OULOO F60 User manual

WARNING: Personal injury may result if this warning is ignored, and special warnings about what
to do or what not to do.
NOTICE: Failure to follow this instruction could result in damage to the vehicle and its equipment
Dear users, for the safety of you and your family and to prevent accidents, please be sure to read
Dear user friends:
Thank you for choosing to purchase "far-reaching" products. Our company and all staff extend
our sincere welcome and heartfelt thanks for your choice.
This "Instruction Manual" introduces you to the safety precautions, main performance
parameters, vehicle structure, pre-driving inspection, inspection, maintenance and repair, fault
phenomenon and elimination, after-sales service, and warranty coverage, so that you can
operate easily and freely This product, to ensure your safe driving on the road.
In order to effectively protect your car and make it as convenient as possible to use your car,
when you find a problem that cannot be solved by yourself or need to replace parts, please
contact the after-sales maintenance department of the dealer or purchase the original parts from
our company. In addition, when you purchase the company's products, please fill in the "User
Warranty Card" completely and clearly, keep the "User Stub Copies" properly, and deliver the
other two copies to the dealer so that we can contact and serve you in time.
The appearance, configuration, and color of the product shown in this "Instruction Manual" are
Notice:
Do not use the electric bicycle before carefully reading the
instruction manual and understand the performance of the
electric bicycle, and please keep the instruction manual
Intelligent electric bicycle
User's Manual
properly.
Preface
for reference only, and the actual product shall prevail.
Safety Precautions
and abide by the following safety precautions and relevant laws and regulations:
or malfunction.
[email protected]
OULOO-Electric Moped
https://www.ouloobikes.com/

Driving Safety
Please read this book carefully before using the vehicle
"Instruction Manual", does a good job of inspection before driving to ensure the safety of riders.
1. It is strictly forbidden for persons under the age of 16 to drive electric bicycles on the road.
2. Electric bicycles should be driven in non-motorized vehicle lanes, and the maximum speed
should not exceed 15 km/h; on roads without non-motorized vehicle lanes, they should drive on
the right side of the roadway.
3. Do not lend electric bicycles to people who can't handle them to avoid injury.
4. Electric bicycles should carry people or items in accordance with laws and regulations.
5. When riding, wear helmets, goggles, and other protective equipment that meet safety
standards correctly, and wear clothing that is bright, free of body movement, not tight, and not
open cuffs. Jackets, boots, trousers, gloves, etc. are effective protective clothing against chafing
and are recommended to be worn properly. Do not wear loose clothing to avoid danger from
being caught by moving parts.
6. When riding in rain or snow, the braking distance will be extended, which is prone to side
slipping, so please slow down; try to avoid travel in bad weather such as heavy rain; turn on the
headlights when driving at night.
7. When driving, do not answer/call, listen to music without headphones, etc. Drive in the
designated lane, don’ t cross the lane, don’ t run a red light, don’ t go wrong, don’ t change speed
suddenly; try to brake as little as possible, don ’t take your hands off the handlebars or hold
objects in your hands, don’t laugh, push, chase, or make trouble with others; don’t tow while
riding, Climbing motor vehicles.
8. Slow down and drive slowly through the intersection, pay attention to pedestrians, and
vehicles, do not rush ahead, observe the road conditions of the front and rear, left and right, and
confirm that it is safe to move forward. When turning, slow down in advance, turn on the turn
signal, and make sure that there is no danger behind you before turning.
9. Those who are prone to sudden diseases such as mental illness or history of mental illness,
high blood pressure, heart disease, hernia, post-concussion sequela, epilepsy, vascular disease,
and deaf and dumb people are prohibited from driving on the road.
Safe to Use
1. Vehicles are not allowed to park in the building foyer, stairwell, evacuation passage, aisle, or
safety exit, and are not allowed to occupy the fire exit. There are no combustibles, fire sources,
electric heating, and gas equipment around the park.
2. Electric bicycles should not be charged and parked in residential buildings and should be kept
away from combustibles when charging, and the charging time should not be too long.
3. Batteries should be properly used and maintained in accordance with the methods required by
the battery manual. Waste batteries should not be disassembled without authorization, and
should be recycled by relevant professional departments.
4. The charger should be properly used and maintained according to the method required by the
charger's manual; please read the charger warning carefully before use; the charger should be

