Optus ZTE MU5001 User manual

ZTE MU5001
5G Modem
Let’s go
Getting started
with your device

1 2
1. Prepare
• A valid nano-SIM card.
nano-SIMmicro-SIM(U)SIM
• Open the back cover and view the label in the battery
slot to get the default information. The following igure
is for reference only.
Model:MU5001
WiFi SSID1:
WiFi SSID2:
WiFi Key:
IMEI:
Made in China
Device Manager Website:
Password:
2. Instal the Battery
1. Open the back cover.

3 4
2. Insert the battery.
3. Put the cover back.
3. Insert the nano-SIM Card
1. Insert the tip of the tray eject tool into the hole.
2. Pull out the card tray and place the nano-SIM card on the
tray, as shown. Carefully slide the tray back into place.

5 6
5. Access the Internet
• WiFi: The default WiFi SSID and password can be found on
the device label. Connect to the WiFi network with your
mobile device and then access the Internet.
Model:MU5001
WiFi SSID1:
WiFi SSID2:
WiFi Key:
IMEI:
Made in China
Device Manager Website:
Password:
Wi-Fi
XXXXXXXX
NOTE:
You can touch the screen to view the default WiFi SSID
and password.
4. Start your Device
Press and hold the power button until the screen lights up and
then the device will connect to the Internet automatically.
NOTE:
If the battery is extremely low, you may be unable to power on
the device. Please charge your device irst.

7 8
6. Change Your Device Settings
You can change the device settings by logging into the 5G
Mobile Hotspot coniguration web page.
1. View the label on your device to get the default Device
Manager Website IP address and Password.
Model:MU5001
WiFi SSID1:
WiFi SSID2:
WiFi Key:
IMEI:
Made in China
Device Manager Website:
Password:
2. Launch your Internet browser. Enter the Device Manager
Website IP address in the address bar.
3. Input the Password and then click Login.
4. After the 5G Mobile Hotspot coniguration web page is
opened, you can change the default settings.
NOTE:
You can also change some settings by touching the screen.
• USB Type-C cable: Connect to your computer via USB port
and then access the Internet.

910
1. External antenna
connector
Connect the antenna if necessary
2. Power button Press and hold for about 2 seconds
to power on your device
3. nano-SIM card tray Insert your nano-SIM card
4. Touch screen icons
5. Charging/USB
Type-C jack
Charge the device or connect to the
USB port of a computer
Network signal
strength
5G/4G Network type
New SMS
Battery power level
Settings: Touch to
conigure the device
settings
WiFi: Touch to
conigure the WiFi
settings
1
Show the number of
connected users
Connected with
your computer via
a network cable
USB
Connected with your
computer via a USB
Type-C cable
Touch Screen Icons and Interfaces
12
3
4
5

11 12
Problem Recommended Action
The client connected
to the device but
cannot access the
Internet.
• Ensure that your nano-SIM card
is available.
• Change the location and ind
a place with a good signal.
• Check the settings of the WAN
connection mode.
• Contact Optus and conirm
your APN settings.
The 5G Mobile
Hotspot
coniguration page
cannot be visited.
• Enter the correct address.
Please view the label on your
device to get the default Device
Manager Website IP address.
• Use only one network adapter
in your PC.
• Do not use any proxy server.
Troubleshooting
Problem Recommended Action
The connection
between your device
and a PC through a
USB cable cannot
be established
automatically.
If the driver of your device is
abnormal, reinstall the software.
You need to uninstall the
software irst.
The connection
between your device
and a client through
WiFi cannot be
established.
• Ensure that the WiFi function
is enabled.
• Refresh the network list and
select the correct SSID.
• Check the IP address, and ensure
that your client can automatically
obtain an IP address.
• Enter the correct network key
(WiFi password) when you
connect the client to your device.

