Oreck AirInstinct AIR75B User manual

AirInstinct
Air Purier
Important!
Read this manual
carefully, and
keep for future
reference.
User’s
Guide
Model:
AIR75B
TM

2
Other Oreck accessories available at:
Other Oreck accessories available at:
Congratulations on your purchase of the Oreck AirI nstinctTM
Air Purier. Use this manual to learn the features, operation
and maintenance of the Oreck Air Purier.
Welcome to our Call. Click. customer service program. To
speak with an Oreck representative call:
Enjoy
Click
Call
USA: 1•800•989•3535
Canada: 1•888•676•7325
On the web, point and click at: www.oreck.com
and click locate a store on the top right.

3
Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
General Warnings . . . . . . . . . . . . . . . . . . . . . . . 4
Placement Warnings . . . . . . . . . . . . . . . . . . . . . . 5
Features ................................6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Maintenance .............................9
Cleaning and Filter Replacement Intervals . . . 10
Replacing the lters .......................11
Filter Reset Mode........................ 12
Forced Reset Mode . . . . . . . . . . . . . . . . . . . . . . 12
Cleaning the Air Sensor . . . . . . . . . . . . . . . . . . 13
Adjusting the Air Sensor .................. 14
Troubleshooting15
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

4
Safety
General Warnings
• Do not operate unit if cord or plug is damaged. Doing so can
result in electric shock. Discard the damaged unit or take
it to an authorized service facility for examination and/or
repair. USA: 1•800•989•3535 Canada: 1•888•676•7325
• Do not run cord under carpeting. Do not cover cord with
throw rugs, runners, or similar coverings. Do not route
cord under furniture or appliances. Arrange cord away
from traffic area and where it will not be tripped over.
• Only use the air purifier as described in this manual.
• Do not handle the unit with wet hands. Thoroughly dry
your hands before handling any part of the air purifier.
• Hair, loose clothing and body parts can get caught in the
machine resulting in injury. Keep hair, loose clothing and
body parts away from openings and moving parts.
• Do not unplug by pulling on the cord. Doing so may result
in electrical spark or fire. Unplug the unit by grasping, and
pulling the plug.
• Do not use an extension cord.
• Do not place the air purier near sources of heat, such as:
stove tops, ovens, radiators or computers.
• Unplug the appliance from the power supply before
servicing.
• This equipment should be inspected frequently and the dirt
that has collected should be removed regularly to prevent
excessive accumulation that may result in flashover or fire.
• Do not use the air purier outdoors or on wet surfaces.
• Do not use the air purier in an enclosed space where
flammable, combustible or explosive gases are present.
!
WARNING: To reduce the risk of re, electric shock or
injury, read and understand this user guide before operating
this appliance.
Cleaning the unit while it is plugged in may
result in electric shock, electric spark and
serious injury. Unplug the unit before cleaning
or maintenance
IMPORTANT SAFETY
INSTRUCTIONS

5
• Do not use in an area where toxic vapors, ammable dust
or oxygen tanks are present. Check the location and make
sure these elements are not present.
• Warning: Product contains chemicals known to the State
of California to cause cancer, birth defects, or other
reproductive harm.
• Do not place open flames, including candles, directly in
front of the air purifier.
• It is important to keep all objects away from the air intake
grille.
• Place the air purier on a at, solid, stable surface. Never
place the unit on soft surfaces such as a bed or sofa.
• Position the air purier so that the dirty air is not drawn
across your head or body while sitting or sleeping.
• Place the air purier so the plug on the power cord easily
reaches a standard electrical outlet for a polarized plug.
• Children should be supervised when product is in use. Do
not allow children to play on or near the air purifier. Keep
children’s hair, loose clothing, and body parts away from/
out of the intake grille, vents, holes, or openings.
• This product is suitable for use with solid-state speed
controls.
READ AND SAVE THESE
INSTRUCTIONS
Note: To reduce the risk of electric shock this product has a
polarized plug (one blade wider than the other). The plug will
only fit in a polarized outlet only one way. If the plug does
not fit properly, reverse the plug. If it still does not fit, contact
qualied personnel to install the proper outlet. Do not alter
the plug in any way.

6
Features
1 Display Panel: Air purier controls and indicator lights.
2 Power Button: Turns the purier On and Off.
3 AU TO M od e and Sp e ed B u t t o n: Auto Mode automatically
adjusts the fan speed. Speed button manually sets the
fan speed to low, medium or high.
4 Check Filter Light: Indicates the lters may need to be
replaced.
5 Air Indicator: Visually displays either a blue, purple, or
red light based on the level of particles detected by the
Air Sensor.
6 Timer Button: Turns unit off after a predetermined
period of time. Time settings are 1, 4 and 8 hours.
7 Air Sensor: Measures the level of particles passing
through the sensor.
8 Front Grille: Air enters here for the rst stage of cleaning.
9 Handle: Use handle to move the purier.
2
3
4
5
6
7
8
1

7
10 Exhaust Grille: Directs the ow of air as it exits the unit.
11 Power Cord: Plug into the outlet to begin use.
12 Pre-lter: Filters large particles such as dust, hair and
lint that pass through the lter.
13 Odor Filter: Reduces odors and VOC’s from the air that
passes through the lter.
14 HEPA Filter: Captures dust, allergens, pet dander, mold
and smoke from the air that passes through the lter.
9
11
12
13
14
10

8
Operation
1 Place Place the air purier on a solid surface. Do not
block the grille with objects and remove candles or
ames near the unit.
2 Plug In Plug into the nearest standard electrical outlet
that accepts a polarized plug.
3 Press The power button turns the purier On. Press and
hold the POWER button approximately two seconds to
turn the purier OFF.
4 Select Choose the desired air cleaning mode (manual or
automatic) and the fan speed. The fan speed is controlled
manually in manual mode or by the Air Sensor in the
automatic mode.
Note: Make sure to open cover and remove each lter’s
plastic packaging before turning unit on. Order of
lters: pre-lter, odor lter, Hepa lter
2
3
4

9
Automatic (AUTO) Mode
Important: The Air Sensor is set to standard sensitivity
when shipped from the factory. If you prefer the air purier
to adjust its speed more or less frequently, you can set the
sensitivity of the Air Sensor (see page 14).
A Press the button to set the purifier in automatic
mode. In automatic mode the air purier will self-adjust
the fan speed. The Auto mode indicator light will illuminate
after the highest speed setting is pushed.
B The indicator light will show when unit has reached
auto mode.
Press the button to set the purier in automatic mode.
In automatic mode the air purier will self-adjust the fan
speed. The auto mode indicator light will illuminate after
the highest speed setting is pushed.
Manual Mode
A Press and release the button for the desired fan
speed: Lowee , Medium , High .
B The indicator lights will display the speed.
Maintenance
B
A
B
A

10
WARNING !
!
Cleaning the unit while it is plugged in may
result in electric shock, electric spark and
serious injury. Unplug the unit before cleaning
or maintenance
Cleaning and Filter Replacement Intervals
Proper care and cleaning of the air purier is critical to
performance. The following chart shows the recommended
cleaning intervals and method.
Part Time Method
Cabinet As needed Wipe with damp cloth rst.
If required, follow with mild,
non-abrasive cleaner.
Air Inlet
and Outlet
Every two
months
Brush with soft brush. Do not
allow dust to fall inside the
purier.
Air Sensor Every two
months
See page 13 for instructions.
Pre-Filter Two to four
weeks
Rinse thoroughly in warm
water as needed. Let dry
before reinstalling.
Odor Filter 1 year * Replace
HEPA Filter 2 years * Replace
*
Filter life will vary by usage and environment.
