Outland Living Tonga Torch User manual

FMI BRANDS INC.
107 – 19052 26th Avenue | Surrey, B.C. Canada V3Z 3V7 | Toll Free 1-888-514-1663 | Fax [phone]
D.1000.000.V0
Owner’s
Manual
Model number FMTT-1000
LP Cylinder
not included
PORTABLE PROPANE
TONGA TORCH
OUTDOOR LIVING PERFECTED

PORTABLE PROPANE
TONGA TORCH
Owner & Safety Manual
D.1000.000.V0
En-1 OUTLAND LIVING PORTABLE PROPANE TONGA TORCH OWNER & SAFETY MANUAL
Model number FMTT-1000 - Tested by CSA International
CAUTION:
For residential and recreational use only.
CAUTION:
Watch for sharp edges, especially as noted in the manual.
Wear protective gloves if necessary.
CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide which has no odour.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed
space such as a camper, tent, car or home.
DANGER:
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odour continues, keep away from the appliance and immediately
call your gas supplier or fire department.
WARNING:
Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
An LP-cylinder not connected for use shall not be stored in the vicinity of
this or any other appliance.
WARNING:
For outdoor use only.
CALIFORNIA PROPOSITION 65 WARNING:
Combustion of this product results in the emission of Carbon
Monoxide, soot and other combustion by-products which are
known by the state of California to cause cancer, birth defects or
reproductive harm.
HANDLE WITH CARE
WARNING! HOT SURFACE!

En-2
1-888-514-1663 | WWW.OUTLANDLIVING.COM
LP SAFETY:
• Use appliance as purchased; use only with LP (propane) gas
and the regulator/valve assembly supplied.
• Appliance is not for use in or on recreational vehicles and/or
boats.
• This appliance is safety certified for use in the United States
and/or Canada only. Do not modify for use in any other
location. Modification will result in a safety hazard.
• Read and follow all of the messages found throughout the
manual.
MINIMUM CLEARANCES:
• Bottom: Non-Combustible Surface
• Top: 80 inches
• Sides: 36 inches
• Do not use this appliance under overhead combustible
surfaces
•
For Installation on (or over) non-combustible floors only
Max. Input: 7,000 BTU/h
Max Gas Supply Pressure: 250 PSI
This appliance shall be used only outdoors in a well-ventilated
space and shall not be used in a building, garage or any other
enclosed area.
Never use this appliance as a heater.
If this appliance is not in use, the gas must be turned off at the
supply cylinder.
Indoor storage of this appliance is permissible only if the
cylinder is disconnected and removed from the appliance.
Cylinders must be stored outdoors in a well-ventilated area out
of the reach of children.
Disconnected cylinders must have threaded valve plugs tightly
installed and must not be stored in a building, garage or any
other enclosed area.
The gas pressure regulator provided with this appliance must
be used, and must be the same model as supplied with the unit.
Replacement parts and a list of such parts are available from
FMI Brands Inc. through the contact information provided on the
last page of this Manual.
Replacement parts:
• Low pressure gas hose and regulator
WARNING:
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Read the
installation, operating and maintenance instructions thoroughly
before installing or servicing this equipment.
WARNING:
If the information in this manual is not followed exactly, a fire
or explosion may result causing property damage, personal
injury or loss of life.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
WARNING:
a. Do not store a spare LP-gas cylinder under or near this
appliance.
b. Never fill the cylinder beyond 80 percent full.
c. If the information in “(a)” and “(b)” is not followed exactly,
a fire causing death or serious injury may occur.