13 14
Legal Information
Copyright © 2021 Optus.
All rights reserved.
No part of this publication may be quoted, reproduced,
translated or used in any form or by any means, electronic
or mechanical, including photocopying and microilm,
without the prior written permission of Optus.
Notice
Optus reserves the right to make modiications on
print errors or update speciications in this guide without
prior notice.
Disclaimer
Images and screenshots used in this guide may differ from
the actual product. Content in this guide may differ from the
actual product or software.
Trade marks
Optus and the Optus logos are trade marks of Optus.
Other trade marks and trade names are those of their
respective owners.
Version No.: R1.0
Getting More Help
You can get help by:
• Phone 133 937
• Visit optus.com.au/contact

15 16
• Do not use the device in an enclosed environment or where
heat dissipation is poor. Prolonged work in such space may
cause excessive heat and raise ambient temperature, which
may lead to automatic shutdown of the device for your
safety. In the case of such an event, cool the device in a well
ventilated place before turning on for normal use.
• Keep the device out of the reach of small children. The device
may cause an injury if used as a toy.
• When the device is operating, do not touch the metallic
parts. Failing to do so may cause burns.
• Use original accessories or accessories that are authorised.
Using any unauthorised accessories may affect the
performance of the device and violate the related national
regulations about telecom terminals.
• Avoid using the device near or inside metallic constructions
or establishments that can emit electromagnetic waves,
because signal reception may be affected.
• The device is not waterproof. Keep the device dry and store
it in a shady and cool place.
• Do not use the device immediately after a sudden
temperature change, because dew may be generated inside
and outside the device. Do not use it until it becomes dry.
• Handle the device carefully. Do not drop, bend or strike it.
Otherwise the device may be damaged.
Warning and Notice
To the User
• If inadequately shielded, some electronic devices, for
example, the electronic system of vehicles, may be affected
by the electromagnetic interference caused by the device.
Consult the manufacturers of such devices before using the
device if necessary.
• Operating the device may interfere with medical
instruments such as hearing aids and pacemakers. Always
keep the device more than 20 centimetres away from
such medical instruments when your device is powered on.
Power off the device if necessary. Consult a physician or
the manufacturers of medical instruments before using the
device if necessary.
• Be aware of the usage limitation when using the device
at places such as oil warehouses or chemical factories,
where there are explosive gases or explosive products being
processed. Power off the device if necessary.
• Do not use electronic transmission devices in aircraft, at
petrol stations or in hospitals. Observe and obey all warning
signs, and power off the device in these conditions.
• Do not touch the inner antenna area unless necessary.
Otherwise the performance of the device may be affected.

17 18
• Please disconnect the charger when the battery is fully
charged. Overcharging may shorten the battery life.
• Do not short-circuit the battery, as this can cause excessive
heat and ire.
• Do not throw the battery into a ire to avoid explosion.
• Do not disassemble, squeeze or puncture the battery, as this
can cause explosion or ire.
• When not using the battery for a long period, please charge
the battery about half then remove the battery from your
device and store it in a cool dry place.
• If the battery damages or shows signs of swelling or
leakage, please stop use immediately and contact Optus or
Optus authorised service provider for replacement.
• Return the worn-out battery to the provider or put it in the
designated recycle place. Do not put it in household waste.
• There is a risk of explosion if the wrong battery model is
replaced.
WARNING!
If the battery is broken, you should avoid contact with the contents
inside. If they contaminate the skin, immediately rinse with plenty
of water and seek medical help when necessary.
• Only qualiied personnel can dismantle and repair the device.
• A humidity between 5% and 95% is recommended.
• Do not connect the charger while using the device for a long
period. Failing to do so will trigger the protection mechanism
of the battery, and the battery will not be charged. If you
want to charge the battery, please reconnect the charger.
• Do not connect the charger while using the device for a
long period or use the device and battery in non-operating
temperature. Failing to do so will shorten battery life or
cause battery swelling or leakage. If the battery shows signs
of swelling or leakage, please stop use immediately.
Battery Safety
• Using Optus-unapproved or incompatible battery, charger or
power adapter may damage your device, shorten its lifespan
or cause a ire, explosion or other hazards.
• The recommended operating temperatures are 0°C to 35°C
and the storage temperatures are -20°C to +45°C. Extreme
temperatures can damage the device and reduce the charging
capacity and lifespan of your device and battery.
• Do not place the device or the battery in or near heating
equipment, such as microwave ovens, stoves or radiators.
Keep the device and the battery away from excessive heat
and direct sunlight. If not, the device or the battery may
overheat and cause explosion or ire.

YESCOR5183 1428782 (10/21)
