Ozark Trail Pop-Out A-Frame User manual

OWNERS MANUAL
OZARK TRAIL
Pop-Out A-Frame
Model: WT186565
CLEANING:
Allow dirt to dry on the tent fabric after a rainfall before lightly
sweeping it off with a brush. For tougher stains, spray the area
with water and lightly wipe it off with a few strokes. Do not use
washer or dryer. DO NOT SCRUB THE FABRIC. ALWAYS MAKE
SURE YOUR TENT IS COMPLETELY DRY BEFORE REPACKING.
WARNING!
DANGER!
Stoves, lanterns, candles,grills,heaters and other fuel burning
devices produce carbon monoxide and will consume the
available oxygen in this tent. Use of such devices in this tent
will cause asphyxiation, carbon monoxide poisoning, and death
or serious and permanent injuries. For this reason:
- DO NOT use fuel burning devices inside or near this tent
- Your failure to follow this warning will cause death or serious
and permanent injury to you or others using this tent.
- KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS
TENT FABRIC. This tent is made with flame-resistant fabric,
which meets CPAI-84 specifications. IT IS NOT FIRE PROOF!
The fabric will burn if left in continuous contact with any
flame source. The application of any foreign substance to
the tent fabric may render the flame resistant properties
ineffective.
- Anchor your tent properly at all times and carefully consider
campsite choice. Be aware of possible falling rocks or tree
limbs, lightning strikes, flash floods, strong winds and other
hazards which may cause injury to tent or occupants.
- Have minimum of two adults assemble tent. During assembly
tent poles are under tension. If not held firmly in place during
assembly, poles could break or flip up possibly causing
serious injury.
- Safety glasses may be worn throughout the assembly
process as an additional precaution.
6 MONTH REPLACEMENT PARTS WARRANTY
This product carries a replacement parts warranty against defects
in materials and workmanship for a period of 6 months from date
of purchase. At its discretion, manufacturer may provide
replacement parts. Original purchaser will be required to provide
proof of purchase. The consumer will be responsible for shipping
cost incurred outside of the US or Canada.
Warranties DO NOT cover normal wear and tear, misuse, abuse,
inclement weather conditions (i.e. wind, rain, hail, lightning,
tornados or hurricanes) or other acts of God, mildew and rotting,
damage or fading caused by prolonged exposure to UV rays. This
warranty gives you specific legal rights. You may also have other
rights which vary from state to state.
Under no circumstances shall the manufacturer be liable for
any incidental or consequential damages.
Although our tents are manufactured according to rigorous
specifications, periods of wind or rain may loosen the stakes and
cause the frame to sink into the ground.This will weaken the
structure’s overall rigidity. Puddles may also form on the roof if
the unit has not been assembled tightly. If pooling should occur
it is advisable to drain the fly to avoid possible damage to frames
and fabric. Adjustment of guy lines may be necessary.
In case of inclement weather remove valuables and seek
appropriate shelter.
Tents are intended for recreational use only.
CAMPERS TIPS
The key to an enjoyable camping experience is planning and
preparation.
Before you go …
Research the area where you intend to camp. Prepare for any
possible weather condition. Be aware of hazards and emergency
protocol. Know the rules and regulations.
Check out your equipment before your trip. Be sure your cook
stove, lanterns, flashlights, air mattress, etc.are in good working
order. Erect your tent to become familiar with setup. Once
you’ve assembled your tent in a dry, well ventilated area, apply
seam sealing compound to the stitching of the inside seams
following manufacturer’s directions. Allow to dry thoroughly
before storage. Reapply annually.
Check lists are great planning tools. Here are some areas to
consider.
Camp Set-up: Tent, chairs, table, ground cloth, entrance mat, tarp,
poles, rope, stakes, bungee cords, duct tape, zip ties,
hammer/tools, bedding.
Kitchen set-up, Food and Beverages: Plan for transport,
preparation, storage and disposal. Remember fire-starting
devices in waterproof containers, pots, dishes, utensils, can
opener, heavy duty trash bags and biodegradable soap. Store
your food in lockers or out of sight in vehicles.
Clothing: Be prepared for all your activities. Include a hat,
sunglasses and quality socks. Dress in layers.
Hygiene: Personal toiletries, rubber gloves, basic first aid items.
Don’t forget your medications.
Miscellaneous: Extra batteries, sewing kit, clothes pins, dust
pan/brush and insect repellant.
Be considerate of others, human and wildlife.
Remember the clean up, dispose of waste properly.
“Leave no trace behind.”
DO NOT...
- Pitch tent near open fire.
- Use candles, matches or open flames of any kind in or near a
tent.
- Leave campfire unattended.
- Leave children unattended inside a tent.
- Use fuel-burning,oxygen-consuming devices (heaters, lanterns,
cooking stoves or other flame sources) inside your tent.
- Build campfires upwind of a tent.
- Refuel lamps, heaters or stoves inside a tent.
- Smoke inside a tent.
- Store flammable liquids inside a tent.
- Use water repellent compounds on your tent other than those
recommended for use on outdoor equipment.
- Spray the tent with insecticide.
- Store tent on concrete floor.
DO...
- Always extinguish campfire before sleeping or leaving the area.
- Exercise care when using electricity and lighting in and near
tents.
- Make certain your tent is properly ventilated in all weather
conditions. In extreme weather conditions, snow could
obstruct airflow and cause asphyxiation unless cleared
frequently.
- Anchor your tent securely to provide additional security in
changing climatic condition. Snow pegs,skis and/or heavy
rocks may be necessary to supplement tent stakes and guy
lines.
- Take your tent down and store properly after camping.
NOTICE!
Do Not Return to Store
for Warranty issue call
8 8 8 – 2 8 0 – 7 8 7 6
WT186565 8/17

