Onkyo CBX-100 User manual

En
CD Tuner Audio System
CBX-100
Instruction Manual
Thank you for purchasing an Onkyo CD Tuner Audio
System.
Please read this manual thoroughly before making
any connections and plugging it in.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new CD Tuner Audio System.
Please retain this manual for future reference.
Contents
Getting Started .......................... 2
Connections ............................ 15
Basic Operation ...................... 20
Playing a Disc.......................... 22
Listening to the Radio ........... 30
Clock and Timer ...................... 38
Miscellaneous ......................... 47
CBX-100_En.book Page 1 Friday, September 15, 2006 9:34 AM

2
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radia-
tors, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are pro-
vided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience recepta-
cles, and the point where they exit from the appara-
tus.
11. Only use attachments/accessories specified by the
manufacturer.
12.
Use only with the cart, stand,
tripod, bracket, or table spec-
ified by the manufacturer, or
sold with the apparatus.
When a cart is used, use cau-
tion when moving the cart/
apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. Damage Requiring Service
Unplug the apparatus from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
A. When the power-supply cord or plug is damaged,
B. If liquid has been spilled, or objects have fallen
into the apparatus,
C. If the apparatus has been exposed to rain or
water,
D. If the apparatus does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the apparatus to its normal operation,
E. If the apparatus has been dropped or damaged in
any way, and
F. When the apparatus exhibits a distinct change in
performance this indicates a need for service.
16. Object and Liquid Entry
Never push objects of any kind into the apparatus
through openings as they may touch dangerous volt-
age points or short-out parts that could result in a
fire or electric shock.
The apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases shall be placed on the apparatus.
Don’t put candles or other burning objects on top of
this unit.
17. Batteries
Always consider the environmental issues and fol-
low local regulations when disposing of batteries.
18. If you install the apparatus in a built-in installation,
such as a bookcase or rack, ensure that there is ade-
quate ventilation.
Leave 20 cm (8") of free space at the top and sides
and 10 cm (4") at the rear. The rear edge of the shelf
or board above the apparatus shall be set 10 cm (4")
away from the rear panel or wall, creating a flue-like
gap for warm air to escape.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE
NE PAS
OUVRIR
AVIS
PORTABLE CART WARNING
S3125A
CBX-100_En.book Page 2 Friday, September 15, 2006 9:34 AM

3
Precautions
1. Recording Copyright —Unless it’s for personal
use only, recording copyrighted material is illegal
without the permission of the copyright holder.
2. AC Fuse —The AC fuse inside the unit is not user-
serviceable. If you cannot turn on the unit, contact
your Onkyo dealer.
3. Care —
Occasionally you should dust the unit all over
with a soft cloth. For stubborn stains, use a soft cloth
dampened with a weak solution of mild detergent and
water. Dry the unit immediately afterwards with a
clean cloth. Don’t use abrasive cloths, thinners, alco-
hol, or other chemical solvents, because they may
damage the finish or remove the panel lettering.
4. Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE
FIRST TIME, READ THE FOLLOWING SEC-
TION CAREFULLY.
AC outlet voltages vary from country to country.
Make sure that the voltage in your area meets the
voltage requirements printed on the unit’s rear panel
(e.g., AC 230 V, 50 Hz or AC 120 V, 60 Hz).
The power cord plug is used to disconnect this unit
from the AC power source. Make sure that the plug
is readily operable (easily accessible) at all times.
Pressing the [STANDBY/ON] button to select
Standby mode does not fully shutdown the unit. If
you do not intend to use the unit for an extended
period, remove the power cord from the AC outlet.
5. Never Touch this Unit with Wet Hands —
Never handle this unit or its power cord while your
hands are wet or damp. If water or any other liquid
gets inside this unit, have it checked by your Onkyo
dealer.
6. Handling Notes
• If you need to transport this unit, use the original
packaging to pack it how it was when you origi-
nally bought it.
• Do not leave rubber or plastic items on this unit
for a long time, because they may leave marks on
the case.
• This unit’s top and rear panels may get warm
after prolonged use. This is normal.
• If you do not use this unit for a long time, it may
not work properly the next time you turn it on, so
be sure to use it occasionally.
• When you’ve finished using this unit, remove all
discs and turn off the power.
7. Installing this Unit
• Install this unit in a well-ventilated location.
• Ensure that there’s adequate ventilation all
around this unit, especially if it’s installed in an
audio rack. If the ventilation is inadequate, the
unit may overheat, leading to malfunction.
• Do not expose this unit to direct sunlight or heat
sources, because its internal temperature may
rise, shortening the life of the optical pickup.
•Avoid damp and dusty places.
• Install this unit horizontally. Never use it on its
side or on a sloping surface, because it may cause
a malfunction.
• If you install this unit near a TV, radio, or VCR,
the sound quality may be affected. If this occurs,
move this unit away from the TV, radio, or VCR.
8. Moisture Condensation
Moisture condensation may damage this
unit.
Read the following carefully:
Moisture may condense on the lens of the optical
pickup, one of the most important parts inside this
unit.
•Moisture condensation can occur in the following
situations:
–The unit is moved from a cold place to a warm
place.
–Aheater is turned on, or cold air from an air
conditioner is hitting the unit.
–In the summer, when this unit is moved from an
air conditioned room to a hot and humid place.
– The unit is used in a humid place.
• Do not use this unit when there’s the possibility
of moisture condensation occurring. Doing so
may damage your discs and certain parts inside
this unit.
If condensation does occur, remove all discs and
leave this unit turned on for two to three hours. By
this time, the unit will have warmed up and any con-
densation will have evaporated.
CBX-100_En.book Page 3 Friday, September 15, 2006 9:34 AM

