ORIGO FH9801G User manual

使用說明書
Instruction Manual
FH9801G
使用暖風機前，請先細閱使用說明，並請妥善保存以便將來翻閱。
本說明書可於本公司網站下載www.origo.hk。
Read all instructions carefully before using the FAN HEATER, and keep this
instruction for furture reference when necessary.
This instruction manual can be acquired at www.origo.hk.
*
**
*
**
陶瓷暖風機
Ceramic Heater

Important Safety Information
重要安全提示
Ceramic Heater
陶瓷暖風機
1
警告：除非提供持續監督，否則當無法
自行離開房間的人佔用時，請勿在細小
房間內使用此暖風機。
WARNING: Do not use this Heater in small rooms
when they are occupied by persons not capable of
leaving the room on their own, unless constant
supervision is provided.
請不要使用曾經掉落的暖風機。
Do not use this Heater if it has been dropped.
切勿把暖風機擺放於電源插座之下。
The Heater must not be located immediately below a
socket outlet.
切勿使用可使暖風機自動開機的外加管
理程式、時間制、遙控系統或任何其他裝
置，以免因暖風機被覆蓋或擺放位置不當
而發生火警。
The Heater is not intended to be operated by means
of an external programmer, timer,seperate remote-
control system or any other device that switches the
Heater on automatically, since a fire risk exists if
Heater is covered or positioned incorrectly.
警告：為防暖風機過熱，切勿覆蓋
暖風機的出、入風口。使用中的暖
風機出口會發出高熱，切勿觸碰。
WARNING: In order to avoid over heating, do
not cover the Heater. The Heater is hot when
in use. To avoid burns, do not let bare skin
touch hot surface.
警告：暖風機的出、入風口應與易燃物品
(如傢俱、枕頭、床舖、毛巾或窗簾等)保
持安全距離不少於1米。
WARNING: To reduce the risk of fire, keep textiles,
curtains, or any other flammable material a
minimum distance of 1m from the air outlet and
inlet of the Heater.
暖風機不可擺放於有潛在危險的地方使
用(例如：非常潮濕環境、易燃物品或化
學品倉庫)。
The Heater must NOT be used in potentially
dangerous location such as flammable explosive,
chemicalladen or wet atmospheres.
暖風機不適用於室外及作工業用途。
Heater is intended for household use ONLY, not
for industrial or outdoor use.
使用暖風機前，請先細閱使用說明。
Read all instructions carefully before using the Heater.
本機不是為8歲以下小孩，體質、感覺或
智力有障礙人士或缺乏經驗及知識者使
用，除非他們曾經接受負責安全人士的監
督或指示。大人應指導小孩不可把玩電器。
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
未滿3歲的小孩除非受到持續監護，否則應
該遠離本產品。
Children of less than 3 years should be kept away unless
continuously supervised.
年齡在3至8歲的小孩只有在設備已經被放
置或安裝在其預期的正常操作位置，並已
經接受了使用本設備的安全指導或監督並
理解可能存在的危險時，才能開關設備。
其不得插拔電源、調節和清潔設備，也不
得進行用戶維護。
Children aged from 3 years and less than 8 years shall
only switch on/off the appliance provided that it has
been placed or installed in its intended normal operating
position and they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children aged from
3 years and less than 8 years shall not plug in, regulate
and clean the appliance or perform user maintenance.
使用時確保暖風機放置於安全、平穩的表
面上。
Use this Heater on a horizontal and stable surface.
如本產品的電源線有損壞痕跡，為保障安
全，請立即停止使用並聯絡供應商更換。
If the supply cord is damaged, it must be replaced by
manufacturer, its service agent or similary qualified
persons in order to avoid a hazard.
如暖風機有明顯的損壞跡象，請勿使用。
Do not use if there are visible signs of damage to the
Heater.

Important Safety Information
重要安全提示
Ceramic Heater
陶瓷暖風機
2
警告；清理前必須先拔除電源插頭。
WARNING: To avoid danger of electric
shock, unplug from outlet when not in
use and before cleaning.
暖風機設有發聲警報裝置，當機身溫
度過熱，警報器自動發聲提示，應立
即關機檢查並立即停止使用此機。
The Heater includes an audible alarm to
warn when the Heater are overheat. If
the alarm sounds, immediately turn the
Heater off and inspect the Heater. DO
NOT OPERATE THE HEATER WITH THE
ALARM SOUNDING!
暖風機不可擺近水盆、浴缸、花灑、
泳池、潮濕或有積水的周邊環境使用。
The Heater is not intended for use in
the immediate surroundings of a basin,
a bath, a shower, a swimming pool, a
wet or damp locations.
切勿將任何異物放入機內；或阻擋機
身出風口及入風口；或將暖風機放置
在柔軟或不穩固的表面上(例如床舖)，
皆因以上一切行為均會導致機身過熱
，引發短路或火警。
本產品含有可回收材料，不可把
本產品作為未分類廢物。請聯繫
當地就近指定回收點。
This product contains recyclable
materials. Do not dispose this
product as unsorted municipal
waste. Please contact your local
municipality for the nearest
collection point.
使用暖風機前，請確定規格標貼上所
示的額定電壓與當地供電電壓相同。
如有疑問可向供應商查詢。
Before using the Heater, check if the
voltage marked on the rating label
corresponds to the mains in your home.
打開包裝，檢查產品。如發現產品有
損壞，請勿使用及即時聯絡供應商。
Remove the package and ensure that the
Heater is undamaged. In case of doubt
do not use the Heater and contact your
supplier.
拔除插頭時不可拉扯電源線，必須緊
握插頭，把插頭拔出。
Do not pull the power cord to disconnect
with power source. Always grasp the plug
to pull out.
請使用獨立插座。使用萬能插頭或拖
板，容易發生危險。
Avoid using extension cord as the
extension cord may overheat and casue fire.
Do not insert any objects into the Heater
as it may cause an electric shock or fire
or damage to the Heater. Do not block
or tamper with the Heater in any manner
while it is in operation. To prevent
a possible fire, do not block air inlet
or oultet in any manner. Do not place on
soft surfaces, like a bed, where opening
may become blocked.
警告：總電源開關鍵不應作為切斷電
源用途。
WARNING: The Main Power Switch and the
On/Off switch should not be used as the
sole means of disconnecting power.
包裝物料並非玩具，不可讓小孩玩耍。
Do not let children play parts of package.
220-240V~ 50-60Hz

