Overland Storage SnapExpansion XSR Guide

10400588-001 ©2014 Overland Storage, Inc. Page 1 of 4
*10400588001*
SnapExpansion XSR™
Spare Chassis Replacement Instructions
This document describes how to replace a SnapExpansion XSR
chassis from Overland Storage.
WARNING: To reduce the risk of electric shock or damage to
equipment, always remove any power cords while working
with the unit.
WARNUNG: Um das Risiko eines elektrischen Schlags oder
Schäden am Gerät zu vermeiden, ziehen Sie stets den
Netzstecker, bevor Sie an der Einheit arbeiten.
AVERTISSEMENT: Pour réduire le risque de choc électrique
ou endommagement de l'équipement, retirez toujours les
cordons électriques en travaillant avec l'appareil.
CAUTION: While working with the unit, observe standard
Electrostatic Discharge (ESD) precautions to prevent damage
to micro-circuitry or static-sensitive devices.
Prepare the Unit
Power Off and Disconnect
If the system is still running, power it down cleanly:
1. Use the Web Management Interface to shut down the
head unit (Maintenance > Reboot and Shutdown >
Shutdown).
This also powers off all the expansion units.
2. When all the LEDs are off, at the expansion unit being
updated, disconnect the power cords.
3. Disconnect the remaining cables from that unit.
Remove the Front Bezel
1. Carefully take hold of the front bezel and pull it straight
out from the appliance until the magnets release.
2. Set the bezel aside on a secure surface.

10400588-001 ©2014 Overland Storage, Inc. Page 2 of 4
Spare Chassis Replacement Instructions
Remove the Drives
IMPORTANT: Overland recommends that you remove the disk
drives to reduce the unit’s weight prior to removal.
Remove all the drive carriers, noting from which slot they were
removed. Blank carriers can remain in their bays.
NOTE: Do not remove the disk drives from their carriers. Doing so
voids the drive warranty.
1. Press the release button on the right side of the carrier.
2. Using the built-in handle, pull the carrier out.
3. Number the carrier and set it on a secure surface.
4. Repeat Steps 1–3 for all the remaining drive carriers.
Remove Unit from Rack
WARNING: It is recommended that a mechanical lifter (or at
least two people) be used during rack installation or removal
to prevent injury.
WARNUNG: Um Verletzungen zu vermeiden, empfehlen wir
zur Rack-Installation oder -Deinstallation die Nutzung einer
mechanischen Hebehilfe (oder mindestens zwei Personen).
AVERTISSEMENT: Pour éviter toute blessure il est
recommande qu'un monte-charge (ou deux personnes au
moins) soit utilisé lors de l'installation ou de l'enlèvement du
support.
1. Remove and retain the four screws securing the unit to
the rack.
2. With a lifter positioned in front of the array, release the
rail locks and slide the chassis out onto the lifter.
3. Move the chassis onto a secure surface.
4. Unpack the new chassis and place it next to the old one.
Transfer Components
Move Inner Sliding Rails
1. Remove and retain the screws securing one of the rails to
the old chassis.
2. Position the rail on the new chassis, and secure it with
the retained screws.
3. Repeat Steps 1–2 for the other rail assembly.
PressPull Handle
1
5
9
2
6
10
3
7
11
4
8
12
Old Chassis New Chassis
Secure Surface

10400588-001 ©2014 Overland Storage, Inc. Page 3 of 4
Spare Chassis Replacement Instructions
Move Power Supplies
1. At the old chassis, press the top release latch and pull
the power supply out using the black handle.
2. At the new chassis, slide the power supply into a bay
until it locks (clicks).
3. Repeat Steps 1–2 for the remaining power supply.
Reassemble the Unit
Install New Chassis in Rack
1. Slide out the middle rails from the rack.
2. Using the mechanical lifter, position the new chassis in
front of the rack.
3. Insert the inner rails into the middle rails and slide the
unit into the rack.
4. Using the four retained screws, secure the SnapServer
to the front of the rack.
Reinstall Drives
Return the drive carriers to the same drive bays:
1. Referring to the numbering, position a drive assembly in
front of its empty bay in the new chassis.
2. Slide the assembly in until the latch clicks, securing it.
3. Repeat Steps 1–2 for all remaining drive carriers.
IMPORTANT: To maintain proper airflow and cooling, a drive
assembly or a blank carrier must be installed in every bay. No
empty bays are allowed.
Reattach Cables and Power Cords
1. Reattach all cables to the same connections as before.
2. Attach the power cords.
3. Power on/reboot the head unit so.
Press
Push In Using Handle
Power Sockets Cable Ports

10400588-001 ©2014 Overland Storage, Inc. Page 4 of 4
http://support.overlandstorage.com
You can get additional technical support on the Internet at the Overland Storage Support web page, or by contacting Overland Storage using
the information found on the Contact Us page on our web site.
Spare Chassis Replacement Instructions
Reattach the Bezel
1. Position the bezel with the tabs aligned inside the top
and bottom edges of the chassis.
2. Move bezel toward the unit until the magnets connect.
3. Verify that the bezel is aligned properly, all the LEDs are
visible, and the Power panel is centered in the left flange.
Return Replaced Parts to Overland
1. Place the old chassis in the anti-static bag and put it in
the replacement part’s box.
2. Use the existing packing materials to secure it.
3. Use an RMA to return the part to Overland Storage.
For return shipping details and RMA number, go to:
http://docs.overlandstorage.com/return-instructions
Magnets Tabs