4
Precautions —Continued
For European Models
This unit contains a semiconductor laser system and is
classified as a “CLASS 1 LASER PRODUCT”. So, to
use this model properly, read this Instruction Manual
carefully. In case of any trouble, please contact the store
where you purchased the unit.
To prevent being exposed to the laser beam, do not try to
open the enclosure.
CAUTION:
THIS PRODUCT UTILIZES A LASER. USE OF
CONTROLS OR ADJUSTMENTS OR PERFOR-
MANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARD-
OUS RADIATION EXPOSURE.
The label on the right is
applied on the rear panel.
1. This unit is a CLASS 1
LASER PRODUCT and
employs a laser inside the cabinet.
2. To prevent the laser from being exposed, do not remove the
cover. Refer servicing to qualified personnel.
For British models
Replacement and mounting of an AC plug on the power
supply cord of this unit should be performed only by
qualified service personnel.
IMPORTANT
The wires in the mains lead are coloured in accordance
with the following code:
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead of this appa-
ratus may not correspond with the coloured markings
identifying the terminals in your plug, proceed as fol-
lows:
The wire which is coloured blue must be connected to
the terminal which is marked with the letter N or
coloured black.
The wire which is coloured brown must be connected to
the terminal which is marked with the letter L or
coloured red.
IMPORTANT
The plug is fitted with an appropriate fuse. If the fuse
needs to be replaced, the replacement fuse must
approved by ASTA or BSI to BS1362 and have the same
ampere rating as that indicated on the plug. Check for the
ASTA mark or the BSI mark on the body of the fuse.
If the power cord’s plug is not suitable for your socket
outlets, cut it off and fit a suitable plug. Fit a suitable fuse
in the plug.
Declaration of Conformity
We, ONKYO EUROPE
ELECTRONICS GmbH
LIEGNITZERSTRASSE 6,
82194 GROEBENZELL,
GERMANY
GROEBENZELL, GERMANY
ONKYO EUROPE ELECTRONICS GmbH
K. MIYAGI
declare in own responsibility, that the ONKYO product
described in this instruction manual is in compliance with the
corresponding technical standards such as EN60065,
EN55013, EN55020 and EN61000-3-2, -3-3.
CBX-100_En.book Page 4 Friday, September 15, 2006 9:34 AM

5
Supplied Accessories
Make sure you have the following accessories:
* In catalogs and on packaging, the letter at the end of the product
name indicates the color. Specifications and operations are the
same regardless of color.
Features
General
• CD tuner audio system
• Built-in stereo hi-fi speakers
• RI-Dock compatible remote controller
• 3-preset equalizer settings
• Line input for RI Dock or other audio source
• Headphones jack
• Dimmable display
• Battery-less memory backup
Speakers
• OMF diaphragm
• Aero Acoustic Drive for powerful and natural sound
Radio
• AM/FM tuner
• 30 presets
• Preset naming
• RDS (Radio Data System)
• FM Auto Preset function
CD Player
• Play audio CDs, MP3/WMA* CDs (CD-R and
CD–RW)
•4playback modes: normal, random, memory, and
1-folder
• 2-mode repeat function (current track or all tracks)
• 25-track playlist
Timers and Clock
•4programmable timers
• Sleep timer
• Snooze function
• AccuClock automatic clock setting
*Windows Media, and the Win-
dows logo are trademarks, or reg-
istered trademarks of Microsoft
Corporation in the United States
and/or other countries.
Remote controller
(Battery preinstalled)
Indoor FM antenna
(Connector type varies from country to country.)
AM loop antenna
Power cord
CBX-100_En.book Page 5 Friday, September 15, 2006 9:34 AM

