Onkyo HTP-450 User manual

HTP-450
SERVICE MANUAL
SERVICE MANUAL
5.1-CH HOME THEATER SPEAKER PACKAGE
Silver model
MODEL HTP-450(S)
Ref. No. 4008
032007
Front Speakers (L / R)
"SKF-450F" Center Speaker
"SKC-450C"
Surround Speakers (L / R)
"SKM-450S"
Powered Subwoofer
"SKW-450"
Cannot remove the speaker grill.
120V AC, 60HzS MDD
120V AC, 60HzS MDC
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.

HTP-450
EXPLODED VIEWS-1
SKW-450 : POWERED SUBWOOFER
HTP-450
A08
x 2 pcs.
SP07
x 10 pcs.
A104
x 2 pcs.
A05
x 2 pcs.
A05
x 5 pcs.
A103
A102
P901
F901
A11
A01
U01
A07
A07
A101
A02
A02
U06 A05
Q515
Q516
Q541
T901
U03
A03
E801
Refer to "EXPLODED VIEWS-2"

HTP-450
EXPLODED VIEWS-2
SKW-450 : POWERED SUBWOOFER
HTP-450
SP01
SP06
SP07
x 6 pcs.
SP08
SP02
x 4 pcs.
SP04
x 4 pcs.
SP03
x 4 pcs.

HTP-450
EXPLODED VIEWS-3
SKF-450F / SKC-450C / SKM-450S
HTP-450
SP13
SP10
SP17 SP19
SP16 SP18
SP14
SP15
SP11
SP12
"SKF-450F (L)" "SKF-450F (R)"
"SKC-450C"
"SKM-450S (R)""SKM-450S (L)"
TERMINAL :
White / Black
TERMINAL :
Red / Black
TERMINAL :
Green / Black
TERMINAL :
Blue / Black
TERMINAL :
Gray / Black
<Note>
Cannot remove the speaker grill.

