A Simple, Streamlined, and Well-Engineered Audio Solution
Onkyo’s devotion to audio integrity is there to see even in our most affordable mini system, the CS-335. This compact two-channel CD
receiver and speaker combo is a great way to bring your favorite tunes to smaller rooms and hear them with a clarity not found in
typical mini systems. Design features such as WRAT amplification technology ensure your music retains its character and balance even
when you turn the volume up. Along with regular audio CDs, M 3-encoded CDs, and FM/AM radio, the CS-335 offers i od connectivity
via an optional RI Dock for the i od. A pair of precise and responsive two-way, bass-reflex speakers round out the package.
SILVER
CS-335 CD Receiver System
Amplification Design Built Around the On yo Sound
Due to their obvious size limitations, mini audio systems present
various challenges to amplification design. The concept behind the
CS-335 was to design a compact system with audio quality as the key
consideration. Therefore, Onkyo’s engineers incorporated the same
technology used in our renowned full-sized amplifiers and receivers:
ide Range Amplifier Technology. RAT gives the CS-335 three
distinct advantages: 1) A wider frequency response compared to similar
mini audio systems; 2) Reduced amplifier distortion at high volume; and
3) Better control of current and electrical/mechanical kick-back from
speakers. This enables the CS-335 to deliver audio of surprisingly high
quality from such a compact component.
Exclusive On yo Circuitry to Maintain Clean
Audio Signals
Lower-quality mini audio systems usually employ just one circuit at the
output stage. ith multiple transistors crammed onto a single circuit,
excess heat is generated and the audio signal is compromised. The
CR-325 CD receiver is different. It uses discrete amplifier technology
similar to that found on Onkyo’s full-sized amplifiers and receivers.
Keeping the transistors separate at the output stage enhances cooling,
so the CR-325’s longevity is extended and interference to the audio
signal is reduced.
Conventional volume-attenuation methods involve initially dropping a
signal close to the noise floor at low volumes. This taints the signal with
noise, which increases when the signal is amplified. By contrast,
Optimum Gain Volume Circuitry adjusts the gain so that less than half
the usual amount of attenuation is necessary. The signal never comes
close to the noise floor, and the risk of noise is therefore reduced.
The Option of iPod Playbac Through RI Doc for
the iPod*
Onkyo’s RI (Remote Interactive) function enables Onkyo component
owners to integrate compatible components for operation via a single
remote control. It also enables you to integrate the iPod with the
CS-335 through Onkyo’s optional RI Dock. Simply connect the dock to
the CS-335’s receiver, then place your iPod in the dock for control via
the CS-335’s remote. The RI Dock offers a heftier and more detailed
sound than can be experienced with an RCA stereo cable.
*Sold separately
Quality Spea ers with Proprietary On yo
Performance Features
Designed to match the CR-325 CD receiver, the accompanying D-035
two-way, bass-reflex speakers incorporate a number of Onkyo speaker
developments. The woofer cones, for example, are made from a pure
cotton weave we call OMF (Onkyo Micro Fiber). This material
effectively absorbs unwanted vibrations while providing the requisite
diaphragm stiffness to enable a fast and accurate response.
Furthermore, each speaker features a balanced-dome tweeter to
deliver high-frequency sounds with greater finesse.
Simple Yet Comprehensive Control of All Your MP3s
ith more and more music being bought online, the CS-335 is an
ideal solution for bringing greater audio fidelity to MP3s. As MP3 files
can be organized hierarchically in folders, you can use either of two
modes—Navigation or All Folder—for selection and playback. In All
Folder mode, all folders appear at the same level, making it easy to
select one. If no specific file or MP3 is selected, all tracks will be played
back in numerical order. On the other hand, Navigation mode lets you
move through the folder hierarchy. The display button on the remote
also enables you to see information about the MP3 being played,
including the artist’s name and the song and album titles.
