Ivation 6-in-1 Emergency Flashlight User manual

6-in-1 Emergency
Flashlight
User Guide
Hello!
Welcome to the Ivation™ family. This guide helps you get to know your new Emergency Flashlight a little better. For additional
information and technical support, please contact our helpful team at [email protected].
Intended use
This multifunction device is designed to offer drivers a number of safety tools in one small, lightweight, rainproof package. It sports a
3-LED flashlight, a red alert strobe, a seatbelt cutter, a window hammer, and a compass. The internal battery pack can be recharged via
USB or with the integrated crank handle, and can even provide a gentle charge for your other mobile devices.
For Your Safety
- Keep away from children under 8 years of age.
- Keep inside your vehicle or home for emergency use.
- Limit use in extreme weather and humid environments.
- When flashlight starts to dim, proceed to charge battery.
- To avoid battery drain, turn off flashlight when not in use.
- Clean with soft cloth and neutral detergent. Do not use strong solvents.
- Do not store together with objects that may be affected by magnetism.
- Metal, magnets and force may cause built-in mechanical compass to
malfunction. To ‘reset’ compass, shake device and/or remove from interference.
- When recharging with integrated crank handle, aim for steady cranking motion.
Forcible cranking may cause damage to internal gears.
What’s in the Box?
1 x Flashlight
1 x USB Adapter Cable
1 x Mini-USB Adapter
1 x Micro-USB Adapter
1 x 8-Pin Lightning Adapter
1 x Owner’s Manual
Parts & Controls
1. Seatbelt Cutter
2. Magnets
3. LED Flashlight
4. Window Hammer w/Cover
5. Charging In Port
6. Charging Out Port
7. Flashlight Power Button
8. Strobe Button
9. Crank Handle
10. Red Strobe
11. Compass
12. Wrist/Hanging Strap
123 4
5/6
789 1012 11
5/
6

Using Your Flashlight
Charging & Power:
Before first use, we recommend that you charge the internal battery fully. To charge it via USB, follow these steps:
1 Connect included micro-USB adapter to included USB adapter cable.
2 Insert micro-USB end into Charging In Port.
3 Insert USB end into computer USB port, or connect to wall outlet using adapter (not included).
4 On full charge, flashlight can work up to 6 hours.
To charge the internal battery using the integrated crank handle, follow these steps:
1 Flip Crank Handle outward.
2 Grip device with one hand, and crank handle with other in either direction.
3 For longevity of internal battery, do not exceed speeds of 120 rounds per minute.
4 For every 1 minute of hand cranking, flashlight can work for 10 minutes.
Note! While battery is charging – regardless of method used – a red indicator light will be lit in lower-right corner of LCD Display.
Flashlight & Strobe
• Press Flashlight Power Button to turn LED Flashlight on and off.
• Single-press Strobe Button to turn Red Strobe on and off.
Note! 4 magnets are embedded around the flashlight chamber. When in strobe mode, place the device on the roof of your vehicle. The
magnets will adhere to the roof, making the strobe visible for a greater distance.
Charging Mobile Devices:
The crank handle charging system is strong enough to provide a charge for your other mobile devices, as follows:
1 Select a charging adapter corresponding to your mobile device (included or your own), and connect it to included USB adapter cable.
2 Insert USB end of cable into Charging Out Port.
3 Insert other end into your mobile device’s charging in port.
4 Turn Crank Handle in either direction to charge your mobile device.
Note! At first, crank handle at relatively high speed, allowing your mobile devicen to detect incoming voltage and begin charging.
Technical Specifications
Battery: Polymer Lithium 3.6V 120mAh
Output: DC 5V 350mA
Input: DC 5V 500mA
LED Life: 10,000> Hours
LED Brightness: 2500 MCD
Strobe Brightness: 500 MCD
Weight: 8.6 Ounces
Dimensions: 10.83˝ x 3.74˝ x 2.28˝
Distributed by
C & A Marketing
2 Bergen Turnpike
Ridgefield Park, NJ 07660
[email protected]
Made in China
ivation is a trademark of
C&A IP Holdings, LLC
©2014 All right reserved