HTP-450
SCHEMATIC DIAGRAM
SKW-450 : POWERED SUBWOOFER
HTP-450
A
1
2
3
4
5
BCDEFGH
+5.6V -56.5V +56.5V
P907A
P906A
J901
MD
J316
E801
Q301(2/2)
NJM4558LD
4
8
5
6
7
Q301(1/2)
NJM4558LD
3
2
1
8
4
Q602
KRC103M
Q606
KRA103M
P301
R651
12K (1/2W)
R951
3.3K
POWER NEED TO CONFIRM
(2W)
R952
3.3K (2W)
R901
820(1W)
R902
820(1W)
0
1
-0.6
1.6V
-1.6
-1
0
0.05
0.6
5.0
D901
D3SBA20
R544 100B
R528
390
(1/2W)
R628
330K
R629
NC
R701
NC
R904
1K
(1/2W)
R903
10K
R609
39K
R611
820K
R610
560K
R616
100K
R617
1K
R621
1K
R615
22K
R612
39K
R614
120K R613
470K
R619
22K
R620
100K
R624
100K
R623
100K R627
680K
R622
10K
R626
2.2M
R625
180K
S901
P901
P901
F901
5A/125V
F901
1.6A/250V
T901
NPT-1539D
T901
NPT-1539P
P903B P903B
J903A
P632A
REDGREEN
D601
MTZJ2.7B
D602
MTZJ2.7B
D501
MTZJ5.6B
D952
MTZJ15C
D951
MTZJ15C
D904
MTZJ5.6B
Q516
2SA1987-O/R
Q519
2SA965-Y
Q517
2SA933S-S
Q507
2SA949-Y
Q505
2SA949-Y
Q509
2SA949-Y
Q514
2SA1930
Q604
2SA933S
Q605
2SA933S
Q607
2SA933S
Q541
2SC3423
Q506
2SC2229-Y
Q510
2SC2229-Y
Q503
2SC2240-BL
Q515 2SC5359-O/R
Q513
2SC5171
Q518
2SC2235-Y
Q502
2SC2240-BL
Q501
2SC2240-BL
Q609
NC
Q603
2SC1740S-S
Q608
2SC1740S-S
P902A
P906B
P902A
JL535A/B
P531
P501B
P633
P631
D651
1SS133
D603
1SS133
D606
1SS133 D903
RL1N4003
or GP104003E
D902
RL1N4003
or GP104003E
D605
1SS133
R302
20K
C301
C303
NC
C955
223J
C506
070
C502
NC
C514
101
C520
224
C519
224
C505
020
C503
224J
C950
104/50
C903
104J/100
(MPA TYPE)
C904
104J/100
(MPA TYPE)
C302
47/50
C527
1/50
C501
47/50
C517
10/50
C528
10/50
C526
10/50
C504
220/16
C951
220/16
C952
220/16
C909
22/50
C601
10/50
C603
470/16
C602
10/50
C604
33/35
C906
5600/71
C905
5600/71
R306
47K
R301
1K R307
2.2K
R305
33K
R303
47K
R304
27K
R531
0.22
(5W)
R533
3.3
(1W)
R508
47
(1/4W)
R511
82
(1/4W)
R512
68
(1/4W)
R514
82 (1/4W)
R513
82
(1/4W)
R516
12K
R515
12K
R502
47K
R510
100K
R543
180
R526
82
(1/2W)
R517
3.3K
R541
820
R542
150
R505
1K
(1/4W)
R506
1K
(1/4W)
R507
33K
R527
270
R509
1K
R504
2.2K
R503
5.6K
R522
220
R521
220
R501
1K
R603
150K
R601
5.6K
R605
22
R602
100K
R604
180
NAPS-8831
AC 230-240V / 50Hz
NAAF-8829
NAPS-8831
MDD/MDC
ONLY
MPP/MPA
ONLY
AC 120V / 60Hz
NASW-8833
(MPA) 224
NC
NC
AGAINST FIRE HAZARD, REPLACE
VA
FOR CONTINUED PROTECTION
AND RATING INDICATED.
ONLY WITH FUSE OF SAME TYPE
CAUTION
ATTENTION
ET CALIBRATION COMME INDIQUE.
D'INCENDIE, REMPLACER UNIQUEMENT
PERMANENTE CONTRE LES RISQUES
AFIN D'ASSURER UNE PROTECTION
PAR UN FUSIBLE DE MEME TYPE
VA
E LENT.POUR UNE PROTECTION PERMANENTE,N'UTILISER
INDIQUE LA QU LE PRESENT SYMBOL EST APPOSE.
QUE DES FUSIBLES DE MEME TYPE. CE DARNIER EST
CE SYMBOLE INDIQUE QUE LE FUSIBLE UTLISE EST
FOR CONTINUED PROTECTION AGAINST FIRE
RATING REFER TO THE MARKING ADJACENT TO THE SYMBOL.
HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE
THIS SYMBOL LOCATED NEAR THE FUSE INDICATES
THAT THE FUSE USED IS SLOW OPERATING TYPE
THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY
REPLACE ONLY WITH PART NUMBER SPECIFIED.
VOLTAGE (MEASURED WITH VOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL).
ALL PNP TRANSISTORS ARE EQUIVALENT TO 2SA1015-GR UNLESS OTHERWISE NOTED.
ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED.
ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED.
ELECTROLYTIC CAPACITORS ( ) ARE IN uF/WV.
ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED.
EX) 030- 3pF 330- 33pF 331- 330pF 333- 0.033uF
ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED.
THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS.
EX) PRINTING SIDE
CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT.
!
NOTE
POWER SWITCH
PC BOARD
U05
POWER TRANSFORMER
PC BOARD
U03
POWER TRANSFORMER
PC BOARD
U03
MAIN PC BOARD
U01
LINE INPUT
OUTPUT
LEVEL
POWER
SWITCH
SPEAKER
LED
MPP/MPA ONLY
ADJUST.
IDLING
<Note>
NC : No mount of parts.

