User Manual
USER MANUAL Model No: 3089
Heavy Duty 1400W Pond Cleaner
•This product is not a toy, and is only to be used for its designated purpose.
•This product is intended for indoor use only.
•Never carry out any alterations or modifications to this product.
•Ensure the power supply to the socket into which the appliance is plugged, is in
accordance with the rating label on the appliance and that the socket is earthed.
•When the appliance is not in use, always unplug from the mains socket.
•To protect against electrical shock, do not immerse cord or the plug into water.
•Ensure the power supply to the socket into which the appliance is plugged, is in
accordance with the rating label on the appliance and that the socket is earthed.
•Make sure to regularly clean the filter to avoid any possible issues.
•Make sure that all obstacles that you do not intend to vacuum are cleared before
using the vacuum as these may cause the suction tube to block.
•Do not use the appliance to remove any burning or smoking objects, such as
cigarette matches or hot ashes, or any flammable liquids.
•Keep the pipe and tube ends away from the body.
•Keep hair, loose items of clothing, fingers and all other extremities away from any
openings and moving parts.
•Never leave the vacuum next to a source of heat.
•Clean only with a damp cloth. Do not use strong industrial cleaning substances or
abrasive materials.
•Do not expose the vacuum cleaner to the elements as this may cause the appliance
to break.
•This appliance operates using dangerous voltage levels. Never switch it on if the
power supply cable is damaged, or if any other damage is visible on the appliance.
Never open the housing but instead contact a qualified electrician for help.
•If the product is damaged or has any defects, please contact cs[email protected]
USER MANUAL Model No: 3965USER MANUAL Model No: 3089
Safety Instructions
Notice: Ensure you read and fully understand instructions before use
While every attempt is made to ensure the highest degree of protection in all equipment, we cannot
guarantee freedom from injury. The user assumes all risk of injury due to use. All merchandise is sold on
this condition, which no representative of the company can waive or change.
Cleaning and Care
1. Before you begin to clean the product, make sure
that the product is off and is unplugged from the
socket.
2. Take the lid off of the vacuum cleaner by
unclipping the clips on the side of the lid. When
removing the lid, be sure to not drop of throw the lid
to the side as the filtration system is built into the lid
and doing so will cause damage to the system.
3. Remove the filtration bag, ensuring that all items
brought in by the input tube are in the bag. Empty
the filtration bag into the correct bin. Wash the
inside of the vacuum cleaner. Put the filtration back
inside the vacuum cleaner. Do not throw the
filtration bag away.
4. If you have used an extender pipe and one of the
attachments, simply wash out the extender pipe
with arm, soapy water and leave to dry. With the
pipe attachments, run them under warm water and
dry manually.
5. Before plugging the product back in, make sure all
areas around the electrical components are dry to
avoid injury and product damage.
Before First Use
•Remove the lid and take all the parts out from
inside the vacuum cleaner. Be sure to check that you
have all the parts.
•Attach the filtration back to the highest hole in the
vacuum cleaner.
•Be sure to check the labels on the plug and ensure
the volts correlate to the volts from the wall socket.
How to Use
1. Place the input tube inset the top hole in the
vacuum cleaner, then place it into the water source.
2. Place the output tube into the opposite hole in the
vacuum cleaner, then place it in the same water
source.
3. Press the ‘ON/OFF’ switch into the ‘ON’ position.
This will cause the water to begin to be sucked into
the vacuum cleaner. Allow the vacuum cleaner to
work. It will suck water in then automatically filter
out the clean water (removed of items such as
stones and wood). Allow this to continue until the
filtration bag is fully or you have cleaned the pond.
4. Once finished, remove both tubes from the
vacuum cleaner and empty the filtration bag. Place
all items into the vacuum cleaner and then store.
Use as a Dry Vacuum Cleaner
ATTENTION: Only use the unit as a dry vacuum cleaner
with the enclosed filter bag!
1. Ensure the unit stands safely.
2. Switch the unit off with the switch and pull the power
plug.
3. Unlock the container locking system and remove the
motor housing.
4. Pull the enclose filter bag over the suction socket
inside the container.
5. Refit and lock the motor housing. Connect the unit to
the power supply and turn it on with the switch.
Select a suitable nozzle.
6. Once you are finished with the product, turn the unit
off at the switch.
USER MANUAL Model No: 3089
Wearing Parts
Foam filters, valve rubber parts and filter bags are
wearing parts and are, therefore, not covered by our
warranty.
Storage
Empty out the collection container and clean the
unit. Store in a dry, frost protected room,
inaccessible to children.
Troubleshooting
Cause
Remedy
The unit does not perform its suction function
Drain Hose incorrectly fitted
The non-return valve must be located at the free
end of the drain hose
Excessive height difference between water level
and unit
The unit does not reach its full capacity
Dirt has accumulated in the foam filter, in the
suction tube or in the suction hose
Remove dirt
Dirt has accumulated in the area of the non-return
valve at the drain hose preventing it from closing
properly
Remove dirt
The collection container does not drain, the unit
switches off immediately following the drain pause
The collection container cannot drain
Lay the drain hose without kinks. Provide a slight
gravity for the drain hose. Once drained, the
container must be almost completely empty
The collection container and drain hose are soiled
Remove dirt
Low suction capacity
The more tubes that are used, the higher the tube
frictional resistance-the suction capacity reduces
How to improve the suction capacity:
Hold the suction tube as flat as possible
USER MANUAL Model No: 3089
Imported into the EU by Oypla.com LLP, Uxbridge, UB8 2FX
Environmental Protection
Products bearing the symbol shown above means that used electrical and electronic equipment (WEEE) should not be mixed with general
household waste. For proper treatment, recovery and recycling, please take this product(s) to designated collection points where it will be
accepted free of charge. Disposing of this product correctly will help save valuable resources and prevent any potential negative effects on
human health and the environment, which could otherwise arise from inappropriate waste handling. Please contact your local authority for
further details of your nearest designated collection point. Penalties may be applicable for incorrect disposal of this waste, in accordance with
your national legislation.
Please retain a copy of all instructions for future
consultation.