replaced with the battery model.
5. Before washing the electric bicycle, you should understand the contents of "Washing
Precautions" in the manual.
6. When adjusting the handlebars or saddles, care should be taken not to expose the safety line
markings of the handlebars and saddles (if applicable).
7. Before driving, check whether the power circuit, lighting circuit, etc. are in normal state;
whether the front and rear brakes work normally; the handlebars and front and rear wheels are
fixed; the air pressure of the tire; whether the reflector is damaged or polluted, etc. If there is any
abnormality, please contact the far-reaching dealer or after-sales maintenance department in
time for maintenance.
8. For new car battery installation and old car battery replacement, professionals must install and
replace the battery according to the schematic diagram of the whole vehicle, battery installation
diagram and electrical schematic diagram in the manual; when replacing the battery, the battery
connection line should be replaced at the same time and not reused. Use the company's original
accessories. Do not place the battery sideways or upside down.
9. Dealers and users are prohibited from wiring or modifying the structure and performance of
vehicles without permission. It is forbidden to modify the vehicle, especially to change the
battery capacity, and voltage, increase the maximum speed of the vehicle and avoid danger. It is
not allowed to illegally modify electric vehicles and use substandard batteries and charging
equipment.
10. It is forbidden to touch the live parts of the electric bicycle with wet hands and metal
conductors, such as the battery box socket, the battery box connection socket and the charger
power plug, and other parts. Strictly prevent water from entering the electrical parts; when
cleaning the vehicle, avoid water impacting electrical components such as charging sockets,
wiring harness connectors, and fuse tubes, and do not splash water directly into the storage box.
11. When replacing the fuse, the fuse of the specified type and specification should be used. It is
strictly forbidden to short-circuit the wires without adding a fuse. The fuse should be in good
contact with the card slot. If it is loose, it may cause the fuse to heat up and cause an accident.
12. Do not put flammable, explosive, and other dangerous goods, items with low heat resistance,
liquid food, and wet rain gear into the storage box.
13. Do not use chargers of other brands and specifications to charge; it is also not allowed to
charge other electric bicycles with the chargers provided by the company.
15. When charging, first connect the output plug of the charger with the charging jack of the
battery, and then connect the input plug of the charger to the AC power supply.
16. The battery and the charger being charged should be placed in a safe place out of reach for
children. There should be no flammable and explosive materials around. It should be ventilated
and dry. It should not be charged in the open air. Accidents such as electrical short-circuit and fire
caused by factors such as rain; it is forbidden to use the charger in an environment that is
unstable, excessive oil fume and dust, humidity, and direct sunlight; do not connect the charger
during thunder and lightning. When charging, the battery and charger should not be covered
with anything, and the charger should not be placed on the saddle, so as to avoid accidents that
affect the heat dissipation. Do not charge the battery at home. Do not connect the charging line
indiscriminately or
Charge the vehicle for a long time.

17. During the charging process, if there is an odor, the temperature is too high, the indicator
light of the charger still does not turn green after charging for more than 10 hours, or the battery
is bulging, please stop charging immediately, and send it to the dealer or after-sales maintenance
department. Repair.
18. Electric bicycles should be kept away from heat and fire sources when parking or charging,
and should not be parked in the storage places of flammable, explosive, corrosive, and other
dangerous goods, as well as in shops, warehouses, and utility rooms. When parking the vehicle
and charging, turn off the electric door lock and remove the key.
19. Parking and charging are not allowed in group rental houses and crowded places.
20. Do not disassemble electrical components without authorization. Maintenance by
non-professionals is strictly prohibited. If there is a fault, you should go to the dealer or
after-sales maintenance department for maintenance.
Vehicle Structure Diagram
Notice
The driving speed at night should be lower than that during the day, and drive as close to
the center of the road as possible to the right.
The distance is generally more than 50 meters. You should be able to change the lights
and correctly judge the road conditions. Basically, you should drive with high beams.
When you find vehicles, bicycles and pedestrians on the opposite side, you should slow
down and switch to low beams. If the lights are dazzling, you should drive on the right
edge of the road immediately, and if necessary, you should take the initiative to stop to
avoid it.
F60

