Ozito IGP-2018 User manual

PETROL
INVERTER
GENERATOR
2000W MAX. POWER
INSTRUCTION MANUAL
SPECIFICATIONS
Engine: 4-Stroke, OHV, 1-Cylinder
Displacement: 119cc
Max. Power: 2,000W (2min)
Rated Power: 1,800W
Economy Mode Power: 500W
AC Outlets: 2 x 240V ~ 50Hz
Max. Current Output: 7.5A
USB Outlets: 5V, 1 x 1.0A, 1 x 2.1A
Fuel Capacity: 10L (Petrol Unleaded)
Sump Capacity: 0.4L
Sound Pressure Level: 77.9dB (A) @ 7m
IP Rating: IP23
Weight: 22.0kg
IGP-2018
STANDARD EQUIPMENT
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY
YOU MUST RETURN THE PRODUCT TO YOUR NEAREST
BUNNINGS WAREHOUSE WITH YOUR BUNNINGS
REGISTER RECEIPT. PRIOR TO RETURNING YOUR
PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR
CUSTOMER SERVICE HELPLINE:
Australia: 1800 069 486
New Zealand: 0508 069 486
The benefits provided under this warranty are in addition to other rights and remedies which
are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this warranty,
however, where you have suffered any additional direct loss as a result of a defective product
you may be able to claim such expenses by contacting our customer service helpline above.
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE
THE MODEL NUMBER AND DATE OF PURCHASE
AVAILABLE. A CUSTOMER SERVICE REPRESENTATIVE
WILL TAKE YOUR CALL AND ANSWER ANY QUESTIONS
YOU MAY HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Office) 25 Fox Drive, Dandenong South, Victoria, Australia 3175.
ozito.com.au
Inverter Generator
0321
1 YEAR REPLACEMENT WARRANTY*
Your product is guaranteed for a period of 12 months from the original date of purchase. If
a product is defective it will be replaced in accordance with the terms of this warranty. Warranty
excludes consumable parts, for example: valve adapters and accessories.
*This product is intended for DIY use only and replacement warranty covers domestic use.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other than that specified on the tool.
• If the tool shows signs of damage or defects caused by or resulting from abuse, accidents
or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
2000W PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
I
0
I
0
I
0
240V
1
240V
2
AC SOCKET 1
USB PORTS
AC SOCKET 2
FUEL ECONOMY
ENGINE POWER
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINETO RESET
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
AC POWER
2000W PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
I
0
I
0
I
0
240V
1
240V
2
AC SOCKET 1
USB PORTS
AC SOCKET 2
FUELECONOMY
ENGINEPOWER
OVERLOAD
ACOUTPUT
AC IFOVERLOADED
RESTARTENGINETO RESET
AUTOMATICENGINE SHUT OFF
REFILLMOTOR OIL
LOWOIL
OFF ON
OFF ON
OFF ON
LOWOIL
ACPOWER
400ml Generator Oil & 200ml Oil
Filler Bottle
15W40
MULTIGRADE OIL
4ST ROKE OVH 119CC
ENGINE OIL
GENERATOR
OIL
400 MILLILITRES
2
1.5
1
0.5
E7RTC Replacement Spark Plug &
Spark Plug Wrench
15W40
MULTIGRADE OIL
4ST ROKE OVH 119CC
ENGINE OIL
GENERATOR
OIL
400 MILLILITRES
2
1.5
1
0.5

2000W PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
I
0
I
0
I
0
240V
1
240V
2
AC SOCKET 1
USB PORTS
AC SOCKET 2
FUEL ECONOMY
ENGINE POWER
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINETO RESET
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
AC POWER
ON
OFF
OHV
PETROL INVERTER GENERATOR
KNOW YOUR PRODUCT
1. LUBRICATION & FUEL
SETUP & PREPARATION
Checking The Oil
The generator is shipped without oil and must be filled before
starting. Oil sump capacity is 400ml.
Always check the oil level before every use. Depending on the
load/usage of the generator, the Generator may require up to
200ml of oil top up every 25 hours.
1. Be sure to check that the generator is on a level surface with
the engine stopped.
2. Remove the dipstick, and
wipe with a clean rag. Check
the oil level by inserting the
dipstick in the filler hole
without screwing it in and
then removing it again.
3. If the oil level is below the hatches on the
dipstick, using the oil filler bottle, refill until
it is just below the max. level. Use premium
quality 4-stroke engine oil. Recommended
SAE30 or 15W40 for most climate
conditions in Australia.
Note: The Oil Alert LED will
automatically illuminate when
the oil level is critically low.
When the LED illuminates,
stop using the generator
immediately and fill according
to instruction above. It is
recommended to check the oil
level before each use and top
up as necessary.
Refer to maintenance schedule for oil replacement
information.
2000W PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
AC SOCKET 1
USB PORTS
AC SOCKET 2
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTARTENGINE TO RESET
AC POWER
I
0
I
0
I
0
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATICENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
H
OIL
L
LOW
IDEAL
MAX.
2000W
PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
AC SOCKET 1
USB PORTS
AC SOCKET 2
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINE TO RESET
AC POWER
I
0
0
I
I
0
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
2 3
1413 15
64
7
9
10
8
1 5
11 12
1716
WARNING! DO NOT START THE GENERATOR WITHOUT
OIL. THE GENERATOR HAS A SAFETY DEVICE WHICH
WILL PREVENT STARTING WITH NO OIL.
WARNING! WHEN CHECKING THE OIL LEVEL, MAKE
SURE THE OIL IS COOL, FAILURE TO DO SO MAY
RESULT IN BURNS & PERSONAL INJURY.
WARNING! ALWAYS WEAR GLOVES, EYE & HEARING
PROTECTION WHEN OPERATING THE UNIT.
WARNING! READ & UNDERSTAND THE INSTRUCTIONS
& WARNINGS PROVIDED WITH THE GENERATOR
BEFORE OPERATION.
ONLINE MANUAL
Scan this QR Code with your mobile
device to take you to the online manual.
1. Frame/Carry Handles
2. Recoil Starter
3. Economy Mode Switch
4. Status Indicator Lights
5. Fuel Cap
6. AC Power Socket
7. Engine Power Switch
8. USB Ports
9. Grounding Terminal
10. Oil Drain Bolt
11. AC Power Switch
12. Oil Dipstick
13. Spark Plug Lead
14. Choke Lever
15. Fuel Tap
16. Spark Arrestor
17. Air Filter Cover

