Ovation HERO 700F User manual

USER MANUAL
HERO 700F
700W LED Moving Head Framing

Table of contents
Caution! ������������������������������������������������������������������������������������������������������������������ 3
Introduction ������������������������������������������������������������������������������������������������������������ 3
Safety instructions ������������������������������������������������������������������������������������������������� 3
Installation�������������������������������������������������������������������������������������������������������������� 4
Read ‘Safety information’ before installing the xture..............................................................................4
Fastening the xture to a at surface........................................................................................................4
Mounting the xture on a truss..................................................................................................................4
Securing with a safety cable ......................................................................................................................4
DMX-512 connection/connection between xtures..................................................................................4
Operation���������������������������������������������������������������������������������������������������������������� 5
Addressing...................................................................................................................................................5
Universal DMX Control................................................................................................................................6
RDM control.................................................................................................................................................6
Stand-alone Mode .......................................................................................................................................6
Master-Slave Operation ..............................................................................................................................6
Control Menu Map�������������������������������������������������������������������������������������������������� 7
DMX Protocol ��������������������������������������������������������������������������������������������������������� 9
Fixture Cleaning���������������������������������������������������������������������������������������������������� 11
Fuse Replacement������������������������������������������������������������������������������������������������ 12
Troubleshooting ��������������������������������������������������������������������������������������������������� 12
The xture does not work, no light...........................................................................................................12
Specifications������������������������������������������������������������������������������������������������������� 12

3Version 2.0
Caution!
Be careful with your operations. With a dangerous voltage you can suffer a dangerous electric
shock when touching the wires!
Avoid looking directly into the light source!
Wear protective glasses and other PPE (personal protective equipment) when working on or
near the xture.
For your own safety, please read this user manual carefully before you initial start-up.
Follow operating safety precautions and pay attention to warning signs methods and equip-
ment on the user manual.
Indoor use only! To prevent risk of re or shock, do not expose this product to rain or moisture.
IP 20 rating.
The ambient temperature must always be between -5° C and +45° C.
Always make sure you are connecting this product to the proper voltage in accordance with the
specications in this manual or on the product’s specication label.Make sure it is grounded
when using it!
Unplug mains lead before opening the housing!
Make sure that the power cord is never crimped or damaged by sharp edges. Check the xture
and the powercord from time to time.
Make sure to replace the fuse with another of the same type and rating.
Warning! This symbol indicates a hot surface. Certain parts of the housing can become hot
during operation. After use, wait for a cool-down period of at least 10 minutes before handling
or transporting the device.
Every person involved with the installation, operation and maintenance of this device has to
- be qualied
- follow the instructions of this manual
- consider this manual to be part of the total product
- keep this manual for the entire service life of the product
- pass this manual on to every further owner or user of the product
- download the latest version of the user manual from the Internet
Introduction
Thank you for having chosen Hero 700F. You will see you acquired a powerful and versatile device.
Unpack your item. Before you initial start-up, please make sure that there is no damage caused by
transportation. Should there be any, consult your dealer and do not use the device.
Safety instructions
This fixture is an extremely sophisticated piece of electronic equipment. To guarantee a smooth
operation, it is important to follow the guidelines in this manual. The manufacturer of this device will not
accept responsibility for damages resulting from the misuse of this xture due to the disregard of the
information printed in this manual.
This device has left our premises in absolutely perfect condition. Always disconnect from the mains,
when the device is not in use or before cleaning it. Keep away children and amateurs from the device!
There are no serviceable parts inside the device. Maintenance and service operations are only to be
carried out by authorized dealers.