6
Contents
Important Safety Instructions ........................... 2
Precautions......................................................... 3
Supplied Accessories........................................ 5
Features .............................................................. 5
Contents.............................................................. 6
Getting to Know the CBX-100 ........................... 7
Top and Front Panels ................................................ 7
Display...................................................................... 8
Rear Panel................................................................. 9
Remote Controller .................................................. 10
Disc Notes......................................................... 13
Connecting Antennas ...................................... 15
Connecting an External Audio Source........... 17
About Connections ................................................. 17
Connecting an Onkyo RI Dock (Remote Interactive
Dock) ...................................................................... 17
Connecting Other Components............................... 18
Connecting the Power Cord............................ 19
AccuClock—Automatic Clock Setting................... 19
Basic Operation................................................ 20
Turning On the CBX-100 ....................................... 20
Adjusting the Volume............................................. 20
Selecting the Input Source ...................................... 20
Using Headphones .................................................. 20
Muting the CBX-100 .............................................. 21
Preset EQ ................................................................ 21
Changing the Input Display .................................... 21
Playing CDs ...................................................... 22
Using the Top Panel Buttons .................................. 22
Using the Remote Controller .................................. 23
Displaying CD Information .................................... 23
Selecting MP3/WMA Files..................................... 24
Displaying MP3/WMA Information....................... 26
Memory Playback................................................... 27
Random Playback ................................................... 28
Repeat Playback...................................................... 28
Setting MP3/WMA Preferences ............................. 29
Listening to the Radio ..................................... 30
Tuning into Radio Stations ..................................... 30
Presetting FM Stations Automatically
(Auto Preset)........................................................... 31
Presetting FM/AM Stations Manually.................... 32
Selecting Preset Stations......................................... 33
Displaying Radio Information ................................ 34
Receiving RDS ....................................................... 34
Naming Presets ....................................................... 35
Copying Presets ...................................................... 36
Erasing a Preset’s Name ......................................... 37
Erasing Presets........................................................ 37
Setting the Clock ..............................................38
Setting the Clock Manually.....................................38
AccuClock with a Specific Station .........................39
Using the Timers ..............................................40
About the Timers.....................................................40
Programming the Timers......................................... 41
Turning Timers On and Off .................................... 43
Checking Timer Settings......................................... 43
Using the Snooze Function ..................................... 44
Using the Sleep Timer.............................................45
Using the CBX-100 with an Onkyo RI Dock ...46
Using the Remote Controller ..................................46
Troubleshooting ...............................................47
Specifications ...................................................50
CBX-100_En.book Page 6 Friday, September 15, 2006 9:34 AM

7
Getting to Know the CBX-100
The page numbers in parentheses show where you can find the main explanation for each item.
A
STANDBY/ON button (20, 38, 42)
Sets the CBX-100 to On or Standby.
B DISPLAY button (21, 26, 34)
Used to change the information shown on the dis-
play. Also used to turn on the backlight of the music
player in the RI Dock.
C
DOCK Play/Pause [ ] button (46)
Starts or pauses playback on an Onkyo RI Dock.
D Previous and Next [ / ]/[ / ]
buttons (22, 33)
For CD and RI Dock playback, the Previous
[/] button selects the previous track. During
playback it selects the beginning of the current
track. Pressing and holding it during playback
rewinds. It’s also used to select radio presets.
For CD and RI Dock playback, the Next [ / ]
button selects the next track. Pressing and holding it
during playback fast forwards. It’s also used to
select radio presets.
E
CD Play/Pause [ ] button (22)
Starts CD playback. Pressing it during playback
pauses playback.
F
Stop [ ] button (22)
Stops CD playback.
G Eject [ ] button (22)
Ejects the loaded CD.
H
VOLUME [ / ] buttons (20)
Adjust the volume level.
I
INPUT button (20, 33, 46)
Used to select the input source.
J
SNOOZE (44)
Once timed playback of a timer set for snooze has
started, pressing any of these buttons will stop play-
back for a set number of minutes, just like the
snooze function you find on a typical alarm clock.
K
STANDBY indicator (19, 20)
Lights up in Standby mode.
L
Disc slot (22)
The CD is loaded here.
M
Display
See “Display” on page 8.
N
Remote control sensor (12)
Receives control signals from the remote controller.
Top and Front Panels
21 3 4
K L MN
5
J
6 7 8 9
*1 *1*2 *2
Top Panel
Front Panel
*1: Speaker duct for
Aero Acoustic
Drive
*2: Speakers
/
/
CBX-100_En.book Page 7 Friday, September 15, 2006 9:34 AM