Product Parameters
Notice
The company reserves the right to change the appearance, accessories and dimensions of the
vehicle. Please understand that any relevant parameters will be adjusted without prior notice.
DS81

Electric bicycle key technical
figures
model
name
F6
Key
technical
figures
Appearance size
(length*width*height)
MM
1660*680*1035
Front/rear wheel center
distance
MM
1200
Vehicle weight
KG
≤60
Top design speed
KM/H
25
Cruising distance
KM
30～80
100KM power consumption
KW.H/100KM
2.01
Carrying capacity
KG
75
Key
technical
figures
for
batteries
Battery type
Volume
AH
15～30
Voltage specification
V
60/72
Main
technical
values of
the
motor
Motor mode
Rated rotation speed
R/MIN
400
Output standard
W
400
Voltage specification
V
60/72
Controll
er Key
Technica
l Values
Overvoltage protection
value
V
51±1
Overcurrent protection
value
A
28±2
Electric bicycle key technical
figures
Model
name
S1
Key
technical
figures
Appearance size
(length*width*height)
MM
1710*700*1055
Front/rear wheel center
distance
MM
1220
Vehicle weight
KG
≤60
Top design speed
KM/H
25
Cruising distance
KM
30～80
100KM power consumption
KW.H/100KM
2.01
Carrying capacity
KG
75
Key
technical
figures
for
Battery type
Volume
AH
15～30
Voltage specification
V
48/60

Instructions
batteries
Motor
main
to skills
Motor mode
Rated rotation speed
R/MIN
400
Output standard
W
400
Voltage specification
V
48/60
Controll
er Key
Technica
l Values
Overvoltage protection
value
V
42±1
Overcurrent protection
value
A
23±2
Electric bicycle key technical
figures
Model
name
S1
Key
technical
figures
Appearance size
(length*width*height)
MM
1710*700*1055
Front/rear wheel center
distance
MM
1220
Vehicle weight
KG
≤60
Top design speed
KM/H
25
Cruising distance
KM
30～80
100KM power consumption
KW.H/100KM
2.01
Carrying capacity
KG
75
Key
technical
figures
for
batteries
Battery type
Volume
AH
15～30
Voltage specification
V
48/60
Motor
main
to skills
Motor mode
Rated rotation speed
R/MIN
400
Output standard
W
400
Voltage specification
V
48/60
Controll
er Key
Technica
l Values
Overvoltage protection
value
V
42±1
Overcurrent protection
value
A
23±2

Use of the instrument
A power display instrument panel is installed above the handlebar, which can instantly display the
current remaining power. In order to ensure the life of the battery, please charge it in time when
the power indicator reaches the red area or the power indicator flashes.
Type F6 Instrument Panel
seagull-type Dashboard
Dashboard Type S1
The use of electric door locks
Electric door lock - with steering lock
Electric door lock - no steering lock

Left combination switch
Instructions

Instructions
Right combination switch
Front brake lever
Headlight switch
Speed control handle
Turn on the headlights: push the 1st gear left to turn on the position light, push the 2nd gear left
to turn on the headlights; push the right to turn off the headlights
Turn on the light Turn on the headlights Turn off the headlights
Speed control handle: Turn the speed control handle (right-hand handle) inward and
counterclockwise, the vehicle starts to start, the rotation angle of the speed control handle is
from small to large, and the corresponding speed is from slow to fast.
Brake operation
When braking, directly hold the front brake lever or the rear brake lever to power off the brake.
After braking, release the brake handle and turn the speed control handle to restart the vehicle.
When the braking force is too large and the tire is locked, please loosen the brake lever, the tire
will resume operation and stabilize the body. Once the front wheels are locked, the steering
ability will be completely lost.
On slippery roads, try to maintain a 1:1 front-to-rear braking force as much as possible.
Inexperienced drivers tend to use only the rear brakes, which will cause accelerated wear on the
brakes and make stopping distances too long.
warn
Using only the front brake is dangerous and can cause slippage or loss of control. Use the brakes
with extreme care and gentleness on wet roads and other slippery surfaces and in all corners.
Using the brakes to brake suddenly is especially dangerous.

