PowerTac E5 Generation IV User manual

E5
USER MANUAL
TACTICAL FLASHLIGHT
INTRODUCTION
The E5 generation IV high-power LED ashlight is designed specically to be the ultimate Every Day Carrying (EDC) and tactical light. It is built with cutting-edge technology,
unparalleled performance, exceptional craftsmanship, and unbeatable reliability. It comes with a user-friendly interface for simple operation and multi-functions for dierent
situations. It is perfectly engineered to be extremely portable and powerful. It delivers on design, performance, quality and reliability. Making it the preferred choice by many
professionals and ideal for military, law enforcement, adventurists, hunters, and search and rescue.
FEATURES & SPECIFICATIONS
• Powerful CREE XM-L2 U2 LED produces 980 Lumens at
the brightest setting including strobe.
• 200+ meters of throw to illuminate both long and short
distances.
• Simple user interface for tactical and self-defense .
Integrated side switch for quick access of functions.
• Unique digital circuit technology to maximize battery
life and give consistent light output.
• Reverse polarity protection. Protects from improper
battery installation.
• 5 dierent settings that include 4 levels of brightness
plus a strobe. Auto memorization for all settings.
• Machined from aircraft grade aluminum. Has type lll
anodized nish.
• Double coated glass lens to give maximum OTF (Out
The Front) brightness and beam distance.
• Tempered glass to resist breaking and scratching upon
impact.
• Waterproof to IPX8 standard. Submersible up to 2
meters under water.
DISCLAIMER
• After long periods of use on the highest setting, the
surface area may get hot. Please use caution when
using the ashlight in a constant high brightness level.
It is recommended to let the ashlight cool down to
prevent any injury.
• High intensity light is harmful to human eyes. This
product is not meant to be handled by children under
the age of 18 without adult supervision.
• Use the highest quality, protected-circuit batteries to
insure maximum performance and safety. Consult
with the manufacturer regarding any questions or
concerns.
• PowerTac’s liability is voided if the light is not used in a
proper manner or if modied.
• PowerTac reserves the right to change the design
and/or specications of all PowerTac products without
prior notice.
• Please do not change batteries at dangerous locations
such as gas stations. Batteries must only be changed
or removed when light is o.
• Do not use or attempt to recharge a disposable CR123
battery! Do not throw the ashlight into a re as an
explosion may occur.
THE POWERTAC NO-HASSLE LIFETIME WARRANTY
PowerTac warrants our illumination tools to be free from
defects in workmanship and materials, including any
LEDs housed within, for the lifetime of the original parts
(The lifetime of the parts are specied by individual parts
manufacturers). If it is determined by us to be defective,
we will repair or replace your original purchase of these
products, at our discretion. Electronics, chargers, and
rechargeable batteries are covered for a period of two
years with proof of purchase. Normal wear and tear –
including lamps burning out, batteries draining, and
switches wearing out – is not covered, nor is damage
resulting from misuse, abuse, neglect, battery damage,
use of other non-approved batteries or altering these
products from their original state. Parts and accessories
for illumination tools are not covered by this warranty.
WARRANTY DISCLAIMER
The above warranty is exclusive, and to the extent
permitted by applicable laws, shall be in lieu of all other
warranties, express or implied, including, without
limitation, any warranty of merchantability or tness for a
particular use or purpose. PowerTac disclaims any and all
liability for product malfunctions, physical injuries, or
property damages that result in whole, or in part, from
the criminal, negligent, or improper use of the product,
or from modications or alterations thereto. In no event
shall PowerTac be liable for any incidental, special, or
consequential damages relating to the purchase, use, or
performance of any PowerTac product.
WARRANTY CLAIMS
Please go to www.powertaclights.com/warranty and
follow instructions.
USAGE INSTRUCTIONS
1. To install battery: Unscrew tail cap. Insert positive end of the battery
towards LED. Tighten the tail cap till it’s completely closed.
2. To turn the light ON: Push the back switch to click. Once Turned on the
ashlight will access the mode last used. To Turn the Light OFF, push the
back button to click.
3. To switch light levels: Turn the light on and press the side switch (click).
Press side switch again (click) will cycle to next light level.
4. Access the direct to strobe function: Turn light on and hold down side
switch (long click, 0.3 seconds). The light will remain on strobe until you
switch light levels.
5. Toggle Strobe / High Function: Access direct to strobe function; release
side switch; hold down side switch again (long click) and light will toggle
to high mode. Hold down side witch again (long click) and toggle to
strobe again.
Maintenance
Every 3 months, threads should be wiped with a clean cloth followed by a
thin coating of silicon-based lubricant.