PORTABLE PROPANE
TONGA TORCH
Owner & Safety Manual
D.1000.000.V0
En-3 OUTLAND LIVING PORTABLE PROPANE TONGA TORCH OWNER & SAFETY MANUAL
LP CYLINDER REMOVAL, TRANSPORT
AND STORAGE:
• Turn OFF all control knobs and LP cylinder valve. Disconnect
propane gas cylinder. Install safety cap onto LP cylinder valve.
Always use cap and strap supplied with LP cylinder valve.
• A disconnected LP cylinder in storage or being transported
must have a safety cap installed. Failure to use safety cap as
directed may result in serious personal injury and/or property
damage.
• Do not store an LP tank in enclosed spaces such as a carport,
garage, porch, covered patio or other building. Never leave an
LP tank inside a vehicle which may become overheated by the
sun. Do not store an LP tank in an area where children play.
APPLIANCE INSPECTION & TEST
SEQUENCE:
Each time the appliance is put to use, and prior to ignition,
conduct the following appliance inspection and test sequence:
• Ensure all clamps are firmly fastened and the appliance is
standing straight.
• Inspect the hose prior to each use. The hose assembly must
be replaced prior to the appliance being put into operation
if there is evidence of excessive abrasion or wear, or if
the hose is damaged. Contact FMI Brands Inc. should you
require a replacement hose.
• Inspect the mid-point gas connection (sealed gas fitting)
prior to each use. Check the fitting is firm and the seal is not
broken or damaged. WARNING: Removal of the sealed gas
fitting and/or seal is not permitted for safe operation and
may affect warranty or claims.
• Inspect the burner prior to each use. Ensure all holes are
clear and there are no leaves, pine needles, spider webs or
other debris in burner area. Burner must be replaced prior
to the appliance being put into operation if there is evidence
of damage. Replacement parts such as burners are available
from FMI Brands Inc.
• Ensure the proper gas connections are made. See section
labelled “Connection”.
• Leak Test all connections. See section labelled “Leak Test”.
• Ensure that the LP gas cylinder and gas hose is placed
in an area where it is unlikely to be tripped over (such as
pathways or trails) or subject to other accidental damage.
WARNING:
Please ensure that all adults and children which use or are
near a unit in use are aware of the hazard of high-surface
temperatures present on the unit during use and should
use caution and stay away to avoid burns or clothing
ignition.
Carefully supervise young children in the area of this
appliance. Clothing or other flammable materials should
not be hung from the appliance or placed on or near the
appliance. Any guard or other protective device removed
for servicing the appliance must be replaced prior to
operating the appliance.
Installation and repair should be done by a qualified
service person. The appliance should be inspected before
use and at least annually by a qualified service person.
More frequent cleaning may be required as necessary.
It is imperative that control compartment, burners and
circulating air passageways of the appliance be kept clean.
LP CYLINDER:
All LP cylinders to be used with this appliance must be:
a. Constructed and marked in accordance with the
specifications for LP-gas cylinders of the U.S. Department
of Transportation (DOT) or for Canada, Standard, CAN/CSA
B339, Cylinders, Spheres and Tubes for the Transportation of
Dangerous Goods.
b. Provided with a listed overfilling prevention device.
c. Provided with a cylinder connection device compatible with the
connection for outdoor cooking appliances.
d. Only a 20 lb. (9 kg) LP gas cylinder is to be used for this
appliance, approximately 18” (46 cm) high & 12” (30 cm)
diameter.
e. LP cylinder must be arranged for vapour withdrawal and
include a collar to protect the LP cylinder valve. Always keep LP
cylinders in upright position during use, transit or storage.
f. The use of an approved LP gas cylinder stabilizer, such as the
one included, must be used when using this appliance in order
to prevent the LP gas cylinder from tipping over.

En-4
1-888-514-1663 | WWW.OUTLANDLIVING.COM
!
WARNING:
DO NOT USE OR PERMIT SOURCES OF IGNITION IN THE
AREA WHILE DOING THE LEAK TEST.
THIS INCLUDES SMOKING.
a) If parts of the fitting begin to produce bubbles, spray liquid, or if
you smell liquid propane gas, immediately close the valve on the
tank. Wait 20 minutes for any gas to dissipate. After waiting for
20 minutes, the leak(s) must be stopped by tightening the loose
joints, if possible, or by replacing the faulty parts(s) with the
part(s) recommended by the appliance manufacturer.
b) If no adverse reaction is observed and the connections all seem
fine then move to the ignition sequence.
THE APPLIANCE IS NOT TO BE USED UNTIL ANY LEAK IS
CORRECTED.
A gas appliance repairman or LP gas dealer should be called if
attempts to stop the leak(s) are unsuccessful and, in such case, the
LP gas supply must be shut off at the cylinder valve or the cylinder
must be removed from the appliance until the leak(s) is corrected.
IMPORTANT: Call OUTLAND for quick delivery of replacement
parts. DO NOT RETURN THE APPLIANCE TO THE RETAILER.
Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
NOTE TO INSTALLER:
Leave this guide with the consumer.
NOTE TO CONSUMER:
Please retain this guide for future use.
WARNING:
If the information in this manual is not followed exactly, a fire
or explosion may result causing property damage, personal
injury or loss of life.
Mid-point Gas Connection
(sealed gas fitting)
Tank Ring
Gas Hose
Caution:
Trip Hazard
Minimum
36” (0.91m)
Gas Hose Regulator
LP Cylinder Valve Coupling
LEAK TEST:
IMPORTANT: Leak testing should be done once per year or
whenever the LP gas cylinder or any other gas system part is taken
apart, serviced or replaced, whichever is more frequent.
1. Be sure the cylinder valve and appliance valves are “off”.
2. Ensure all gas system coupling joints are tight and properly
attached.
3. Prepare a leak testing solution of half liquid detergent and half
water.
4. CAUTION: ***SLOWLY*** turn cylinder valve to the open
position to avoid tripping the CSA excess flow safety device in
the gas regulator. For more information about the CSA excess
flow safety device see SECTION 3: IGNITION, STEP 4 What is
an Excess Flow Safety Valve? (EFV).
5. Apply the solution to the LP gas delivery system at points as
shown in illustration: STOP:
Do not return this product to the store.
If you need help or parts, call the Outland Hotline:
1-888-514-1663
Get help for:
Missing/damaged parts • Assembly • Troubleshooting
Warranty Assistance • Product Information