Cruise control (if any)
After the normal driving speed is stable, press and hold the cruise button for 3-5 seconds to enter
the constant speed state.
Charging Method
The vehicle can be charged directly on the vehicle
Charging location
Please turn off the power and remove the key. Open the protective cover of the charging hole,
insert the output end of the charger into the charging socket, and insert the input end into the
220v power socket.
1. When the input and output terminals of the charger are connected, the indicator light of the
charger will emit red light, indicating that the power supply is connected and charging.
2. According to the remaining power of the battery, the charging time is 8-10 hours, and the
indicator light of the charger turns green to indicate that the battery is fully charged, and the
charging should be terminated.
3. When charging, connect the battery first and then turn on the power supply. This process is
irreversible; after charging, cut off the power first, and then disconnect the battery from the
charger. Avoid generating electrical sparks that could cause injury.
4. It is strictly forbidden to charge the battery over time (do not exceed
14 hours), reasonable charging will ensure battery life.
5. Please use a special charger for far-reaching, so as not to damage the battery.
6. Charger types and applicable voltages are strictly prohibited. It is strictly forbidden to use any
non-profound dedicated fast charging device to charge.
7. When charging, do not put the charger on the saddle, so as not to affect the heat dissipation
effect of the charger during the charging process.
8. Be sure to close the electric door lock when charging, so as to avoid accidental injuries such as
speeding caused by the unintentional turning of the speed control knob during charging.
9. There is a high-voltage circuit inside the charger. It is strictly forbidden to disassemble or repair
the charger by yourself. If the above behavior occurs, the charger will not enjoy the warranty
service, and our company is not responsible for other adverse effects caused by it.
10. Do not place the charger in the seat bucket or trunk of the vehicle for charging.

Inspection Before Driving
Inspection before driving / inspection before riding, if there is any abnormality, please repair in
time or seek professional repair.
Tire inspection
1. Is the tire pressure normal? According to the depression of the grounded part of the tire, judge
whether the air pressure is appropriate. If the air pressure is abnormal, check it with a tire gauge
and adjust it to normal pressure. The normal tire pressure of this vehicle is 250±5kpa.
2. Whether the tire is cracked or abnormally worn.
3. Whether there are nails, stones, or glass embedded in the tread groove.
4. When the tire is used to the tread wear mark, the tire should be replaced.
Lighting installation, brake power off, turn indicator inspection
1. Turn on the power, operate the lighting switch and the high and low beam switch, check
Warn
1. It is strictly forbidden to use conductors or limbs to touch the electrodes of the charging port to avoid harming
the human body.
2. It is strictly forbidden for the charging port of the battery to enter the water, so as to avoid short-circuit damage
to the battery or the whole vehicle. 3. It is strictly forbidden to take electricity from the charging port (such as
external lighting bulbs), and test the power (such as electric vehicle riding through the power supply of the
charging port). Otherwise, the fuse of the charging port will be burned, resulting in an open circuit of the charging
circuit, or even damage to the circuit. 4. The special charger for Yuanyuan is for indoor use. Please use it in a dry
and well-ventilated environment with shelter.
And keep it in a safe place out of the reach of children. It is strictly forbidden to charge in an environment of
lampblack, dust, confined space, hot sun, high temperature, rain, and humidity.
5. Vehicles should not be charged and parked in corridors or at home in residential buildings.
6. During the use and storage of the charger, pay attention to avoid the entry of foreign objects, especially to
avoid the inflow of water or other liquids, so as to avoid a short circuit of the charger. Chargers are prohibited
from being carried in the vehicle.
7. During the charging process, if the indicator light is abnormal, there is a peculiar smell or the charger shell is
overheated, please stop charging immediately and send it to the local dealer for after-sales maintenance or
replacement.
8. When the green indicator light of the charger is on, please cut off the power supply, do not overcharge, and it is
strictly forbidden to connect the charger to the power supply without a load for a long time.

