OSKA Pulse User manual

USER MANUAL
ENGLISH

2
Manufacturer:
Oska, Inc. DBA Oska Wellness
2725 Jeerson Street, #15A
Carlsbad, CA 92008
USA
European Representative:
Emergo Europe
Prinsessegracht 20 2514 AP
The Hague
The Netherlands
Technical Support and Customer Service:
Oska, Inc.
[e-mail]
([phone]
Contact a local distributor
www.oskawellness.com/pages/contact

3
PLEASE READ ALL INSTRUCTIONS BEFORE USE
NOTE: You will need to charge your Oska® Pulse before use.
Refer to CHARGING OSKA PULSE (Section 7) in this manual
Contact your local Oska customer care team if:
• If you need assistance in setting up, using, charging, or maintaining Oska® Pulse
• To report any unexpected event or operation to Oska, Inc. or your local distributor
Contact information is available at www.oskawellness.com/pages/contact.
SAVE THESE INSTRUCTIONS

4
TABLE OF CONTENTS
1. Introduction 5
2. Intended Use 5
3. Contraindications 6
4. Warnings 7
5. Precautions 9
6. Package Contents 11
7. Charging Oska Pulse 12
8. Operating Oska Pulse 14
9. Using A Compression Wrap 16
10. Device Care & Maintenance 18
11. Troubleshooting 19
12. Technical Description 19
13. Specifications 20
14. Symbols 21
15. Warranty Information 23

5
1. INTRODUCTION
Oska Pulse is a wearable, portable, cordless, rechargeable, pre-programmed, and
easy-to-use Pulsed Electromagnetic Field (PEMF) device.
Oska Pulse can be worn on or near the target area, under or over clothing. (Note: thick
or multiple layers of clothing could obstruct the electromagnetic field). The device emits
a PEMF that passes through all tissue types in the body, to work with your body for
long-term recovery.
Individual response to therapy and recovery time may vary. Some may begin to feel relief
within just two weeks, while for many it takes longer. Repeated and consistent use is required
for best results. Those who are compliant with integrating Oska Pulse into their daily life will
receive the most profound benefit.
With Oska Pulse you will not feel intense heat, pulsing or tingling. Some may notice a slight
warming of the target area due to increased blood flow.
2. INTENDED USE
Oska Pulse is a non-invasive pulsed electromagnetic therapy device intended for relief or reduction
of all major types of pain, including back, shoulder, neck, knee, muscle, and joint.

6
3. CONTRAINDICATIONS
The Oska Pulse patient population includes adult men and women who do not have any of
the following contraindications:
• Do not use if you have a heart pacemaker, defibrillator, or other implanted medical
device, unless your doctor has first approved.
• Do not use if you have an implant made from magnetic or metallic materials.
Ask your doctor first if you are unsure.
• Do not use if you received a corticosteroid injection. Consult your doctor prior to use.
• Do not use if you are pregnant or nursing.
• Do not use if you had cancer or are getting cancer treatment unless you have
consulted your doctor and use is approved.
• Do not use if you feel pain but do not know the cause or origin of your pain. Consult
your doctor prior to use.
• Do not use if you have a tendency for bleeding following acute injury or breaks in bones.
• Do not use if you or any other, including children, have reduced physical, sensory,
or mental capabilities, or lack of experience and knowledge, unless given proper
instruction and supervision.

7
4. WARNINGS
• Do not use Oska Pulse device near medical monitoring equipment (e.g., heart monitors,
heart tracing, oxygen saturation devices), which may not operate properly when
Oska Pulse is in use.
• Do not place Oska Pulse near operating MRI equipment as it may adversely aect
Oska Pulse operation through electromagnetic interference as well as magnetic force.
• Do not use Oska Pulse near products that may have strong magnetic fields, such as
microwaves or strong audio speakers. The device may not work properly around
these products.
• Only use an AC charging adapter certified to UL60950, IEC60950-1, IEC60335-2-29,
or IEC60601-1, with an output marked Class 2 or meeting limited power source (LPS)
requirements, not to exceed 16V.
• Only use the USB charging cable supplied with Oska Pulse. Using cables not provided
by Oska Inc. may damage or burn Oska Pulse device. Contact Oska Customer Service
to obtain a replacement.
• Always store Oska Pulse out of reach of children to avoid the risk of choking resulting
from a child swallowing or inhaling a small part that has broken o.

8
• Keep the charging cable and compression wrap out of the reach of children because
strangulation could result from entanglement.
• Do not modify or repair the Oska Pulse device. Sharp edges or electrical components
may cause injury or electrical shock. Return the device to Oska Inc. for examination if
you believe the device is not working properly.
• The Oska Pulse device surface temperature is more than 41°C (105°F) when the device is charging.
• Do not use Oska Pulse while the device is charging or connected to a power source.
• Do not connect Oska Pulse to a high-power source.
• Do not use or discontinue use if the device surface becomes hot.
• Do not use Oska Pulse near heat or fire, such as fireplace, radiant heater, etc.
• Do not throw the device or battery in a fire.
• Do not use Oska Pulse in an oxygen-enriched environment or near oxygen equipment
(e.g. oxygen cylinder, oxygen generator or concentrate, etc.).
• Dispose of the device and its battery in compliance with local regulations.
• Keep all electrical appliances (including Oska Pulse, charger, and power supply) away
from liquid and water, including baths, showers, toilets, and sinks.
• Do not submerge or drop Oska Pulse in any liquid at any time, including while the device
is in use, being charged, or powered o.

