Osmio D7 Instruction manual

Installation, Operation &
Maintenance Manual for:
D7 Direct Flow Reverse Osmosis
System
For more details, please visit:
www.osmiowater.co.uk
osmio

Revitalised mind, body and spirit
Pure hydration by
Smart water technology for point of use and point of entry
www.osmiowater.c o.uk

The Osmio D7 Direct Flow Reverse Osmosis System
High quality Reverse Osmosis water filtration system that is
specifically designed for safer, healthier waer. Revitalise your mind,
body and spirit with the Osmio D7 Reverse Osmosis System.
Product Features:
• Small footprint, under counter mounted system for ease of use.
• Removes up to 99% of over 1,000 contaminants including: lead,
chlorine, fluoride, arsenic, heavy metals, asbestos, hardness,
sodium, microorganisms and much more.
• Experience clean, safe, good-tasting water every time you turn
on the faucet. Enjoy crystal clear ice cubes, fresher tea and
coffee, better tasting foods, healthier baby formula – even
safer than most bottled water.
• Premium hygienically packaged filters with a 6-12 months filter
life-span. High quality components with NSF certification.
• Easy installation and maintenance with Plug & Play parts.
• Direct Flow system which instantly produces RO water.
• Backed by 2-year Osmio Warranty with lifetime support.
• Full, courteous,
industry-leading, 24/7 Osmio
support provided
by experienced professionals. Call us today [[phone]]

Table of Contents
1. Introductions
1.1 - Purpose of This Manual
1.2 - Purpose of This Product
1.3 - Filters
1.4 - Pre-Filtration
1.5 - Reverse Osmosis Membrane
1.6 - Post-Filtration
2. Specifications
2.1 - Technical Requirements
2.2 - Supply Water Requirements
3. Planning the Installation
3.1 - Tools Required
3.2 - Electrical Connection
3.3 - Checking the Parts
3.4 - Making Space for The System
4. Installation, Start-Up and Schematics
4.1 - How to Use Quick Connect Fittings
4.2 - System Water Connections
4.3 - Water Connection Schematic
4.4 - Feed Water Connection
4.5 - Drain Saddle Connection
4.6 - Faucet Connection
4.7 - Pre-Filter Installation
4.8 - Membrane Installation
4.9 - Osmio D7 Direct Flow Reverse Osmosis System Diagram
4.10 - Osmio D7 Direct Flow HUD Icons
4.11 - Verifiying The Installation
5. Maintenance
5.1 - Reccomended Filter Change Durations
5.2 - Changing the Filters
5.3 - Going on Holiday
5.4 - Troubleshooting
5.5 - Service Log Table
6. After Sales
6.1 - Warranty Registration

1. Introduction
1.1 Purpose of This Manual
The purpose of the Installation, Operation & Maintenance Manual is
to give users a reference for Technical Specifications, Connection
Diagrams, Installation Procedures, System Operation and System
Maintenance of their Osmio D7 Direct Flow Reverse Osmosis System.
The essential information contained in this manual will allow the
user to make full use of the system. For special situations, it is
recommended that the user contact their authorized dealer or
Osmio Water Technology (www.osmiowater.co.uk).
1.2 Purpose of This Product
Reverse Osmosis is the most advanced technology of water
purification in use today. The technique uses a nanotechnology
enabled semipermeable membrane which can reduce or remove
most harmful impurities found in tap and well water including:
microorganisms, nitrates, heavy metals, insecticides and much more.
The table below lists the performance of specific contaminants. This
is only a partial list of the virtually hundreds of thousands of
contaminants that Reverse Osmosis can filter.
Aluminum 97-98%Nickel 97-99%
Ammonium 85-95%Nitrate 93-96%
Arsenic 94-96% Phosphate 99+%
Bacteria 99+% Polyphosphate 98-99%
Bicarbonate 95-96% Potassium 92%
Boron 50-70% Pyrogen99+%
Bromide 93-96% Radioactivity 95-98%
Cadmium 96-98% Radium 97%
Calcium 96-98%Selenium 97%
Chloride 94-95%Silica 85-90%
Chromate 90-98%Silicate 95-97%
Chromium 96-98%Silver 95-97%
Copper 97-99% Sodium 92-98%
Cyanide 90-95%Sulphate 99+%
Ferrocyanide 98-99% Sulphite 96-98%
Fluoride 94-96% Zinc 98-99%
Iron98-99%
Lead 96-98%Insecticides 97%
Magnesium 96-98%Detergents 97%
Manganese 96-98% Herbicides 97%
Mercury 96-98%Virus 99+%
TDS (Total Dissolved Solids) 95-99% Hardness 93-97%
Estimated Reverse Osmosis Rejection Percentages
* Figures given above are estimates of normal performance, under normal conditions and water quality.