whether the headlights and taillights are on, and whether the headlights are normal.
2. Check the front and rear brake levers respectively to see if the power is off and whether the
rear brake lights are on.
3. Operate the turn signal switch and check whether the turn indicator is working normally.
Inspection, Maintenance and Repair
Dear user friends:
In order to prolong the service life of the vehicle and enable it to drive safely and comfortably,
please check and maintain it regularly. When the vehicle is stagnant for a long time, it should also
be checked regularly.
When a new car drives 300 km, it needs to be checked and maintained.
Preparation before inspection
1. Please choose a spacious and flat place with double support.
2. Check whether the power supply can be used normally. Status of the power circuit, lighting
circuit, etc.
3. When the driving inspection is required, it should be carried out in a safe place. Pay attention
to the surrounding safety and eliminate abnormality before driving.
4. Whether the vehicle reflector is damaged or contaminated.
5. If it is difficult to solve it by yourself, you can entrust the far-reaching dealer or the after-sales
maintenance department for inspection.
Image inspection of rear view mirrors (if any)
1. Check the rear view mirror for dirt and damage, keep the mirror surface clean, and replace it in
time if it is damaged.
2. From the driver's position, observe whether the rear view mirror can see the road conditions
behind and on the side respectively.
Reflector, license plate inspection
1. Check whether the reflector is stained or damaged. If it is stained or damaged, it cannot be
Warn
Lighting will affect the observation of road conditions and pedestrians at night, as well as the
observation of oncoming vehicles. The taillights can interfere with the view of the car behind. The
brake lights and turn signals (if any) will prompt the rear car to clearly understand the driver's
intention and avoid danger.

used.
2. Check whether the license plate is installed firmly, whether the number is clear, and whether
there is dirt or damage.
Handlebar Steering Inspection
1. Shake the handlebar to check for any abnormal noise, and check the handlebar, front fork, and
shock absorber for deformation, bending, cracks, and other abnormal phenomena.
2. Check the hydraulic front fork and shock absorber for oil leakage and other abnormal
phenomena. If there is any abnormality, please go to the far-reaching dealer or the far-reaching
after-sales maintenance department for inspection and maintenance.
3. Shake the handlebar to check whether the front fork has any abnormal noise or movement. If
there is any abnormality, please go to the far-reaching after-sales maintenance department for
Inspection of handlebars
1. Swing the handlebar up, down, front, back, left, and right to see if there is any looseness. 2.
Check if the handlebar is too tight.
3. Shake the handlebar to check whether the front fork has any abnormal noise or movement. If
there is any abnormality, please go to the far-reaching after-sales maintenance department for
inspection and maintenance.
Wheel inspection
1. Check whether the wheels rotate smoothly, whether there is abnormal noise, and whether the
front and rear wheel fixing screws are tightened.
2. Check whether the wheel rim is deformed or cracked. If there is any damage, please go to the
far-reaching dealer or after-sales maintenance department for inspection and maintenance.
Brake inspection
1. Whether the idle stroke of the brake handle is within the specified range, the idle stroke of the
drum brake handle is generally 10-20 mm, the idle stroke of the hydraulic disc brake handle is
generally 5-10 mm, and the idle stroke of the brake pedal is generally 10-20 mm. Generally
20-30 mm. The measurements are known, and if not, they should be adjusted.
2. Drive at low speed on dry and flat roads, use the front and rear brakes respectively, and check
their respective braking effects. The brake lever or brake pedal should reach maximum braking
effect within 3/4 of full stroke. When the force is stopped, the braking force should disappear
along with it, and there should be no self-braking during driving.
3. When the brake pads are seriously worn or worn to the wear mark, they should be replaced in
time.
Notice
If you do not have special mechanical tools and measuring instruments, please go to the dealer's
after-sales maintenance department for inspection and replacement. Do not disassemble it before
you master the technology to avoid damage to other parts.

Inspection Before Driving
Tire inspection
When the tire is cooled, check whether the tire pressure is appropriate, whether there are sharp
objects such as nails, glass, etc. on the tire surface, and whether there is a large area of cracks or
wear.
Inspection of tire groove depth
Check the tire wear, check the depth of the grooves, and replace the tire when the tire is used to
the tread wear mark. When the tires are abnormal, please go to the after-sales service
department of the dealer to check or replace the tires with new ones. The recommended
rear-wheel tightening torque is 55~65 N.m, and the front-wheel tightening torque is 45~55 N.m.
Warn
Abnormal tire pressure, tire cracks, damage, and abnormal wear are all causes of steering failure
and tire explosion.
Chain inspection
Loosen the rear axle nut first and turn the adjusting chain nut to the left or right to correct the
slack of the chain. When adjusting the chain, the front and rear sprockets must be aligned to
form a straight line. After the adjustment, re-fix the rear axle nut and lock the wire drawing nut,
so that the upper and lower movable distance of the loose edge of the chain at the midpoint of
the two sprockets is 10 -15 mm.
The open end of the chain head clamp should be installed away from the direction of movement
Movement direction
Chain head clamp

