Orbita P8010 User manual

Lock body
Rear panel
Battery and battery cover
Indoor
Door
Outside the house
Front panel
Strike plate&box
a
b
b
a
a
a
a
a
a
a
aKA4*20 10PCS
bPM5*60 2PCS
Installation screws
Installation exploded view
P8010

9.Install strike plate&box
5.Install cable
ANNOTATION
ŸSmart locks must retain mechanical keys for emergency use.
ŸAfter the fingerprint lock is installed, the fingerprint, password and other
information should be set at the first time. The management password and
password should be set separately. The management password should not be the
same as the unlocking password
ŸIt is recommended to set up fingerprints for children to open the door and not tell
the password, to avoid disclosing password. Once the password is revealed, please
delete the original password in time and change to a new one.
ŸPlease keep the instructions and packing boxes . If you need services, can contact
factory or local office.
ŸWish you a happy life.
connection
4.Mounting spindle & handle spring
(spring head
close to spindle)
3.Install front panel fix with screw
1.Install lock body
outside the
house
indoor
2.Remove the battery cover
battery cover
6.Fix screws and install rear panel 7.Install battery
battery
8.Install battery cover
Square hole up
battery cover
INSTALLATION STEPS