WT186565
ASSEMBLY INSTRUCTIONS
Step 1:Verify package contents
Step 3: Pop-out walls
Step 2: Unfold tent
1) Remove tent from carry bag.
2) Unfold the tent with fabric floor down.
IMPORTANT NOTES:
* Assemble your tent before camping to become
familiar with the assembly.
* Select a clean, level area for the campsites, free
of debris and sharp objects, away from a
natural watercourse.
* Use of a ground cloth is recommended to
prolong the life of the tent floor and provide
additional insulation and moisture protection.
* To prevent damage to the zippers, unzip the
doors and windows of the tent prior to
disassembly, allowing air to move freely.
* Seam seal the inside stitched seams of the tent.
This will improve weather resistance. Available
in sporting goods departments. Discoloration
may occur if applied to outside seams.
WT186565 8/17
Tent : 1 each
Fiberglass Poles : 2 each Pre-Attached
Rainfly : 1 each
Tablet Pocket : 1 each
Tent Stakes : 13 each
1) Grasp the roof line along one wall.
2) Lift the roof line and locate the loop attached to the center hub.
3) Grasp the roof line with one hand. With your foot along the bottom edge of the wall, grasp the loop and pull outward. The wall will pop out erecting the wall.
4) Repeat to erect the other wall.

Step 5: Attach flyStep 4: Stake tent
1) Stake down the tent by inserting a stake
through the stake loops, located at the
corners of the tent.
2) Make certain the tent floor is pulled out
evenly and tightly.
3) Hammer the stakes into the ground at a
45 degree angle using a hammer or mallet.
Step 6: Fully assembled
Media pocket may be attached to loops at back wall.
Guy lines must be secured for proper function.
1) Remove all stakes and fold guy lines.
2) Remove accessories.
3) Remove fly.
4) Collapse each wall, pushing inward at the center hub.
5) Once flat, fold and roll the tent. Place in the carry bag.
6) Place stake in their bags inside the carry bag
Disassembly
WT186565 8/17
1) Unfold the fly and place over the tent with logo at the door.
2) Attach the hooks on the fly to the D-ring on the tent corners.
3) Stake the guy lines from each top corner.
4) Stake the fly through the loops at either side of the front door, at back flap and at each side.
Tent appears as shown. Note:Tent must be clean and dry before storage. Store in a clean dry area off concrete.

A2
KEY
NO.
MODEL NO. WT186565 QTY.
REQ
DESCRIPTION
Fiberglass pole set HFP11-135cx4+hub
1
HTFWT186565
Replacement fly
13
HMS4-7
Tent stakes
PART NO.
REPLACEMENT PARTS
TROUBLESHOOTING GUIDE
PROBLEM
1. CONDENSATION
2. SEAM LEAKAGE
3. MILDEW
4. REPAIRING A TEAR
5. FAULTY ZIPPER
6. FADING FABRIC
7. FLOOR CONDENSATION
This is caused by lower temperatures on the outside of the tent combined with body heat on the inside of the tent.When this occurs, avoid touching walls to reduce
contact leakage. Leaving the doors and windows open will reduce moisture condensation. Store wet clothing outside of tent. Not applicable to screen houses.
Apply a generous amount of seam sealer on inside seams. Seam sealer may be purchased at any local sporting goods store.
To avoid mildew, store tent/screen house ONLY when thoroughly dry. However, if mildew occurs use a soft bristle brush or sponge with mild dishwashing soap or Fels
Naptha soap to clean. Let dry thoroughly and a tent approved water repellent compound may be applied.
For small tears use a self-adhesive patch kit.We recommend a canvas or awning repair shop for larger tears.
Zippers are self repairing.If the zipper separates, you can move the slider to the beginning of the zipper tape and rework the zipper.
Do not leave up in direct sunlight longer than necessary. If left in sunlight for prolonged periods of time, fabric will fade and weaken.
A ground cloth under the floor helps prolong its life, provides additional insulation and moisture protection.The cloth should be smaller than the floor to prevent rain
from running under the tent. Not applicable to screen houses.
8. USE OF STAKES Stakes should be installed at a 45 degree angle using a hammer or mallet. Stake loops should be kept taut without over stretching fabric or webbing. This could cause
tears or leakage.To remove safely, use a hammer or stake puller. Do not remove by pulling on the fabric.
SOLUTION
WT186565 8/17
SPECIFICATIONS: 3 Persons
Floor size: 6.5’ x 6.5’ (1.98 x 1.98 m)
Center Height: 65” (1.65 m)
Weight: 11 lb 7 oz (5.19 kg)
