Over Obox User manual

Version 1.2 - Subject to change without notice

OBOX

GATEWAY DATALOGGER

1 ETHERNET PORT

2 USB PORTS

CLOUD CONNECTION

EDS BUS COMMUNICATION

INTEGRATION OF THIRD-PARTY SYSTEMS

INTERNET CONNECTION VIA

ETHERNET/LAN OR DATA SIM CARD

STANDARD 9-WAY DIN-RAIL MOUNT

OBox is the gateway of the OVER energy management and indoor air quality system able to connect the

network of EDS devices (OMeter, NanOMeter, OSensor, etc.) with the OVER infrastructure cloud platform,

through an ETHERNET/LAN port or DATA SIM card. The connection between the OBox and the cloud

complies with the highest IT security requirements, allowing communication on the local network even in

sensitive environments such as banks. The OBox is designed for standard 9-way DIN-rail mount.

Version 1.2 - Subject to change without notice

2Version 1.2 - Subject to change without notice

MODEL OBox

PRODUCT CODE OBB

CERTIFICATIONS RoHS, CE

UAE RoHS, ECAS

SIZE 159x90x63mm - 9 DIN modules

WEIGHT 340g

POWER SUPPLY 12÷15Vdc from EDS Bus

CURRENT DRAW max 1A, average 200mA

BUS COMMUNICATION EDS, MODBUS

INTERNET CONNECTION Connectivity through Ethernet or

by using internet stick (not included)

CLOUD COMMUNICATION PROTOCOL HTTPS

DISPLAY Monochromatic LCD 1.53x1.38 inch for working

operational icons

OPERATING TEMPERATURE min -10°C

max 50°C

WAREHOUSING TEMPERATURE min -40°C

max 80°C

DATA SHEET

INSTALLATION INSTRUCTIONS

SAFETY

In order to maintain these conditions and ensure safe use, the user must follow the indications and markings contained in the following instructions.

• Upon receipt of the instrument, before proceeding with the installation, check that it is intact and has not been damaged during

transport.

• Check that the operating voltage and the mains voltage coincide and then proceed with the installation.

• The instrument power supply must not be grounded.

• The instrument does not have a fuse to protect the power supply, so it must be protected by the installer

• Maintenance and/or repair operations must be performed only by qualied and authorized personnel.

• If you suspect that that the instrument is no longer safe, remove it from service and ensure that it is not used inadvertently

• Dangerous voltages can be present in the terminals of the instruments. Following standard safety precautions before performing

any installation or service activity.

• The instrument and its connections must be properly protected.

• The instrument must be installed following all local regulations.

Version 1.2 - Subject to change without notice

OPERATION

Once the BUS is connected, the OBox will start in about 1 minute and messages will appear on the display. A longer start-up time may indicate a lack of

DHCP service by the router or a failure to connect the Ethernet cable to the OBox and/or router. During the start-up phase the two progress bar described

below will be shown on the display.

Screen 1

After connecting the OBox, wait for approximately 30 seconds to display the start-up screen on the LCD monitor. The code that appears under the

heading “starting” (“192.168.1.100” in the example in gure 2) is the IP address that the Obox has acquired from the router.

Screen 2

The second screen indicates that the Obox can be reached via Ghost for any remote access/assistance services. The alphanumeric code (“ABC123”

in the example in gure 2) that appears above the IP address is the identication of the system (ID) while the progress bar at the bottom indicates the

stage of the start-up procedures.

Screen 3

At the end of the start-up procedure, the system’s “home” screen will pop up as demonstrated in the gure below.

HOME screen

1Mobile signal power: indicates the signal strength in case the OBox has been connected to the internet via an internet key.

2Network connection: the presence of this symbol indicates that the OBox is connected to a local network.

3Cloud: indicates that the OBox can be reached remotely via the Over cloud service.

4Power supply: indicates that the OBox is correctly powered by BUS.