4Version 2.0
Installation
Read ‘Safety information’ before installing the fixture
The xture is designed for indoor use only and must be used in a dry location with adequate ventilation. Ensure that
none of the xture’s ventilation slots are blocked.
Fasten the xture to a secure structure or surface. Do not stand it on a surface or leave it where it can be moved or
fall over. If you install the xture in a location where it may cause injury or damage if it falls, secure it as directed in
this user manual using a securely anchored safety cable that will hold the xture if the primary fastening method
fails.
Fastening the fixture to a flat surface
The xture can be fastened to a hard, xed, at surface that is oriented at any angle. Ensure that the
surface and all fasteners used can support at least 10 times the weight of all xtures and equipment to
be installed on it.
Fasten the xture securely. Do not stand it on a surface or leave it where it can be moved or fall over. If
you install the xture in a location where it may cause injury or damage if it falls, secure it as directed
below with a securely anchored safety cable that will hold the xture if the primary fastening method
fails.
Mounting the fixture on a truss
The xture can be clamped to a truss or similar rigging structure in any orientation. When installing the
xture hanging vertically down, you can use an open-type clamp such as a G-clamp. When installing in
any other orientation, you must use a half-coupler clamp that completely encircles the truss chord.
To clamp the fixture to a truss:
1. Check that the rigging structure can support at least 10 times the weight of all xtures and equipment
to be installed on it.
2. Block access under the work area.
3. Fold the legs of the mounting bracket together and bolt a rigging clamp securely to the mounting
bracket. The bolt used must be M12. It must pass through both mounting bracket legs and be
fastened with a self-locking nut.
4. Working from a stable platform, hang the xture with its clamp on the truss and fasten the clamp
securely.
5. Secure the xture with a safety cable as directed below.
Securing with a safety cable
Secure the xture with a safety cable (or other secondary attachment) that is approved for the weight of
the xture so that the safety cable will hold the xture if a primary attachment fails.
Loop the safety cable through the eyebolt in the back of the xture and around a secure anchoring point.
Do not loop the safety cable around the fixture’s mounting bracket only, as this will leave the fixture
unsecured if it separates from the bracket.
DMX-512 connection/connection between fixtures
Occupation of the XLR-connection:

5Version 2.0
1. Group
2. Signal (-)
3. Signal (+)
DMX OUT
1. Group
2. Signal (-)
3. Signal (+)
DMX IN
If you are using controllers with this occupation, you can connect the DMX-output of the controller
directly with the DMX-input of the rst xture in the DMX-chain. If you wish to connect DMX-controllers
with other XLR-outputs, you need to use adapter-cables.
Building a serial DMX-chain:
Connect the DMX-output of the rst xture in the DMX-chain with the DMX-input of the next xture.
Always connect one output with the input of the next xture until all xtures are connected.
DMX-512 connection with DMX terminator:
For installations where the DMX cable has to run a long distance or is in an electrically noisy environment,
such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption
of the digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120
resistor connected between pins 2 and 3, which is then plugged into the output XLR socket of the last
xture in the chain.
Caution: At the last fixture, the DMX-cable has to be terminated with a terminator. Solder a 120
resistor between Signal (–) and Signal (+) into a 3-pin XLR-plug and plug it in the DMX-output of the
last xture.
Connection with the mains:
The Hero 700F is equipped with auto-switching power supply that automatically adjusts to any 50-60Hz
AC power source from 100-240 Volts.
This xture must be earthed. To use the xture, a plug must be xed.
The correct assembly of a sufcient plug may be done by professional persons only.
The conductors in the cable are marked by the following table.
Connect the device to the mains with the enclosed power supply cable.
Cable color Connection International
Brown Live L
Blue Neutral N
Yellow/green Earth(Ground)
Operation
The Hero 700F can operate in three different modes. In each mode you can run the xture as a stand
alone fixture or in a master/slave confiugration. This next section will detail the dif-ferences in the
operating modes.
Addressing
All xtures should be given a DMX starting address when using a DMX signal, so that the correct xture
responds to the correct control signals. This digital starting address is the channel number from which
the fixture starts to listen to the digital control information sent out from the DMX controller. The
allocation of this starting address is achieved by setting the correct number on the display located on the
base of the device.

