Optical Systems Design OSD2010 User manual

OPERATOR MANUAL
OSD2010
FIBER MODE
CONVERTER

OPTICAL SYSTEMS DESIGN
DOC ID: 10117301
OSD2010 OPERATOR MANUAL
PAGE
3
INDEX 1
1 TECHNICAL SUMMARY........................................................................................................ 4
1.1 BRIEF DESCRIPTION ............................................................................................................ 4
1.1.1 OVERVIEW......................................................................................................................... 4
1.1.2 APPLICATIONS.................................................................................................................. 4
1.1.3 FEATURES AND BENEFITS............................................................................................. 4
1.2 TYPICAL CONFIGURATION................................................................................................ 5
1.3 ECHNICAL SPECIFICATIONS.............................................................................................. 5
2 INSTALLATION AND OPERATION..................................................................................... 6
2.1 INTRODUCTION .................................................................................................................... 6
2.2 INSTALLATION ..................................................................................................................... 6
2.2.1 WARNING AND PRECAUTIONS..................................................................................... 6
2.2.2 OSD2010 DRAWINGS AND DIMMENSIONS ................................................................. 7
2.3 CONNECTIONS ...................................................................................................................... 8
2.3.1 POWER SUPPLY CONNECTIONS ................................................................................... 8
2.3.2 ALARM CONNECTIONS................................................................................................... 8
2.3.3 INDICATORS.................................................................................................................... 10
2.3.4 FITTING SFP CONNECTORS.......................................................................................... 11
3 MAINTENANCE...................................................................................................................... 12
3.1 INTRODUCTION .................................................................................................................. 12
3.2 EXTERNAL INSPECTION ................................................................................................... 12
3.3 ROUTINE MAINTENANCE................................................................................................. 12
4 WARRANTY ............................................................................................................................ 13
4.1 WARRANTY PERIOD.......................................................................................................... 13
4.2 REPAIRS................................................................................................................................ 13
4.2.1 WARRANTY REPAIRS.................................................................................................... 13
4.2.2 OUT-OF-WARRANTY REPAIRS.................................................................................... 13
4.2.3 SITE REPAIRS .................................................................................................................. 13
4.2.4 EXCLUSIONS ................................................................................................................... 13
FIGURE 1: OSD2010 TYPICAL CONFIGURATIONS........................................................................................... 5
FIGURE 2: OSD2010 MOUNTING DIMENSIONS ................................................................................................ 7
FIGURE 3: OSD2010 POWER SUPPLY CONNECTIONS..................................................................................... 8
FIGURE 5: ALARM PINOUT .................................................................................................................................. 8
FIGURE 4: ALARM OUTPUT EQUIVALENT CIRCUIT ...................................................................................... 9
FIGURE 6: LED INDICATORS ............................................................................................................................. 10
FIGURE 7: FITTING/REMOVING SFP CONNECTORS ..................................................................................... 11
TABLE 2: TECHNICAL SPECIFICATIONS........................................................................................................... 5
TABLE 2: DC OR AC POWER CONNECTION ..................................................................................................... 8
TABLE 3: PIN ASSIGNMENT................................................................................................................................. 9
TABLE 4: INDICATOR FUNCTION..................................................................................................................... 10