8
Getting to Know the CBX-100 —Continued
A
SLEEP indicator
Lights up when the Sleep function has been set.
B
MP3 indicator
Lights up when an MP3 CD is loaded.
C WMA indicator
Lights up when a WMA CD is loaded.
D
FOLDER indicator
Lights up while the number and name of an
MP3/WMA folder is being displayed.
E
MUTING indicator
Flashes while the CBX-100 is muted.
F
Playback mode indicators
1FOLDER: Lights up when 1-folder playback is
selected.
MEMORY: Lights up when memory playback is
selected.
RANDOM: Lights up when random playback is
selected.
REPEAT: Lights up when repeat playback is
selected for all tracks.
REPEAT 1: Lights up when repeat playback is
selected for one track.
G Play and Pause indicators
The Play indicator lights up for playback. The
Pause indicator lights up while playback is paused.
H TIMER indicators
Show the status of the timers.
TIMER: Lights up when a timer has been pro-
grammed.
1, 2, 3, 4: Light up when a timer has been pro-
grammed.
: Lights up when a timer has been set for snooze.
I
Tuning indicators
AUTO: Lights up when Auto mode is selected and
disappears when Mono mode is selected.
: Lights up when the CBX-100 is tuned to
a radio station.
FM ST: Lights up when receiving a stereo FM sig-
nal.
RDS: Lights up when the CBX-100 is tuned to a
radio station that supports RDS (Radio Data Sys-
tem).
J FILE indicator
Lights up when an MP3/WMA file number and
name is being displayed.
K TRACK indicator
Lights up when a CD track number is being dis-
played.
L TITLE, ARTIST, and ALBUM indicators
TITLE: Lights up when the title of an MP3/WMA
file is being displayed.
ARTIST: Lights up when the artist name from an
MP3/WMA file is being displayed.
ALBUM: Lights up when the album name from an
MP3/WMA file is being displayed.
M
DISC, TOTAL, and REMAIN indicators
These indicators light up when the total time or the
remaining disc or track time is being displayed.
N
Message area
Various information is displayed here, including
radio preset numbers, tuning frequency, current
time, volume level, timer settings, mode settings,
and so on.
Display
7 8 9 J K L M N
1 432 5 6
/
CBX-100_En.book Page 8 Tuesday, September 19, 2006 10:33 AM

9
Getting to Know the CBX-100 —Continued
The page numbers in parentheses show where you can find the main explanation for each item.
A
PHONES jack (20)
This stereo minijack is for connecting a pair of ste-
reo headphones for private listening.
B
INPUT DOCK/LINE jacks (17, 18)
This analog audio input is for connecting an Onkyo
RI Dock or other external audio source.
C
REMOTE CONTROL jack (17)
This (Remote Interactive) jack can be con-
nected to the jack on an Onkyo RI Dock. The
CBX-100’s remote controller can then be used to
control the RI Dock. To use , you must make an
audio connection and connection between the
CBX-100 and the RI Dock.
D
AM ANTENNA terminals (15, 16)
These push terminals are for connecting an AM
antenna.
E
FM ANTENNA jack (15, 16)
This jack is for connecting an FM antenna.
F
AC INLET (19)
The supplied power cord is connected here. The
other end of the power cord should be connected to
a suitable wall outlet.
Rear Panel
1
5
4 6
2 3
See pages 15–18 for connection information.
CBX-100_En.book Page 9 Tuesday, September 19, 2006 10:33 AM

10
Getting to Know the CBX-100 —Continued
The page numbers in parentheses show where you can
find the main explanation for each item.
A
STANDBY/ON button (20)
Sets the CBX-100 to On or Standby.
B
SLEEP button (45)
Sets the Sleep timer, which turns off the CBX-100
after a specified time.
C
DISPLAY button (23, 26, 34, 35, 46)
Used to change the information shown on the dis-
play. Also used to select characters when naming
radio presets.
D
DIMMER button
Sets the display brightness to normal or dim (works
only while the CBX-100 is on).
E
Number buttons (23, 33)
Used to select tracks and radio presets. Also used to
set the clock manually, set the timers, and enter
names for radio presets.
F
Rewind/Fast Forward [ ]/[ ] and
[ TUNING]/[TUNING ] buttons (23, 30,
46)
Used to rewind or fast forward CD playback. Also
used to tune the radio and edit preset names.
G
Previous/Next [ ]/[ ] and
[ PRESET]/[PRESET ] buttons (23,
25–27, 29, 33, 46)
Used to select the previous or next CD track. Also
used to select radio presets and edit preset names.
H
CD control buttons (22)
:Pauses playback.
: Stops playback.
: Starts playback.
I
Onkyo RI Dock control buttons (46)
ALBUM [ / ]: Selects albums on an Onkyo RI
Dock.
PLAYLIST [ / ]: Select playlists on an Onkyo RI
Dock.
DOCK [ / ]: Starts or pauses playback on an
Onkyo RI Dock.
J
SNOOZE button (44)
Once timed playback of a timer set for snooze has
started, pressing this button will stop playback for a
set number of minutes, just like the snooze function
you find on a typical alarm clock.
K
CLOCK CALL button (38)
Calls up the clock to display the day and time.
Remote Controller
B
AJ
L
M
N
R
T
O
K
Q
P
V
U
S
4
3
5
6
7
8
9
Remove the plastic film before
using the remote controller.
CBX-100_En.book Page 10 Tuesday, September 19, 2006 10:33 AM