HTP-450
SCHEMATIC DIAGRAM
SKW-450 : POWERED SUBWOOFER
HTP-450
A
1
2
3
4
5
BCDEFGH
+5.6V -56.5V +56.5V
P907A
P906A
J901
MD
J316
E801
Q301(2/2)
NJM4558LD
4
8
5
6
7
Q301(1/2)
NJM4558LD
3
2
1
8
4
Q602
KRC103M
Q606
KRA103M
P301
R651
12K (1/2W)
R951
3.3K
POWER NEED TO CONFIRM
(2W)
R952
3.3K (2W)
R901
820(1W)
R902
820(1W)
0
1
-0.6
1.6V
-1.6
-1
0
0.05
0.6
5.0
D901
D3SBA20
R544 100B
R528
390
(1/2W)
R628
330K
R629
NC
R701
NC
R904
1K
(1/2W)
R903
10K
R609
39K
R611
820K
R610
560K
R616
100K
R617
1K
R621
1K
R615
22K
R612
39K
R614
120K R613
470K
R619
22K
R620
100K
R624
100K
R623
100K R627
680K
R622
10K
R626
2.2M
R625
180K
S901
P901
P901
F901
5A/125V
F901
1.6A/250V
T901
NPT-1539D
T901
NPT-1539P
P903B P903B
J903A
P632A
REDGREEN
D601
MTZJ2.7B
D602
MTZJ2.7B
D501
MTZJ5.6B
D952
MTZJ15C
D951
MTZJ15C
D904
MTZJ5.6B
Q516
2SA1987-O/R
Q519
2SA965-Y
Q517
2SA933S-S
Q507
2SA949-Y
Q505
2SA949-Y
Q509
2SA949-Y
Q514
2SA1930
Q604
2SA933S
Q605
2SA933S
Q607
2SA933S
Q541
2SC3423
Q506
2SC2229-Y
Q510
2SC2229-Y
Q503
2SC2240-BL
Q515 2SC5359-O/R
Q513
2SC5171
Q518
2SC2235-Y
Q502
2SC2240-BL
Q501
2SC2240-BL
Q609
NC
Q603
2SC1740S-S
Q608
2SC1740S-S
P902A
P906B
P902A
JL535A/B
P531
P501B
P633
P631
D651
1SS133
D603
1SS133
D606
1SS133 D903
RL1N4003
or GP104003E
D902
RL1N4003
or GP104003E
D605
1SS133
R302
20K
C301
C303
NC
C955
223J
C506
070
C502
NC
C514
101
C520
224
C519
224
C505
020
C503
224J
C950
104/50
C903
104J/100
(MPA TYPE)
C904
104J/100
(MPA TYPE)
C302
47/50
C527
1/50
C501
47/50
C517
10/50
C528
10/50
C526
10/50
C504
220/16
C951
220/16
C952
220/16
C909
22/50
C601
10/50
C603
470/16
C602
10/50
C604
33/35
C906
5600/71
C905
5600/71
R306
47K
R301
1K R307
2.2K
R305
33K
R303
47K
R304
27K
R531
0.22
(5W)
R533
3.3
(1W)
R508
47
(1/4W)
R511
82
(1/4W)
R512
68
(1/4W)
R514
82 (1/4W)
R513
82
(1/4W)
R516
12K
R515
12K
R502
47K
R510
100K
R543
180
R526
82
(1/2W)
R517
3.3K
R541
820
R542
150
R505
1K
(1/4W)
R506
1K
(1/4W)
R507
33K
R527
270
R509
1K
R504
2.2K
R503
5.6K
R522
220
R521
220
R501
1K
R603
150K
R601
5.6K
R605
22
R602
100K
R604
180
NAPS-8831
AC 230-240V / 50Hz
NAAF-8829
NAPS-8831
MDD/MDC
ONLY
MPP/MPA
ONLY
AC 120V / 60Hz
NASW-8833
(MPA) 224
NC
NC
AGAINST FIRE HAZARD, REPLACE
VA
FOR CONTINUED PROTECTION
AND RATING INDICATED.
ONLY WITH FUSE OF SAME TYPE
CAUTION
ATTENTION
ET CALIBRATION COMME INDIQUE.
D'INCENDIE, REMPLACER UNIQUEMENT
PERMANENTE CONTRE LES RISQUES
AFIN D'ASSURER UNE PROTECTION
PAR UN FUSIBLE DE MEME TYPE
VA
E LENT.POUR UNE PROTECTION PERMANENTE,N'UTILISER
INDIQUE LA QU LE PRESENT SYMBOL EST APPOSE.
QUE DES FUSIBLES DE MEME TYPE. CE DARNIER EST
CE SYMBOLE INDIQUE QUE LE FUSIBLE UTLISE EST
FOR CONTINUED PROTECTION AGAINST FIRE
RATING REFER TO THE MARKING ADJACENT TO THE SYMBOL.
HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE
THIS SYMBOL LOCATED NEAR THE FUSE INDICATES
THAT THE FUSE USED IS SLOW OPERATING TYPE
THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY
REPLACE ONLY WITH PART NUMBER SPECIFIED.
VOLTAGE (MEASURED WITH VOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL).
ALL PNP TRANSISTORS ARE EQUIVALENT TO 2SA1015-GR UNLESS OTHERWISE NOTED.
ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED.
ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED.
ELECTROLYTIC CAPACITORS ( ) ARE IN uF/WV.
ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED.
EX) 030- 3pF 330- 33pF 331- 330pF 333- 0.033uF
ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED.
THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS.
EX) PRINTING SIDE
CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT.
!
NOTE
POWER SWITCH
PC BOARD
U05
POWER TRANSFORMER
PC BOARD
U03
POWER TRANSFORMER
PC BOARD
U03
MAIN PC BOARD
U01
LINE INPUT
OUTPUT
LEVEL
POWER
SWITCH
SPEAKER
LED
MPP/MPA ONLY
ADJUST.
IDLING
<Note>
NC : No mount of parts.