Fuel Consumption
Load Fuel Consumption Runtime (Full
Tank)
Full Load (2000W) 1950mL/h 5.0 hours
Half Load (1000W) 1200mL/h 8.3 hours
Economy Load
(500W) 720mL/h 13.9 hours
Fuel Stabiliser
Fuel gets old, oxidizes, and breaks down over time. It is
recommended that a fuel stabiliser (not included) is used to extend
the usable life of fuel and help prevent deposits from clogging the
fuel system. Follow the fuel stabiliser manufacturer’s directions for
correct ratio of stabiliser to fuel.
1. Mix fuel stabiliser and fuel prior to filling the tank by using an
approved fuel container and shaking gently to combine.
Note: To ensure correct amount of fuel stabiliser is added to the
engine, always mix fuel stabiliser with fuel before fueling the tank
rather than adding fuel stabiliser directly into the generator’s fuel
tank.
2. Start and run the engine for at least 5 minutes to allow stabiliser
to treat the entire fuel system.
Grounding Terminal
The inverter generator is
supplied with a grounding
terminal that may reduce the
risk of electric shock in certain
applications.
WARNING! ALWAYS CONSULT A QUALIFIED
ELECTRICIAN BEFORE CONNECTING THE GROUNDING
TERMINAL OR WHEN USING THE GENERATOR FOR
APPLICATIONS OTHER THAN DIRECT CONNECTION OF
APPLIANCES (SUCH AS CONNECTION TO A CARAVAN).
Refuelling The Generator
1. Switch off engine by moving
the engine switch to the OFF
position.
2. Remove the fuel cap by
rotating in a anti-clockwise
direction.
3. Add fuel to the tank (91 RON
Unleaded Petrol). Do not
overfill the fuel tank, check
the fuel gauge on the fuel
tank. Do not use ethanol
blended fuels. Fuel tank
capacity is 10L.
4. After refuelling, make sure the fuel cap is closed properly and
securely.
WARNING! BE CAREFUL NOT TO SPILL FUEL WHEN
REFUELLING. SPILLED FUEL OR FUEL VAPOUR MAY
IGNITE. IF ANY FUEL IS SPILLED, MAKE SURE THE
AREA IS DRY BEFORE STARTING THE ENGINE.
2000W PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
AC SOCKET 1
USB PORTS
AC SOCKET 2
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINE TO RESET
AC POWER
I
0
I
0
I
0
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
2000W
PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
AC SOCKET 1
USB PORTS
AC SOCKET 2
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINETO RESET
AC POWER
I
0
I
0
I
0
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
E | F
FUEL
GAUGE
E | F
FUEL
GAUGE
WARNING! PETROL IS VERY FLAMMABLE. DO NOT
SMOKE OR CAUSE ANY SPARKS OR FLAMES NEAR
FUEL. MAKE SURE THAT YOU STOP THE ENGINE
& ALLOW IT TO COOL BEFORE REFUELLING THE
GENERATOR. SELECT AN OPEN OUTDOOR AREA FOR
FUELLING & MOVE AT LEAST 3M AWAY FROM THE
FUELLING POINT BEFORE STARTING THE ENGINE.
WARNING! MAKE SURE TO STORE FUEL IN A
APPROPRIATE FUEL CONTAINER & KEEP AWAY FROM
FOOD & DRINK SOURCES.
WARNING! CHECK FUEL LINES, TANK, CAP AND
FITTING FREQUENTLY FOR CRACKS OR LEAKS.
WARNING! ONLY USE RON 91 UNLEADED PETROL. DO
NOT USE DIESEL OR ANY OTHER TYPE OF FUEL.

