Onkyo SKR-101 User manual

E
Thank you for purchasing of the Onkyo speaker system.
Please read this manual thoroughly before using it.
Following the instructions in this manual will enable you to
obtain optimum performance and listening enjoyment from
your new speaker system.
Please retain this manual for future reference.
Before using this unit
●The speaker cabinet is made of wood and sensitive to extreme
temperatures and humidity. Avoid placing the speaker system in
locations subjected to direct sunlight or in humid places such as
near an air conditioner, bathroom, or kitchen.
●Be sure to turn off your amplifier before connecting the speaker
system. Connecting it while the amplifier is on may result in
damage to the amplifier or the speaker system.
Dimensions
Connections
● Be sure to turn off your amplifier before connecting the speaker
system.
● Thenominalimpedanceofthisspeakersystemis6Ω.Useonly
amplifiers capable of handling this impedance.
● Use the supplied speaker cables to connect between the
speaker’s input terminals and the amplifier’s speaker terminals
as illustrated below.
● Be sure that you are connecting the speaker’s positive (+) and
negative (–) input terminals with the amplifier’s corresponding
positiveandnegativespeakerterminals.Otherwise,undesirable
sound field or impaired bass-range reproduction will result.
● Before turning on the amplifier’s power switch, pull lightly on
the speaker cables to ensure that they are connected securely.
The speaker grille is not removable.
Instruction Manual
SKR-101
Precaution on use
● This speaker system can handle the specified input power
when it is used for ordinary music reproduction. If the following
abnormalsignalsarefedtothespeaker,however,anovercurrent
may flow in the internal circuits, causing burning or breakage of
the wires even if the input power is below the specified rating.
1. Noise produced when FM station is not tuned in.
2. Sound produced when fast-forwarding cassette tape deck.
3. High-frequency sound generated by an oscillator, an
electronic musical instruments, etc.
4. Oscillating amplifier signals.
5. Special test signals produced by audio checking CD, etc.
6. Sound produced when connecting or disconnecting audio
connection cables. (Always turn off the amplifier’s power
before connecting or disconnecting cables.)
7. Howling when a microphone is used.
SPEAKER SYSTEM
+–
–+
SURROUND
SPEAKERS CENTER
SPEAKER
SURROUND BACK
SPEAKER
R
L
–+
–+
SKC-101
AV amplifier
SKR-101
for surround
L ch
SKR-101
Surround Back
Speaker
SKR-101
for surround
R ch
125 mm 115 mm
145 mm
217 mm

http://www.onkyo.co.jp/
HOMEPAGE
SN 29343445
Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: [phone] Fax: [phone] http://www.onkyo-intl.com
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: [phone] Fax: [phone] http://www.onkyousa.com
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: [phone] Fax: [phone] http://www.onkyo.net
ONKYO CHINA LIMITED
Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung,
N.T., HONG KONG Tel: [phone] Fax: [phone] http://www.onkyochina.com
D0208-1
Specifications
Type: Full range accoustic suspension
Impedance: 6 Ω
Maximum input power: 100 W
Output sound pressure level: 83 dB/W/m
Frequency response: 100 Hz-20 kHz
Cabinet capacity: 2 L
Speaker: 10-cm cone
Dimensions: 125 (W) x 217 (H) x 145 (D) mm
4-15/16" x 8-9/16" x 5-11/16"
(Including speaker grille)
Weight 1.2 kg, 2.6 lbs
Accessory: 8-m speaker cable (1 pc.)
Cushioning pad (2 pcs.)
Instruction manual (1 pc.)
Specifications and appearance may subject to change for improvement without
prior notice.
Speaker care
Your Onkyo speaker is finished with a very high quality polymer
laminate covering that serves to protect the wood speaker cabinet.
Wipe the cabinet periodically with a dry, silicon-embedded or plain
soft cloth.
The covering may be cleaned with a soft cloth moistened with water
and a mild soap. Avoid the use of furniture polishes or harsh
cleansers.
Use a soft brush or hand vacuum cleaner to remove dust and lint
from the grille material.
If the speaker is to be wall-mounted, make sure that the walls are
strong enough to support the speaker’s weight. The weight that
mounting screws can support varies greatly depending on the wall
material and the position of the reinforcing ribs embedded in the
wall. Use the thickest and longest possible mounting screws with
mounting screw head diameters less than 7.5 mm and shank
diameters less than 4 mm (please consult with your interior
designer or contractor).
Attach the supplied cushioning pads as shown to wall-mount the
speaker securely.
Placement
For better-quality sound, observe the following precautions when
you install the speaker system:
•Placingthespeaker system on severalsmall-diametersupports
generally results in better sound than placing it directly on a
wide installation surface. Also note that high quality bass
cannotbe obtained ifthespeaker system isunstablypositioned.
Always use thin discs of cork or metal (such as coins) to seat
the speaker stably.
•Placethe Rightand Leftsurround speakersinsimilarconditions.
If they are placed in extremely different conditions, left right
channel balance will be adversely affected.
When using as a Surround Back Speaker
It is very important to place your speakers properly to obtain the
optimum sound space for your listening pleasure.
The surround back speaker is required for enjoying Dolby Digital
EX or DTS-ES audio. The surround back speaker will also improve
the quality of sound effects for far more realistic acoustics.
Place the speaker so that its height is 1 meter higher than that of
the listner's ears.
TV or Screen
Center
speaker
Surround
right
speaker
Surround
back
speaker
Surround
left
speaker
Listener
Sub-
woofer
Front left
speaker
Front right
speaker
Cushioning pads
+–