HTP-450
PRINTED CIRCUIT BOARD VIEWS-1
SKW-450 : POWERED SUBWOOFER
MAIN PC BOARD (NAAF-8829)U01
Component side
R544
P502A
Q517
R543
R533
Q515
C502
R527
C514
J332
Q541
Q516
R522
R521
J322
R513
R511
J334
R516 R515 R507
R504
R510
C503
R651
R503
R509
R501
R502
C504
C951
R517
R542
R541
Q510
Q506
Q507
R514
R512
R508
C526
C517
C506
Q505
Q509
Q503
C505
J310
Q502
Q501
R505
R506
C501
C519 C520
J323
NCAF-8829
1
25138829A
P531
R531
J324
J308
C527
C903 C904
Q518
Q519
C528
J306
J311
J305
J312
R528
R526
J304
J303
J321
J313 J319
C952
J307
Q514
Q513
J330
J340
J333 D903
D902
R902
R901
C909
R903 D904
R605
C602
R604
R603
R602
R904
C604
R622
Q608
R626
R624
Q606
Q607
Q604
R619
R623
R621
Q603
Q605
D605
Q602
R610
C603
R601
J346
J331
D952
D951
J320
J314
J325
D651
P632A
J336 J335
JL535A
JL535B
P633
RED
BLACK
BC E CEB
BCE
E C B
E C B
1
-Vee
+Vcc
+Vcc
J352
J351
C601
D603
R304
R305
R303
R307
J316
R620
R614
R613
R612
R302
R302
P301
P301
C955
R627
Q609
R629
R628
D606
R625
J348 R611
J337
J327
J326
R616
J342
R301
J344
R617
J338
J347
R609
J341
J318
C950
R314
R311
C311
R315
R312
C316
R313
R316
81234567
R319
C314
R317
7654 3218
R320
J302
C303
J309
J329
R615
J349
J350
2345 678
P911
J301
D501
R545
Q504
P903A
RED REDBLK
Q301
Q302
Q303
R701
E701
C301
P631
P912
C906
C906
C905
C905
R952
J955
R951
E801
D601
D602
C302
R306
D901
J956
P301A
C312
C315
R321
C313
7
25
12
22
17
15
12
15
7
20
7
17
12
17
7
20
7
7
7
7
7
7
7
7
7
A
1
2
3
4
5
BCD

HTP-450
PRINTED CIRCUIT BOARD VIEWS-2
SKW-450 : POWERED SUBWOOFER
POWER TRANSFORMER PC BOARD (NAPS-8831)U03
Component side
POWER SWITCH PC BOARD (NASW-8833)U05
Component side
<Note>
MPP/MPA type only
NCPS-8831
25138831
1
2356
810121416
AC-H
AC-G
P902A
F901A F901B
5A/125V F901
1
P905A
P907A
P906A
J901
J905
J903
J904
J902
T901
T901
P910A
P910A
P903A P903A
AC-G AC-H
RISK OF FIRE
-REPLACE FUSE
AS MARKED.
NCSW-8833
25138833 1
S901
C901
P906B
J908B
BLACK
AC-G AC-H
15
15
15
15
A
1
2
3
4
5
BCD

ADJUSTMENT PROCEDURE
SKW-450 : POWERED SUBWOOFER / ADJUSTMENT OF IDLING CURRENT
HTP-450
Test point
DC voltmeter
100 ohm
(1/4W)
P531
<Fig-1>
Test point
P631
MAIN PC board ass'y "NAAF-8829"
Test point
P531
Trimming resistor
R544
Short
[When]
1. Exchange transistors (Q505 - Q519).
2. Exchange MAIN PC board ass'y (NAAF-8829).
[Procedure]
<Note> No speaker load and No input signal.
1. Short test point P631 for amplifier is under active mode.
2. Adjust the trimming resistor R544 so that the reading of multimeter becomes 52 ohm to 53 ohm.
3. Connect the DC voltmeter to test point P531. <Fig-1>
4. Connect the AC power cord into a wall outlet.
5. Press POWER button to turn on the unit. (MPA type only)
6. Confirm the voltage of above point after 6 minutes to 8 minutes. (Heat running)
7. When less than 3.20 mV : Readjust the trimming resistor above so that the voltage becomes 4.5 mV to 5.0 mV.
When 3.30 mV to 5.20 mV : Not necessary to adjust.
When 5.21 mV to 10.0 mV : Readjust the trimming resistor above so that the voltage becomes 5.0 mV to 5.5 mV.
When 10.1 mV to 20.0 mV : Readjust the trimming resistor above so that the voltage becomes 5.6 mV to 6.0 mV.
8. Press POWER button to turn off the unit. (MPA type only)
9. Disconnect the DC voltmeter.
10. Disconnect the AC power cord from a wall outlet.

