Optimus F-7345WH User manual

Instruction Manual
and Owner’s Guide
Model: F-7345WH/F-7345BK
INFORMATION HOTLINE:If, after reading this owner’s guide, you
have any question or comments, please feel free to write us or call us at
1-888-672-5832 or e-mail us at S[email protected]. Our customer
service representative will be happy to help you.
PLEASE READ AND SAVE THESE INSTRUCTIONS
IMPORTANT INSTRUCTIONS:
Thank you for choosing an Optimus fan. To ensure the best performance from your
Fan, please read and save the following instructions.
WHEN USING ELECTRICAL APPLIANCES, BASIC PRECAUTIONS
SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK AND INJURY TO PERSONS, INCLUDING THE
FOLLOWING:
•Read all instructions before using this product.
•Use this fan only as described in this manual. Any other use not recommended by the
manufacturer may cause fire, electrical shock or injury, and may void the warranty.
•Always unplug the unit before assembling, disassembling or cleaning.
•Always unplug the unit when not in use or when moving from one location to another.
•To disconnect, grip the plug and pull it from the wall outlet. Never yank the cord.
•The use of attachments not recommended or sold by the appliance manufacturer may
cause hazards.
•Avoid contact with moving parts.
•DO NOT operate this fan with a damaged cord or plug, after a malfunction, or is
dropped or damaged in any manner. Return the unit to Optimus Enterprise, Inc. for
examination, electrical or mechanical adjustment, or repair.
•DO NOT operate this fan in the presence of explosive and/or flammable fumes.
•DO NOT place the fan or any parts near an open flame, cooking or other heating
appliance.
•Extreme caution is necessary when fan is used by or near children or invalids and
whenever the fan is left operating and unattended.
•This product is intended for household use only and not for commercial or industrial
use. DO NOT use outdoors.
•Always use on a dry level surface.
•DO NOT operate if the fan housing is removed or damaged.
•A loose fit between the AC outlet and plug may cause over heating of the plug. Have a
qualified electrician replace the outlet.
•DO NOT run cord under carpeting. Do not cover cord with throw rugs, runners or like.
Arrange cord away from traffic area and where it could be tripped over.
•This fan is equipped with a polarized alternating current line plug (a plug having one
blade wider than the other). This plug fits into the power outlet only one way. This is a
safety feature. If you are unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact an electrician to replace the obsolete
outlet. DO NOT defeat the safety purpose of polarized plug.
•This product employs an overload protection (fuse). A blown fuse indicates an
overload or short-circuit. If the fuse blows, unplug the product from the outlet. Replace
the fuse as per the Maintenance Instructions (follow product marking for proper fuse
rating). If the replacement fuse blows, a short-circuit may be present and the product
should be discarded or returned to Optimus Enterprise, Inc. for examination and/or
repair.
•NEVER connect the fan to any power sources other than a 120 volt alternating current
polarized outlet.
•WARNING: To reduce the risk of electric shock. DO NOT use this fan with any
solid-state speed control and DO NOT insert finger or any object into grill.

OPERATING INSTRUCTIONS:
SETTING UP
•Carefully remove your fan from the box (please save the carton for off-season storage).
•Make sure the unit is in the OFF position before plugging the unit into the outlet.
FUNCTIONS & OPERATION
1. Plug in the product, the power light will be lit.
2. :Click this button, fan will turn on. Clicking the button again will turn the unit off.
3. Speed: Click this button to select speed of : low-high
4. Swing: Click this button to use swing function. Click it again to stop swing function.
CLEANING
During Season Care:
•Before cleaning, be sure to turn off and unplug the unit.
•Keep the fan clean. Carefully wipe the unit with a soft, damp cloth. Please be very cautious
near the motor.
•DO NOT immerse the fan in water and never allow water to drip into the Motor Housing.
•Never use gasoline, benzene or thinner. This will damage the surface of the unit.
•After cleaning, be sure to completely dry the unit with a cloth or towel.
After Season Care:
•Your fan can be stored in the off-season.
•Before putting the fan in storage, clean it thoroughly, cover it with a vinyl bag, and store it
in a cool and dry place. We recommend using the original (or appropriately sized) box.
•
MAINTENANCE INSTRUCTIONS:
A loose fit between the AC outlet and plug may cause over heating of the plug. If the plug
over heats, it might cut off the fuse inside the power cord plug.
If your fuse access cover is located on the side of the plug:
•Grasp plug and remove from the receptacle or other outlet device. Do not yank the
cord to unplug.
•Select a suitable tool such as a small flat screwdriver or travel scissors.
•To open the fuse cover. Slide open fuse access cover on top of attachment plug
toward blades. (see fig.1)
•Carefully remove the fuse by prying it out. (see fig.2)
•Risk of fire can result by using wrong fuse rating. Replace fuse only with 2.5 Amp,
125 Volt rating.
•To close the fuse access cover. Slide to close access cover on top of attachment
plug. (see fig.3)
Fig.1 Fig.2 Fig.3
If your fuse access cover is located on the face of the plug:
•Grasp plug and remove from the receptacle or other outlet device. Do not yank the
cord to unplug.
•Select a suitable tool such as a small flat
screwdriver or travel scissors.
•To open the fuse cover. Press the tool
down, and then pry the protection door off
of the face of the plug. (see fig. #1)
•Continue to remove protection door until
you can access the fuse below. (see fig.
#2)
•Carefully remove the fuse by prying it out.
•Risk of fire can result by using wrong fuse
rating. Replace fuse only with 5Amp, 125 Volt rating.
•To close the Close fuse cover. Push the protection door back onto the face of the
plug and press it securely in place.
SERVICE AND REPAIR:
•Do not attempt to repair or adjust any electrical or mechanical functions on this
unit. Doing so will void the warranty.
•If you have any questions regarding this unit’s operation or believe any repair is
necessary, please call 1-888-672-5832 to speak with a Customer Service
Representative. Or e-mail us at [email protected]. E-mail will be easier to
get answer.
•If you need to exchange the unit, please return it, in its original carton with a sales
receipt enclosed, to the store where you purchased the unit.
•If you are returning the unit more than 30 days after the date of purchase, please
see the enclosed warranty for return procedure.
•If you have any other question or comments, feel free to write us:
Optimus Enterprise, Inc.
Customer Service Department
2201 E. Winston Road, Unit #J. Anaheim, CA 92806
E-mail: [e-mail]