PORTABLE PROPANE
TONGA TORCH
Owner & Safety Manual
D.1000.000.V0
En-5 OUTLAND LIVING PORTABLE PROPANE TONGA TORCH OWNER & SAFETY MANUAL
SECTION 1: ASSEMBLY
STEP 1
Set up Tonga Torch base.
Release leg clamps and deploy legs. With base standing straight,
firmly lock down leg clamps.
Note: unwinding clamp counter clockwise will loosen clamp force;
winding clamp clockwise tightens clamp force.
SUPPLIED PARTS & HARDWARE LIST:
Leg
Clamps
Legs
1. Tonga Torch Top with
factory assembled low
pressure gas hose and
regulator
2. Tonga Torch Base
3. Tank Ring (split-hinged
design)
Tonga Torch Top
Tonga Torch
Base
Tank Ring
Gas Hose
IMPORTANT:
Always ensure leg clamps and top tube collar are tightly locked
in position.
IMPORTANT:
Always ensure the Tonga Torch stands straight and vertical.
The Tonga Torch is meant to be deployed on level ground. In
the event of uneven ground adjust the fixed angle of the legs.
This is done by releasing the leg clamp and adjusting the leg
position. Depending on ground terrain, it may be necessary to
fine tune more than one leg to achieve a straight and vertical
standing position. Lock the leg clamp upon repositioning.
IMPORTANT:
Only use the base provided.

En-6
1-888-514-1663 | WWW.OUTLANDLIVING.COM
Hose
Restraint
Loops
Mid-point gas
connection
(sealed gas fitting)
Tube
Collar
Clamp
STEP 2
Insert Tonga Torch top into base tube.
STEP 3
Align hose and fittings. Ensure the gas
hose is running straight down from the
mid-point gas connection through the
two restraint loops. The gas hose must
go straight through both restraint
loops for safe operation. Pull gas hose
through hose restraint loops. Unwind
any twists or kinks in the gas hose.
Ensure hose exits the bottom restraint
loop in a straight manner.
STEP 4
Lock down the tube collar clamp.
Important adjustment points:
• Legs
• Leg Clamps
• Hose Restraint Loops
• Tube Collar Clamp
CAUTION:
Use caution, the hose is a potential trip hazard. Watch out for
children and pets during use. Ensure that the LP gas cylinder
and gas hose is placed in an area where it is unlikely to be
tripped over (such as pathways or trails) or subject to other
accidental damage.
DANGER!
NEVER USE TONGA TORCH UNDER TREES, ROOFING, TARPS,
CANOPIES OR UNDER ANY OVERHANGING STRUCTURE OR
MATERIAL.
NOTE TO USER:
Before igniting the unit for the first time, follow steps one
through 8 in the below Ignition section.