11
Getting to Know the CBX-100 —Continued
L
INPUT [ ]/[ ] buttons (20)
Used to select the input source.
M
MUTING button (21)
Mutes the CBX-100.
N VOLUME [ / ] buttons (20, 23)
Adjust the volume level.
O
FOLDER button (24, 25)
Used to select MP3/WMA folders.
P
TIMER button (38, 39, 41, 43)
Used to set the timers and clock.
Q
EDIT/NO/CLEAR button (29, 31, 32, 35–37)
Used with various functions and settings for select-
ing, cancelling, and deleting.
R
YES/MODE/SHUFFLE button (26–28, 39)
Used with various functions and settings for con-
firming, selecting modes, and selecting random
playback.
S
ENTER button (24–27, 29, 31, 32, 35–39,
41–43)
Used to confirm various functions and settings.
T
REPEAT button (28)
Sets repeat playback.
U
PRESET EQ button (21)
Selects the preset equalizer settings.
V
TUNER button (30, 31, 33)
Selects FM or AM radio as the input source.
See page 46 for how to control an Onkyo RI Dock
with the remote controller.
CBX-100_En.book Page 11 Friday, September 15, 2006 9:34 AM

12
Getting to Know the CBX-100 —Continued
Replacing the Battery
Use only a battery of the same type (CR 2025, lithium
button battery).
Notes:
• If the remote controller doesn’t work reliably, try
replacing the battery.
•If you intend not to use the remote controller for a long
time, remove the battery to prevent damage from leak-
age or corrosion.
•An expired battery should be removed as soon as pos-
sible to prevent damage from leakage or corrosion.
Caution: Replacing the battery incorrectly may cause an
explosion. Use only a battery of the same type or an
equivalent.
Aiming the Remote Controller
When using the remote controller, point it toward the
CBX-100’s remote control sensor, as shown below.
Notes:
• The remote controller may not work reliably if the
CBX-100 is subjected to bright light, such as direct
sunlight or inverter-type fluorescent lights. Keep this
in mind when installing.
• If another remote controller of the same type is used
in the same room, or the CBX-100 is installed close to
equipment that uses infrared rays, the remote control-
ler may not work reliably.
•Don’t put anything, such as a book, on the remote con-
troller because the buttons may be pressed inadvert-
ently, thereby draining the batteries.
• The remote controller will not work if there’s an
obstacle between it and the CBX-100’s remote control
sensor.
1
While pushing the locking tab toward the
center of the remote controller, slide out
the battery holder.
2
Remove the old battery from the battery
holder, insert the new battery, and then
slide the battery holder back into the
remote controller.
Back of remote
controller
Locking tab
Positive (+) side up
Battery holder
Locking tab
Battery type
Polarity (+) symbol
30°
30°
Approx. 5 m (16 ft.)
Remote control sensor
CBX-100
CBX-100_En.book Page 12 Friday, September 15, 2006 9:34 AM