Main Parts
各部名稱
Ceramic Heater
陶瓷暖風機
3
Function Setting
功能設定
注意：第一次使用暖風機，可能會出現少量氣味約數分鐘，因本產品在生產時發熱
元件帶有一層保護油，此乃正常現象。
NOTE: For first time operation, there will have some smell for about few
minutes. Because this Heater have some protective oil on the surface
of the heating element.
正面
FRONT
圖片只供參考 ，
一切以實物為準
The picture is for
reference only,
everything in kind
shall prevail.
出風口
Air Outlet
Base
底座
電源線
Power Cord
插頭
Plug
Air Inlet
入風口
Handle
把手
開關功率鍵
On/Off &
Power Switch
溫控旋鈕
Thermostat
Knob
背面
BACK

Function Setting
功能設定
Ceramic Heater
陶瓷暖風機
4
暖風機可使用機背開關功率鍵及溫控旋鈕操控。
1. 將暖風機擺放於穩固的平面上。
2. 按開關功率鍵至關機狀態 ，將插頭插入電壓220-240V的獨立插座。
按開關功率鍵至低熱 (1100瓦)或高熱 (2000瓦)，暖風機開始工作。
The Heater may be operated by the on/off & power switch and thermostat
knob located on the back of the Heater.
1. Place the Heater on a stable flat surface.
2. Set the on/off & power switch to position. Plug the Power Cord into a
a.c. 220-240V electrical outlet. Press the on/off & power switch to
Low Heat (1100W) or High Heat (2000W), the Heater is starts
operating.
3. 溫控操作: - 溫控器可自動控制暖風機開啟或暫停，達到維持於某一溫度的效果。
- 溫控旋鈕調整至最大位置;
- 當室溫達至理想溫度，將溫控旋鈕逆時針方向旋轉，直至電源顯示燈熄滅
(暖風機暫停加熱);
- 待室內溫度降低後，暖風機自動重新開啟直至達到設定溫度，暖風機再次暫停
加熱;
- 暖風機將不斷循環開啟暫停工作。
3. Thermostat control: - The thermostat can control on and off of the
Heater to keep the room temperature at a desired level.
- Turn the Thermostat knob to the maiximun position.
- Once the desired room temperature has reached, turn the knob
anti-clockwise unit the power indicator turn off (the Heater is
temporary cut off).
- When the room temperature has decreased, the Heater will turn on
automatically, and will turn off again when the desired temperature
has reached.
- It is normal for the Heater to cycle ON and OFF as it maintains the SET
TEMP.
4. 關機: 如需關掉暖風機，按開關功率鍵至關機狀態 。
4. OFF: Press the on/off & power switch to position to shut down the
Heater.

 



 

Safety Features
特殊安全裝置
Maintenance
清理及維護
Ceramic Heater
陶瓷暖風機
1. 暖風機內置恆溫保護裝置，防止機身過熱。
2. 當機內溫度超出限定溫度，暖風機將自動停止操作。需要重新設置才
可恢復正常。
1. A thermal overload protector is built-in to prevent overheating.
2. When the Heater is overheat, it will be shut off automatically. To RESET
the Heater:
2.1. Unplug the Heater and wait for 30 minutes to cool down.
2.2. Turn ON the Heater again to resume operation.
警告：不使用本機時，經常保持拔除電源，及切勿將此機浸於水或其他液體中。
清理時切勿將此機浸於水或其他液體中。清潔前應確保暖風機處於冷卻狀態。
清理：使用吸塵機毛刷將入風口的塵埃及雜物吸走。機身使用濕潤軟布抹擦清潔。
注意：切勿使用含有腐蝕性的清潔劑或溶液清理此機。
儲存：連同使用說明，把暖風機存放於清涼及乾爽的地方。
WARNING: ALWAYS UNPLUG THE POWER CORD BEFORE MOVING OR
SERVICING. DO NOT IMMERSE THE HEATER IN WATER! MAKE
SURE THE HEATER IS COMPLETELY COOL DOWN BEFORE CLEANING
CLEANING: Clean the Air Inlet with the vacuum brush attachment on your
vacuum cleaner. Clean the body of the Heater with a soft cloth.
CAUTION: Do NOT use gasoline, benzene, thinner, harsh cleaners, etc., as
STORAGE: Store the Heater with these instructions in the original box in a
they will damage the Heater. NEVER use ALCOHOL or any other
SOLVENTS.
cool and dry place.
2.1. 拔除插頭，等待30分鐘，讓機內溫度降低。
2.2. 重新插上插頭，讓暖風機正常繼續操作。
5

Specifcation
技術規格
Origin Map
源澤地圖
Ceramic Heater
陶瓷暖風機
6
型號 Model Number
電源 Power Supply
額定功率 Rated Power
產品尺寸 Product Dimension
FH9801G
220-240V~ 50-60Hz
2000W
143 x 149 x 179 mm (約/Approx.)
