Onkyo CS-535 User manual

BLACK
uality Compact Audio with USB and iPod Connectivity
When it comes to mini systems, Onkyo has earned a reputation over the years for class-leading quality. That reputation is further
boosted by the CS-535, a system that delivers an audio performance belying its compact size. Much of the credit can go to the
proprietary Onkyo technologies driving the system. At the digital conversion stage, VLSC™(Vector Linear Shaping Circuitry) works to
remove noise from the audio signal. And at the amplification stage, WRAT (Wide Range Amplifier Technology) provides the foundation
for a genuinely musical listening experience. As well as handling most music CD formats, the CS-535 offers superb connectivity options.
A front-panel USB port lets you connect mass storage devices such as flash memory sticks and MP3 players, while the included Onkyo
Dock for the iPod lets you hook up and recharge your iPod.
SILVER
CS-535 CD Receiver System
(iPod not included)
Ampli ication Design Built Around the Onkyo Sound
Due to their obvious size limitations, mini audio systems present a
range of challenges in terms of amplification design. To overcome these
limitations, Onkyo’s engineers incorporated into the compact CS-535
the same technology that’s used in our renowned full-sized amplifiers
and receivers: ide Range Amplifier Technology. RAT gives the CS-
535 three distinct advantages: A wider frequency response compared
to rival mini audio systems; reduced amplifier distortion at high volume;
and better control of current and electrical/mechanical kick-back from
the speakers. This enables the CS-535 to deliver audio of surprisingly
high quality for such a compact component.
VLSC (Vector Linear Shaping Circuitry) and Optimum
Gain Volume Circuitry to Maintain Clean Audio Signals
The CS-535 employs VLSC to extract a noise-free analog signal from
digital music sources. This technology works to effectively remove pulse
noise during the digital-to-analog conversion process, thereby
maintaining the purity of the signal. Employed in Onkyo’s A/V receivers
and playback components, VLSC ensures you get the best possible
audio output from CDs and compressed formats such as MP3.
Under conventional volume attenuation methods that don’t involve
adjusting the gain, the audio signal drops close to the noise floor at low
volumes. This taints the signal with noise that becomes noticeable as
the signal is amplified. To prevent such noise from adversely affecting
the audio signal, the CS-535 employs Onkyo’s Optimum Gain Volume
Circuitry. This circuitry performs continual gain adjustments that reduce
attenuation by 50%, so the signal never comes close to the noise floor.
Front Panel USB Inter ace or Audio Playback rom
Mass Storage Devices
ith the CS-535’s front-panel port for a USB mass storage device, you
can access MP3 and MA files from USB flash drives (e.g. memory
sticks) or from portable audio players that support the USB Mass
Storage Class standard. Once your device is connected, you can use
the CS-535’s remote control to play back the music files in sequence.
The CS-535’s USB port makes it easy to relay digital files from your
computer for playback, or to use your MP3 player as a music source.
iPod Playback Through the RI Dock or the iPod
The Remote Interactive (RI) system enables Onkyo owners to integrate
compatible components for operation via a single remote control. It also
enables you to integrate your iPod with the CS-535 through the included
Onkyo RI Dock for the iPod. Simply connect the dock to the CD
receiver, then place your iPod in the dock for control via the CS-535’s
remote. The RI Dock has been praised for offering a “heftier and more
detailed” sound than can be experienced with an RCA stereo cable.
Quality Speakers with Proprietary Onkyo
Per ormance Features
Designed to match the CR-535 CD receiver, the accompanying D-035
two-way, bass-reflex speakers incorporate a number of Onkyo speaker
developments. The woofer cones, for example, are made from a pure
cotton weave we call OMF (Onkyo Micro Fiber). This material
effectively absorbs unwanted vibrations while providing the requisite
diaphragm stiffness to enable a fast and accurate response.
Furthermore, each speaker features a balanced-dome tweeter to
deliver high-frequency sounds with greater finesse.