1/6 PAGE
HTP-450
EXPLODED VIEWS PARTS LIS
T
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EXPLODED
SKW-450 : POWERED SUBWOOFER
EXPLODED
AMPLIFIER SECTION (SKW-450)
EXPLODED
Q515 TR 2SC5359-R 1 2203082 !
EXPLODED
Q515 or TR 2SC5359-O (1) 2203083 !
EXPLODED
Q516 TR 2SA1987-R(Q) 1 2203072 !
EXPLODED
Q516 or TR 2SA1987-O (1) 2203073 !
EXPLODED
Q541 TR 2SC3423-Y 1 2202104
EXPLODED
Q541 or TR 2SC3423-O (1) 2202103
EXPLODED
<Note>
EXPLODED
When replacement the following the transistor, made from the same HFE rank as the original type.
EXPLODED
Q515, Q516, Q541
EXPLODED
A01 HEAT SINK 230 1 27160591
EXPLODED
A02 CUSHION --- 2 28141682
EXPLODED
A03 CUSHION --- 1 28141691
EXPLODED
A05 SCREW 3TTB+8B(3BC) 8 838430088GR
EXPLODED
A07 ISO SHEET AC262 2 223025
EXPLODED
A08 SCREW 3SMS8W.SW+14B(CU) 2 801634
EXPLODED
A11 RETAINER (PCB) 1 27142025
EXPLODED
A101 REAR PANEL (MDD) 1 27123731
EXPLODED
A102 BUSHING S-RELIEF #2271 1 27300750 !
EXPLODED
A103 KNOB (VOL) 1 28326463
EXPLODED
A104 SCREW 3SMS8W.SW+14B(3BC) 2 801433GR
EXPLODED
F901 FUSE 5A-UL/T-233 1 252326GR !
EXPLODED
P901 AC CORD AS-UC-2 1 253333VOL !
EXPLODED
P901 or AC CORD AS-UC-2 (1) 253368LTK !
EXPLODED
P901 or AC CORD AS-UC-2 (1) 253368YUN !
EXPLODED
P901 or AC CORD AS-UC-2 (1) 253368HSN !
EXPLODED
T901 P TRANS NPT-1539D 1 2301863 !
EXPLODED
E801 WIRE TIE BSK-1 1 260208
EXPLODED
U01 MAIN PC BOARD ASS'Y NAAF-8829-1L 1 1B138529-1L
EXPLODED
U03
POWER TRANS. PC BOARD ASS'Y
NAPS-8831-1L 1 1B138531-1L
EXPLODED
U06 HOLDER PC BOARD NAETC-8834 1 --- NSP
EXPLODED
SPEAKER SECTION (SKW-450)
EXPLODED
--- SUBWOOFER ASS'Y COMPLETE UNIT SKW-450 (GRAY) 1 ANW8W700S-BM20
EXPLODED
SP01 CABINET ASS'Y (Without SP UNIT and AMP) 1 ANK8W700S-BM20
EXPLODED
SP02 PLASTIC FOOT BLACK 4 BPE800008-0001
EXPLODED
SP03 RUBBER FOOT PORON, BLACK 4 DUF803004-0001
EXPLODED
SP04 SCREW 3.5 x 20 TRUSS HEAD, BLACK 4 NST855041-8200
EXPLODED
SP06 WOOFER SPEAKER 10' (25 cm) 4 ohm 80-160 W 1 W2301E
EXPLODED
SP07 WOOD SCREW 4 x 20 BIND HEAD (For SP and AMP) 16 NST855051-8201
EXPLODED
SP08 LED HARNESS ASS'Y LED, WIRE RED/WHITE/BLUE 1 WMA8KW450-0002
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
!ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.

