FX & VFX Series Export
Sealed & Vented True Sinewave Inverter/Charger
e OutBack true sinewave inverter/charger is a complete power
solution. It incorporates a DC to AC true sinewave inverter, battery
charger and AC transfer switch all housed within a die-cast aluminum
chassis. “Smart” multistage battery charging means less generator
“on” time, and extends the life of your batteries. Outback’s modular
system architecture permits exibility allowing small systems the
ability to increase the power output as the demand grows from
2 to 30kW - even in 3-phase congurations. Non-volatile memory
retains all programming information even when the inverter isn’t on.
Our FX series uses a sealed chassis that can operate in the harshest
environmental conditions such as high humidity and corrosive salt air
- excellent for coastal and marine installations. e VFX series uses a
vented chassis with “bug proof” screened openings that allow higher
AC output power.
OutBack Power inverter/chargers are the best choice when you need
a true sinewave, powerful, modular and reliable power solution for
your home, business, telecom or mobile application.
Sealed FX
Sinewave Output
“Smart” Battery Charging
Modular System Design
Non-Volatile Memory
Sealed Aluminum Chassis
Network Communications
Light Weight
Vented VFX
Sinewave Output
“Smart” Battery Charging
Modular System Design
Non-Volatile Memory
High Surge Power
Network Communications
Light Weight
Sealed FX
Vented VFX

Available From:
Main Oce:
19009 62nd Avenue NE
Arlington, WA 98223 USA
Phone: [phone]
Fax: [phone]
European Specications
Sealed Models Vented Models
FX2012ET FX2024ET FX2348ET VFX2612E VFX3024E VFX3048E
Nominal DC Input Voltage 12 VDC 24 VDC 48 VDC 12 VDC 24 VDC 48 VDC
Continuous Power Rating at 25° C 2000 VA 2000 VA 2300 VA 2600 VA 3000 VA 3000 VA
AC Voltage/Frequency 230 VAC 50 Hz 230 VAC 50 Hz 230 VAC 50 Hz 230 VAC 50 Hz 230 VAC 50 Hz 230 VAC 50 Hz
Continuous AC RMS Output at 25° C 8.7 amps AC 8.7 amps AC 10.0 amps AC 11.3 amps AC 13.0 amps AC 13.0 amps AC
Idle Power Full ~ 20 Watts ~ 20 Watts ~ 23 Watts ~ 20 Watts ~ 20 Watts ~ 23 Watts
Search ~ 6 Watts ~ 6 Watts ~ 6 Watts ~ 6 Watts ~ 6 Watts ~ 6 Watts
Typical Eciency 90% 92% 93% 90% 92% 93%
Total Harmonic Distortion Typical 2% 2% 2% 2% 2% 2%
Maximum 5% 5% 5% 5% 5% 5%
Output Voltage Regulation ± 2% ± 2% ± 2% ± 2% ± 2% ± 2%
Maximum Output Current Peak 28 amps AC 35 amps AC 35 amps AC 28 amps AC 35 amps AC 35 amps AC
RMS 20 amps AC 25 amps AC 25 amps AC 20 amps AC 25 amps AC 25 amps AC
AC Overload Capability Surge 4600 VA 5750 VA 5750 VA 4600 VA 5750 VA 5750 VA
5 Second 4000 VA 4800 VA 4800 VA 4000 VA 4800 VA 4800 VA
30 Minutes 2500 VA 3100 VA 3100 VA 3100 VA 3300 VA 3300 VA
AC Input Current Maximum 30 amps AC 30 amps AC 30 amps AC 30 amps AC 30 amps AC 30 amps AC
AC Input Voltage Range (MATE Adjustable) 160 to 300 VAC 160 to 300 VAC 160 to 300 VAC 160 to 300 VAC 160 to 300 VAC 160 to 300 VAC
AC Input Frequency Range 44 to 56 Hz 44 to 56 Hz 44 to 56 Hz 44 to 56 Hz 44 to 56 Hz 44 to 56 Hz
DC Input Voltage Range 10.5 to 17.0 VDC 21.0 to 34.0 VDC 42.0 to 68.0 VDC 10.5 to 17.0 VDC 21.0 to 34.0 VDC 42.0 to 68.0 VDC
Continuous Battery Charge Output 100 amps DC 55 amps DC 35 amps DC 120 amps DC 85 amps DC 45 amps DC
Warranty Standard 2 year / Optional 5 year Standard 2 year / Optional 5 year
Weight Unit 62.2 lbs (28.4 kg) 61 lbs (27.7 kg)
Shipping 67 lbs (30 kg) 64 lbs (29 kg)
Dimensions (H x W x L) Unit 13 x 8.25 x 16.25” (33 x 21 x 41 cm) 12 x 8.25 x 16.25” (30 x 21 x 41 cm)
Shipping 21.75 x 13 x 22” (55 x 33 x 56 cm) 21.75 x 13 x 22" (55 x 33 x 56 cm)