OPTICAL SYSTEMS DESIGN
DOC ID: 10117301
OSD2010 OPERATOR MANUAL
PAGE
4
1TECHNICAL SUMMARY
1.1 BRIEF DESCRIPTION
1.1.1 OVERVIEW
The OSD2010 series is an industrially rated fiber mode converter. The unit can be used in a number of
different applications such as a repeater, fiber mode converter or to add CWDM to existing fiber
networks. The OSD2010 requires two SFP modules per unit to operate. It also has convenient LED
status indicators and alarm outputs. The OSD2010 is powered by non-critical dual power supply inputs
The OSD2010 is available as a module and require an external power source.
1.1.2 APPLICATIONS
▲ Any network utilizing a mix of
singlemode and multimode fiber
▲ Adding CWDM to an existing fiber
network
▲ Extending optical transmission
distances by operating as an optical
repeater
▲ Networks using Ethernet devices such
as cameras, intercoms, access control,
telephones, etc.
1.1.3 FEATURES AND BENEFITS
▲ Protocol transparent SFP to SFP
mode converter
▲ Operates with multimode or
singlemode fiber simply by selecting
the SFP used
▲ Operates with SFPs of up to 10Gbps
▲ Plug and play operation: no user
settings needed
▲ Works with SDH, Ethernet, CPRI,
and Fiber Channel
▲ Can be used with 1 or 2 fibers on
either singlemode or multimode fibers
over a variety of link budgets
▲ Provides wavelength conversion for
CWDM or DWDM applications
▲ Powered by non-critical 10 to 36V
DC
or 24V
AC
supplies
▲ Dual power supply inputs
▲ Operates over the temperature range
of -20 to +75°C
▲ Alarm outputs for loss of input power
and for laser failure
▲ SFP modules sold separately

OPTICAL SYSTEMS DESIGN
DOC ID: 10117301
OSD2010 OPERATOR MANUAL
PAGE
5
1.2 TYPICAL CONFIGURATION
Figure 1 below indicates the typical set-up for an OSD2010 system.
FIGURE 1: OSD2010 TYPICAL CONFIGURATIONS
1.3 ECHNICAL SPECIFICATIONS
TABLE 1: TECHNICAL SPECIFICATIONS
SPECIFICATION PERFORMANCE
Optical Data Interface
Protocol transparent
Optical Data Rate 10Mbps to 10Gbps
Optical Port Connectors
SFP
SFP Options Short haul, Long haul, CWDM, single fiber operation, etc.
Please consult OSD SFP datasheets or contact OSD
Alarms
SFP #1 Laser Fail
SFP #1 Loss of Received Optical Signal
SFP #2 Laser Fail
SFP #2 Loss of Received Optical Signal
Alarm Interface
4 Open drain outputs rated at 500mA @ 24V maximum;
Short to Ground when OK
Open Circuit when not OK or power off
Operating Temperature -20°C to +75°C
Relative Humidity 0 to 95% non-condensing
Power Requirements +10V to +36V
DC
or 22V to 28V
AC
@ 4VA
Power Connector 4 way 5.08mm terminal block
Alarm Connector
6 way 3.5mm terminal block
Indicators 2 x Laser OK/Not OK
2 x Received Optical Power OK/Not OK
Dimensions (mm) 60W x 94D x 26H (excluding flanges and connectors)
Weight
0.4kg
102201001

OPTICAL SYSTEMS DESIGN
DOC ID: 10117301
OSD2010 OPERATOR MANUAL
PAGE
6
2INSTALLATION AND OPERATION
2.1 INTRODUCTION
This section outlines the methods required to install and operate the OSD2010 successfully. It should be
studied carefully if damage to the equipment or poor results are to be avoided.
This equipment has been fully tested prior to dispatch and is ready for immediate operation. However it
is advisable to check for external transportation damage before operation. If damage is evident, return
the unit with the packaging to your supplier immediately.
2.2 INSTALLATION
2.2.1 WARNING AND PRECAUTIONS
▲ ELECTROMAGNETIC COMPATIBILITY
WARNING: This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
▲ OPTICAL OUTPUT OPERATION
WARNING: Laser Safety: Class 1 Laser Product per IEC/EN 60825-1:2014 standard.
Class 1
The OSD2010 is a Class 1 laser product when SFP is fitted
PRECAUTIONS
▲ All service personnel should be provided training as to the hazards of direct viewing of laser
radiation and of the precautionary measures during servicing of equipment
▲ Areas where laser products are installed should be restricted in access to trained service
personnel only and appropriate warning signs posted in the work area.
▲ All laser apertures should be covered by protective covers when not connected to optical
fibers. Never leave outputs uncovered.
▲ Laser equipment should be positioned above or below eye level where possible. Apertures
should be positioned away from personnel.
▲ Protective eyewear should be worn in the vicinity of laser equipment.