13
Disc Notes
Supported Discs
The CBX-100 supports the following discs.
•Some audio CDs use copy protection that doesn’t con-
form to the official CD standard. Since these are non-
standard discs, they may not play properly in the
CBX-100.
• The CBX-100 supports CD-R and CD-RW discs.
However, some CD-R and CD-RW discs may not
work properly for any of the following reasons: disc
burner characteristics, disc characteristics, the disc is
damaged or dirty. See the manual supplied with your
disc burner for more information. Condensation or
dirt on the optical pickup lens can also affect play-
back.
• The CBX-100 supports 8 cm and 12 cm discs.
• The CBX-100 does not support disc types not listed.
• Don’t use discs with an unusual shape, such as those
shown below, as you may damage the CBX-100.
•Don’t use discs that have residue from adhesive tape,
rental discs with peeling labels, or discs with custom-
made labels or stickers. Doing so may damage the
CBX-100 and you may not be able to remove the disc
properly.
Discs Made on Personal Computers
Discs made on personal computers, including those of a
compatible format, may not work properly in the
CBX-100 because of incorrect settings in the disc burn-
ing software. Check the manuals supplied with your disc
burning software for additional compatibility informa-
tion.
MP3/WMA Compatibility
•The CBX-100 can play MP3 and WMA files recorded
on CD-R and CD-RW discs.
•Discs must be in ISO 9660 Level 1 or Level 2, Romeo
or Joliet compliant. Supported formats: Mode 1,
Mode 2 Form 1.
•Multisession discs are supported, however, some mul-
tisession discs may take a long time to load and some
may not load at all. When burning CDs, we recom-
mend that you use a single-session (disc-at-once) and
select “Disc Close.”
•You can determine the order in which the CBX-100
plays the MP3/WMA files in a folder by prefixing file
names with a 3-digit number. For example,
001.Track.mp3, 002.Track.mp3, and so on.
•Disc, file, and folder names may contain up to 30 char-
acters. MP3/WMA file and folder names (excluding
the extension) are shown on the display.
• The CBX-100 supports up to 499 MP3 files and fold-
ers. Files and folders in excess of this cannot be
played. Note that if the file and folder structure is very
complicated, the CBX-100 may not be able to read or
play all of the MP3 files on the disc.
•MP3/WMA files without the proper extension will not
be recognized. To prevent noise and malfunction, do
not use these extensions for other types of files.
■ MP3
• MP3 files must be MPEG-1/MPEG-2 Audio Layer 3
format with a sampling rate of between 8 kHz and 48
kHz and a bit-rate of between 8 kbps and 320 kbps.
Incompatible files cannot be played.
• MP3 files must have a “.mp3” or “.MP3” filename
extension.
•Variable bit-rate (VBR) MP3 files between 8 kbps and
320 kbps are supported. (Playing times may not dis-
play correctly.)
■ WMA
•WMA files must have the copyright option turned off.
• Sampling rates between 8 kHz and 48 kHz and a bit-
rate of between 32 kbps and 192 kbps are supported.
Incompatible files cannot be played.
•Variable bit-rates (VBR) from 32 kbps to 192 kbps are
supported. (Playing times may display incorrectly
with VBR.)
•WMA files must have a “.wma” or “.WMA” filename
extension.
Disc Logo Format or file type
Audio CD PCM
CD-R Audio CD, MP3, WMA
CD-RW Audio CD, MP3, WMA
CD Extra
Audio CD (Session 1),
MP3/WMA (Session 2)
CBX-100_En.book Page 13 Friday, September 15, 2006 9:34 AM

14
Disc Notes —Continued
About WMA
WMA stands for Windows Media Audio and is an audio
compression technology developed by Microsoft Corpo-
ration. Audio can be encoded in WMA format by using
Windows Media
®
Player.
Disc Content Organization
■ Audio CD
Audio CDs contain tracks.
■ MP3/WMA Disc
MP3/WMA discs contain MP3/WMA files organized
in folders.
Handling Discs
•Never touch the underside of a disc.Always hold discs
by the edge, as shown.
•Never attach adhesive tape or sticky labels to discs.
Cleaning Discs
•For best results, keep your discs clean. Fingerprints
and dust can affect the sound quality and should be
removed as follows. Using a clean, soft cloth, wipe
from the center outwards, as shown. Never wipe in a
circular direction.
•To remove stubborn dust or dirt, wipe the disc with a
damp, soft cloth, and then dry it with a dry cloth.
•Never use solvent-based cleaning fluids, such as thin-
ner or benzine, commercially available cleaners, or
antistatic sprays intended for vinyl records, as they
may damage the disc.
Storing Discs
•Don’t store discs in places subject to direct sunlight or
near heat sources.
•Don’t store discs in places subject to moisture or dust,
such as in a bathroom or near a humidifier.
•Always store discs in their cases and vertically. Stack-
ing, or putting objects on unprotected discs may cause
warping, scratches, or other damage.
Track 2 Track 3 Track 4Track 1
Audio CD
Track 5
Folder 1 Folder 2
File 2 File 3 File 1File 1 File 2
MP3/WMA disc (CD-R/CD-RW)
Underside
✔
CBX-100_En.book Page 14 Friday, September 15, 2006 9:34 AM