6Version 2.0
You can set the same starting address for all xtures or a group of xtures, or make different address for
each xture individually.
If you set the same address, all the units will start to listen to the same control signal from the same
channel number. In other words, changing the settings of one channel will affect all the fixtures
simultaneously.
If you set a different address, each unit will start to listen to the channel number you have set, based on
the quantity of control channels of the unit. That means changing the settings of one channel will affect
only the selected xture.
Universal DMX Control
This function allows you to use a universal DMX-512 controller to control the chases and patterns,
dimmer and strobe. A DMX controller allows you to create unique programs tailored to your individual
needs.
RDM control
The Hero 700F RDM can communicate using RDM (Remote Device Management) in accordance with
ESTA’s American National Standard E1.20-2006: Entertainment Technology RDM Remote Device Man-
agement Over DMX512 Networks.
RDM is a bi-directional communications protocol for use in DMX512 control systems, it is the open stan-
dard for DMX512 device conguration and status monitoring.
The RDM protocol allows data packets to be inserted into a DMX512 data stream without affecting ex-
isting non-RDM equipment. It allows a console or dedicated RDM controller to send commands to and
receive messages from specic xtures.
With RDM function, you can set the DMX address of your xtures remotely. This is especially useful when
the device is installed in a remote area.
Each Hero 700F has a factory set RDM UID (unique identication number).
Stand-alone Mode
In this mode, you can run internal program without a controller.
1. Press the Setting icon in in the touch screen.
2. Select the Fixture Set tab.
3. Press Up or Down button and select Run Mode and select Host.
4. The xture will run internal programs.
Master-Slave Operation
This function will allow you to link up to 16 units together and operate without a controller. In a Master-
Slave set up one unit will act as the controlling unit and the others will react to the controlling units
programs. Any unit can act as a Master or as a Slave.
1. Using approved DMX data cables, daisy chain your units together via the XLR connector on the rear
of the units.
2. For the Master unit press the Setting - Fixture set - Run Mode - Host icon in in the touch screen.
3. For the slave units press the DMX address icon in the touch screen. Set the DMX address to 001.
4. The slave units will now follow the Master unit.

7Version 2.0
Control Menu Map
The control panel on the front of the fixture, provides access to the system menu and is where all
necessary system adjustments are made to the fixture. LCD touch screen makes it very easy to
navigate the system menus.
During normal operation, pressing MENU button once will access the xture’s main menu.
Once in the main menu you can navigate through the different functions and access the sub-menus
with the UP, DOWN, and ENTER buttons.
Once you reach a eld that requires adjusting, press the ENTER button to activate that eld and use
the UP and DOWN buttons to adjust the eld. Pressing the ENTER button once more will conrm your
setting.
You may exit the main menu at any time without making any adjustments by pressing the MENU
button.
Main Menu Level 1 Level 2 Function
Setting
DMX channel 001-512 DMX address setting
RMD function Off Control mode, RDM
On
Language Chinese Language, Chinese
English Language, English
Screen rotatio Off Display Reverse 180°
On
Screen automatically
turning
Off Screen automatically
On
Screen saver Off Screen always on
On Black screen after 30 seconds
DMX signal
Keep According to the original state
continues to run
Reset The motor returns to position
and stops runn
X reverse Off X reverse movement
On
Y reversal Off Y reverse movement
On
XY swap Off The exchange of XY channels
(including ne-tuning)
On
XY encoder
Off
Using encoder (light coupling)
judging out-of-step and
automatically correct position
On Do not use the encoder (light
coupling) correct position