1.3 Filters
The most essential part of any Reverse Osmosis system is its filters.
It is a misconception that all filters remove materials from the
incoming water, some filters actually add materials into water to
improve the taste, increase the mineral content and for other health
benefits. Although a Reverse Osmosis system can consist of many
filters, they all fall into one of three categories:
• Pre-Filters
• Reverse Osmosis Membrane Filter (RO membrane)
• Post-Filters
This Osmio D7 System will consist of five filters, which we will detail
below.
1.4 Pre-Filtration
The main purpose of pre-filters is to protect the more expensive
RO membrane from specific contaminants. Traditional RO systems
have pre-filters which only target sediment down to 5 microns and
chlorine as they can damage the RO filter and cause it to fail early.
The Osmio D7 Direct Flow system has the following 3 pre-filters:
• 5 Micron Sediment Filter
• GranularActivated Carbon (GAC)
• 1 Micron Sediment Filter
The Osmio D7 Direct Flow System uses High performance
pre-filters which are not only capable of removing Chlorine and
Sediments, but also reduce heavy meatals as well as other impurities
before the water goes into the RO membrane. Heavy metals
detrimental to the membranes life-span and performance

1.5 Reverse Osmosis Membrane
At the heart of every Reverse Osmosis system is the membrane
filter. The membrane filter consists of microporous, semipermeable
membrane sheets. The average pore sizes on the RO membrane is in
the range of 0.0005 mm (0.5 nanometers). The sheets are glued to
each other around three edges with a thin spacer in between
(this prevents the sheets from sticking to each other) to form a “leaf”.
Next, depending on the desired capacity of the membrane filter,
multiple leafs with mesh spacers in between (to allow the water to
pass between leafs) are stacked on top of each other. The stack is
then spirally wound with the open end of the leafs adhered to a
perforated tube that runs up and down the center.
The membrane filter has one water inlet and two exits. The feed
water first travels through the pre-filters and then to the membrane
filter. At the exit of the membrane filter one of the ports is the waste
water which is connected to the drain, while the other port is the
purified water which is plumbed to the post-filters. The figures on the
next two pages will help to better understand the RO membrane filter.
1.6 Post-Filtration
Contrary to including the word “filters” in their name, the post-filters
do not actually remove or “filter” anything from the water
(exception of coconut shell carbon based final polishing filters). Their
purpose is actually the opposite, to add health and aesthetic benefits
to the purified water. More specifically for tank-based systems, a final
polishing step is needed in order to remove any remaining odours or
flavours that may come from the system hoses or the holding tank.
Also, for residential systems additional minerals can be added to the
purified water to increase it’s health benefits.

Smallest known virus
Parvovirus - 0.018 mm diameter
Reverse Osmosis membrane
average pore size - 0.0005 mm diameter
Smallest known bacteria
Mycoplasma- 0.12 mm diameter
(does not fit on page)
Relative Size of Membrane Pore Size to Specific Microorganisms

Schematic of a Reverse Osmosis Membrane Filter
Reverse Osmosis Membrane Filter
Dissolved Solids Spacer
Pores
BacteriaBacteria
Contaminants
Purified Water
Perforated Tube
PressurePressure
Semipermeable Membrane
Purified Water
Waste
Water
Feed water
Single Leaf
Perforated Tube
Purified Water Flow
Double Sided Membrane
Sheet With Spacer in Between

2. Specifications
2.1 Technical Requirements
The technical requirements for this system can be found in the table
below.
2.2 Supply Water Requirements
The supply water requirements for this system can be found on page
9. If the water supply does not meet these requirements, the filter
lifetime and output water quality of the system can be affected.
Please see the table on the next page for the recommend filter
lifetime of this system. This duration will be reduced depending on
how much the water quality exceeds the limits.
Electricity 220 VAC/50 Hz*
Feed Water Pressure 1Bar Min. -4Bar Max.**
Feed Water Temperature 5-38
o
C
Feed Water Connection 1/2" NPT
System Weight (no water) 14 KG
If the feed water is supplied with raw well water, laboratory test of
the water should be done before installing the system. If there is a
significant exceeding of these limits, a well water treatment system
at the source should be considered to correct the water quality.