Fuel Economy Mode
The generator has a maximum rated power of 500W in fuel
economy mode.
If you will not be using the generator to run appliances with
a cumulative power draw of 500W, this mode will allow the
generator to run for longer before needing to be refuelled.
Flip the economy mode switch
to the on position to start this
function.
Note: The generator can be set to economy mode at any point
whether it is already running or not. There is no need to stop and
restart the generator when switching modes.
WARNING! ENSURE THAT THE POWER DRAW OF ALL
CONNECTED APPLIANCES DOES NOT TOTAL MORE
THAN 500W IN FUEL ECONOMY MODE. FAILURE TO DO
SO WILL CAUSE THE OVERLOAD SWITCH TO TRIP.
Stopping The Generator
Before stopping the generator, turn off any equipment it may be
powering.
1. Set the engine power switch
to the off position.
2. For transport or storage,
set the fuel tap to the ‘OFF’
setting.
2. STARTING & STOPPING
OPERATION
2000W PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
AC SOCKET 1
USB PORTS
AC SOCKET 2
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINE TO RESET
AC POWER
I
0
I
0
I
0
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
2000W PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
AC SOCKET 1
USB PORTS
AC SOCKET 2
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINE TO RESET
AC POWER
0
I
I
0
I
0
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
Starting The Generator
Before starting the engine, disconnect all appliances from the
generator. Also check that there is sufficient oil and fuel.
1. Set the fuel tap to the ‘OPEN’
position.
2. Set the engine power switch to the
on position.
3. Adjust the choke lever to suit the conditions.
COLD START: If the weather
is cold, push the choke all
the way right to the ‘ON’
position.
WARM START: If the
weather is warm, or the
generator has recently been
running, push the choke all
the way to the left in the
‘OFF’ position.
4. Hold the generator steady
with one hand. With the
other hand, pull slightly until
you feel resistance on the
recoil starter, then pull hard
and swiftly.
Note: Do not let the recoil
starter retract by itself, guide it
back by hand.
Note: You may have to pull the recoil starter a few times until the
generator starts.
5. Once started, push the
choke all the way left to
the ‘OFF’ position if it’s not
already there.
2000W PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
AC SOCKET 1
USB PORTS
AC SOCKET 2
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINE TO RESET
AC POWER
I
0
0
I
I
0
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
OHV
FUEL TAP OPEN
CLOSED
CHOKE LEVER
COLD
START
ON
WARM
START
OFF
ON
OFF
2000W PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
AC SOCKET 1
USB PORTS
AC SOCKET 2
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTARTENGINE TO RESET
AC POWER
0
I
0
I
0
I
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
OHV
FUEL TAP OPEN
CLOSED
CHOKE LEVER
COLD
START
ON
WARM
START
OFF
ON
OFF
OHV
ON
OFF
OHV
ON
OFF
WARNING! DO NOT CONNECT THE GENERATOR TO
OTHER POWER SOURCES.
WARNING! PLACE THE GENERATOR AT LEAST 1M
AWAY FROM BUILDINGS OR OTHER EQUIPMENT
DURING OPERATION INCLUDING OVERHEAD. ALWAYS
OPERATE GENERATOR A MINIMUM OF 2M FROM
ANY CONDUCTIVE SURFACE EG. METALS. KEEP ALL
BYSTANDERS, CHILDREN, & PETS AT LEAST 3M AWAY

Low Oil Indicator (YELLOW)
If the oil level becomes low while the generator
is running, the oil level LED will light up yellow.
The generator will also switch off automatically to
prevent damage to crank case.
Follow the steps for checking the oil level, add
engine oil and restart the generator as normal.
AC Power Indicator (GREEN)
The green indicator LED will light up when power
is ready to be supplied to the AC power sockets.
Overload Indicator (RED)
If the generator is overloaded or there is a short
in the connected appliance, the red overload
indicator will light up and current to the AC outlets
will be cut-off.
Substantial overloading that continuously trips
the generator may cause irreversible damage to
the unit. Marginal overloading that temporarily
lights up the overload indicator may shorten the service life of the
generator.
WARNING! STOP THE GENERATOR IF THE OVERLOAD
INDICATOR LIGHTS UP AND INVESTIGATE THE
OVERLOAD SOURCE.
WARNING! ENSURE THAT ALL APPLIANCES ARE IN
GOOD WORKING ORDER BEFORE CONNECTING THEM
TO THE GENERATOR. IF AN APPLIANCE BEGINS TO
OPERATE ABNORMALLY, BECOMES SLUGGISH OR
STOPS SUDDENLY, SWITCH THE GENERATOR OFF &
DISCONTINUE USE OF THE APPLIANCE.
Follow the steps below to reset the generator after an overload.
1. Flip the AC and engine
power switches off.
2. Disconnect all appliances.
3. Restart the generator as
described in the ‘Starting
The Generator’ section.
4. Connect the appliances one at a time. If the overload switch
trips again then the appliance is faulty - contact Ozito Customer
Service.
3. INDICATORS & ALERTS
2000W
PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
AC SOCKET 1
USB PORTS
AC SOCKET 2
OVERLOAD
AC OUTPUT
AC
IF OVERLOADED
RESTART ENGINE TO RESET
AC POWER
I
0
I
0
I
0
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
Starting Watts (aka Surge Watts)
You may find that even though the appliance you wish to connect
to the generator is below the rated power, the generator overloads.
Some appliances require a higher power than noted on the
appliance for start up; this is called starting watts or surge watts.
Some examples are listed below.
Appliance Running Power Start-up Power
Light 70W 70W
Airless Sprayer 650W 1300W
Refrigerator 700W 2000W
Water Pump 800W 2000W
Air Compressor 1100W 4000W
Circular Saw 1200W 2100W
Heater 2000W 2000W
Mitre Saw 2100W 3200W
Electric Stove 2400W 2400W
*Table details are approximate. Always check your appliance for
accurate wattage.
WARNING! THE START-UP POWER OF CONNECTED
DEVICES SHOULD NOT EXCEED THE MAX. POWER
RATING OF THE GENERATOR. THE RUNNING POWER
SHOULD NOT EXCEED THE RATED POWER.
Extension Cord
When an extension cable is required, be sure to use a rubber
sheathed flexible cable. Limit length of extension cables to:
• 60m for cables of 1.5mm² and
• 100m for cables of 2.5mm2.
2000W
PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
AC SOCKET 1
USB PORTS
AC SOCKET 2
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINE TO RESET
AC POWER
I
0
0
I
I
0
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
2000W
PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
AC SOCKET 1
USB PORTS
AC SOCKET 2
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINE TO RESET
AC POWER
I
0
0
I
I
0
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
2000W
PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
AC SOCKET 1
USB PORTS
AC SOCKET 2
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINE TO RESET
AC POWER
0
I
0
I
0
I
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
IGP-2018