Daily Maintenance
Lubrication part and cycle
NO
Lubricatio
n part
Lubricatio
n cycle
Recommended
lubricating oil
1
Front fork
joint
one year
Butter (calcium based
grease)
2
Front and
rear axles
one year
Butter (calcium based
grease)
3
central
axis
one year
Butter (calcium based
grease)
4
Pedal
shaft
one year
Butter (calcium based
grease)
5
sprocket
a week
lubricating oil
6
Chain
a week
engine oil
7
Inside the
flywheel
a month
lubricating oil
8
Brake
lever
a month
lubricating oil
WARNING: Do not fill the brake with oil, otherwise the brake will slip and the braking ability will
be lost.
Pay attention to paint film, decals and other parts to avoid oil pollution and prevent damage.
Charger Use and Maintenance
This charger is specially used for the company's vehicles and takes care of the battery to
effectively improve the service life of the battery.
1. Warning, the user must follow the instructions when charging, otherwise the consequences
will be at your own risk.
2. Prompt, the original charger must be used.
3. Pay attention to the type and applied voltage of the battery that the charger can charge.
Mixed-use is strictly prohibited.
4. When charging, it should be placed in a ventilated environment. It is strictly forbidden to
charge in a confined space or in the hot sun and high-temperature environment. Do not place the
charger in the saddle or tail box to charge.
5. When charging, plug in the battery first, then the power supply; when it is sufficient, cut off

the power first, then unplug the battery.
6. When the green light is on, the power supply should be cut off in time. It is forbidden to
connect the charger to the AC power supply with no load for a long time without charging.
7. During the charging process, if the indicator light is abnormal, there is a peculiar smell or the
charger shell is overheated, the charging should be stopped immediately, and the charger should
be repaired or replaced.
8. During the use and storage of the charger, pay attention to avoid the entry of foreign objects,
especially to avoid the inflow of water or other liquids, so as to avoid a short circuit inside the
charger. Try not to carry the charger with the car. If you really need to carry it, it should be placed
in the toolbox after shock absorption.
9. Do not disassemble or replace the components in the charger by yourself.
Use and maintenance of batteries
1. When the new car is used for the first time, the battery should be fully charged.
2. After each use of the vehicle, it should be fully charged as soon as possible. This will help
prolong the battery life.
3. When the battery is used, it is forbidden to over-discharge, under-charge, and over-charge, so
as not to damage the battery and shorten its service life of the battery.
4. The battery should not be close to an open flame or a high-temperature heat source. It is
strictly forbidden to expose to the sun in the high-temperature season to avoid damage to the
battery.
5. It is recommended to deeply discharge the battery on a regular basis, generally, once a month
is appropriate. That is long-distance riding until the under-voltage indicator shows that the power
is exhausted or the under-voltage protection device starts to function. At this time, the power is
turned off for charging, which can effectively prolong the service life of the battery.
6. If the vehicle is not used for a long time, the power supply should be cut off, and the battery
should be removed from the vehicle and put away. The battery is best placed in a cool place.
Stored for 20-30 days, it must be recharged once.
7. Waste batteries cannot be dismantled without authorization, and should be recycled by
relevant professional departments.
Notice
1. The battery is a key component of an electric vehicle and should be used correctly and
properly protected. Conditional users should be able to charge at any time. If the daily
travel distance is greater than 20 kilometers, they should be charged every day.
2. The performance of the battery is greatly affected by the ambient temperature. When
the air temperature drops below 0 °C, the discharge capacity of the battery may drop by
more than a quarter. Therefore, in winter or cold areas, it is normal for the continuation
mileage to decrease on a single charge. When the temperature rises above 20 °C, its
performance will automatically recover.
3. Do not discard used batteries at will, so as not to pollute the environment. The used
batteries of this product are recycled by the dealer's after-sales maintenance department
and government-designated outlets.

