Outback RC4341PC User manual

Assembly and Operating Instructions for
Outback® Magnum 3 Gas/Charcoal Hybrid
Photographs are not to scale.
Specifications subject to change
without prior notice.
WARNING
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open barbecue lid or hood.
4. If odour continues, discontinue use and contact
your local dealer.
FOR YOUR SAFETY
1. Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2. A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
RC4341PC
2575
 For outdoor use only. Not for commercial use.
 Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
 Warning: accessible parts may be very hot. Keep young children and pets away.
 Do not move the appliance during use.
 Turn off the gas supply at the gas bottle after use.
 Any modification of the appliance, misuse, or failure to follow the instructions
may be dangerous and will invalidate your warranty. This does not affect your
statutory rights.
 Retain these instructions for future reference.
 Leak test annually, and whenever the gas bottle is removed or replaced. Check
that the hose connections are tight and leak test each time you reconnect the gas
bottle.
 For Flare-up control please refer to the 'OPERATION' section of this manual.
0359

2
Parts List
Quantities vary according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see ‗Hardware Reference Diagram‘.
CODE PART QTY Magnum 3 Gas/Charcoal Hybrid
HOOD
A1 Hood (Pre-Assembled to Body) 1
A2 Hood Handle 1
A3 Heat Indicator 1
A4 Warming Rack 1
BODY
B1 Cooking Grill 2
B2 Round Grill 1
B3 Flame Tamer 3
B4 Charcoal Basket 1
B5 Barbecue Body 1
B6 Knob 3
B7 Control Panel 1
B8 Main Burner 3
B9 Drip Tray 1
B10 Drip Tray Left Bracket 1
B11 Drip Tray Right Bracket 1
B12 Side Burner Valve, Hose and Regulator Assembly 1
TROLLEY
C1 Side Burner Shelf 1
C2 Side Burner Base 1
C3 Side Burner Ignitor 1
C4 Side Burner 1
C5 Side Burner Electrode 1
C6 Side Burner Grid 1
C7 Side Burner Knob 1
C8 Side Shelf 1
C9 Hook Rail 1
C10 Tool Hook 3
C11 Left Front Leg 1
C12 Left Rear Leg 1
C13 Right Front Leg 1
C14 Right Rear Leg 1
C15 Bottle Opener 1
C16 Front Screen 1
C17 Trolley Base 1
C18 Axle 1
C19 Wheel 2
C20 Hubcap 2
HARDWARE
D1 M5x15 Bolt 4
D2 M5 Washer 4
D3 M5 Nut 4
D4 M6x10 Bolt 19 
D5 M6x15 Bolt 12 
D6 M6x145 Bolt 8
D7 Spacer 8
D8 M6 Nut 4
D9 M4x10 Bolt 2
D10 Locknut 2
D11 Wing Nut 1
 Pre-Assembled Component

3
Parts Diagrams
Quantities vary according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see hardware pack page.
A4
C12C11
B12
A1
B1
A3
A2
B3
B6
B8
C8
C20
C15
C9
C10
C19
C14
C16
B7
B5
C18
C1
B9
B11
B10
C13
D10
C17
C2
C4
D11
C6
C5
C7
C3
B2
B4

4
Hardware Reference Diagram
Specifications subject to change without prior notice.
D1,D2,D3
D4
D6,D7
D5,D8
D5
D9
M4X10 Bolts (2 pcs)
M6X10 Bolts (19 pcs)
M6X15 Bolts (4 pcs)
M6 Nut (4 pcs)
M5X15 Bolts (4 pcs)
M5 Nut (4 pcs)
Washer (4 pcs)
M6X145 Bolts (8 pcs) Spacer (8 pcs)
M6X15 Bolts (8 pcs)

5
Assembly
IMPORTANT!
 TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver,
adjustable spanner or metric spanner set.
 The assembly of this barbecue at least requires 2people.
 Remove any internal components or packaging from the barbecue body.
 Whilst every care is taken in the manufacture of this product, care must be taken during assembly in
case sharp edges are present.
 Please read the Important Information section carefully before assembly and use of your
barbecue.
1
2
Attach the Left Front Leg (C11) and Right Front Leg (C13) onto the Trolley Base (C17) using
the M6x15 Bolts (D5x4pcs) as shown.
Attach the Left Rear Leg (C12) and Right Rear Leg (C14) to the trolley base using the
M6x15 Bolts (D5x4pcs) as shown.
C13
C17
C11
D5
C14
C12
C11 C13
D5

6
3
Unscrew the Locknuts (D10x2pcs) from both ends of the Axle (C18). Slide the axle through
the corresponding holes in the left legs. Slide a Wheel (C19) over each end of the axle.
Secure the wheels into place with the locknuts. Place the Hubcaps (C20) onto the outsides of
the wheels.
4
Insert M6x145 Bolts (D6x8pcs) through the trolley legs, the Spacers (D7x8pcs), and keep the
tip of the bolts inside the spacers. While holding the barbecue body into position (2 people
required), screw the bolts into the barbecue body as shown.
CAUTION! Care must be taken to ensure the hood or lid does not fall open
unexpectedly or becomes damaged when it is set on the ground.
D6 D7
C19
C18
D10C20

7
6
Attach the Bottle Opener (C15) to the right front leg using a M6x10 Bolt (D4).
5
Attach the Front Screen (C16) to the Front Left / Right Legs as shown.
D4
C15
(Rear view of the barbecue trolley.)
C16
Velcro

8
Attach the Drip Tray Left Bracket (B10) to the barbecue body using M5x15 Bolts (D1x2pcs),
M5 Washers (D2x2pcs) and M5 Nuts (D3x2pcs) as shown. Repeat above process for the Drip
Tray Right Bracket (B11).
NOTE: Ensure that the big tabs of the brackets which stop the drip tray are located at
the front of the barbecue.
8
7
Attach the Side Burner Shelf (C1) to the Left Front / Rear Legs using M6x10 Bolts (D4x8pcs).
FRONT
REAR
B10
D1 D2 D3
FRONTREAR
C1
D4

9
10
9
Attach the side burner valve onto the side burner base using M4x10 Bolts (D9x2pcs) as shown.
C3
C2
Retaining Nut
D5
Unscrew the retaining nut from Side Burner Ignitor (C3). Insert the ignitor through the Side Burner
Base (C2) and secure with the retaining nut.
Carefully lay the side burner base into the side burner shelf horizontally, and fix it using M6x15
Bolts (D5x4pcs) and M6 Nuts (D8x4pcs).
D8
D9

10
12
11
C7
Press the Side Burner Knob (C7) onto the side burner valve stem.
Step②
Step①
Step③
Step④
C4
D11
C5
Unscrew the pre-assembled Wing Nut (D11) from the Side Burner (C4). Insert the wire of the
Side Burner Electrode (C5) through the side burner base; make sure it is installed in correct
position as shown. Feed the venturi tube of the side burner through the central hole in the
bottom of the side burner base, then fix it and the side burner electrode onto the side burner
base using the wing nut. Make sure that the end of the venturi tube is set over the gas
outlet of the side burner valve.
D11