4. OUTLETS 5. TROUBLESHOOTING
AC Appliances
Check the total rating of the appliance to be connected and ensure
the rating of the appliance(s) does not exceed the rating of the
generator.
1. Start the generator and ensure
the AC power indicator lights up.
Allow the engine to stabilise before
connecting appliances.
2. Check that the appliance
and the AC power switch are
switched off.
3. Plug the appliance into
either of the AC sockets.
4. Flip the AC power switch
to the on position and then
you can start using the
equipment.
Note: If the connected appliance does not operate, refer to the
‘Overload Indicator (RED)’ and ‘Inrush Current Overload’
sections for troubleshooting.
USB Output
The generator has 2 USB outlets that supply 1.0A and 2.1A
respectively. These are always on once the generator is started.
Connect the device to be
charged/powered via a USB
cable (not supplied) to the USB
port.
Note: The USB outlets provides
power only, it does not
provide any communication
capabilities. A suitable USB
cable must be used (not included).
Maintenance
Refer to the Maintenance Manual for maintenance instructions.
The instructions should be followed to ensure optimum operation.
2000W
PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
AC SOCKET 1
USB PORTS
AC SOCKET 2
OVERLOAD
AC OUTPUT
AC
IF OVERLOADED
RESTART ENGINE TO RESET
AC POWER
I
0
I
0
I
0
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
2000W
PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
AC SOCKET 1
USB PORTS
AC SOCKET 2
OVERLOAD
AC OUTPUT
AC
IF OVERLOADED
RESTART ENGINE TO RESET
AC POWER
0
I
0
I
0
I
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
2000W
PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
AC SOCKET 1 AC SOCKET 2
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINE TO RESET
AC POWER
I
0
0
I
0
I
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
1.0A
USB PORTS
2.1A
2000W
PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
AC SOCKET 1
USB PORTS
AC SOCKET 2
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINE TO RESET
AC POWER
I
0
0
I
I
0
240V
1
240V
2
FUEL ECONOMY
ENGINE POWER
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
WARNING! BEFORE CONNECTING, INSPECT THE
APPLIANCE CABLES. DO NOT USE THE APPLIANCE IF
THERE ARE SIGNS OF FRAYING AND/OR DAMAGE.
WARNING! NEVER ADD MORE LOAD THAN THE
GENERATOR CAPACITY. TAKE CARE TO CONSIDER
SURGE LOADS IN GENERATOR CAPACITY.
WARNING! DO NOT USE THE OUTLET IF THE COVERS
ARE BROKEN.
Problem Possible Cause Solution
Engine
• will not start,
• shuts down
after starting
or
• starts but
runs rough
Choke is in off
position. Move choke to on position.
No fuel. Add unleaded 91 RON petrol
to fuel tank.
Engine switch is
in the off position. Set engine switch to on.
Oil is low. Check oil level and fill if
necessary.
Spark plug
connector is
not properly
connected.
Check and reattach
connector if necessary.
Spark plug is
faulty. Replace spark plug.
Fuel is stale/old,
or there is water
in the fuel.
Drain system of all fuel and
refill with fresh unleaded 91
RON petrol.
Engine is flooded. Wait 5 minutes before
restarting engine.
Engine stored
without treating
or draining fuel.
Bad fuel is used.
Drain system of all fuel and
refill with fresh unleaded 91
RON petrol.
Air filter is dirty. Check air filter. Clean if
necessary.
Fuel filter is dirty. Check fuel filter. Clean if
necessary.
Engine lacks
power
Engine stored
without treating
or draining fuel.
Bad fuel is used.
Drain system of all fuel and
refill with fresh unleaded 91
RON petrol.
Air filter is dirty. Check air filter. Clean if
necessary.
No power
Device plugged
in is faulty.
Check device for damage,
try plugging in a different
device.
Generator is
overloaded.
Refer to overload indicator
section.
Poor connection
or defective
cable.
Check for damage and
replace if necessary.

DESCRIPTION OF SYMBOLS
Engine may continue to rotate
after machine is switched off
Warning! Risk of shock
Warning
Add 4-stroke engine oil
Regulatory Compliance Mark
(RCM)
Use unleaded 91 RON petrol
Keep bystanders away
Ground/Chassis, consult with local
electrician to determine the
grounding requirements before
operation
Do not expose to rain
Exhaust containes poisonous
carbon monoxide. Do not operate
generator in confined areas.
Extremely hot surface, do not
touch. Risk of burns
Hot surface
Toxic fumesDo not smoke
VVolts Hz
W
Hertz
~
AL
Alternating Current Watts
AmperesLitres
dBcc DecibelsCubic centimetres
mWear hearing protectionMetres
Read Instruction Manual
HOT !
Health hazardHarmful chemicals
Warning
Wear eye, ear & breathing
protection
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases
or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of
electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord
away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric
shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use
a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
b.Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or
energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool
in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from
moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can reduce dust-related hazards.
h. Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool
safety principles. A careless action can cause severe injury within a fraction of a second.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power tool will do
the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before making
any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the
risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other
condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into
account the working conditions and the work to be performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
h. Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the tool in unexpected situations.
5. Service
a. Have your power tool serviced by a qualified repair person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.
Power tools that are no longer usable should not
be disposed of with household waste but in an
environmentally friendly way. Please recycle where
facilities exist. Check with your local council authority for
recycling advice.
Recycling packaging reduces the need for landfill and raw
materials. Reuse of recycled material decreases pollution
in the environment. Please recycle packaging where
facilities exist. Check with your local council authority for
recycling advice.
CARING FOR THE ENVIRONMENT
SPARE PARTS
Spare parts can be ordered from the Special Orders Desk at your
local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]

