Ortech ODDMF-ST User manual

WARNING
Smart Controller
MODEL ODDMF-ST
PLEASE READ INSTRUCTION BEFORE COMMENCING INSTALLATION AND RETAIN FOR FUTURE REFERENCES.
Electrical products can cause death or injury, or damage to property.
If in any doubt about the installation or use of this product, consult a competent technician.
SCREEN ICONS AND BUTTONS
WARNING — THE INSTALLATION MUST BE CARRIED OUT BY A QUALIFIED TECHNICIAN.
1. For use with EC motor fans
2. Please read the instructions before use
Instruction Manual
1-888-543-6473
1-888-541-6474
13376 Comber Way
Surrey BC V3W 5V9
[email protected]
www.ortechindustries.com
375 Admiral Blvd
Mississauga, ON L5T 2N1
CAUTION
Auto Mode
In auto mode, this smart controller can
maintain your desired temperature level
by automatically adjusting the speed of all
connected fans.
Manual Mode
In manual mode, this smart controller can
maintain a constant speed on all
connected fans.
Fan speed icon
Controller lock icon
Temperature
setting
Room temperature setting
Alarm
Setting
Power
button
Mod
button
Up
button
Down
button
Auto mode icon
Alarm icon
Manual mode icon
Temperature icon
Connect up to 4 fans
This smart speed controller can
manage up to 4 EC fans
simultaneously.
Thermal Probe
Each smart controller comes equipped
with a thermal probe, which allows the
controller to register temperature
changes in the surrounding environment.
WALL INSTALLATION
1) Disconnect the fan mounting bracket from the back
wall of the smart controller. Using the holes in the
mounting bracket as a stencil, mark 2 dots on the wall
and pre-drill two holes for the included screws.
2) Use screws to attach the mounting bracket to the wall
with the two round mounting knobs pointing out and
away from the wall.
3) Slide the controller
3) onto the round
3) mounting knobs
3) to secure it in place.

CONNECTION AND SETUP
Smart Controller
MODEL ODDMF-ST Instruction Manual
1-888-543-6473
1-888-541-6474
13376 Comber Way
Surrey BC V3W 5V9
[email protected]
www.ortechindustries.com
375 Admiral Blvd
Mississauga, ON L5T 2N1
Operation with 1 Fan
Connect thermal probe to NTC
port. Connect fan to port OUT1
using the 3.5mm jack wire
included with your fan.
Powering the Controller
•This speed controller
receives power through its
connection to the fan
•Once the thermal probe and
at least one EC fan is
connected to the controller,
the POWER button will
illuminate on the screen
Operation with 2 Fans
Connect thermal probe to NTC port. Connect
fan to ports OUT1 and OUT 2 using the
3.5mm jack wires included with your fans.
Operation with 3 Fans
Connect thermal probe to NTC port. Connect fan to
ports OUT1, OUT 2 and OUT3 using the 3.5mm jack
wires included with your fans.
Operation with 4 Fans
Connect thermal probe to NTC port. Connect fan
to ports OUT1, OUT2, OUT3 and OUT4 using the
3.5mm jack wires included with your fans.
Celsius/Fahrenheit
•When the controller is powered
off (and connected to the fan),
press and hold the MODE
button for 3 seconds. Once the
temperature appears on the
screen, use the UP and DOWN
arrows to select Celsius or
Fahrenheit. Press POWER
button to save your preference.
Screen Light ON/OFF [Night Mode]
•When the controller is
powered ON, the screen
light can be turned off by
pressing the MODE button
and UP arrow button
simultaneously. The light will
turn back on once any
button is pressed
Lock Controller Buttons
• To prevent any changes to your
settings, you may lock the
controller. You can LOCK and
UNLOCK the controller by
holding the UP and DOWN
arrow buttons simultaneously.
The LOCK icon will flash on the
screen when the controller is in
the locked state.
Manual/Auto Mode
•To select the smart controller's operating mode, press and hold the
MODE button for 3 seconds. In AUTO mode, you will see the AUTO
icon displayed in the top central section of the display. In MANUAL
mode, you will see the HAND icon displayed in the top central
section of the display.