8Version 2.0
Running mode
Self-walk mode
DMX Receive DMX signals from
console or host
Since the go Self-walk and send DMX signal
to slave
Voice control
Manual control Manual control into the interface
Light xture reset All motors begin to reset
XY reset x, y motors start reset
MT reset The small motor begins to reset
System
informatio
Software Version Software Version
Temperatureinformation Fixture temperature
Fan information Display fan speed informat
The system time
Total light bubble Total light bubble time
The bright bubble Time of this bright bubble
Total used Cumulative usage time
The use The use of this boot since time
The access time
9999 means no encryption and
can be used for a long time;Other
numerical said the rest of the
time, have the encryption;
Sensors to
monitor
X hall
Y Hall
Color hall
CMY Cyan Hall
CMY magenta hall
CMY yellow hall
CTO Hall
Fixed pattern hall
Glass design hall
Glass rotates hole
pattern
Adjustable
JiaoHuoEr
Enlarge hole
Optocoupler Hall status
viewing,When the magnetic is
detected, it is 0, otherwise it is 1
Prism rotating hall.
X coding state
Y coding state
X encodes the step value
Y code the step value
Were walking direction, step
value should be increased,
walking in the opposite direction,
step value should be reduced.
System error
DMX monitoring
Dimming curve
SCurve (sinusoidal) The default is linear dimming
curve, reference the dimming
curve
InSquare (log)
Square (index)
Linear (straight line)

9Version 2.0
Motor
calibration
The X axis
The Y axis
Color
Gobo
Gobo 2
Gobo 2 Rotating
Gobo 3
Gobo 3 disc stroke
Display nger zero
Cyan
Magenta
yellow
Color temperature
Focusing
Zoom
Prism zero
Prism stroke
Prism rotating
Frost zeros
Frost trip
Cutting rotary disc
The aperture
Cut 1
Cut 1
... Cut 8
power 0-255 power regulati
DMX Protocol
36 CH mode Function DMX value Function Control
CH1 Pan 0-255 Pan movement by 540°
CH2 Pan ne 0-255 Fine control of pan movement
CH3 Tilt 0-255 Tilt movement by 270°
CH4 Tilt ne 0-255 Fine control of tilt movement
CH5 Pan/Tilt speed 0-255 Pan/Tilt speed, decreasing
CH6 Strobe
0-3 Closed
4-127 Pulse strobe slow to fast
128-191 Fade strobe, slow - fast
192-251 Random strobe slow to fast
252-255 Open
CH7 Dimmer 0-255 0-100 linear dimmer
CH8 C0-255
CH9 M0-255
CH10 Y 0-255
CH11 CTO 0-255

10 Version 2.0
CH12 Color
0-127 Linear color
128-137 Color 1
138-146 Color 2
147-155 Color 3
156-164 Color 4
165-173 Color 5
174-191 Color 6
192-222 Forwards rainbow effect fast to slow
223-224 Stop
225-255 Backwards rainbow effect slow to fast
CH13 light frost 0 No function
1-255 0-100% linear insertion
CH 14 Gobo
0-4 Open/hole
5-9 Gobo1
10-14 Gobo2
15-19 Gobo3
20-24 Gobo4
25-29 Gobo5
30-34 Gobo6
35-39 Gobo7
40-44 Gobo8
45-49 Gobo9
50-54 Gobo10
55-59 Gobo11
60-64 Gobo12
65-69 Shaking gobos from slow to fast 1
70-74 Shaking gobos from slow to fast 2
75-79 Shaking gobos from slow to fast 3
80-84 Shaking gobos from slow to fast 4
85-89 Shaking gobos from slow to fast 5
90-94 Shaking gobos from slow to fast 6
95-99 Shaking gobos from slow to fast 7
100-104 Shaking gobos from slow to fast 8
105-109 Shaking gobos from slow to fast 9
110-114 Shaking gobos from slow to fast 10
115-119 Shaking gobos from slow to fast 11
120-124 Shaking gobos from slow to fast 12
125-190 Forwards rainbow effect fast to slow
191-192 Stop
193-255 Backwards rainbow effect slow to fast
CH15 Rot. gobo
0-9 Open/hole
10-19 Gobo 1
20-29 Gobo 2
30-39 Gobo 3
40-49 Gobo4
50-59 Gobo5
60-69 Gobo6
70-79 Shaking gobos from slow to fast 1
80-89 Shaking gobos from slow to fast 2
90-99 Shaking gobos from slow to fast 3
100-109 Shaking gobos from slow to fast 4
110-119 Shaking gobos from slow to fast 5
120-129 Shaking gobos from slow to fast 6
130-190 Forwards rainbow effect fast to slow