WARNING! The appliance is not to be used by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction.
Young children should be supervised to ensure that they do not play with the appliance.
Important Safety Information
The manufacturer cannot possibly anticipate every possible circumstance that might involve a hazard. The warnings
in the manual and the tags and labels on this generator are therefore, not all inclusive. If you use a procedure, work
method or operating technique that the manufacturer does not specifically recommend, you must satisfy yourself
that it is safe for you and others. You must also make sure that the procedure, work method or operating technique
that you choose does not render the generator unsafe.
IMPORTANT! When using the equipment, a few safety precautions must be observed to avoid injuries and damage.
Please read the complete operating manual with due care. Keep this manual in a safe place so that the information
is available at all times. If you give the equipment to any other person, give them these operating instructions as well.
We cannot accept any liability for damage or accidents which arise due to a failure to follow these instructions and
the safety information.
The generator is designed to give safe and dependable service if operated according to instructions. Read and
understand the Owner’s Manual before operating the generator. Failure to do so could result in personal injury or
equipment damage.
• The generator is designed to supply electrical power for operating compatible electrical lighting, appliances,
tools, and motor loads.
• Only use generator at rated output load and at standard atmospheric conditions.
• Do not use the product to provide power for emergency medical equipment or life support devices.
• Do not use the product to jump start vehicles. Doing so could result in damage to the vehicle or its electrical
components.
• Do not use the product for any other purpose.
• The product operates best in temperatures between 5°C and 35°C with a relative humidity of 50%
• Gasoline is extremely flammable and explosive under certain conditions. Refuel in a well ventilated area with
the engine stopped.
• Keep away from cigarette, smoke and sparks when re-fuelling the generator. Always refuel in a well
ventilated location.
• Prevent the spilling of fuel as this may also ignite with the hot motor. Wipe up spilled gasoline at once. Never
refuel whilst the engine running.
• Do not allow the generator’s gas tank to overflow when filling. Fill to 25mm (1”) below the top neck of the
gas tank to allow for fuel expansion.
• Mix fuel outdoors where there are no sparks or flames. Wipe any fuel spillage. Move 9m away from refuelling
site before starting engine.
• Never start or run the engine inside a closed or partially enclosed area. Breathing exhaust fumes will kill you.
• Keep all parts of your body away from any moving parts and all hot surfaces of the product.
• Wear eye protection as well as hearing protection when operating the product.
• Wear sturdy and dry shoes or boots. Do not operate while barefoot.
• Connections for standby power to a building’s electrical system must be made by a qualified electrician
and must comply with all applicable laws and electrical codes. Improper connections can allow electrical
current from the generator to back feed into the utility lines. Such back feed may electrocute utility company
workers or others who contact the lines during a power outage, and when utility power is restored, the
generator may explode, burn, or cause fires in the building’s electrical system.
• Do not touch bare wires or 240V outlets.
• Before each use, make sure to check the generator wiring, outlets, and connectors for damage. You should
not use the product if any of these parts are damaged.
• Do not remove the oil dipstick or the fuel tank cap when the engine is running.
• Store the generator in a dry area away from inflammable liquids.
• Always make a pre-operation inspection before you start the engine. You may prevent an accident or
equipment damage.
• Always place the generator on stable flat surface.
• Place the generator at least 1m (3ft) away from buildings or other equipment during operation, including
overhead. ALWAYS operate generator a minimum of 2 meters from any conductive surface eg. metals. Keep
all bystanders, children, and pets at least 3m away
• Persons who are fitted with a heart pacemaker, or similar medical conditions should take care when using
this device. Even the extra low voltage of the Battery charging output should not be handled by a person with
medical conditions as or similar to the above.
• Operate the generator on a level surface. If the generator is tilted, fuel spillage may result.
• Do not operate in a hazardous location. Such areas include where there is a risk of explosion of petrol fumes,
leaking gas or explosive dust.
• Know how to stop the generator quickly and understand operation of all the controls. Never permit anyone to
operate the generator without proper instructions.
• Keep children and pets away from the generator when it is in operation.
• Keep away from rotating parts while the generator is running.
• The generator is a potential source of electrical shocks when misused; do not operate with wet hands.
• Always pick up with two people using the handles.
• Your power tool should only be passed on with these instructions.
• Do not use in rain, wet or damp environment, this may lead to electrocution. Always keep the generator,
appliances and power cords dry.
• The electrical continuity of the ‘earthing’ core should be checked periodically from pin to socket to ensure
continued electrical safety.
• Some electrical appliances, e.g. portable drills, are marked or ‘double insulated’, in which case there will not
be an earthing conductor in its mains lead (even though it may have a 3-pin plug).
• Maintain normal safety precautions with appliances and accessories as for use on normal reticulated normal
supply.
• Locate set in convenient place, avoiding long extension leads and possible damage to leads by pedestrian
or vehicular traffic.
• Make sure to check plugs/cables connected to generator for faults before switching on.
• Never open the Inverter cover. Always repair at certified electrician/repairer.
• Always dispose used oil/fuel according to local environmental regulations.
• Do not operate if housing is damaged. Take it to authorized repair agent.
• Only used recommended fuel and oil for the Generator
• Do not operate without the fuel cover
• Do not operate if the switch cover is broken
• Do not modify the electrical wires/components in any way.
• This generator is NOT intended to be used in a construction site, worksite or demolition site. It is intended
for DIY use only.
• Only use this Generator with 91 RON Unleaded Petrol.
• Do not operate the generator when you are tired or under the influence of drugs, alcohol, or medication.
• The generating set must not be connected to other power sources.
• Store unused engine oil in a well-ventilated place. Keep container tightly closed
• Dispose of oil bottle contents to authorised hazardous or special waste collection point in accordance with
any local regulation
• DO NOT INGEST engine oil. IF SWALLOWED: Immediately call the Poisons Information Centre on 13 11
26 (Australia) or 0800 764 766 (NZ) for 24/7 expert advice.
WARNING! Do not parallel connect other cables to receptacles, use special jack, or it may cause an
electrical shock.
WARNING! The muffler becomes very hot during operating and remains hot for a while after
stopping the engine. Be careful not to touch the muffler while it is hot. Let the engine cool before
storing the generator indoors.
WARNING! Exhaust contains poisonous carbon monoxide. Do not operate generator in confined
area. Be sure to operate the generator in a well-ventilated environment or with an aerator. Using a
generator indoors will kill you in minutes. Never use in the home or in a partly enclosed area such
as garages. Only use outdoors and far from open windows doors and vents.
WARNING! Engine exhaust contains carbon monoxide, a poisonous gas that could kill you in
minutes. You cannot smell it, see it, or taste it. Even if you do not smell exhaust fumes, you could
still be exposed to carbon monoxide gas. If you start to feel sick, dizzy, or weak while using this
product, get fresh air right away. See a doctor. You may have carbon monoxide poisoning.
WARNING! The output of this generating set is potentially Lethal. The set shall not be connected to
a fixed electrical installation (such as household wiring) by fixed wiring except by an appropriately
licensed person.
WARNING! The inverter generator is supplied with a grounding terminal that may reduce the risk of
electrocution in certain applications. Always consult a qualified electrician before connecting the
grounding terminal or when using the generator for applications other than direct connection of
appliances (such as connection to a caravan).
WARNING! Do not operate in hazardous location e.g. Where there may be a risk of explosion of
petrol fumes, leaking gas or explosive dust.
WARNING! Do not operate in a confined area where exhaust gases, smoke or fumes could reach
dangerous concentrations.
WARNING! Do not refuel while engine is running. Position the product on level ground, stop engine,
and allow the product to cool down before refuelling.
WARNING! When using mains-powered tools, basic safety precautions, including the following, should
always be followed to reduce risk of fire, electric shock, personal injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency,
before operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The unit has been designed to output 240V only. Always check that the power supply corresponds to the voltage on
the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.
Using an Extension Lead
WARNING! Damaged or overloaded extension cords could overheat, arc, and burn, resulting in death or
serious injury.
Always use an approved extension lead suitable for the power output from this generator. Before use, inspect the
extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective. When
using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the
power input of the tool or which is damaged or defective may result in a risk of fire and electric shock.
It is recommended at a minimum that 1.5mm2 Heavy Duty extension leads are used with the Generator and that
the length is kept as minimal as possible to prevent power loss. All extension leads must incorporate an earthing
conductor to ensure that there is no voltage difference between the generating set and any equipment powered by
the generating set.
GENERATOR SAFETY WARNINGS
ELECTRICAL SAFETY