3. Planning The Installation
3.1 Tools Required
The following tools will be needed for the installation of this system.
3.2 Electrical Connection
This Osmio D7 Direct system comes with all of the internal
electrical connections manufactured, installed and tested. It is
Tools Required for Installation and Their Functions
Tools Required Installation Function
Electric Drill Openhole onsink to mount the faucet*
5mm or 1/8” diamond tip drill bit Pilot hole for faucet*
12 mm or 1/2” diamond tip drill bit Mainhole for faucet stem*
7mm or 1/4” tip drill bit Tubing hole for drainsaddle
Adjustable Wrench Installing feed water diverter valve, metal ball valve and faucet
Phillips Screw Driver Mount drainsaddle
Sharp Scissors or KnifeShortentubing ifneeded
equipped with an SMPS type power supply which is rated for 3.0
Amps 100-240V~50/60Hz. No additional power
conversion should be necessary. The power supply comes with a
1.5 meter length power cord. Depending on the region, the
electrical plugs on the power cord will differ. Make sure to have a
properly maintained power socket for the system at the place of
installation.
Model
D7ROSYS
Capacity
400G/500G
Rated voltage
220V~/50HZ
Power
Rated Power 120W
Type of Anti-Electric-Shock protection
I
Applicable water quality
Mains Water
Applicable water pressure
0.1Mpa~0.4Mpa
Applicable water temperature
5℃~38℃
Ambient humidity
≤90%
Rated pure water flow
62.4L/H 78.8L/H
Rated total pure water flow
6000L/7500L

3.3 Checking The Parts
This Osmio D7 Direct Flow comes with parts that will be helpful
for the installation and maintenance of the system. Under normal
circumstances no other parts should be required for a successful
install. Please see the table below for a list of the installation parts
and their functions.
3.4 Making Space for The System
This Osmio D7
system if you see the figure below, you will have the
dimensions of the unit, please take note that the system once full of
water will weigh around 18 kilograms. Please make sure the platform
the system rests on is adequate to support it’s weight, please make sure
the tubing is not kinked, bent or damaged.
Installation Parts
Function
Faucet Assembly Installed ontop ofthe counter to access purified water
Tube Cutter
Used to safely and cleanly cut the tubing
Reverse Osmosis Membrane
Mainfilter, Comes already pre-installed into the system
1/4” and 3/8” Tubing
1/4" tube to faucet and drain, 3/8" tubing for feed water
Diverter Valve
Tee offcold feed water supply (1/2")
Metal Ball Valve
Recommended to be used on threads to ensure a better seal
PTFE Tape
Connects to tank, disables/enables tank from the system
DrainSaddle Assembly Mounts to under the counter drainline for system drain
Filter Housing Wrench Helps to open filter housings during replacements

1/2” Diverter Valve
Drain Saddle Assembly
Faucet Assembly
Tube Cutter
Osmio D7 Direct Flow Installation Parts
Filter Housing Wrench
400 GPD Reverse Osmosis Membrane Filter
1.5 Meter 1/4” Tubing
Metal Ball Valve
PTFE Tape

4. Installation and Start-up
4.1 How to Use Quick Connect Fittings
Quick connect fittings (push fittings) are used in a wide variety of
plumbing, heating, electrical and fire suppression systems. Quick
connect works by inserting the tubing into a connection mechanism
that deploys fastening teeth onto the tubing surface. When opposing
force is applied to the union, the teeth are forced deeper into the
tubing, preventing separation of the union. The advantages of using
quick connect fittings are:
• They offer a significant time saving benefit over traditional connectors
• They tend to have less user failures compared to traditional connectors
• They require little skill or strength for their usage
• They do not require any tools to use and maintain them
All Osmio D7 Direct systems take advantage of quick connect
fittings. To make a connection, the tubing is simply pushed into the
fitting. The unique locking system holds the tubing firmly in place
without deforming it or restricting flow. Use the steps in the figure on
the next page in reference to quick connect tubing connections for
this system.
Body
O-Ring
O-Ring Guide
Cap
Collet
Exploded Diagram of a Quick Connect Fitting

Step 1: It is essential that the outside diameter of the tubing being
inserted into the fitting is completely free of scratch marks, dirt and
any other material. Inspect the outside of the tubing carefully.
Step 2: It is also very important that the sliced edge of the tubing is
cut cleanly. If the tubing needs to be cut, use a sharp knife or scissors.
Make sure to remove all burrs or sharp edges before inserting the
tubing into the fitting.
Step 3: The fitting grips the tubing before it seals. Lightly push the
tubing into the fitting until the grip is felt.
Step 4: Now push the tubing into the fitting harder until the tube
stop is felt. The collet has stainless steel teeth which hold the tubing
in position while the O-ring provides a permanent leak proof seal.
Step 5: Pull on the tubing away from the fitting and make sure it is
stays firmly in place. It is good practice to test the connection with
pressurized water before finishing installation.
Step 6: To disconnect the tubing from the fitting, ensure that the
system is depressurized first. Push in the collet squarely against
the face of the fitting. With the collet held in this position, the tubing
can be removed by pulling. The fitting and tubing can be reused.
How to Use Quick Connect Fittings
Push In Collet
Pull Tubing