9
• Do not use or charge Oska Pulse if exposed to or submerged in liquid because exposure
to liquids may cause irreparable damage to the electronic components.
• Do not use the device or compression strap between users without proper cleaning and
disinfection due to risk of contamination, such as contact with body fluids and expired
gases, etc. Use Oska Inc.’s recommended method of cleaning and disinfectant or follow
your institution’s instructions.
• The device is designed for a single user.
5. PRECAUTIONS
• If you suspect that you have a negative reaction from using the electromagnetic field
device, discontinue use and consult your doctor immediately.
• If you have recently had or are planning to have any surgery or laser/cosmetic
procedure, please consult your doctor before using Oska Pulse.
• Do not apply the wrap too tightly as it may aect blood circulation.
• Do not use soap, cleanser, bleach, or any other cleaning agent not recommended
by Oska Inc. that may potentially damage the device.
• Do not store Oska Pulse in direct sunlight or on a hot surface.

10
• Never store Oska Pulse or any of its parts in an automobile in cold or hot weather.
• If the device begins to generate heat, stop the session, or unplug the device
immediately, and place the device in a cool place. Do not directly touch the
overheated device.
• The device should be operated, transported, and stored in the manner specified
in this manual in the SPECIFICATIONS section of this manual.
• Use caution prior to using the device if storing or not using Oska Pulse for long
periods. Inspect the device and do not use the device if you see any signs
of internal battery leaks.
• Always keep the device away from pets to avoid device damage, or risk from exposed
wire, small and sharp objects.
• Oska Pulse is approved for air and ground transportation. However, if requested,
please hand the device to designated authorities for inspection.
• Do not dispose of as household waste. Contact your local authorities to determine
the proper method of disposal of electronic equipment.

11
6. PACKAGE CONTENTS
Your Oska Pulse kit contains the
following items:
• 1 Oska Pulse Device
• 1 Large Compression Wrap
• 1 Small Compression Wrap
• 1 USB Charging Cable
• 1 AC Power Adapter*
• 1 User Manual (not pictured)
• 1 Quick Start Guide (not pictured)
Figure 1: Contents of the Oska Pulse kit.
*May vary based on model of Oska Pulse

12
7. CHARGING OSKA PULSE
To charge your Oska Pulse, plug the charging cable into the USB port on your computer
or an AC charging adapter and plug the other end into the docking port on the end of the
Oska Pulse device.
During the charging process, do not position the equipment in such a way
that it is dicult to unplug the power supply.
Step 1a Step 1b Step 2a Step 2b Step 3
Figure 2: Charging your Oska Pulse

13
Only use an AC power adapter certified to either UL60950, IEC60950-1,
IEC60335-2-29, or IEC60601-1, with an output marked Class 2 or meeting
limited power source (LPS) requirements, not to exceed 16V. Contact Oska, Inc.
or your local Oska distributor for a replacement.
When the device is connected to a power source, LED lights located at the opposite end
of the charging port will illuminate. If the battery is fully depleted the LEDs may take a few
minutes to illuminate. The LEDs will remain lit (not pulse) until the device is fully charged,
then will turn out. It may take up to three (3) hours for the battery to reach a full charge.
A fully charged battery can provide five (5) or more 3-hour sessions. Battery charge time
may vary by environmental conditions and use patterns. Battery life may decline following
extended use. The battery is not user replaceable.

14
8. OPERATING OSKA PULSE
POWER ON
Press and release the button located on top
of the device to power on your Oska Pulse.
The device will emit a soft beep. LED lights
will begin to pulse at the perimeter of the
device to indicate PEMF is being emitted.
The PEMF session starts as soon as the
device is powered on. The device will start
a new session each time it is powered on.
Note: Most individuals will not feel the electromagnetic
field (PEMF) due to its low frequecy range. This is
normal and expected. Oska Pulse PEMF
therapy is non-invasive.
POWER OFF
Oska Pulse is preset to run for 3-hours without
interruption, then automatically turn o when the duration completes. A session
can be stopped early by quickly pressing and releasing the power button three (3) times.
The device will beep and LED lights will turn o to indicate the device is powered o.
Figure 3: Turn on your Oska Pulse
On = 1-press
LED lights start flashing
O = 3-press
LED lights stop flashing

15
LOW BATTERY
When the battery level is low, the device will beep additional times during power on and
more than power o. The extended beep sequence indicates that the device should be
charged (see Section 7, CHARGING OSKA PULSE). Oska Pulse will turn o early, before
the full 3-hour duration is completed, if a critical low battery level is reached during the
active session.
RECOMMENDED USE
Generally, it is recommended to complete two (2) or more 3-hour sessions each day.
Maintain or adjust use according to your body’s response. Sessions may be broken
up into 1-hour segments. However, consistent daily use is recommended for
maximum results.
Appropriate use may vary by specific user condition. Consult your doctor to identify
recommended use for your individual condition.
Drink plenty of water to maintain hydration
and help your body maximize the benefits.

