Oricom AD50 User manual

Oricom AD50 Aroma Diffuser Night Light
Oricom AD50 Aroma Diffuser Night Light
User Guide
User Guide
Oricom AD50 Aroma Diffuser Night Light
User Guide
This Aroma Diffuser uses Ultrasonic waves to continually vaporize water and
essential oil in the water tank, to produce a cool, fragrant mist.
Specications
Size 120mm (dia)*160mm (height)
Weight 400g
Power adaptor AC100-240V 50/60Hz 24V
Length of cord About 1.5m
Power consumption 7~14W
Interval time Spray for 10s / pause for 10s
Water capacity 160ml
LED light 4PCS RGB LED
Original material ABS+PP
Ultrasonic frequency 2.4MHZ
Operation
1. Connect the AC adaptor to the DC jack at the
base of the main body via cable guide.
2. Remove upper cover. (Fig 2)
3. Add water into the water tank; do not exceed
the max line on the water tank.
(Fig 3)
4. Drop essential oil into the water tank vertically,
the dosage is about 2-3 drops (about 0.1-
0.15ML) per 100ML water.
(Fig 3)
5. Install the cover of the main body and twist
into position. (Fig 4)
IMPORTANT: The upper cover must be in
position before using the product.
6. Connect power adaptor to a wall plug.
Step One
Step Two
FIG 1
FIG 2
FIG 3 FIG 4

Oricom AD50 Aroma Diffuser Night Light
Oricom AD50 Aroma Diffuser Night Light
User Guide
User Guide
7. Press the "MIST" button:
1st press: 1 short click to activate the diffuser for spraying. The unit will
automatically shut off when it detects a low water level in the reservoir.
2nd press: "2 clicks" to enter the interval mode for cycling through spray for 10s,
pause for 10s.
3rd press: the diffuser will shut off.
8. Press the "LIGHT" button to cycle through the different colour selections. Hold the
"LIGHT" button for two seconds to turn the light off.
9. The diffuser will automatically shut off when it detects a low water level in the
reservoir. The diffuser can also be manually shut off by holding the "MIST" button
for two seconds.
Attention
•The amount and intensity of mist produced will vary, but this is not unusual and
should not be considered a fault. Factors that affect this include water level in the
water tank, water type, humidity, temperature, air currents and so on.
•The unit will not work without water.
•Use 2-3 drops essential oil per 100ML water only. Too much oil will clog the system
and cause malfunction. Please clean the unit as per the maintenance instructions,
before changing to a new type of essential oil.
•Add water rst, followed by the essential oil, as the essential oil may block the
Ultrasonic vibration plate and cause malfunction.
Accidental leakage
In the event the unit is knocked over or spillage occurs during use, please follow the
steps below to avoid malfunction.
•Unplug the unit and remove cover.
•Empty water tank.
•Shake the unit gently to drain any water inside the mechanism, and then allow to dry
for at least 24 hours.
Maintenance
After 5-6 uses or 3-5 days of operation, please clean the product as follows:
•Unplug the unit from mains supply and remove cover.
•Unplug power cord from base of unit.
•Add 1 tablespoon of citric acid in the water tank, add just under 100ml of warm water
(up to 70°C).
•Wipe with a soft cloth. Avoid Ultrasonic Vibration plate area, which can be gently
cleaned with a cotton bud.
Precautions
•Add water into the water tank rst, then drop essential oil into water tank.
•Do not ll over 160ML “MAX” at any time.
•Do not switch on power when the tank is empty.
•Do not touch the Ultrasonic vibration plate.
•Clean regularly as per maintenance instructions to avoid malfunction.
•Always unplug from power supply before maintenance.
•After use, empty remaining water and wipe with a clean dry cloth.
•Essential oil can stain the Ultrasonic vibration plate, please wipe away with a soft cloth
and clean water.
•Do not let mist blow directly onto furniture, clothing, walls etc.
•Keep away from electronic equipment, such as TV and Audio equipment.
•Do not tip the product. This may cause water to enter the mechanism and cause
malfunction.
•Do not use for more than 10 hours continuously.
Wait 60 minutes before restart to avoid damage to Ultrasonic vibration plate.
•Use tap water only. Do not use mineral water, sparkling water etc.
•Do not move product while in use.
•Do not touch any part of the product with wet hands.
•Keep out of reach of children and pets. Also, this appliance is not to be used by
children or persons with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction.
•Keep cord clear of pathways, and do not pull forcefully at any point.
•If smoke or burning smell is detected, unplug immediately.