1-888-543-6473
1-888-541-6474
13376 Comber Way
Surrey BC V3W 5V9
[email protected]
www.ortechindustries.com
375 Admiral Blvd
Mississauga, ON L5T 2N1
USER MANUAL INDEX
Smart Controller
MODEL ODDMF-ST Instruction Manual
Manual Mode
•MANUAL MODE allows you to keep your fan at a constant speed
level, regardless of the current room temperature
•MANUAL MODE is indicated with the HAND icon in the top
centre section of the screen
•To select your desired speed level, press the UP or DOWN arrow
buttons on the controller
•You can select between 6 speed levels, which correspond to the
following percentages from the maximum fan motor output:
-Level 0 corresponds to the output of 0% from the max. speed
-Level 1 corresponds to the output of 15% from the max. speed
-Level 2 corresponds to the output of 32% from the max. speed
-Level 3 corresponds to the output of 50% from the max. speed
-Level 4 corresponds to the output of 67% from the max. speed
-Level 5 corresponds to the output of 83% from the max. speed
-Level 6 corresponds to the output of 100% from the max. speed
•The selected speed level is indicated on the controller's screen by
the rotating impeller icon and the number between 0-6.
•AUTO MODE allows the controller to automatically adjust the
speed of the connected fans to maintain your pre-determined target
temperature (based of the temperature reading of the
thermal probe).
•To set up AUTO MODE, ensure that the AUTO icon is displayed in the
centre of the top row of the controller's screen. If you see the HAND
icon instead, press and hold the MODE button for 3 seconds until the
icon switches to AUTO.
•Use the UP and DOWN arrows to select the desired temperature.
This temperature represents the level that you want to maintain in
your ventilated space. The desired temperature can be selected from
0ºC (32ºF) up to 60ºC (140ºF).
Programmable Auto Mode
Auto Mode Baseline Speed
•BASELINE (DEFAULT) speed level is the speed level maintained
by the controller when your desired temperature has
been reached
•Select the BASELINE speed level by pressing the MODE button
once again when AUTO MODE is already activated. The number
displayed under the spinning propeller icon will start blinking,
allowing you to select a value from 0 to 6.
•In applications which require moving air even when your target
temperature is reached, we recommend the BASELINE speed be
set at level 1-3, so that the fan maintains low to medium airflow
while the temperature is already at your desired level
•If your application requires the fan to be turned off when your
target temperature has been reached, the BASELINE speed must
be set at level 0. This effectively means that you want the fan to
be blowing only when the temperature in your ventilated space
exceeds your target level.
Auto Mode Speed Adjustment Logic
•When the room temperature increases over your desired level, the
controller will automatically accelerate the speed of all connected
fans to reduce the temperature to your desired level.
•The fan's speed will increase by 1 additional speed level for every
2ºC/2ºF difference over your desired temperature level.
•In the scenario when your desired temperature level selected for
AUTO MODE is 30°C and your baseline speed level is 1. Once the
room temperature increases to 32°C, the fan's speed will increase to
level 2. If the temperature increases to 34°C, the fan's speed will
increase to level 3 and so on until the fan's speed reaches level 6 at
40°C or above.
•The fan speed will decrease by 1 speed level for each 2ºC/2ºF
reduction in difference over your desired temperature level.
Temperature Alarm
•TEMPERATURE ALARM feature allows the user to select the
temperature level, which once reached, triggers the fan to
immediately accelerate to the maximum speed.
•The fan will override the current speed setting and blow at
maximum speed until the temperature reduces below the
TEMPERATURE ALARM level or unless the TEMPERATURE
ALARM is deactivated by the user.

1-888-543-6473
1-888-541-6474
13376 Comber Way
Surrey BC V3W 5V9
[email protected]
www.ortechindustries.com
375 Admiral Blvd
Mississauga, ON L5T 2N1
ORTECH reserves the right to modify at any time, without notice, any or all of our product's
features, designs, components and specifications to meet market changes.
USER MANUAL INDEX
Smart Controller
MODEL ODDMF-ST Instruction Manual
Temperature Alarm (cont'd)
•To access the TEMPERATURE ALARM setup, when the controller is powered OFF
(and connected to the fan), press and hold the UP arrow button for 3 seconds.
Press the UP or DOWN arrows to select the temperature in which you would like
the alarm to be triggered. Once you've selected the TEMPERATURE ALARM trigger
level, press the POWER button to save it and power ON the controller.
•Once the controller is powered ON, activate the TEMPERATURE ALARM feature by
pressing and holding the MODE and the DOWN arrow buttons simultaneously until
the BELL icon illuminates on the controller's screen.
•To deactivate the TEMPERATURE ALARM feature, press and hold the MODE and
the DOWN arrow buttons simultaneously until the BELL icon disappears from the
controller's screen.
Fan Failure Detection and Error Messages
•EC fans send frequent tachometer signals to the controller. These signals are used
to detect fan failures and alert the user by beeping and displaying error
notifications
•To use this feature, please make sure to connect your fans to consecutive OUT
ports on the controller. For instance, if you run 1 fan only then connect it to OUT1
port. If you run 2 fans on the same controller, then connect them to OUT1 and
OUT2 ports. Similarly, if you run 3 fans on the same controller, then connect them
to OUT1, OUT2 and OUT3 ports. If one of the OUT ports won't have a working fan
connected to it, but the alerts for that port are activated, it will result in false error
alerts. Only activate these alerts for the number of OUT ports currently in use.
•To activate the fan failure detection and error alerts features, when the controller is
powered OFF (and connected to the fan), press and hold the DOWN arrow button
for 3 seconds. Using the UP and DOWN arrows, select a number from 0 to 4 to
match the amount of fans currently connected to controller's OUT ports.
•0-This mode indicates that fan failure detection is disabled for all ports.
•1-This mode indicates that fan failure detection is enabled on port OUT1.
•2-This mode indicates that fan failure detection is enabled on ports OUT1 and 2.
•3-This mode indicates that fan failure detection is enabled on ports OUT1,2 and 3.
•4-This mode indicates that fan failure detection is enabled on ports OUT1,2,3, and 4
•If your controller is connected to 4 EC fans and the fan connected to OUT1 port
becomes disabled, the controller will beep and display error message "E1"
indicating the problem is on port OUT1. Similarly, "E2" will indicate failure of the fan
on port OUT2, "E3" will indicate failure of the fan on port OUT3 and "E4" will
indicate failure of the fan on port OUT4. If multiple fans will fail at the same time,
multiple error messages will be displayed in sequence.
•Error message, Er', indicates a connection problem with the thermal probe. The
smart controller cannot operate without a working thermal probe.