16
9. USING A COMPRESSION WRAP
Compression wraps are included in the kit package. The
wraps are elastic to help secure Oska Pulse on or near the
target area. Wraps are designed to be used one at a time.
Use the wrap that provides the best fit.
Step 1: Slip the device in the loop located at the
end of the wrap, Oska label and top of device
positioned upward. Be sure the ends of the device
are visible, the device is centered and secure.
Step 2: Position the device on or near the target area. Oska Pulse may be worn under or
over clothing.
Note: The electromagnetic field extends approximately 11 inches from the device, in all directions. Optimal
strength is within 8 inches. The further the distance from the device, the weaker the magnetic field strength.
Step 3: Attach the wrap around your limb, torso, or other target area and fasten it with
the hook and loop.
The compression wrap contains natural rubber latex which may cause allergic reactions.
Do not apply the wrap too tightly as it may aect blood circulation, especially when used
for a prolonged period.
Figure 4: Compression Wrap

17
Figure 5: Examples of wearing a compression wrap on shoulder and back.
Figure 6: Examples of wearing a compression wrap on knee, calf, ankle, and foot.
Do not forget that you are wearing Oska Pulse and accidentally expose the device to water, liquid,
or unsuitable environmental conditions. Should this occur, do not use, or charge the device.
Exposure to liquids may cause irreparable damage to the electronic components.

18
10. DEVICE CARE AND MAINTENANCE
• Clean the surface of Oska Pulse and the silicone skin with a slightly damp cloth only.
Use warm water and household laundry detergent to clean the strap.
• We recommend disinfecting the device with 70% isopropyl alcohol dampened cloth
or wipe periodically.
• Always store Oska Pulse in a cool, dry place. Never keep it where the temperature
is less than -10°C (14°F) or greater than 70°C (158°F).
• Never store Oska Pulse or any of its parts in an automobile in cold or hot weather.
• Use caution prior to using the device if storing or not using Oska Pulse for long periods.
Inspect the device and do not use if you see any signs of internal battery leaks.
• Never store Oska Pulse for prolonged time with the battery charge depleted.
• Do not use or charge Oska Pulse after submerging or dropping it in any liquid because
exposure to liquids may cause irreparable damage to the electronic components.
• Do not use soap, cleanser, bleach, or any other cleaning agent that may potentially
damage the device.

19
11. TROUBLESHOOTING
If you encounter any problem in the operation of the device, first turn the device OFF,
then back ON again (see Section 8, OPERATING OSKA PULSE). This will allow the e-Tec
programming to reboot and reset itself. Next, ensure the device is suciently charged
(see Section 7, CHARGING OSKA PULSE).
If the problem persists, please contact Oska, Inc. or your local Oska distributor. Oska, Inc.
can be reached at [e-mail] or ([phone]. Distributor contact
information is available on Page 24, or visit www.oskawellness.com/pages/contact.
12. TECHNICAL DESCRIPTION
Oska Pulse consists of a copper coil which generates a magnetic field. A frequency gener-
ator is used to energize the coil to create a pulsed electromagnetic field.
Pulsed Electromagnetic Field can influence the signal transduction pathway, ion binding
and ion transport across the human cell membrane. It is capable of increasing Calcium
(Ca++) ion transport resulting in tissue repair and regeneration.

20
13. SPECIFICATIONS
Manufacturer Oska, Inc.
Device Name Oska Pulse
Model/Variant Name From Your Doctor
Model/Variant Part Number HCP012
Software Version 1.4.0
Operation Time 180-minutes
Operator Patient or user
Operating Temperature 10°C (50°F) to 38°C (100°F)
Operating Atmospheric pressure 700 to 1060 hPa
Operating Humidity Maximum 95% Relative Humidity, non-condensing
Storage & Transportation Temperature -10°C (14°F) to 70°C (158°F)
Storage & Transportation Atmospheric Pressure 700 to 1060 hPa
Storage & Transportation Humidity Maximum 95% Relative Humidity, non- condensing
Protection from Solid Particle and Liquid Ingress IP22
Weight 2.12 ounces (60 grams)
Dimensions 5.25 inches x 3.50 inches x 1.25 inches (13.3 cm x 8.9 cm x 3.2 cm)
Rechargeable Battery 3.7V Li-Ion battery, rechargeable. The battery is not replaceable.
External Power Supply Charger Globtek, type GTM46101-1005-USB Input: 100-240VAC, 50-60Hz, 0.3A Output: 5VDC, 2A
Applied Part Device surface area contacting treatment area(s).
