ORION TELESCOPES & BINOCULARS Dynamo Mini User manual

Orion®Dynamo™Mini 74.88Wh AC/
USB Lithium PowerBank
#2306
INSTRUCTION MANUAL
Congratulations on your purchase of an Orion Dynamo™ Mini Lithium PowerBank.The
generous 74.88 Watt-hour battery capacity provides power for any AC powered device,
as well as USB charging power for USB accessories as well as phones and tablets. It
includes two USB outputs (2.4A Max), and an 85 watt (100w max) AC output. All of this
in a battery that weighs only 1.6 lbs, which makes it ideal for campers, hikers, and any-
one looking for an extremely portable power supply! Peel back the two rubber covers
over the top edge and side wall to expose the ports and power button.
1. Operation
Powering USB devices
The Dynamo Mini has two USB ports (gure 1) that can be used to power or charge
USB devices such as smartphones and tablets, with a max output of 2.4A each. To
use, simply plug the USB device into one of the two USB ports, and the Dynamo will
automatically begin to charge the device (it is not necessary to press the power button
to activate USB charging). Both USB ports can be used simultaneously to charge two
devices.
Powering 110v AC devices
The Dynamo Mini also has a single 85w continuous/100w max 3-prong 110v AC out-
put port (gure 1) for powering small electronic devices such as telescopes equipped
with an AC adapter, lamps, televisions and laptop computers. Please note laptops can
draw 65w (or more), so keep in mind that a computer can quickly deplete the 74.88Wh
capacity of the Dynamo Mini. To use, plug in your 110v device to the AC port, then press
and hold the power button (gure 1) for approximately 3 seconds until the green AC
power indicator (gure 1) light turns on. If no device is detected on the AC output, the
AC port will power down soon after in order to conserve power.
IN 612 01/18
Corporate Offices: 89 Hangar Way, Watsonville CA 95076 - USA
Toll Free USA & Canada: [phone]
International: [phone]
Customer Support: [email protected]
Copyright © 2019 Orion Telescopes & Binoculars.All Rights Reserved. No part of this product instruction
or any of its contents may be reproduced, copied, modied or adapted, without the prior written consent
of Orion Telescopes & Binoculars.
AN EMPLOYEE-OWNED COMPANY

2
Also note that the AC output waveform is a modied sine wave, not a pure sine wave.
If you are plugging in an AC device with a direct AC motor (such as a fan, laser printer,
or output voltage control device such as a dimmer, they may not work properly. Please
check with the manufacturer for your AC device if it will work with modied sine wave AC.
2. Recharging the Dynamo Mini
The battery charge percentage is displayed as a series of LED lights on the side of the
battery (gure 1). As the battery capacity is depleted, fewer of the lights will be lit. The
battery can be recharged from an AC outlet using the included power adapter. Simply
plug the included AC adapter into a wall outlet, and then plug other end of the AC adapt-
er cable into the Micro USB charging input port on the Dynamo Mini (gure 1). As the
Dynamo Mini charges, the status indicator lights will ash in succession, showing the
charge level. When all four lights are solid, the unit is fully charged.
The Micro USB port is the only power charging input on the Dynamo Mini. DO NOT try
to charge the device by connecting a wall outlet to the other two larger USB ports – they
are for output only. Charge time with the included AC adapter is ~6 hours, but if a lower
capacity 2A AC adapter is used, it can be up to 12 hours. It is recommended to only use
the included AC charger. Do not leave the battery charging when in storage—charge
until full and then unplug the AC charger.
3. Protection Mode
The Dynamo Mini will go into protection mode if it senses too much power being drawn
through the outputs. If more than 100W is pulled through the AC output, protection
mode will activate, shutting the unit down. Remove the device and either press the
power button or recharge the Dynamo to reset the unit. Please do not overload the
Dynamo Mini with devices that pull more power than the unit is capable of handling.
Short circuits or overheating will also activate protection mode.
4. Storage and Maintenance
To optimize the life of the Dynamo Mini, several steps should be taken for proper stor-
age and maintenance. Keep the unit stored a dry, cool area when not in use. Fully
charge the Dynamo Mini before putting it into storage. If you are going to store the
Dynamo Mini for long periods of time, you should occasionally recharge it – once every
three months for optimal storage and lifespan, and at LEAST once every 6 months.
Figure 1.
Micro USB
charging input USB outputs Power button
AC output
AC Power
indicator
Battery status
indicator lights

3
Figure 1.
The Dynamo Mini has a useful lifespan of at least 300 full charge cycles, and proba-
bly more with proper handling. At some point, as with all rechargeable batteries, the
lithium ion cells inside will no longer be able to hold a full charge, and the capacity will
decrease. After its useful life, please recycle this battery at a facility that can take used
batteries. Please do not dispose of in the trash to avoid waste pollution. Most city and
counties have recycling programs that can handle Lithium Ion batteries.
5. Safety
1. Do not use or charge the unit if the housing is cracked.
2. Do not ship the unit if the housing is cracked.
3. Do not attempt to short circuit the battery.
4. Do not heat the unit, or dispose of in re, water or other liquids. Keep away from
high temperatures (normal operating range: 32°F-113°F (0°C-45°C).
5. Do not attempt to disassemble the unit.
6. Do not drop the unit or place heavy objects on top.
7. Children should be supervised when in proximity to the unit.
8. The unit may become warm when charging, this is normal.
9. Do not leave the charger plugged into the unit for prolonged periods of time after
charging is complete.
10. Do not throw the unit away if it no longer works, recycle at an appropriate
disposal facility.
6. Specifications
Capacity: 20,[email protected]/74.88Wh
Dimensions: 6.9" x 4.4" x 1.4"
Weight: 1.6 lbs.
Internal Batteries: Lithium Ion
Recharging: QC 18W adapter with Micro USB cable (included)
Full Charge Time: ~6 hours with included QC 18W charger
Output: 2x USB 5v/2.4A(max), 1x 110v AC 60Hz
AC output power: Continuous 85W output, Modied Sine Wave
Power indicator bulbs: LED indicators
Operating temp: 32°F–113°F (0°C-45°C)
Recharge lifespan: >300 full cycles
Package includes: Dynamo Mini
AC power adapter
User manual

4
One-Year Limited Warranty
This Orion product is warranted against defects in materials or workmanship for a period
of one year from the date of purchase. This warranty is for the benet of the original retail
purchaser only. During this warranty period Orion Telescopes & Binoculars will repair or
replace, at Orion’s option, any warranted instrument that proves to be defective, provided it is
returned postage paid. Proof of purchase (such as a copy of the original receipt) is required.
This warranty is only valid in the country of purchase.
This warranty does not apply if, in Orion’s judgment, the instrument has been abused,
mishandled, or modied, nor does it apply to normal wear and tear. This warranty gives
you specic legal rights. It is not intended to remove or restrict your other legal rights under
applicable local consumer law; your state or national statutory consumer rights governing the
sale of consumer goods remain fully applicable.
For further warranty information, please visit www.OrionTelescopes.com/warranty.