PETROL INVERTER
GENERATOR
2000W MAX. POWER
MAINTENANCE MANUAL
IGP-2018
0321
2000W
PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
I
0
I
0
I
0
240V
1
240V
2
AC SOCKET 1
USB PORTS
AC SOCKET 2
FUEL ECONOMY
ENGINE POWER
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINE TO RESET
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
AC POWER

2000W PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
I
0
I
0
I
0
240V
1
240V
2
AC SOCKET 1
USB PORTS
AC SOCKET 2
FUEL ECONOMY
ENGINE POWER
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINETO RESET
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
AC POWER
2
KNOW YOUR PRODUCT
CONTENTS
Know Your Product ...................................................................................... Page 2
Maintenance...................................................................................... Page 4
Storage & Transport...................................................................................... Page 10
Risk Assessments...................................................................................... Page 12
2 3 64
7
9
10
8
1 5
11 12

ON
OFF
OHV
3
ONLINE MANUAL
Scan this QR Code with your mobile
device to take you to the online manual.
PETROL INVERTER GENERATOR
1. Frame/Carry Handles
2. Recoil Starter
3. Economy Mode Switch
4. Status Indicator Lights
5. Fuel Cap
6. AC Power Socket
7. Engine Power Switch
8. USB Ports
9. Grounding Terminal
10. Oil Drain Bolt
11. AC Power Switch
12. Oil Dipstick
13. Spark Plug Lead
14. Choke Lever
15. Fuel Tap
16. Spark Arrestor
17. Air Filter Cover
1413 15
1716