WARRANTY
For your own records, staple or attach your sales receipt to this manual. Please also write
the store name /location and date purchased below.
STORE NAME/LOCATION:
DATE PURCHASED:
ONE (1) YEAR LIMITED WARRANTY
(SAVE THIS WARRANTY INFORMATION)
Optimus Enterprise. Inc, warrants to its customers and /or consumer of this electric fan and
the parts thereof will be free from defect in material and workmanship, under normal use,
for a period of one (1) year from the date of initial purchase. The warranty does not apply
to repairs necessitated by damage, misuse, abuse or alteration and to any repairs of
merchandise not used within the United States unless otherwise prescribed by law. Optimus
Enterprise, Inc, shall not be liable for any personal injury, property damage or any
incidental or consequential damages of any kind (including water damage) resulting from
malfunctions, defects, misuse, improper installation or alternation of this product. This
warranty is the only warranty extended by Optimus Enterprise, Inc, to its original
customers and /or consumers purchasing fan, Optimus Enterprise, Inc, disclaims all other
warranties, expressed or implied, that arise by the operation of law, specifically including
the implied warranties of merchantability and fitness for a particular purpose. Optimus
Enterprise, Inc, shall not be liable for any incidental or consequential damage, which may
have resulted from any alleged breach of warranty. Some states do not allow limitations on
how long implied warranty lasts or the exclusion or limitation of consequential damage, so
the above limitations or exclusion may not apply to you. This warranty gives you specific
legal rights you may also have other rights which vary from state to state.
Should the fan fail during the warranty period, the owner should:
● Within the first 30 days from date of purchase, the store from which you purchased your
Optimus product should replace this product if it is defective in material or
workmanship (provided the store has in-stock replacement).
● Within the first 12 months from date of purchase, Optimus Enterprise, Inc, will repair or
replace the product if it is defective in material or workmanship providing it is
returned to Optimus Enterprise, Inc. with freight prepaid, with evidence of purchase
date (cash register receipt) together with US$12.00 CHECK OR MONEY ORDER for
handling and return packaging/shipping charges.
IMPORTANT: ANY REPAIRS SHOULD BE PERFORMED BY AN AUTHORIZED
SERVICE REPRESENTATIVE. DO NOT ATTEMPT TO REPAIR THIS FAN
YOURSELF. DOING SO MAY VOID YOUR WARRANTY.
PLEASE RETAIN THIS WARRANTY AND SALES RECEIPT TO INSURE YOUR
PRODUCT WARRANTY.
IMPORTANT: RETURN INSTRUCTIONS:
Your warranty depends on your following these instructions if you are returning the unit
more than 30 days after the date of purchase:
● Carefully pack the fan in the original container or a suitable container to avoid damage in
shipping.
●
Seal the carton. Address an envelope as follows : Optimus Enterprise, Inc.
2201 E. Winston Road, Unit #J
Anaheim, CA 92806
● Inside the envelope, enclose your name, full address with zip code, daytime phone
number, evidence of purchase date (cash register receipt) AND A CHECK OR
MONEY ORDER for handling and return packaging/shipping charges. Please also
include a brief explanation of the problem you are having with the unit.
● Optimus Enterprise, Inc. recommends you insure the package as damage in shipments is
not covered by your warranty.
● All shipping/ handling charges must be prepaid by you (as noted as above).