PORTABLE PROPANE
TONGA TORCH
Owner & Safety Manual
D.1000.000.V0
En-7 OUTLAND LIVING PORTABLE PROPANE TONGA TORCH OWNER & SAFETY MANUAL
SECTION 2: CONNECTION
STEP 1
Ensure the LP cylinder valve is CLOSED and the appliance gas valve
is “of f ”.
STEP 2
Ensure the gas hose is running straight down from the mid-point
gas connection through the two restraint loops. Unwind any twists,
or kinks, in the gas hose so it exits the bottom restraint loop in
a straight manner. The gas hose must go straight through both
restraint loops for safe operation.
CAUTION:
When making the connection, hold the regulator in a straight
line with the cylinder valve, so as not to cross thread the
connection.
STEP 3
Set up tank stabilizer ring (snap
closed in round position).
STEP 4
Place full
LP gas
cylinder
on tank
stabilizer
ring.
STEP 5
Securely attach regulator (large end of
hose) to your propane cylinder. Extend
hose to full length and ensure that
the propane tank is as far as safely
possible from the appliance. Place the
LP tank in the included stabilizer ring.
Use caution, the hose is a potential trip
hazard.
• Do not use tools. Hand tighten only.
• Center the nipple in the cylinder valve and hold in place.
• Using the other hand, turn the hand wheel clockwise until
there is a positive stop.
STEP 6
Leak Test all connections. See section labelled “Leak Test”.
SECTION 3: IGNITION
STEP 1
Each time the appliance is put to use, and prior to ignition, conduct
the appliance inspection and test sequence. See section labelled
“Inspection & Test Sequence”.
STEP 2
Using a lighter or match, ignite lighter and hold flame slightly
above the burner, then open the valve on the appliance slowly by
turning (counter-clockwise) until the unit ignites.
Burner
Gas Valve/Gas Knob
TIP: You
may find it
convenient
to place your
foot on one
of the legs to
help stabilize
the appliance
during the
ignition
sequence.
DANGER:
Keep hair tied back and keep head and face away from Tonga
Torch during ignition!

En-8
1-888-514-1663 | WWW.OUTLANDLIVING.COM
WARNING:
Ensure that no parts of your body, clothing, or any other
combustible material are above the burner before, during and
after ignition.
CAUTION:
Always ensure the gas valve
orifice and burner tube
venturi is clear of all debris
including spider webs.
STEP 3
Once the unit is burning normally set the dial to desired flame
height.
STEP 4
GOT A LOW FLAME? OR FLAME HEIGHT DOES NOT APPEAR TO
BE NORMALLY ADJUSTED BY THE GAS KNOB?
CORRECTIVE ACTION:
1. Confirm your propane tank is NOT empty J, then;
2. Close propane cylinder valve.
3. Open and then close appliance gas knob valve to release
pressure.
4. Disconnect and reconnect the propane cylinder valve
connection.
5. ***SLOWLY*** open propane cylinder valve.
6. Perform Leak Test and follow Ignition sequence.
The whole story…
A low flame can be caused by an empty propane tank or if the
Excess Flow Safety Valve (the EFV) has been tripped.
WHAT IS AN EXCESS FLOW VALVE? (EFV)
The EFV is a safety mechanism contained within every propane
gas regulator. The purpose of the EFV is to restrict the gas
supply if too much gas is flowing too quickly through the gas
hose. For example this
could happen if the gas
hose was severed. It is
normal that your EFV trips
if you open the propane
tank valve too quickly or
if you leave the gas knob
open before lighting, or
both.
HOW TO PREVENT LOW FLAME OR EFV TRIPS
1. Always check that your Outland appliance gas valve/gas knob is closed before opening tank valve.
2. Always open propane tank valve **SLOWLY**.
PLEASE DO NOT RETURN TO STORE – IT’S NOT BROKEN
Questions? Outland support team: 1.888.514.1663
GAS REGULATOR
NIPPLE WITH EXCESS
FLOW LIMITING
DEVICE (EFV)
GAS HOSE