CS-335_EU:CS-335 09/09/18 10:14 ページ 1Downloaded from www.Manualslib.com manuals search engine

CS-335 CD Receiver System
SPECIFICATIONS
■RECEIVER SECTION
AMPLIFIER SECTION
Power Output 19 W + 19 W
(4 Ω, 1 kHz, 2 channels driven, IEC)
Dyna ic Power 22 W + 22 W (3 Ω)
20 W + 20 W (4 Ω)
14 W + 14 W (8 Ω)
Total Har onic Distortion 0.9% (Rated power),
0.4% (1 kHz, 1 W)
Da ping Factor 25 (Front, 1 kHz, 8 Ω)
Input Sensitivity and I pedance 150 mV/50 kΩ(Line)
Output Level and I pedance 150 mV/2.2 kΩ(Rec Out)
Frequency Response 10 Hz 100 kHz/±3 dB (Line)
Tone Control ±6 dB, 80 Hz (Bass)
±8 dB, 10 kHz (Treble)
+7 dB, 80 Hz (Super bass)
Signal-to-Noise Ratio 100 dB (Line, IHF-A)
Speaker I pedance 4 Ω16 Ω
TUNER SECTION
Tuning Frequency Range
FM 87.5 MHz 108 MHz
AM 522 kHz 1,611 kHz
CD PLAYER SECTION
Frequency Response 10 Hz 20 kHz
Audio Dyna ic Range 95 dB
Total Har onic Distortion 0.009%
Wow and Flutter Below threshold of measurability
Audio Output/I pedance 1.3 V (rms)/1.0 kΩ
GENERAL
Power Supply AC 220 230 V, 50/60 Hz
Power Consu ption 58 W
Standby Power Consu ption 0.25 W
Di ensions (W x H x D) 205 x 116 x 367 mm
Weight 4.0 kg
■SPEAKER SECTION
Speaker Type 2-way, bass reflex
Drivers
Woofer 10 cm OMF diaphragm
Tweeter 2.5 cm balanced-dome
Frequency Response 50 Hz 50 kHz
Crossover Frequency 7 kHz
Output Sound Pressure Level 83 dB/W/m
Max. Input Power 40 W
No inal I pedance 4 Ω
GENERAL
Di ensions (W x H x D) 137 x 234 x 230 mm
Weight 2.3 kg
■CARTON
Di ensions (W x H x D) 454 x 540 x 318 mm
Weight 10.8 kg
■PACKAGE CONTENTS
• CR-325 CD receiver • D-035 2-way bass reflex speakers
• AM loop antenna • FM indoor antenna • Remote controller and
two batteries • Speaker cable and cork spacers • Instruction manual
CR-325 CD Receiver
Amplifier Features
• 19 W/Ch, 4 Ω, 1 kHz, 2 Channels Driven, IEC
• WRAT (Wide Range Amplifier Technology)
• High-Current, Low-Impedance Drive
• Discrete Output Stage Circuitry
• Optimum Gain Volume Circuitry
• Direct Mode
• 2 Audio Inputs and 1 Output
• Subwoofer re Out
CD Player Features
• lays Audio CDs and M 3s Burned to CD-R and
CD-RW*
• 4 lay Modes (Normal/Memory/Random/1 Folder)
• Navigation/All Folder Modes for Selecting and
laying M 3 Files
• M 3 Settings for ersonal references
• Memory layback (25-Track rogramming)
• 2 Repeat Modes (Track/Full)
*Discs that have not been properly finalized may be only partially
playable or not playable at all.
Tuner & Other Features
• 4-Mode Timer ( lay or Rec/Once or Every)
• Sleep Timer
• Accuclock
• RDS ( S/RT)
• reset Function with 40 FM/AM/RDS Selections
• reset Naming (Up to 8 Characters)
• Manual and Automatic FM/AM Tuning
• FM Auto reset
• Tone Control (Bass/Treble) via Remote Control
• Super Bass Function
• Battery-Free Memory Backup
• Aluminum Front anel
• FM Indoor Antenna Supplied
• AM Loop Antenna Supplied
• Headphone Jack
• Banana lug-Compatible Speaker osts
• Compatible with RI (Remote Interactive) Dock for
the i od
• RI (Remote Interactive) Remote Control
D-035 2- ay Bass Reflex Speakers
• 10 cm OMF Diaphragm Woofer
• 2.5 cm Balanced-Dome Tweeter
• Magnetically Shielded
• Impedance: 4 Ω
• Max. Input ower: 40 W
• Frequency Response: 50 Hz–50 kHz
Note: Speaker cable and cork spacers included.
NPR No. 09N65 09/09
Due o a policy of con inuous produc improvemen , Onkyo reserves he righ o change specifica ions and appearance wi hou no ice. iPod is a rademark of Apple Inc., regis ered in he U.S. and o her coun ries. WRAT and OMF are rademarks of Onkyo Corpora ion. All o her rademarks and regis ered
rademarks are he proper y of heir respec ive holders.