4
MAINTENANCE
Maintenance Schedule
The purpose of the maintenance and adjustment schedule is to keep the generator in the
best operating condition.
Inspect or service as scheduled in the table below.
Part Operation
Periodic Maintenance Time (1)
Every
Use
Every month
or 20hrs
Every 3 months
or 50hrs
Every 6 months
or 100hrs
Every year
or 300hrs
Oil
Examine •
Replace •
Air Filter
Examine •
Clean • (2)
Muffler
& Spark
Arrestor
Examine •
Clean •
Spark Plug Clean/Adjust •
Fuel
Sediment
Bowl
Clean •
Valve
Clearance Examine/Adjust • (3)
Fuel & Fuel
Filter Clean • (3)
Fuel Line Examine Every 2 years (If necessary, please change) (3)
WARNING! SHUT OFF THE GENERATOR & DISCONNECT ANY APPLIANCES/
CABLES BEFORE PERFORMING ANY MAINTENANCE. PLACE GENERATOR
ON A LEVEL SURFACE AND REMOVE SPARK PLUG CAP TO PREVENT
ACCIDENTAL STARTING.
WARNING! ALWAYS WEAR EYE PROTECTION WITH SIDE SHIELDS. FAILURE
TO DO SO COULD RESULT IN OBJECTS BEING THROWN INTO YOUR EYES,
RESULTING IN POSSIBLE SERIOUS INJURY.
WARNING! ENGINE PARTS WILL GET EXTREMELY HOT WHILE THE
GENERATOR IS RUNNING. WAIT UNTIL THE GENERATOR HAS COMPLETELY
COOLED DOWN BEFORE CARRYING OUT ANY MAINTENANCE.
WARNING! NEVER REMOVE THE FRONT PANEL OR THE INVERTER COVER. IF
THE FRONT PANEL AND/OR THE INVERTER COVER IS DAMAGED, STOP USING
THE GENERATOR IMMEDIATELY. CONTACT OZITO CUSTOMER SERVICE.

5
Note:
(1) Log hours of operation to determine proper maintenance.
(2) Service more frequently when used in dusty areas.
(3) These items should only be carried out by an authorised service centre.
Note: Ozito Industries will not be responsible for any damage or injuries caused by the
repair of the tool by an unauthorised person or by mishandling of the tool.
WARNING! USE AUTHORISED PARTS OR THEIR EQUIVALENT. THE USE OF
REPLACEMENT PARTS WHICH ARE NOT OF EQUIVALENT QUALITY MAY
DAMAGE THE GENERATOR.
Oil Change
WARNING! ENSURE THE ENGINE SWITCH & FUEL LEVER ARE OFF BEFORE
DRAINING.
WARNING! DO NOT CHANGE OIL WHILE IT IS HOT. ACCIDENTAL CONTACT
WITH HOT ENGINE LUBRICANT CAN RESULT IS SERIOUS BURNS.
1. Use a spanner (not supplied) to remove the oil drain
screw.
2. Place a suitable container underneath the oil drain hole & tilt the generator to collect the
oil.
3. Refit the oil drain screw.
4. Refill the generator with new oil as per the instructions in ‘Checking The Oil’. Use a
clean rag to wipe up any spilled oil.
Note: Dispose of used motor oil in a manner that is compatible with the environment. Do
not throw it in the rubbish bin, pour it down the drain or on the ground.
2000W
PETROL INVERTER GENERATOR
4 STROKE 119CC ENGINE
2000W
INVERTER
TECHNOLOGY
2x
I
0
I
0
I
0
240V
1
240V
2
AC SOCKET 1
USB PORTS
AC SOCKET 2
FUEL ECONOMY
ENGINE POWER
OVERLOAD
AC OUTPUT
AC IF OVERLOADED
RESTART ENGINE TO RESET
AUTOMATIC ENGINE SHUT OFF
REFILL MOTOR OIL
LOW OIL
OFF ON
OFF ON
OFF ON
LOW OIL
AC POWER

6
Air Filter Service
A dirty air filter will restrict air flow to the carburettor. To prevent carburettor malfunction,
service the air cleaner regularly. Service more frequently when operating the generator in
extremely dirty areas.
1. Undo the air filter screw.
2. Lift the filter cover from the bottom edge and
unhook it from the two tabs on the top edge.
3. Check the air filter sponge is intact and clean. If not, rinse with water and allow to dry
or replace the filter.
Note: It is normal for a little oil to appear under the air filter box if the generator is running
for a long period of time, or if a lot of oil is in the engine. Wipe up the excess oil after each
use and after stopping the generator.
WARNING! DO NOT USE PETROL OR LOW FLASHPOINT SOLVENTS FOR
CLEANING. THEY ARE FLAMMABLE & EXPLOSIVE UNDER CERTAIN
CONDITIONS.
WARNING! NEVER RUN THE ENGINE WITHOUT THE AIR FILTER IN PLACE.
RAPID ENGINE WEAR WILL RESULT FROM CONTAMINANTS SUCH AS DUST &
DIRT BEING DRAWN THROUGH THE CARBURETTOR & INTO THE ENGINE.
4. Pour a small amount of oil on the filter sponge then squeeze, but do not wring out
excess oil. The filter sponge should be damp, but not dripping with oil.
5. Ensure the filter plate & rubber seal are located
properly then reinsert the air filter sponge and
replace the cover.
OHV
a.
b. ON
OFF
FILTER
PLATE
FILTER
SEAL
FILTER
COVER

