Optoma HD25-LV User manual

The Optoma HD25-LV delivers outstanding
high-denition 1080p video and graphics
with unsurpassed color accuracy and
incredibly sharp detail.
The Optoma HD25-LV will dazzle your
audience with its stunning image clarity. Its
3200 ANSI lumens and 20,000:1 contrast
ratio provide the brightness you need
for your most demanding home theater
installation.
It offers full 3D compatibility for seamless
integration with either DLP®Link™or *RF
3D glasses along with your favorite 3D
content from your Blu-ray player, Xbox,
PS3 and other gaming consoles.
Designed for maximum performance and
reliability, the Optoma HD25-LV features
industry-leading energy saving features
and whisper quiet operation to help you
create the most magnicent home theater.
DIGITAL
CAMERAS
CAMCORDERS
GAME
CONSOLES
TABLETS
SMART
PHONES
COMPUTERS SET TOP BOXES
3D BLU-RAY/DVD PLAYERS
3D HOME THEATER PROJECTOR
HD25-LV
EXTRAORDINARY IMAGE CLARITY
CONNECTIVITY (May require optional accessories)
Deliver powerful high-resolution home
theater experience
Native 1080p resolution for the sharpest,
most visually stunning image quality
Full 3D compatibility; immerse yourself
in your favorite 3D movie or video game
Comprehensive connectivity to satisfy
your current and future needs
SRS WOW HD™ Surround Sound
technology built-in for rich deep bass
and exceptional sound quality
HD
SRS
*RF 3D glasses also require the use of the RF 3D Emitter.

Four Directional Select Keys
Resync
Source
Power LED Lamp LED
Temp LED
Power and Standby
AV Mute
Keystone Correction
Menu
Power On Power Off
Native
Re-sync/
Four Directional
Select Keys
Gamma
3D Format
16:9
VGA1
HDMI2
Video
LBX
4:3
Lamp Mode
Brightness
Contrast
Mode
HDMI
Menu
VGA2
Volume Up
Volume Down
Source
3D HOME THEATER PROJECTOR — HD25-LV
OPTICAL/TECHNICAL SPECIFICATIONS
Display Technology Single 0.65ʺ DC3 DMD DLP® Technology by
Texas Instruments™
Native Resolution HD 1920 x 1080
Maximum Resolution WUXGA 1920 x 1200
Brightness 3200 ANSI lumens
Contrast Ratio 20,000:1 (full on/full off)
Displayable Colors 1.07 Billion
Lamp Life and Type† 6000/5000/3500 Hours (ECO+/ECO/Bright)
240W Philips
Projection Method Front, rear, ceiling mount, table top
Keystone Correction ±20° Vertical
Uniformity >80%
Offset 116%
Aspect Ratio 16:9 Native, 4:3 compatible
Throw Ratio 1.5–1.8 (distance/width)
Projection Distance 3.9ʹ–32.8ʹ (1.5–10 m)
Image Size 37.6ʺ–301.1ʺ (0.7–7.62 m)
Projection Lens F=2.55–2.86, f=22.37–26.73 mm,
1.2x manual zoom and focus
Digital Zoom 1.0 ~ 2.0
Audio 16-Watt stereo speaker system
Noise Level 26dB
Remote Control IR remote control
Operating Temperature 41–113°F (5–45°C), 85% max humidity
Power Supply AC Input 100–240V, 50–60Hz, auto-switching
Power Consumption Max 339W (Normal), Min 241W
(Eco+), <0.5W (standby-ECO)
COMPATIBILITY SPECIFICATIONS
Computer Compatibility WUXGA, UXGA, SXGA+, WXGA+, WXGA,
SXGA, XGA, SVGA, VGA resized, VESA,
PC and Macintosh compatible
Video Compatibility NTSC, PAL, SECAM, SDTV (480i), EDTV
(480p), HDTV (720p, 1080i/p)
3D Compatibility‡Supports all HDMI 1.4a mandatory 3D
format, side-by-side format and top and
bottom format. 3D glasses are needed and
sold separately.
Vertical Scan Rate 24–85Hz, 120Hz, 144Hz
Horizontal Scan Rate 15.375–91.146KHz
User Controls Complete on-screen menu, adjustments
in 28 languages
I/O Connection Ports Two HDMI v1.4a, two VGA-in, VGA-out, 3D
VESA Port, composite video, two audio-in,
audio-out, RS-232C, USB-B
Loop Through (Audio, VGA) Monitor: D-Sub 15 pin VGA output
(functional in both normal and standby modes)
Audio: VAO audio out, HDMI VAO audio out
supported (VAO in normal mode, xed in
Standby)
PHYSICAL SPECIFICATIONS
Security Kensington® lock, security bar and
keypad lock
Weight 6.4 lb (3.1 kg)
Dimensions 12.7ʺ x 3.8ʺ x 9.2ʺ
‡3D content can be viewed with either RF or DLP Link active shutter glasses when projector is
used with a compatible 3D player. RF 3D glasses require the use of the RF 3D emitter. Please
visit www.OptomaUSA.com for more information.
†Lamp life is dependent on many factors, including lamp mode, display mode, usage,
environmental conditions and more. Lamp brightness can decrease over time.
Warranty
1-Year Limited Parts and Labor, 90-Days on Lamp
In the Box (Standard Accessories)
AC power cord, remote control, batteries for remote, lens cap, multilingual
CD-ROM user’s manual, quick start card, and warranty card
Optional Accessories
HDMI cable, ceiling mount, component to VGA cable, composite video cable,
RS-232 cable, Optoma screen, RF 3D glasses, RF 3D emitter, DLP®Link™
3D glasses , Lens cap
Accessory Part Numbers
Lamp: BL-FU240A Remote: BR-3067B
RF Emitter: BG-BC100B RF 3D Glasses: BG-ZF2100GLS
Power Cord (11M): BC-PUPIXY11 DLP®Link™ 3D Glasses: BG-ZD301
VGA to component adaptor: BC-VGCRXY00 Mount: BM-5001U
Lens cap: 75.8EG02G001
UPC: 796435 81 202 7
www.OptomaUSA.com
Copyright © 2013 Optoma Technology, Inc. DLP®and the DLP logo are registered trademarks
of Texas Instruments™. All other trademarks are the property of their respective owners.
All specications subject to change at any time.