LED TYPE: CREE XM-L2 U2 LED
HEAD
POCKET CLIP
SIDE SWITCH
BATTERY TUBE
ILLUMINATION FUNCTIONS
Mode: Firey Low Medium High Strobe
Output: 2 lm 82 lm 416 lm 980 lm 980 lm
Runtime: 706 hrs 15 hrs 3 hrs 1.5 hrs 3 hrs
BACK SWITCH
Battery: (2) CR123A or (1) 18650 Rechargeable Li-ion.
NOT compatible with RCR123A / 16340
Size: Length:128.5mm
Bezel Diameter: 25.4mm
Body Diameter: 22mm
Weight: 69g (without battery)

FEATURES & SPECIFICATIONS
• Powerful CREE XM-L2 U2 LED produces 980 Lumens at
the brightest setting including strobe.
• 200+ meters of throw to illuminate both long and short
distances.
• Simple user interface for tactical and self-defense .
Integrated side switch for quick access of functions.
• Unique digital circuit technology to maximize battery
life and give consistent light output.
• Reverse polarity protection. Protects from improper
battery installation.
• 5 dierent settings that include 4 levels of brightness
plus a strobe. Auto memorization for all settings.
• Machined from aircraft grade aluminum. Has type lll
anodized nish.
• Double coated glass lens to give maximum OTF (Out
The Front) brightness and beam distance.
• Tempered glass to resist breaking and scratching upon
impact.
• Waterproof to IPX8 standard. Submersible up to 2
meters under water.
DISCLAIMER
• After long periods of use on the highest setting, the
surface area may get hot. Please use caution when
using the ashlight in a constant high brightness level.
It is recommended to let the ashlight cool down to
prevent any injury.
• High intensity light is harmful to human eyes. This
product is not meant to be handled by children under
the age of 18 without adult supervision.
• Use the highest quality, protected-circuit batteries to
insure maximum performance and safety. Consult
with the manufacturer regarding any questions or
concerns.
• PowerTac’s liability is voided if the light is not used in a
proper manner or if modied.
• PowerTac reserves the right to change the design
and/or specications of all PowerTac products without
prior notice.
• Please do not change batteries at dangerous locations
such as gas stations. Batteries must only be changed
or removed when light is o.
• Do not use or attempt to recharge a disposable CR123
battery! Do not throw the ashlight into a re as an
explosion may occur.
THE POWERTAC NO-HASSLE LIFETIME WARRANTY
PowerTac warrants our illumination tools to be free from
defects in workmanship and materials, including any
LEDs housed within, for the lifetime of the original parts
(The lifetime of the parts are specied by individual parts
manufacturers). If it is determined by us to be defective,
we will repair or replace your original purchase of these
products, at our discretion. Electronics, chargers, and
rechargeable batteries are covered for a period of two
years with proof of purchase. Normal wear and tear –
including lamps burning out, batteries draining, and
switches wearing out – is not covered, nor is damage
resulting from misuse, abuse, neglect, battery damage,
use of other non-approved batteries or altering these
products from their original state. Parts and accessories
for illumination tools are not covered by this warranty.
WARRANTY DISCLAIMER
The above warranty is exclusive, and to the extent
permitted by applicable laws, shall be in lieu of all other
warranties, express or implied, including, without
limitation, any warranty of merchantability or tness for a
particular use or purpose. PowerTac disclaims any and all
liability for product malfunctions, physical injuries, or
property damages that result in whole, or in part, from
the criminal, negligent, or improper use of the product,
or from modications or alterations thereto. In no event
shall PowerTac be liable for any incidental, special, or
consequential damages relating to the purchase, use, or
performance of any PowerTac product.
WARRANTY CLAIMS
Please go to www.powertaclights.com/warranty and
follow instructions.
USAGE INSTRUCTIONS
1. To install battery: Unscrew tail cap. Insert positive end of the battery
towards LED. Tighten the tail cap till it’s completely closed.
2. To turn the light ON: Push the back switch to click. Once Turned on the
ashlight will access the mode last used. To Turn the Light OFF, push the
back button to click.
3. To switch light levels: Turn the light on and press the side switch (click).
Press side switch again (click) will cycle to next light level.
4. Access the direct to strobe function: Turn light on and hold down side
switch (long click, 0.3 seconds). The light will remain on strobe until you
switch light levels.
5. Toggle Strobe / High Function: Access direct to strobe function; release
side switch; hold down side switch again (long click) and light will toggle
to high mode. Hold down side witch again (long click) and toggle to
strobe again.
DISTRIBUTED BY:
POWER TAC LIGHTS INC.
Middletown, NY 10941
www.PowerTacLights.com