11 Version 2.0
191-192 Stop
193-255 Backwards rainbow effect slow to fast
CH16 Gobo Auto
0-127 0-400°
128-190 Forwards rainbow effect fast to slow
191-192 Stop
193-255 Backwards rainbow effect slow to fast
CH17 Effect Insertion 0-10 Open/hole
11-255 linear insertion
CH18 Effect
0-2 Stop
3-128 Forwards rainbow effect fast to slow
129-255 Backwards rainbow effect slow to fast
CH19 Focus 0-255 From far to near
CH20 Focus ne 0-255
CH21 Zoom 0-255 From small to large
CH22 Prism1 0-127 Open position (hole)
128-255 Prism1
CH23 Prism1 rotation
0-127 0-400°
128-187 Forwards rainbow effect fast to slow
188-195 Stop
196-255 Backwards rainbow effect slow to fast
CH24 Prism Auto ne 0-255
CH25 Heavy frost 0-127 No function
128-255 Frost
CH26 Cutting slice1 0-255 linear insertion
CH27 a slice 2 0-255 linear insertion
CH28 a slice 3 0-255 linear insertion
CH29 a slice 4 0-255 linear insertion
CH30 a slice 5 0-255 linear insertion
CH31 a slice 6 0-255 linear insertion
CH32 a slice7 0-255 linear insertion
CH33 a slice 8 0-255 linear insertion
CH34 Cutting disc 0-255 linear insertion
CH35 Iris 0-255 range from large to small
CH36 function
210-215 Reset over 6 seconds XY
220-235 Reset effect motor in more than 6 seconds
240-255 Reset all in more than 6 seconds
Fixture Cleaning
Due to fog residue, smoke, and dust cleaning the internal and external optical lenses and mirror should
be carried out periodically to optimize light output. Cleaning frequency depends on the environment in
which the xture operates (I.e. smoke, fog residue, dust, dew). In heavy club use we recommend cleaning
on a monthly basis. Periodic cleaning will ensure longevity, and crisp output.
To clean the xture:
1. Disconnect the xture from power and allow it to cool for at least 10 minutes.
2. Vacuum or gently blow away dust and loose particles from the outside of the fixture with low-
pressure compressed air.
3. Clean the surfaces by wiping gently with a soft, clean lint-free cloth moistened with a weak detergent
solution. Do not rub glass surfaces hard: lift particles off with a soft repeated press. Dry with a soft,
clean, lint-free cloth or low-pressure compressed air. Remove stuck particles with an unscented
tissue or cotton swab moistened with glass cleaner or distilled water.
4. Check that the xture is dry before reapplying power.

12 Version 2.0
Fuse Replacement
This fuse is located in a fuseholder next to the MAINS OUT socket on the connections panel.
To replace a fuse:
1. Disconnect the xture from power and allow it to cool for at least 10 minutes.
2. Unscrew the cap of the fuseholder and remove the fuse. Replace with a fuse of the same size and
rating only.
3. Reinstall the fuseholder cap before reapplying power.
Troubleshooting
Listed below are a few common problems that you may encounter, with solutions.
The fixture does not work, no light
• Check the connection of power and main fuse. Be sure the external fuse has not blown.
• Measure the mains voltage on the main connector.
Specifications
Model Hero 700F
Power supply: AC100 - 240V, 50/60Hz
Light source: 700W white LED
Color temperature: 8000K
Color Rendition: CRI ≥70 or CRI 95 optional
Pan: 540°
Tilt: 270°
Zoom: 5.5°~50°motorized
Power connection: PowerCON in & out
Signal connection: 3-pin XLR in & out(5-pin optional)
DMX channel: 36
Control mode: RDM, DMX, Auto program, Sound, Master-slave
Housing: Colour black, ABS+PC
Size: 420 x 290 x 800 mm
N.W.: 32.7 kg
Dimming: 0%-100% dimming
Accessories(included): Power cable, safety rope, manual
Accessories (optional): Omega bracket
Enviroment: IP20
Please note: All information is subject to change without prior notice. 18.08.2023
