Openplan DSH-L User manual

www.openplan.com | [email protected]  844.OPS.OPS1  REV 03.11.21
DSH-L DESK SCREEN DIVIDER
ASSEMBLY GUIDE
Install Surface Bracket to a Corner Bracket using (2)
provided screws.
1.
Surface Bracket is attached
beneath work surface with
self-tapping screws.
Install Corner Bracket at the top where two screen
corners meet by sliding screen edge into bracket
channel. Tighten bolt to secure. Install Surface
Bracket below work surface with self-tapping
screws. Slide screen edge into bracket channel
and tighten bolt to secure.
2.
Install Clamp Bracket at the end of each screen
run. Clamp Bracket is installed with self-tapping
screws. Tighten knob to secure screen.
When installing Clamp Bracket,
adjustment knob should be facing
inside the work surface.
3.
Clamp Bracket
Surface Bracket
Corner Bracket
NOTE: 24mm PET board required.

www.openplan.com | [email protected]  844.OPS.OPS1  REV 03.11.21
DSH-LU DESK SCREEN DIVIDER
ASSEMBLY GUIDE
Install Corner Brackets at the top where two
screen corners meet by sliding screen edge
into bracket channel. Tighten bolt to secure.
Install Surface Brackets below work surface
with self-tapping screws. Slide screen edge
into bracket channel and tighten bolt to
secure.
2.
Install Clamp Brackets at the end of
each screen run. Clamp Brackets is
installed with self-tapping screws.
Tighten knob to secure screen.
3.
Install Surface Brackets to a Corner Bracket using (4)
provided screws.
1.
When installing Clamp Bracket,
adjustment knob should be facing
inside the work surface.
Surface Bracket is attached
beneath work surface with
self-tapping screws.
Clamp Bracket
Surface Bracket
Corner Bracket
