OPT7 Quantum Rock Lights Bluetooth User manual

QUANTUM ROCK LIGHTS
BLUETOOTH
COMPONENTS
INSTALLATION GUIDE
x6
10ft Extension Cable
Fuse Tap (3 different sizes) x1
Metal Screw x8
Hardwire Power Harness x1
x4
Quantum Rock Light Pod RubberPad x4
Control Box with Accessory Wire
Y-Splitter x2
Door Assist Function
x1
1V1.1.041119

WHERE TO INSTALL
2
RECOMMENDED LOCATIONS FOR ROCK LIGHT PODS

3
INSTALLATION STEPS
Designate your mounting locations for each Rock Light Pod and the
control box. (Refer to page 4 for recommended mounting locations)
Avoid hot surfaces and/or moving parts.
Use a pen to mark the holes where you want to mount the Rock Light
Pods. Then, drill a 5/32” hole(s) for the wire connector to pass
through.
Drill a 7/64” hole for each marked hole.
Secure the Rock Light Pods using the included screws. (If mounting on
a rounded or uneven surface, utilize the optional rubber mounting
pads.)
Caution: Rock Light Pods become extremely hot during use - keep
away from any vehicle parts that may be damaged by exposure to
high temperatures.
Connect all Rock Light Pod wires to the control box connectors.
Secure by twisting.
Connect the red positive line from the control box either directly to
the vehicle battery or by using an open fuse tap.
Ground the negative wire from the control box by connecting it to an
unpainted area on your vehicle's frame.
Optional: If you would like for the door assist function to be used, it is recom-
mended to connect the door assist wire from the control box to a positive (+) light
source that is turned on when the door is open or to the dome light. This will
activate the Rock Lights to be ON when the door is turned on.
Open the OPT7 AURA App, pair your smart device to the control box,
and pick your desired color!
1.
2.
3.
4.
5.
6.
7.
8.
TOOLS REQUIRED
5/32-inch Drill Bit
7/64-inch Drill Bit
Phillips Head Screwdriver
•
•
•

SPECIFICATIONS
OPT7 Lighting is not liable for damages or personal injuries while installing this
product. The Installation Guide is intended as assistance to reduce setup time.
OPT7 Lighting assumes no responsibility for improper installation. If you are
unfamiliar with your vehicle or inexperienced with aftermarket upgrades,
please seek professional assistance.
Watts
Amp Draw
8 LEDs
Raw Lumens
Voltage
Waterproof IP Grade
Operating Temperature
96W
Quad-Core CREE
8A
3,600 (All 4 Pods Combined)
10-30V
IP67
65-120F
OPT7 AURA APP
NEED HELP?
Scan for
troubleshooting
tips, and more.
4
DISCLAIMER
Colors
Modes
Door Assist
Support
Ability to control up to
4 devices at once
-
-
-
-
-
QR CODE TO DOWNLOAD
Subcribe to our
YouTube channel.
Opt7Lighting
Follow us on
Instagram
@opt7lighting
YEAR
2
WARRANTY
CONNECTED
ON
WHITE
RANDOM
BRIGHTNESS
SOLID
DOOR
ASSIST
OFF