2/6 PAGE
EXPLODED
SKF-450F : FRONT SPEAKERS (L)
EXPLODED
SP10 COMPLETE UNIT "SKF-450F (S) L", WHITE/B (Inch nut) 1 ASL5M0504-BM01
EXPLODED
SP11 BACK LABEL (L) BLACK 1 YLB510169-0430
EXPLODED
SKF-450F : FRONT SPEAKERS (R)
EXPLODED
SP12 COMPLETE UNIT "SKF-450F (S) R", RED/B (Inch nut) 1 ASL5M0504-BM02
EXPLODED
SP13 BACK LABEL (R) BLACK 1 YLB510169-0431
EXPLODED
SKC-450C : CENTER SPEAKER
EXPLODED
SP14 COMPLETE UNIT "SKC-450C (S)", GREEN/B (Inch nut) 1 ASL5C0504-BM01
EXPLODED
SP15 BACK LABEL BLACK 1 YLB510169-0434
EXPLODED
SKM-450S : SURROUND SPEAKERS (L)
EXPLODED
SP16 COMPLETE UNIT "SKM-450S (S) L", BLUE/B (Inch nut) 1 ASL5U0504-BM01
EXPLODED
SP17 BACK LABEL (L) BLACK 1 YLB510169-0432
EXPLODED
SKM-450S : SURROUND SPEAKERS (R)
EXPLODED
SP18 COMPLETE UNIT "SKM-450S (S) R", GRAY/B (Inch nut) 1 ASL5U0504-BM02
EXPLODED
SP19 BACK LABEL (R) BLACK 1 YLB510169-0433
EXPLODED
SATELLITE PACKAGE
EXPLODED
--- SATELLITE PACKAGE (S) --- 1 ANB5NS504-BM01
HTP-450
PRINTED CIRCUIT BOARD PARTS LIS
T
SKW-450
U01 MAIN PC BOARD (NAAF-8829-1L)
U03 POWER TRANS. PC BOARD (NAPS-8831-1L)
CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PWB
<Note>
PWB
When replacement the following the transistor, made from the same HFE rank as the original type.
PWB
Q301 IC NJM4558L-D 1 22240293
PWB
Q501 TR 2SC2240-BL(TPE2_F) 1 2211406T
PWB
Q502 TR 2SC2240-BL(TPE2_F) 1 2211406T
PWB
Q503 TR 2SC2240-BL(TPE2_F) 1 2211406T
PWB
Q505 TR KTA1024-Y 1 2215844T
PWB
Q505 or TR 2SA949-Y(TPE6_F) (1) 2211354T
PWB
Q505 or TR 2SA949-O(TPE6_F) (1) 2211353T
PWB
Q506 TR 2SC2229-Y(TPE6_F) 1 2211634T
PWB
Q506 or TR 2SC2229-O(TPE6_F) (1) 2211633T
PWB
Q507 TR 2SA949-Y(TPE6_F) 1 2211354T
PWB
Q507 or TR 2SA949-O(TPE6_F) (1) 2211353T
PWB
Q507 or TR KTA1024-Y (1) 2215844T
PWB
Q509 TR KTA1024-Y 1 2215844T
PWB
Q509 or TR 2SA949-Y(TPE6_F) (1) 2211354T
PWB
Q509 or TR 2SA949-O(TPE6_F) (1) 2211353T
PWB
Q510 TR KTC3206-Y 1 2215854T
PWB
Q510 or TR 2SC2229-Y(TPE6_F) (1) 2211634T
PWB
Q510 or TR 2SC2229-O(TPE6_F) (1) 2211633T
PWB
Q513 TR KTD2061-Y 1 2203434
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
!ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.

3/6 PAGE
PWB
Q513 or TR 2SC5171(ONK_Q) (1) 2203010
PWB
Q514 TR KTB1369-Y 1 2203424
PWB
Q514 or TR 2SA1930(ONK_Q) (1) 2203000
PWB
Q517 TR 2SA933S-S 1 2213355T
PWB
Q517 or TR 2SA933S-R (1) 2213354T
PWB
Q517 or TR KTA1267-GR (1) 2215995T
PWB
Q518 TR 2SC2235-Y(TPE6_F) 1 2211654T
PWB
Q519 TR 2SA965-Y(TPE6_F) 1 2211644T
PWB
Q602 TR KRC103M 1 2215810T
PWB
Q602 or TR DTC124ES (1) 2213160T
PWB
Q603 TR 2SC1740S-S 1 2213285T
PWB
Q603 or TR 2SC1740S-R (1) 2213284T
PWB
Q603 or TR KTC3199-GR (1) 2215864T
PWB
Q604 TR 2SA933S-S 1 2213355T
PWB
Q604 or TR 2SA933S-R (1) 2213354T
PWB
Q604 or TR KTA1267-GR (1) 2215995T
PWB
Q605 TR 2SA933S-S 1 2213355T
PWB
Q605 or TR 2SA933S-R (1) 2213354T
PWB
Q605 or TR KTA1267-GR (1) 2215995T
PWB
Q606 TR KRA103M 1 2215780T
PWB
Q606 or TR DTA124ES (1) 2212600T
PWB
Q607 TR 2SA933S-S 1 2213355T
PWB
Q607 or TR 2SA933S-R (1) 2213354T
PWB
Q607 or TR KTA1267-GR (1) 2215995T
PWB
Q608 TR 2SC1740S-S 1 2213285T
PWB
Q608 or TR 2SC1740S-R (1) 2213284T
PWB
Q608 or TR KTC3199-GR (1) 2215864T
PWB
D501 ZENER D MTZJ5.6B 1 224470562T
PWB
D501 or ZENER D DZ-5.6BSB (1) 224850562T
PWB
D601 ZENER D MTZJ2.7B 1 224470272T
PWB
D601 or ZENER D DZ-2.7BSB (1) 224850272T
PWB
D602 ZENER D MTZJ2.7B 1 224470272T
PWB
D602 or ZENER D DZ-2.7BSB (1) 224850272T
PWB
D603 DIODE 1SS133 1 223163T
PWB
D603 or DIODE 1SS133(DS) (1) 223280T
PWB
D605 DIODE 1SS133 1 223163T
PWB
D605 or DIODE 1SS133(DS) (1) 223280T
PWB
D606 DIODE 1SS133 1 223163T
PWB
D606 or DIODE 1SS133(DS) (1) 223280T
PWB
D651 DIODE 1SS133 1 223163T
PWB
D651 or DIODE 1SS133(DS) (1) 223280T
PWB
D901 DIODE D3SBA20 1 22380271F
PWB
D902 DIODE RL1N4003 1 22380260T
PWB
D902 or DIODE GP104003E (1) 22380035T
PWB
D903 DIODE RL1N4003 1 22380260T
PWB
D903 or DIODE GP104003E (1) 22380035T
PWB
D904 ZENER D MTZJ5.6B 1 224470562T
PWB
D904 or ZENER D DZ-5.6BSB (1) 224850562T
PWB
D951 ZENER D MTZJ15C 1 224471503T
PWB
D951 or ZENER D DZ-15BSC (1) 224851503T
PWB
D952 ZENER D MTZJ15C 1 224471503T