4.2 System Water Connections
This system comes with three quick connect water ports for easy
installation and maintenance. For directions on how to use quick
connect fittings, please see the previous page. The following water
connections will need to be made: Feed water to RO system, RO
system to tank, RO system to drain and RO system to faucet. Please
see the table below for the function of each.
4.3 Water Connection Schematic
Below is a water connection diagram can be found for the Osmio
D7 Direct Flow reverse osmosis system.
Connection Function Connected To
Feed Water Water that needs to be purified Cold Feed Line
CleanWater Water that is purified and ready for consumptionFaucet
Drain Drainfrom Reverse Osmosis membrane filters Drain
Function of System Water Connections

4.4 Feed Water Connection
The purpose of the feed water connection is to feed the system with
water which is to be purified by tapping the cold water supply which is
usually located under the kitchen counter. Please see the figure below for
instructions on how to make the feed water connection.
Feed Water Connection Diagram

Drain Saddle Connection Diagram
Drain Saddle Installation Location
Drill here
Do not drill here
U-bend
4.5 Drain Saddle Connection
The purpose of the drain saddle is to prevent the tubing connected
to drain from popping out of place and potentially leaking where the
system is installed. Please see the figure below for instructions on
how to make the drain saddle connection.
1Step 1: Select a location for the drain hole based on the design of
the plumbing. The drain saddle should be installed above the u-bend
if possible, on a vertical tail piece. Locate the drain saddle away from
the garbage disposal to prevent potential contamination and system
fouling. Please see figure below for a more detailed explanation. Use
a 7 mm (1/4”) drill bit to drill a small hole in the drain pipe for the
drain to pass through. Clean the debris from the plumbing and hold
before continuing.
2Step 2: Remove the backing from the foam gasket and stick that half
of the drain saddle on the drain pipe so that the holes line up (a small
drill bit or other long narrow object can be used to help align
correctly). Place the other half of the drain saddle on the opposite
side of the drain pipe. Clamp and loosely tighten the drain saddle
using the nuts and bolts included. Use a Phillips screwdriver to
tighten the drain saddle. Connect the tubing from the drain saddle
quick connection to the “Drain” connection on the system.
1/4” Drain
Tubing
1/4” Bolt
1/4” Nut
Drain Saddle
Front Plate Drain Saddle
Back Plate
Foam Gasket
Drain Pipe
To “Drain”
Port on System

4.6 Faucet Connection
The purpose of the faucet connection is to have access to water
on-demand. A proper location needs to be selected on the sink.
Special attention needs to be given to the stem on the faucet which
will be under the counter, it will need to be accessed in order to
fix the tubing nut with a wrench. Once the faucet location is picked,
a pilot hole of 5 mm should be made, followed by a 12 mm hole.
Important: Choose the correct type of drill bit for counter type.
Hammer Drill Bit: Cement, Tile, Granite, Marble and Marmoreal.
HSSDrill Bit: Steel, Wood, Chrome, Metal and Aluminum.
1. Place the faucet stem through the 12 mm hole and mount it per
the pictures above.
2. Connect the remaining faucet installation parts to the tubing per
the diagram above
3. Connect the tubing to the stem of the faucet
Locking Washer
Tubing Nut
Tubing Ring
Faucet
Nut Rubber Gasket
Flange
Tubing Pin

4.7 Pre-filter Installation
The pre-filters are packaged in hygienically sealed bags. Do not break
the seal of the bags until right before their installation. Wash the
hands with soap before handling the pre-filters. Any bacteria that is
passed to the pre-filters can limit their lifetime and performance.
4.8 Membrane Installation
The RO membrane is packaged in a hygienically sealed bag. Do not
break the seal of the bag until right before its installation. Wash the
hands with soap before handling the filter. Any bacteria that is
passed to the RO membrane can limit its lifetime and performance.
1. When changing any filter, open the systems cover to reveal the
filters.
2. Open the sealed filters in order of the filter replaced and push and twist
into place as according to the corrosponding labels on the system
3. Use the filter housing wrench to tighten up the filters.
4. Recover the system with the cover previously removed
5. When installing a brand new set of filters make sure to run
the faucet for 5-10 minutes to clear the carbon fines
(allow for 3-4 days if any milky look to the water as this is trapped air)
