Oricom TP6 User manual

Designer phone TP6
User Guide
Keep for future reference

1
Warnings
Do not use your telephone during an electrical storm
thunderstormasitis possibletoget anelectricshock. Refer
to information contained in Telstra White pages directory.
Theearpiece ofthehandset mayattractsmallmetalobjects
such as staples and pins. Care should be taken when
placing the handset near these items.
Temperature and ambient conditions
The telephone is designed for indoor use (temperature
range of -10 °C to 50 °C). Do not install the telephone in
areas where there is the risk of an explosion, excessive
exposure to smoke, dust, vibrations, chemicals, moisture,
and heat.The unit must not be installed in damp locations
such as a bathroom or laundry, do not expose the unit to
direct sunlight.
Cleaning and care
The surface of the case can be cleaned with a dry, soft,
lint-free cloth. Never use cleaning agents, particularly
aggressive solvents. Apart from occasional cleaning of the
case, no other care is necessary. The rubber feet of the
base station are not resistant to all cleaning agents. The
telephone feet do not normally leave any marks on the
surface.However, on account of the multitude of varnishes
and surface finishes used, surface marks caused by the
feet of the unit cannot be ruled out.

2
Location of controls
1 Mute button
2 Recall button
3 Memory button
4 Redial button
5 Store button
6 Recall setting switch
7 Ringer Hi/Lo/Off switch
N13134
TheA-Ticksymbolindicatesthat thisproductcomplieswithall currentAustralian
ACA standards.
1
23
4
5
6
7

3
1.1 Notes for operation in New Zealand
ThegrantofaTelepermitforany itemofterminalequipment
indicates only that Telecom has accepted that the item
complies with the minimum conditions for connection to its
network. It indicates no endorsement of the product by
Telecom, nor does it provide any sort of warranty. Above
all,it provides noassurancethatanyitem willworkcorrectly
inall respectswithanother itemofTelepermittedequipment
of a different make or model, nor does it imply that any
productiscompatiblewithallofTelecom’snetworkservices.
This equipment shall not be set to make automatic calls to
theTelecom“111”EmergencyService.Thisequipment may
not provide for the effective hand-over of a call to another
device connected to the same line.
This device may be subject to ringing or bell tinkle when
certain other devices are connected to the same line. If
this occurs, the problem should not be referred to the
Telecom Faults Service.
REN (RN for New Zealand)
The REN (Ringer Equivalence Number) or (RN) is of
significance only if you wish to connect more than 1
telephone to your telephone line.A standard telephone line
has a maximum REN capacity of 3 (RN of 5).It is possible
to connect 3(5) devices with a REN of 1 (RN of 1) with no
degradation to the product’s performance. Exceeding this
limit may cause the volume of the ringer in any phone to
decrease or not ring at all.

1.2 Quick Setup
The Oricom TP6 telephone is used like any conventional
telephoneand workswith allmodern telephoneexchanges
using the tone dialling system. Plug one end of the line
cord into the bottom of the phone and the other into the
wall socket using the plug supplied.
1.3 Check contents of pack
The following items are supplied in this pack:
one telephone base one telephone handset
one short telephone cable one long telephone cable
one warranty card one operating Manual
1.4 Connect the line cord
Plug one end of the telephone cable (long for desk
installation) into the wall socket.Plug the other end into the
socket located in the indentation on the base of the
telephone.Then feed the cable through the cable guide.
1.5Wall mounting
Method A. Atthedesired locationdrilltwoholes oneabove
the other, 83mm apart, use two screws (not supplied) for
fixing and leave them protruding 5mm from the wall. Now
place the telephone base over the screws and gently push
forwards and then downwards.
Method B If you wish to fit to an existing telephone wall
plate with modular connector simply plug in the short
telephone line cord into the base of the phone and plug the
other end into the telephone wall plate socket.Position the
mounting holes on the base of the phone over the two
protruding screws on the wall plate.Gently push the phone
flushagainst thewallplatethen slidethe phonedownwards
locking it into place.
4

1.6 Adjustable ringer volume
You can use the RINGER HI/LO/OFF slide switch located
on the side of the telephone to select the incoming ring
volume. Should you not want to be disturbed, use select
OFF position.
1.7 Last number redial
If the number you have dialled is engaged or you were
unable to get through to anybody, simply replace the
handset. The last number dialled will be saved in the
telephone memory. To use the redial facility, proceed as
follows:
1. Lift the handset.
2. Press the REDIAL button the last saved redial number
will now be dialled.
1.8 Recall button
You will use the RECALL button when using your network
operator’s services such as call waiting etc. If this feature
is not working check the position of the Recall switch on
the side of the phone.In Australia it should be set at 100ms
and in New Zealand 600ms.
1.9 Storing and dialling numbers from
memory
You can store up to 10 numbers in memory and dial those
numbers quickly.
Storing a number in memory:
1. Pick up the handset.
2. Press STORE button.
3. Dial the number (up to 16 digits) you wish to store.
4. PressSTOREbuttonandthenenterthedesiredmemory
location (0,1 ...9)
5. Replace handset. 5

Dialling a Stored Number:
PickupthehandsetandpressMEMORYbutton.Thenpress
the memory location number (0, 1 ...9).The telephone then
automatically dials the number stored in that location.
1.10 Muting the microphone
You can switch off the microphone during a call using the
MUTE button.It is then possible to speak without the other
party hearing you.You can still hear the other party.
To mute the microphone, press and hold the MUTE button
during a call. Release the MUTE button and you can
continue the call as normal.
1.11 Important information
Troubleshooting
Ifyoufeelthisproductisnotworking correctlypleaseconsult
the user guide and ensure that you are using the product
in accordance with the instructions.
Remove all extra telephone equipment and connect only
this telephone directly to the telephone socket.
If the fault is still present, connect another telephone (if
available) to the telephone socket. The results will show
you whether the fault lies with this product or with the
telephone line. If this product is working correctly the fault
is on the telephone line. Please contact your network
operator for assistance
In the case of technical problems with this product please
consult our website for further information or send us an
email for a prompt response to your enquiry.
6

Warranty Information
This product is covered by a 12 month warranty against
defective workmanship or parts, effective from the date of
purchase.
Thewarrantydoesnotextendtodamagecausedbymisuse,
negligence, excessive voltage, faults on the telephone line
or lightning.This warranty in no way affects your statutory
rights. Full details of the warranty are contained in the
enclosed warranty card.
Technical support
In the unlikely event of a fault during this period, please
consult our website for assistance or send us an email for
a prompt response to your enquiry. If the product is then
found to be faulty you will be asked to return it directly to us
with a copy of the purchase receipt.
For further information about the Oricom range of products
please visit our website.
7
Australia
Oricom International Pty Ltd
ABN 46 086 116 369
PO Box 5681
South Windsor, NSW 2756
Customer support
Email:
[email protected]
Web: www.oricom.com.au
Fax: [phone]
Ph: 1300 889 785
New Zealand
Atlas Gentech (NZ) Ltd,
Private Bag 14927,
Panmure,
Auckland
Customer Support
Email:
[email protected]
Fax [phone]
Ph: 0900 50025 (Toll Call)
NLM113Y1
