, or if it fails
to perform to your expectations, make sure to contact
our After Sales Support Centre on 1300 886 649 before
returning it to the store for a refund.