PORTABLE PROPANE
TONGA TORCH
Owner & Safety Manual
D.1000.000.V0
En-9 OUTLAND LIVING PORTABLE PROPANE TONGA TORCH OWNER & SAFETY MANUAL
SECTION 5: EXTINGUISHING THE APPLIANCE
STEP 1
1. Turn valve on propane cylinder to “CLOSE” position.
2. Wait for flame to visibly extinguish.
3. Turn valve on unit to “OFF” position.
STEP 2
Allow unit to cool for at least five (5) minutes before relighting.
Upon igniting the appliance, visually
verify that the burner is indeed burning
as demonstrated in the image to the left.
The presence of flames will confirm that the
burner is burning.
Periodically check that the burner flame
is present during operation by visually
inspecting the burner to ensure the presence
of flames.
SECTION 4: PERIODIC INSPECTION OF BURNER FLAMES
If there are no flames present, as
demonstrated in the image to the left,
the appliance is likely not burning. If this
is the case, IMMEDIATELY turn the valve
to the “off” position if it is not already.
Allow unit to cool for at least five (5)
minutes before relighting. Repeat the
ignition procedure as outlined in
Section 3.
SECTION 6: APPLIANCE MAINTENANCE
Your Outland appliance requires periodic maintenance to keep
it in good running order. Follow the steps below to ensure your
appliance will provide you with the best possible performance:
1Keep your appliance out of the rain and store it in a dry place.
2 If you experience any signs of your propane cylinder ‘freezing
off’ or start to experience lower flames than usual, please simply
turn the burner control setting to low for 5–10 minutes, or replace
the cylinder with a full one.
3 Ensure that you clean the top of your Outland appliance after
every use to keep it looking GREAT. Simply use warm soap
water to wipe down your appliance to keep it clean. Do not use
abrasive cleaners.
Burner
Torch Head
Burner Screen
Wind Guard
Top Screw
4. Should any part of this appliance (including the burner) become
soiled or dirty, wipe lightly with a damp cloth. Do not use
flammable or corrosive cleaning products on or near this unit.
5 Periodically clean the
burner orifice holes out
with a small pin.
a. Remove top screw
b. Remove Burner
Screen
c. Locate burner
d. Clean burner and
burner screen
orifice holes
with small pin or
paperclip.

En-10
1-888-514-1663 | WWW.OUTLANDLIVING.COM
SECTION 7: APPLIANCE DIMENSIONS
NOTES:
• This portable propane Tonga Torch appliance is NOT a toy.
• Expected burn time: the anticipated burn time for your
OUTLAND Propane Tonga Torch is 60 hrs. This assumes starting
with a full 430,000 BTU/h 20lb (9kg) LP cylinder and operating
with gas valve open at maximum. The gas valve for your torch
appliance is rated at 7,000 BTU/h max. Operating the Torch at a
lower flame setting will increase the burn time.
• When using this unit, children should be supervised at all times,
without exception.
• Do not place any objects inside the burner component.
• Do not add wood or any other materials to the fire. It is designed
to safely combust propane only.
• Solid fuels shall not be burned in this appliance.
• Keep the appliance area clear and free from combustible
materials, gasoline and other flammable vapors and liquids.
• Do not connect to a remote gas supply.
• Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the
appliance and to replace any part of the control system and any
gas control which has been under water.
• Appliance accessories and parts can be purchased at
www.outlandliving.com or by calling 888-514-1663.
• Always inspect and clear all valve and gas orifices of any foreign
debris including spider webs prior to lighting.
Top View
Front View
33.5”
857mm
71”
1800mm

PORTABLE PROPANE
TONGA TORCH
Owner & Safety Manual
D.1000.000.V0
E n -11 OUTLAND LIVING PORTABLE PROPANE TONGA TORCH OWNER & SAFETY MANUAL
FOR REPLACEMENT PARTS AND ACCESSORIES PLEASE VISIT
WWW.OUTLANDLIVING.COM
The owner’s manual is available as a free download from www.outlandliving.com
Replacement part orders can be sent by mail to the address on the cover of this booklet, or faxed to [phone]. Should you have any questions
or comments regarding this appliance, please do not hesitate to contact FMI Brands Inc. at [phone] or E-Mail to [e-mail].
STOP:
Do not return this product to the store.
If you need help or parts, call the Outland Hotline: [phone]
Get help for:
Missing/damaged parts • Assembly • Troubleshooting • Warranty Assistance • Product Information
1 YEAR LIMITED WARRANTY
Customers in Canada and USA
All components are warranted by the manufacturer for a period of 1 year after date of purchase by the
original owner against defects in materials and workmanship under normal use. This warranty does NOT
cover normal wear and weathering, assembly and/or maintenance OR use in a commercial application.
At FMI Brands’ sole discretion, products under warranty will be repaired and/or replaced at no charge to
the customer. Any returns sent back to FMI Brands must be sent via prepaid freight and in the original
retail packaging.
Please register your OUTLAND Living product for proof of purchase and warranty at
http://outlandliving.com/register-products/
For more warranty information and details please contact FMI Brands Inc. at [e-mail]