OPTICAL SYSTEMS DESIGN
DOC ID: 10117301
OSD2010 OPERATOR MANUAL
PAGE
7
2.2.2 OSD2010 DRAWINGS AND DIMENSIONS
The OSD2010 is designed to be mounted on an even surface and to be secured by means of M4 or
smaller screws.
FIGURE 2: OSD2010 MOUNTING DIMENSIONS
R2.1
R2.1
Ø8.5
8.0
8.0
DETAIL A
DETAIL A
6
94
38
25.6
25.6
26.4
60
83.4

OPTICAL SYSTEMS DESIGN
DOC ID: 10117301
OSD2010 OPERATOR MANUAL
PAGE
8
2.3 CONNECTIONS
2.3.1 POWER SUPPLY CONNECTIONS
The OSD2010 module has dual power supply inputs which requires external +10 to +36V
DC
or 22 to
28V
AC
power @ 4VA. Power should be connected to the power socket located at the back of the case.
DC power should be connected as indicated in Table 2.
TABLE 2: DC OR AC POWER CONNECTION
Power Pin Specification
Pin 1 +10V to +36V
DC
or
22V to +28V
AC
Pin 2 0V
Pin 3 +10V to +36V
DC
or
22V to +28V
AC
Pin 4 0V
FIGURE 3: OSD2010 POWER SUPPLY CONNECTIONS
2.3.2 ALARM CONNECTIONS
The alarm contact closure output on the OSD2010 can be connected to the relay coil. Maximum ratings
the OSD2010 can drive is 0.5A @ 24V
(max)
.
FIGURE 4: ALARM PINOUT
4 3 2 1
6 5 4 3 2 1

OPTICAL SYSTEMS DESIGN
DOC ID: 10117301
OSD2010 OPERATOR MANUAL
PAGE
9
FIGURE 5: ALARM OUTPUT EQUIVALENT CIRCUIT
Pin assignments for the 6 way 3.5mm terminal block Alarm connectors (Figure 4) are shown in Table 3
below. Use the below table in conjunction with the LED indicator.
TABLE 3: PIN ASSIGNMENT
Alarm
Pin Specification Parameter
Pin 1 0V Ground
Pin 2 Laser Ch A Fail Ch A Short to GND (Pin 1) when OK
Ch A Open Circuit when not OK or Power off
Pin 3 Rx Ch A Fail
Ch A Short to GND (Pin 1) when OK
Ch A Open Circuit when not OK or Power off
Pin 4 Laser Ch B Fail Ch B Short to GND (Pin 1) when OK
Ch B Open Circuit when not OK or Power off
Pin 5 Rx Ch B Fail Ch B Short to GND (Pin 1) when OK
Ch B Open Circuit when not OK or Power off
Pin 6 0V Ground
OSD2010
External
Relay
24V
(max)
Pin5
Pin3
Pin4
Pin2
Pin1
Pin6
24V
(max)
24V
(max)
24V
(max)
Laser A OK
Rx A OK
Laser B OK
Rx B OK

OPTICAL SYSTEMS DESIGN
DOC ID: 10117301
OSD2010 OPERATOR MANUAL
PAGE
10
2.3.3 INDICATORS
FIGURE 6: LED INDICATORS
TABLE 4: INDICATOR FUNCTION
LED Specification Parameter