15
Connecting Antennas
This section explains how to connect the supplied indoor
FM antenna and AM loop antenna, and how to connect
commercially available outdoor FM and AM antennas.
The CBX-100 won’t pick up any radio signals without
an antenna connected, so you must connect the antenna
to use the tuner.
Connecting the Indoor FM Antenna
The supplied indoor FM antenna is for indoor use only.
If you cannot achieve good reception with the supplied
indoor FM antenna, try a commercially available out-
door FM antenna instead (see page 16).
Connecting the AM Loop Antenna
The supplied indoor AM loop antenna is for indoor use
only.
If you cannot achieve good reception with the supplied
indoor AM loop antenna, try using it with a commer-
cially available outdoor AM antenna (see page 16).
1
Attach the FM antenna, as shown.
Once the CBX-100 is ready for use, you’ll need to
tune into an FM radio station and adjust the posi-
tion of the FM antenna to achieve the best possi-
ble reception.
2
Use thumbtacks or something similar to
fix the FM antenna into position.
Caution: Be careful that you don’t injure yourself
when using thumbtacks.
FM antenna jack
AM antenna push terminals
Insert the plug fully
into the jack.
Thumbtacks, etc.
1
Assemble the AM loop antenna, inserting
the tabs into the base, as shown.
2
Connect both wires of the AM loop
antenna to the AM push terminals, as
shown.
The antenna’s wires are not polarity sensitive, so
they can be connected either way around.
Make sure that the wires are attached securely and
that the push terminals are gripping the bare
wires, not the insulation.
Once the CBX-100 is ready for use, you’ll need to
tune into an AM radio station and adjust the posi-
tion of the AM antenna to achieve the best possi-
ble reception.
Keep the antenna as far away as possible from the
CBX-100, power cord, and your TV.
Push Insert wire Release
CBX-100_En.book Page 15 Friday, September 15, 2006 9:34 AM

16
Connecting Antennas —Continued
Connecting an Outdoor FM Antenna
If you cannot achieve good reception with the supplied
indoor FM antenna, try a commercially available out-
door FM antenna instead.
Notes:
• Outdoor FM antennas work best outside, but usable
results can sometimes be obtained when installed in
an attic or loft.
•For best results, install the outdoor FM antenna well
away from tall buildings, preferably with a clear line
of sight to your local FM transmitter.
• Outdoor antenna should be located away from possi-
ble noise sources, such as neon signs, busy roads, etc.
•For safety reasons, outdoor antenna should be situated
well away from power lines and other high-voltage
equipment.
• Outdoor antenna must be grounded in accordance
with local regulations to prevent electrical shock haz-
ards.
■ Using a TV/FM Antenna Splitter
It’s best not to use the same antenna for both FM and TV
reception, as this can cause interference problems. If cir-
cumstances demand it, use a TV/FM antenna splitter, as
shown.
Connecting an Outdoor AM Antenna
If good reception cannot be achieved using the supplied
AM loop antenna, an outdoor AM antenna can be used
in addition to the loop antenna, as shown.
Outdoor AM antennas work best when installed horizon-
tally outside, but good results can sometimes be obtained
indoors by mounting horizontally above a window. Note
that the AM loop antenna should be left connected.
Outdoor antenna must be grounded in accordance with
local regulations to prevent electrical shock hazards.
To CBX-100 To TV (or VCR)
TV/FM antenna splitter
Outdoor antenna
AM loop antenna
Insulated antenna cable
CBX-100_En.book Page 16 Friday, September 15, 2006 9:34 AM

17
Connecting an External Audio Source
• Before making any connections, read the manuals
supplied with your other components.
•Don’t connect the power cord until you’ve completed
and double-checked all connections.
Connection Color Coding
RCA-type audio connections are usually color-coded:
red and white. Use red plugs to connect right-channel
audio inputs and outputs (typically labeled “R”). Use
white plugs to connect left-channel audio inputs and out-
puts (typically labeled “L”).
•Push plugs in all the way to make
good connections (loose connec-
tions can cause noise or malfunc-
tions).
•To prevent interference, keep
audio cables away from power
cords.
The following diagram shows how to connect an optional Onkyo RI Dock (Remote Interactive Dock).
Connect the CBX-100’s INPUT DOCK/LINE jacks to the RI Dock’s AUDIO OUT jacks.
What can you do with ?
• Connecting an Onkyo RI Dock to the CBX-100 with an cable allows you to control the RI Dock with the
CBX-100’s remote controller. In addition, when playback is started on the RI Dock, the CBX-100 will automatically
select it as the input source.
Notes:
•To use with an Onkyo RI Dock, the Input Display for the INPUT DOCK/LINE jacks must be set to DOCK. Since
this is the default setting, unless you’ve changed it, it can be left as it is (see page 21).
•To use , you must connect the RI Dock to the CBX-100 with an cable and an analog audio cable (RCA).
About Connections
Left (white)
Right (red)
Analog audio
cable Left (white)
Right (red)
Right!
Wrong!
Connecting an Onkyo RI Dock (Remote Interactive Dock)
R
AUDIO OUT DC INS VIDEO OUT
----
L
: Signal flow
CBX-100’s
rear panel
White
Red
Red
White
Analog audio cable (RCA)
cable supplied
with the RI Dock
Onkyo RI Dock’s rear panel
(DS-A1 shown here)
CBX-100_En.book Page 17 Friday, September 15, 2006 9:34 AM