5IP: The IP alternates with the software version installed on the OBox (in the example gure the version name is Antares1234), with the conguration

and with the date.

6ID: unique identication of the OBox useful in case of assistance, maintenance and remote access through the Cloud platform.

7Messages per second: it is indicative of the trac on the BUS (number of messages per second). Values above 30 indicate that the BUS (in normal

operation) is congested. However, high values are permissible during scanning/ programming (up to 100 messages per second).

Screen 4/5

It indicates that the shutdown of the OBox is occurring when the SOFT HALT button on the top

of the device is pressed. Rarely should the screen remain blocked on-screen n°4 even if the swi-

tch-off has alrady taken place. In this circumstance, it is acceptable to disconnect and re-connect

the power supply in order to force a restart of the OBox.

Screen 6

It indicates that the OBox is restarting when the “REBOOT” button on the top of the device is

pressed.

Screen 1 Screen 2

Screen 4 Screen 5 Screen 6 Particular symbols

When the power turns to battery

mode, the icon labeled ‘battery mode’

appears with a percentage of the re-

maining charge. This icon replaces

the standard icon no. 4 of the HOME

screen, until battery mode is no longer

active.

Battery

mode

HOME screen

The OBox is equipped with 3 buttons, located on the opposite side of the BUS and network inputs. The “ON / OFF” button performs a forced shutdown

of the OBox. The Display will then be turned off immediately. Unlike the other two, this button needs a long press. The “SOFT HALT” button performs a

safe shutdown of the OBox. It should therefore always be considered the preferred option, when possible, switching the device ON / OFF. The “REBOOT”

button performs a restart of the software application.

4Version 1.2 - Subject to change without notice

CONNECTION EXAMPLE

ASSISTENCE

WARRANTY

This product is guaranteed against any material and manufacturing defects according to the period established by law from the date of purchase, even if

the product has not been installed. The warranty period starts from the moment of purchase. The buyer must report any defects in the delivered products

in writing to Over S.p.A.: the communication must contain a description of the reasons for defects and/or discrepancies, also indicating the serial

number, the delivery date, the delivery number and date of the transport document or invoice.

The Supplier’s warranty does not extend to products that are defective and/or damaged due to natural attrition or breakdown caused by improper use

or an operating procedure not contemplated in this manual, of negligence, or are tampered with or repaired by third parties or accidentally damaged

caused by atmospheric agents, or rmware updates.

The warranty intervention by the Supplier remains subject to the Buyer’s compliance with the payment conditions as well as the technical evaluation of

the existence of the warranty conditions veried by Over S.p.A. During the warranty period, Over S.p.A. undertakes to repair or replace, free of charge,

those products that have manufacturing defects or bad quality at its headquarters.

RETURN AND REPAIR PROCEDURE

All returned products must be returned in the same condition in which they were supplied at the Buyer’s expense, to the headquarters of Over S.p.A. in

Viale Piemonte 37 - 20093 Cologno Monzese (MI) and packed by the Buyer in order to avoid damages for which the Buyer himself would be responsible.

No return of goods will be accepted in the absence of authorization by Over S.p.A. to the Buyer.

No refund, even if authorized, will be accepted if the information regarding quantity, type of device returned and reason for return is not included in the

transport document or the accompanying letter.

Products not covered by the warranty will be returned to the Buyer at his own expense and charged to him for the costs incurred, after quantication and

communication, for the control and further testing and calibration of the same.

The replaced parts remain the property of Over S.p.A.

DECLARATION OF CONFORMITY

Over S.p.A. declares that its family of instruments complies with the directives EMC 89/336/ECC 73/23CE 93/68 CE and meets the requirements of the

following product standards IEC 61326, IEC 61010.

The device was tested in the typical installation conguration and with peripherals complying with the directive EMC and the low voltage directive

Device designed, produced and distributed by Over S.p.A.

This manual was last updated on 04/27/2021.