Ch A Receive Signal OK
Red No Received Signal
Green Received Signal OK

Ch A Laser OK
Red Transmit Laser Fail
Green Transmit Laser OK

Ch B Receive Signal OK
Red No Received Signal
Green Received Signal OK

Ch B Laser OK
Red Transmit Laser Fail
Green Transmit Laser OK




OPTICAL SYSTEMS DESIGN
DOC ID: 10117301
OSD2010 OPERATOR MANUAL
PAGE
11
2.3.4 FITTING SFP CONNECTORS
Care should be taken when inserting/removing the SFP connectors from the SFP port as SFP modules
are Electrostatic (ES) sensitive and Electrostatic Discharge (ESD) precautions should be taken when
installing. Ensure that the SFP is fully engaged and latched into position.
Inserting SFP – Ensure that the SFP lever is in the locked position and insert into appropriate SFP
port. Gently push the SFP until it locks into place. Remove plastic/rubber dust cap and fit appropriate
fiber cable.
Removing SFP – Remove fiber connector. Pull the SFP lever down to unlock SFP from housing.
Using the lever, gently pull the SFP out.
Fiber SFP
FIGURE 7: FITTING/REMOVING SFP CONNECTORS
Inserting
SFP
Removing
SFP
1
2

OPTICAL SYSTEMS DESIGN
DOC ID: 10117301
OSD2010 OPERATOR MANUAL
PAGE
12
3MAINTENANCE
3.1 INTRODUCTION
The following section outlines the fault-finding procedure for the OSD2010 modems. Please take note
of the following:
▲ Personnel without appropriate training should not attempt any maintenance except that outlined
below.
▲ If further maintenance is attempted you are warned that every care should be taken to ensure that
internal measurements made while the equipment is operational are taken carefully as some
components within the unit are expensive and may be damaged by failure of any portion of their
support circuitry.
▲ Some components within the unit are Electrostatic (ES) sensitive and Electrostatic Discharge
(ESD) precautions should be taken when performing maintenance upon the unit.
3.2 EXTERNAL INSPECTION
Visually check for the following:
▲ Check that the correct power source is connected to the power socket.
▲ Check that the SFPs are connected to the modem correctly.
▲ Inspect the optical connectors for any contamination and clean using isopropyl alcohol and a lint
free tissue if any contamination is detected.
▲ Check that any external termination resistors are connected if the system configuration requires
them.
3.3 ROUTINE MAINTENANCE
▲ There is no routine maintenance required with the OSD2010.

OPTICAL SYSTEMS DESIGN
DOC ID: 10117301
OSD2010 OPERATOR MANUAL
PAGE
13
4WARRANTY
Thank you for purchasing equipment designed, manufactured and serviced by Optical Systems Design
(OSD). OSD warrants that at the time of shipment, its products are free from defects in material and
workmanship and conforms to specifications. Our Warranty conditions are outlined below:
4.1 WARRANTY PERIOD
For warranty period, please call your local OSD distributor.
4.2 REPAIRS
Optical Systems Design reserves the right to repair or replace faulty modules/units. Please obtain a
“Return Material Authorisation” (RMA) form and number before returning goods.
Goods must be returned in adequate packing material to Optical Systems Design, Warriewood or its
nominated authorised representative, for all repairs.
4.2.1 WARRANTY REPAIRS
Return shipments to OSD shall be at customer's expense and freight back to the customer will be at
OSD expense.
4.2.2 OUT-OF-WARRANTY REPAIRS
OSD reserves the right to repair or replace any faulty goods. Freight costs and insurance for both
journeys are met by the user. All equipment repaired by OSD will have a 3-Month Warranty from the
date of dispatch.
4.2.3 SITE REPAIRS
By agreement site repairs may be undertaken for which out of pocket, hotel and travel expenses will be
charged.
4.2.4 EXCLUSIONS
This warranty does not apply to defects caused by unauthorized modifications, misuse, abuse or
transport damage to the equipment. All modifications to OSD’s standard product will need written
authorization and will be charged at normal repair rates. All modifications are to be carried out by OSD
Technicians. Warranty is void if unauthorized removal and/or tampering with serial number and/or
labels is evident.

Optical Systems Design Pty. Ltd.
7/1 Vuko Pl. Warriewood 2102
P.O. Box 891 Mona Vale
N.S.W. Australia 2103
Telephone: [phone]
Facsimile: [phone]
Email: [e-mail]
Web Site: www.osd.com.au
OPTIC L
SYSTEMS
DESIGN
PTY LTD A.B.N. 83 003 020 504
Printed in Australia