18
Connecting an External Audio Source —Continued
Connect the CBX-100’s INPUT DOCK/LINE jacks to the other component’s audio output jacks.
Tip:
To listen to the component, select the LINE input source (see page 20).
Connecting Other Components
: Signal flow
CBX-100’s rear panel
White
Red
Red White
Analog audio cable (RCA)
TV
DVD player Cassette deck MD recorder
etc.
CBX-100_En.book Page 18 Friday, September 15, 2006 9:34 AM

19
Connecting the Power Cord
Notes:
• Before connecting the power cord, complete and double-check all other connections.
•Turning on the CBX-100 may cause a momentary power surge that might interfere with other electrical equipment
on the same circuit. If this is a problem, plug the CBX-100 into a different branch circuit.
•Do not use a power cord other than the one supplied with the CBX-100. The supplied power cord is designed exclu-
sively for use with the CBX-100 and should not be used with any other equipment.
•Never disconnect the power cord from the CBX-100 while the other end is still plugged into a wall outlet. Doing so
may cause an electric shock. Always disconnect the power cord from the wall outlet first, and then the CBX-100.
For the AccuClock function to work properly, the CBX-100 must be able to receive RDS radio stations, which means
an FM antenna must be connected. Be sure to connect an FM antenna before plugging in the power cord (see page 15).
The very first time you plug the power cord into a wall outlet, the AccuClock function automatically searches for an
RDS radio station that’s broadcasting CT (Clock Time) information and sets the clock accordingly. While the CT infor-
mation is being received, “AccuClock…” appears dimly on the display, as shown. Note that it may take a few minutes
to set the clock.
If the clock is set successfully, the day and time will be displayed brightly for 2 seconds, as shown.
The AccuClock function automatically updates the clock daily at 2 A.M., 3 A.M., and 2 P.M.
If for some reason the clock cannot be set automatically, see “Setting the Clock” on page 38.
12
To wall outlet
Supplied power cord
1
Connect the supplied power cord to the CBX-100’s AC INLET.
2
Plug the power cord into a suitable wall outlet.
The STANDBY indicator lights up.
AccuClock—Automatic Clock Setting
CBX-100_En.book Page 19 Friday, September 15, 2006 9:34 AM

20
Basic Operation
To turn on the CBX-100, press the [STANDBY/ON]
button on the CBX-100 or remote controller. The
STANDBY indicator goes off.
Press the [STANDBY/ON] button again to set the
CBX-100 to Standby. The STANDBY indicator lights
up.
Tip:
When you turn on or start playback on an Onkyo RI
Dock that’s connected to the CBX-100 with an
cable and analog audio cable, the CBX-100 turns on
automatically.
Press the VOLUME Up [ ] button to increase the vol-
ume or the VOLUME Down [ ] button to decrease it.
You can also use remote controller’s VOLUME
[ ]/[ ] buttons.
The adjustable range is: Min, 1, 2, 3...39, 40, 41, Max.
You can select CD, FM, AM, or DOCK/LINE, which
can be an external component such as an Onkyo RI
DOCK.
To select the input source, press the remote controller’s
INPUT [ ]/[ ] buttons repeatedly. On the CBX-100,
press the [INPUT] button repeatedly. The input sources
are selected in the following order.
Turn down the volume, then connect your stereo head-
phones to the PHONES minijack.
You can adjust the volume and mute the sound as nor-
mal.
The speakers output no sound while the headphones are
connected.
VOLUME
STANDBY/ON
INPUT
STANDBY indicator
(front panel)
VOLUME
/
STANDBY/
ON INPUT
/
PHONES
(rear panel)
Turning On the CBX-100
Adjusting the Volume
Remote
controller
CBX-100
Remote
controller
CBX-100
Selecting the Input Source
Using Headphones
CD FM AM
DOCK/LINE
PHONES jack
CBX-100_En.book Page 20 Friday, September 15, 2006 9:34 AM