Use and Maintenance of Controller and Motor
Use and maintenance of the controller
1. Regularly check whether the fixing screws and wiring of the controller are loose.
2. Regularly clean the dust on the surface of the controller, which is conducive to heat dissipation.
It is forbidden to wash electrical components with water, so as to avoid the danger of electrical
short-circuit failure.
3. It is strictly forbidden to modify the controller circuit without permission.
4. Regularly check the controller circuit, fuse, etc.
5. When the controller is found to work abnormally, it should stop running immediately and send
it to the authorized repair shop designated by the dealer's after-sales maintenance department
for repair and replacement.
Use and maintenance of electric motors
1. Regularly check whether the end cap screws on both sides of the motor are loose.
2. Regularly check whether the motor wiring is loose, whether the appearance is deformed, and
whether the motor phase wire is damaged.
3. For use in rainy days, the motor cannot be driven in deep water, and the water surface cannot
exceed the position of the rear axle.
4. The hub of the motor cannot be violently impacted, the motor cannot be forced to run under
the condition of a locked rotor, and overloading of the motor is strictly prohibited.
5. If the motor is found to be running abnormally, it should stop running immediately and send it
to the dealer's after-sales maintenance department for repair or replacement.
Tightening torque inspection and adjustment
Precautions for washing
1. Disconnect the power supply of the whole vehicle before cleaning. It is forbidden to touch
the live parts with wet hands and metal conductors, such as battery charging and discharging
ports.
2. It is strictly forbidden for water to impact electrical components. When cleaning the
vehicle, you should use a wet towel to dry the appearance of the vehicle.
3. Avoid the impact of water on the charging socket, wiring harness connectors, and fuses,
etc., and do not directly splash water on the storage box.
4. Do not splash water directly on the brakes, motors, and front and rear axles to prevent
water from affecting the life of the vehicle components.
5. Do not use steam or high-pressure water to wash the vehicle.

Unit: N.M
serial number
Parts
Tightening torque
wheel
front wheel
1
rear wheel
2
front fork
Front fork lock nut
3
rear fork
Rear fork lock nut
4
front shock
Front shock lock nut
5
rear shock
Front shock shaft
tightening nut
Schematic Diagram of Battery Installation
How to install battery
1. Open the seat cushion and turn off the air switch;
2. Put the battery in the seat bucket;
3. Connect the battery plug to make it stable. Open air switch; lower seat cushion.
Warn
Battery installation is dangerous. During installation, professional installers (distributors
designated by the company) must be responsible for installation. Unauthorized operation
leads to an accident, and the user shall bear all the consequences.

Troubleshooting and troubleshooting
· Fault phenomenon
· cause of issue
· Method of exclusion
·
Turn on the power, the
instrument has no display
and the speed regulation
fails
·
Fuse open
·
Poor contact between the
power plug and the
battery socket
· The power lock switch is
damaged or the plug-in
connection
·
bad touch
·
·
Find out the cause and replace the fuse
· Replacing the power plug or battery socket
· Replace the power lock or connector
·
· Turn on the power, the
instrument display is
normal, the speed
regulation fails
· Battery voltage is too low
· The speed control handle
is damaged or loose
·
Front or rear brake lever
cut-off switch failure
·
Controller or motor failure
·
· Fully charged
· Replace the speed control handle or clamp
·
Replace the power off switch
·
Repair or replace the controller/motor
·
· Insufficient mileage after
a single charge
· Insufficient battery charge
· Insufficient tire pressure
· Lots of uphill/strong
headwind/frequent
braking/heavy load
·
Aging or damaged battery
· Check that the brakes are
properly adjusted
· Check if
rotating/transmission
parts are lubricated
· Fully charge or check if the charger plug is in
poor contact
· full of gas
· Minimize braking/starting times and load
conditions
·
Repair or replace the battery
· Adjust brake status
· Lubricate rotating/transmission components
·
· Battery not charging
·
The connection between
the charger plug and the
battery socket is loose
· The battery pack wiring is
disconnected
·
Blown fuse in charger
·
Replace the plug or socket
· Solder or fasten connecting wires
· Replace the charger