CS-535_EU:CS-535_EU 09/08/07 11:53 ページ 1Downloaded from www.Manualslib.com manuals search engine

CS-535 CD Receiver System
SPECIFICATIONS
■RECEIVER SECTION
AMPLIFIER SECTION
Power Output 20 W + 20 W
(4 Ω, 1 kHz, 2 channels driven, IEC)
Dyna ic Power 22 W + 22 W (3 Ω)
20 W + 20 W (4 Ω)
14 W + 14 W (8 Ω)
Total Har onic Distortion 0.4% (1 kHz, 1 W)
Da ping Factor 25 (Front, 1 kHz, 8 Ω)
Input Sensitivity and I pedance 150 mV/50 kΩ(Line)
Output Level and I pedance 150 mV/2.2 kΩ(Rec Out)
Frequency Response 10 Hz–100 kHz/±3 dB (Line)
Tone Control ±6 dB, 80 Hz (Bass)
±8 dB, 10 kHz (Treble)
+7 dB, 80 Hz (Super bass)
Signal-to-Noise Ratio 100 dB (Line, IHF-A)
Speaker I pedance 4 Ω–16 Ω
TUNER SECTION
Tuning Frequency Range
FM 87.5 MHz–108 MHz
AM 522 kHz–1,611 kHz
CD PLAYER SECTION
Frequency Response 4 Hz–20 kHz
Audio Dyna ic Range 96 dB
Total Har onic Distortion 0.005%
Wow and Flutter Below threshold o measurability
Audio Output/I pedance 1.3 V/1 kΩ
GENERAL
Power Supply AC 220–230 V, 50/60 Hz
Power Consu ption 65 W
Standby Power Consu ption 0.25 W
Di ensions (W x H x D) 205 x 116 x 367 mm
Weight 4.0 kg
■SPEAKER SECTION
Speaker Type 2-way, bass re lex
Drivers
Woo er 10 cm OMF diaphragm
Tweeter 2.5 cm balanced-dome
Frequency Response 50 Hz–50 kHz
Crossover Frequency 7 kHz
Output Sound Pressure Level 83 dB/W/m
Max. Input Power 40 W
No inal I pedance 4 Ω
GENERAL
Di ensions (W x H x D) 137 x 234 x 230 mm
Weight 2.3 kg
■CARTON
Di ensions (W x H x D) 454 x 540 x 318 mm
Weight 11.3 kg
CR-535 CD Receiver
Ampli ier Features
• 20 W/Ch, 4 Ω, 1 kHz, 2 Channels Driven, IEC
• WRAT (Wide Range Amplifier Technology)
• High-Current, Low-Impedance Drive
• Discrete Output Stage Circuitry
• Optimum Gain Volume Circuitry
• Direct Mode
• 2 Audio Inputs and 1 Output
• Subwoofer Pre Out
CD Player Features
• Plays Audio CDs, MP3s (via USB, CD-R, CD-RW)*
and WMA (via USB)
• VLSC™(Vector Linear Shaping Circuitry)
• Wolfson®Stereo DAC
• 4 Play Modes for CD (Normal/Memory/
Random/Group)
• Navigation Mode for Selecting and Playing MP3 Files
Burned to CD-R, CD-RW
• MP3 Settings for Personal Preferences
• Memory Playback (25-Track Programming)
• 2 Repeat Modes (Track/Full)
*Discs that have not been properly finalized may only be partially
playable or not playable at all.
Tuner & Other Features
• Front Panel USB Interface for Mass Storage Devices
• 4-Mode Timer (Play or Rec/Once or Every)
• Sleep Timer
• Accuclock
• RDS (PS/RT)
• Preset Function with 40 FM/AM/RDS Selections
• Preset Naming (Up to 8 Characters)
• Manual and Automatic FM/AM tuning
• FM Auto Preset
• Tone Control (Bass/Treble)
• Super Bass Function
• Battery-Free Memory Backup
• Aluminum Front Panel and Volume Knob
• FM Indoor Antenna Supplied
• AM Loop Antenna Supplied
• Headphone Jack
• Gold-Plated Banana Plug-Compatible Transparent
Speaker Posts
• Compatible with RI (Remote Interactive) Dock for
the iPod
• RI (Remote Interactive) Remote Control
D-035 2- ay Bass Reflex Speakers
• 10 cm OMF Diaphragm Woofer
• 2.5 cm Balanced-Dome Tweeter
• Magnetically Shielded
• Impedance: 4 Ω
• Max. Input Power: 40 W
• Frequency Response: 50 Hz–50 kHz
Speaker cable and cork spacers included.
DS-A1XP RI Dock for the iPod
• Recharges iPod When Connected to AC
Power Supply
• Superior uality for Digital Music Files
• Compatible with RI Remote Control
• Remote Interactive Functions (Auto Power On,
Auto Selector, Time Play/Sleep Timer)
NPR No. 09N55 07/09
Due t a p licy f c ntinu us pr duct impr vement, Onky reserves the right t change specificati ns and appearance with ut n tice. iP d is a trademark f Apple Inc., registered in the U.S. and ther c untries. "Made f r iP d" means that an electr nic access ry has been designed t c nnect
specifically t the iP d and has been certified by the devel per t meet Apple perf rmance standards. WRAT, VLSC, and OMF are trademarks f Onky C rp rati n. All ther trademarks and registered trademarks are the pr perty f their respective h lders.
