Outwater PLUS TLL-PLUS Series User manual

1
Please keep hands away from the support bars. They move during height adjustment and
may cause injuries.
To avoid damage, please ensure all objects on the workstation are secure and not
exceeding the edges.
Adhesive clips help to keep cables organized. Please leave enough length of the cables to
allow for height adjustment.
To remove your computer and accessories, please rst raise the workstation to the highest
position in order to avoid any damage or injury.
If the workstation needs to be moved, please ask another person for assistance.
1-
2-
3-
4-
5-
Caution!
Please read all instructions carefully before using
this product. Keep this manual for future reference.
The specications of this product may vary slightly
from the illustrations and are subject to change
without notice.
24 River Road, P.O. Box 500, Bogota, NJ 07603-0500
Phone: [phone] • Fax: [phone]
www.outwater.com
ARCHITECTURAL PRODUCTS by OUTWATER
OVER THE DESK ADJUSTABLE TABLE
Model: PLUS TLL-PLUS- *
Assembly and instructions

2
Part List
A:3~15kg
B:<=2kg
A+B=3~15kg
A
B
150~500
580
566
680
590
610
°‹
740
°‹
A
C
x1
B
x1
x8 x4
x1
x1
x2
B
A
Note: The drawings above are for reference
only and may vary slightly from the actual
product. If you are missing any component
or have any questions, please contact
Architectural Products by Outwater.
min
min
Technical Data

3
Assembly Instructions
+
Please Remove packaging and place the
product on the table
Attach the decorative cover towards the
center of the x-shaped support.
Step 1
Please ensure that the table you are placing the
workstation on is at least the size shown on the
technical data page.
c
a
d
b
Step 2

4
c
a
d
b
c
a
d
b
Step 3
Step 4
Tighten
Hang the junction plate on the knobs shown
assembled and then tighten the knob on both
sides.
Attach the junction plate and keyboard
ray using 8 screws. Tighten with a Phillips
screwdriver.

5
Please do not put hands near the support
bars to avoid risk of injury during height
adjustment.
Step 5
Press the handle grips both sides
simultaneously and adjust the workstation to
the desired height.

6
Please ensure all objects on the
workstation are secure and not
exceeding the edges.
Step 6
Step 7
Place desired objects onto the workstation.
The wire management clips are self-adhesive
to stick to the underside of the workstation.
Please ensure that the cables will not hinder
the correct functioning of the table.