4/6 PAGE
PWB
D952 or ZENER D DZ-15BSC (1) 224851503T
PWB
C302 VX C CE04W50V 47M(VX_BLK) 1 397384707T
PWB
C501 VX C CE04W50V 47M(VX_BLK) 1 397384707T
PWB
C503 TF C ECQ-V50V-224J 1 374722244T
PWB
C504 VX C CE04W16V-220M(VX_BLK) 1 397342217T
PWB
C505 CERA C CC45CH50V-020C 1 345340201T
PWB
C506 CERA C CC45CH50V-070D 1 345340702T
PWB
C514 TF C ECQ-B50V-101J 1 374721014T
PWB
C517 VX C CE04W50V-10M(VX_BLK) 1 397381007T
PWB
C519 TF C ECQ-V50V-224J 1 374722244T
PWB
C520 TF C ECQ-V50V-224J 1 374722244T
PWB
C526 VX C CE04W50V-10M(VX_BLK) 1 397381007T
PWB
C527 VX C CE04W50V-1M(VX_BLK) 1 397380107T
PWB
C528 VX C CE04W50V-10M(VX_BLK) 1 397381007T
PWB
C601 VR C CE04W50V-10M(VR) 1 394681007T
PWB
C602 VR C CE04W50V-10M(VR) 1 394681007T
PWB
C603 VR C CE04W16V-470M(VR) 1 394644717T
PWB
C603 or VX C CE04W16V-470M(VX_BLK) (1) 397344717T
PWB
C604 VR C CE04W35V-33M(VR) 1 394663307T
PWB
C604 or ELECT C CE04W35V-33M (1) 354763309T
PWB
C905 ELECT C CE62W71V5600M 1 3504444
PWB
C906 ELECT C CE62W71V5600M 1 3504444
PWB
C909 VR C CE04W50V-22M(VR) 1 394682207T
PWB
C950 TF C ECQ-V50V-104J 1 374721044T
PWB
C951 VR C CE04W16V-220M(VR) 1 394642217T
PWB
C952 VR C CE04W16V-220M(VR) 1 394642217T
PWB
C955 TF C ECQ-B50V-223J 1 374722234T
PWB
R301 CARBON R R16J-1K 1 417341024T
PWB
R302 VARI R N17RGL20KB15M 1 5151508
PWB
R303 CARBON R R16J-47K 1 417344734T
PWB
R304 CARBON R R16J-27K 1 417342734T
PWB
R305 CARBON R R16J-33K 1 417343334T
PWB
R306 CARBON R R16J-47K 1 417344734T
PWB
R307 CARBON R R16J-2.2K 1 417342224T
PWB
R501 CARBON R R16J-1K 1 417341024T
PWB
R502 CARBON R R16J-47K 1 417344734T
PWB
R503 CARBON R R16J-5.6K 1 417345624T
PWB
R504 CARBON R R16J-2.2K 1 417342224T
PWB
R505 NF CARBON R R25J-1.0K 1 415471024T !
PWB
R506 NF CARBON R R25J-1.0K 1 415471024T !
PWB
R507 CARBON R R16J-33K 1 417343334T
PWB
R508 NF CARBON R R25J-47 1 415474704T !
PWB
R509 CARBON R R16J-1K 1 417341024T
PWB
R510 CARBON R R16J-100K 1 417341044T
PWB
R511 NF CARBON R R25J-82 1 415478204T !
PWB
R512 NF CARBON R R25J-68 1 415476804T !
PWB
R513 NF CARBON R R25J-82 1 415478204T !
PWB
R514 NF CARBON R R25J-82 1 415478204T !
PWB
R515 CARBON R R16J-12K 1 417341234T
PWB
R516 CARBON R R16J-12K 1 417341234T
PWB
R517 CARBON R R16J-3.3K 1 417343324T

5/6 PAGE
PWB
R521 CARBON R R16J-220 1 417342214T
PWB
R522 CARBON R R16J-220 1 417342214T
PWB
R526 METAL O R RS1/2WBJ-82 1 443528204T
PWB
R527 CARBON R R16J-270 1 417342714T
PWB
R528 METAL O R RS1/2WBJ-390 1 443523914T
PWB
R531 METAL PR RF-5EGKR22 1 4000201
PWB
R531 or METAL P R RGC55C 0.22 K (1) 4000157
PWB
R531 or METAL PR RGC55 0.22 (1) 4000132
PWB
R531 or METAL PR MPR5W+5W 0R22 (1) 4000233
PWB
R533 METAL R RNU1WCJ-3.3 1 453630334T
PWB
R541 CARBON R R16J-820 1 417348214T
PWB
R542 CARBON R R16J-150 1 417341514T
PWB
R543 CARBON R R16J-180 1 417341814T
PWB
R544 TRIM R N06HR100BC 1 5210359T
PWB
R601 CARBON R R16J-5.6K 1 417345624T
PWB
R602 CARBON R R16J-100K 1 417341044T
PWB
R603 CARBON R R16J-150K 1 417341544T
PWB
R604 CARBON R R16J-180 1 417341814T
PWB
R605 CARBON R R16J-22 1 417342204T
PWB
R609 CARBON R R16J-39K 1 417343934T
PWB
R610 CARBON R R16J-560K 1 417345644T
PWB
R611 CARBON R R16J-820K 1 417348244T
PWB
R612 CARBON R R16J-39K 1 417343934T
PWB
R613 CARBON R R16J-470K 1 417344744T
PWB
R614 CARBON R R16J-120K 1 417341244T
PWB
R615 CARBON R R16J-22K 1 417342234T
PWB
R616 CARBON R R16J-100K 1 417341044T
PWB
R617 CARBON R R16J-1K 1 417341024T
PWB
R619 CARBON R R16J-22K 1 417342234T
PWB
R620 CARBON R R16J-100K 1 417341044T
PWB
R621 CARBON R R16J-1K 1 417341024T
PWB
R622 CARBON R R16J-10K 1 417341034T
PWB
R623 CARBON R R16J-100K 1 417341044T
PWB
R624 CARBON R R16J-100K 1 417341044T
PWB
R625 CARBON R R16J-180K 1 417341844T
PWB
R626 CARBON R R16J-2.2M 1 417342254T
PWB
R627 CARBON R R16J-680K 1 417346844T
PWB
R628 CARBON R R16J-330K 1 417343344T
PWB
R651 METAL O R RS1/2WBJ-12K 1 443521234T
PWB
R901 METAL O R RS1WBJ-820 1 443628214T
PWB
R902 METAL O R RS1WBJ-820 1 443628214T
PWB
R903 CARBON R R16J-10K 1 417341034T
PWB
R904 METAL O R RS1/2WBJ-1K 1 443521024T
PWB
R951 METAL O R RS2WBJ-3.3K 1 441723324F
PWB
R952 METAL O R RS2WBJ-3.3K 1 441723324F
PWB
F901A FUSE HOL NSCT-1P2506 1 25052609T !
PWB
F901A or FUSE HOL NSCT-1P2031 (1) 25052133T !
PWB
F901B FUSE HOL NSCT-1P2506 1 25052609T !
PWB
F901B or FUSE HOL NSCT-1P2031 (1) 25052133T !
PWB
JL535A SOCKET AS NSAS-2P1335 1 2009990876UL
PWB
P301 PIN JACK NPJ-1PDB556 1 25045774

6/6 PAGE
PWB
P301 or PIN JACK NPJ-1PDB581 (1) 25045801
PWB
P531 PLUG NPLG-2P29 1 25055038
PWB
P631 PLUG NPLG-2P29 1 25055038
PWB
P632A PLUG NPLG-3P131 1 25055147
PWB
P901A PLUG B3P-VB-2(LF) 1 25056616
PWB
P902A PLUG NPLG-2P632 1 25055676 !
PWB
P903A SOCKET AS NSAS-6P1693 1 2009991088UL
PWB
P911 WS CLAMP CB-71683(L=50) 1 260261
PWB
E801 RETAINER KANAGU(EARTH) 1 27141059

HTP-450
ONKYO EUROPE UK Office
Suite 1, Gregories Court, Gregories Road, Beaconsfield, Buckinghamshire, HP9 1HQ
UNITED KINGDOM Tel: [phone] Fax: [phone]
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: [phone] Fax: [phone] http://www.us.onkyo.com/
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: [phone] Fax: [phone] http://www.eu.onkyo.com/
Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: [phone] Fax: [phone]
ONKYO CORPORATION
http://www.onkyo.com/
HOMEPAGE
ONKYO CHINA LIMITED
Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung,
N.T., HONG KONG Tel: [phone] Fax: [phone]
http://www.ch.onkyo.com/