7
Spark arrestor
1. Loosen the bolt then remove the spark arrestor.
2. Check the spark arrester mesh for carbon deposits.
Remove carbon deposits from all three meshes
gently with a wire brush (not included).
3. Check the spark arrester for damage. If damaged replace with replacement parts
specifically designed for this unit.
4. Re-install the spark arrester. Tighten the bolt to secure the spark arrester.
WARNING! DO NOT RUN GENERATOR WITHOUT THE SPARK ARRESTOR
PROPERLY ASSEMBLED.
WARNING! USE CAUTION AROUND THE MUFFLER, CYLINDER AND
OTHER ENGINE PARTS AS THEY CAN BE EXTREMELY HOT. ALLOW HOT
COMPONENTS TO COOL BEFORE TOUCHING.

8
Spark Plug Servicing
Use only good quality Torch E7RTC spark plugs. To ensure proper engine operation, the
spark plug must be properly gapped and free of deposits.
1. Pull out the spark plug lead.
2. Remove the spark plug using the spark plug wrench supplied by turning it anti-
clockwise.
3. Clean the electrode with a metal brush and remove
any carbon build-up or replace the spark plug. Set
the electrode gap to 0.6 - 0.7mm.
4. Install the spark plug carefully by hand to avoid cross-threading. Tighten it securely with
the spark plug wrench.
5. Reinstall the spark plug lead.
OHV
ON
OFF
0.6 - 0.7mm

9
Fuel Filter
A dirty fuel filter will restrict fuel flow to the carburettor. Replace the fuel filter if it
becomes noticeably discoloured. The fuel filter can be found under the fuel cut off tap.
1. Detach fuel line after emptying the fuel tank.
2. Unscrew the nut using an M14 spanner (not supplied) whilst
holding on to the fuel tap.
3. Unscrew filter by hand and carefully clean with carburettor
cleaner.
4. Ensure the filter is dry before reattaching it to the fuel tap.
5. Install the fuel tap to the fuel tank, ensuring the rubber seal is
flush. Reinstall the fuel line and clamp.
6. Add some fuel to the fuel tank and open the fuel tap
to check that there are no leaks.
ON
OFF
a.
a.
b.
ON
OFF
ON
OFF
OHV
ON
OFF
ON
OFF
a.
b.

10
Transporting The Generator
WARNING! THE GENERATOR IS A HEAVY PIECE OF MACHINERY. HAVE 2
PEOPLE CARRY THE GENERATOR BY THE HANDLES WHEN MOVING IT.
• Wait until the generator has completely cooled down before transporting. Always
ensure to grip by the provided gripping surfaces.
• Do not move generator while it is in operation. The generator may be damaged when
operating this way.
• Do not overfill the fuel tank.
• Avoid exposure to direct sunlight when putting the generator in a vehicle. If the
generator is left in an enclosed vehicle for many hours, high temperatures inside the
vehicle could cause fuel to vaporize, resulting in a possible explosion.
• Do not operate the generator while it is on a vehicle. Take the generator off the
vehicle and use it in a well ventilated place.
• Do not drive on a rough road for an extended period with the generator on board. If
you must transport the generator on a rough road, drain the fuel from the generator
beforehand.
Note: Dispose of fuel in a manner that is compatible with the environment. Do not throw it
in the rubbish bin, pour it down the drain or on the ground.
TRANSPORT & STORAGE

11
Storage
Ensure the storage area is not excessively humid or dusty and not accessible to
unauthorised persons.
1. Completely drain the fuel from the tank or open the fuel valve, start the engine and
operate it in the idle position until all remaining fuel is gone and the engine stops
automatically.
2. Allow the generator to cool completely.
3. Discharge the oil as described in the ‘Oil Change’ section.
4. Ensure the fuel tap is in the closed position.
5. Wipe any oil and petrol residues on the generator with a clean dry cloth before putting
away for storage.

12
Risk of Fire
Hazard What could happen How to prevent it
Attempting to
fill the fuel tank
while the engine
is running
Fuel and fuel vapours can become
ignited by coming in contact
with hot components such as the
muffler, engine exhaust gases, or
from an electrical spark.
Turn engine off and allow it to
cool before adding fuel to the
tank. Equip area of operation
with a fire extinguisher
certified to handle fuel fires.
Sparks, fire, hot
objects
Cigarettes, sparks, fires, or other
hot objects can cause fuel or fuel
vapours to ignite.
Add fuel to tank in well
ventilated area. Make sure
there are no sources of ignition
near the generator.
Improper storage
of fuel
Improperly stored fuel could
lead to accidental ignition. Fuel
improperly secured could get into
the hands of children or other
unqualified persons.
Store fuel in an approved
container designed to hold
fuel. Store container in secure
location to prevent use by
others.
Inadequate
ventilation for
generator
Materials placed against or near
the generator or operating the
generator in areas where the
temperature exceeds 40°C.
ambient (such as storage rooms
or garages) can interfere with
its proper ventilation features
causing overheating and possible
ignition of the materials or
buildings.
Operate generator in a clean,
dry, well ventilated area.
DO NOT OPERATE UNIT
INDOORS OR IN ANY
CONFINED AREA.
Overfilling the
fuel tank - fuel
spillage
Spilled fuel and its vapours can
become ignited from hot surfaces
or sparks.
Use care in filling the tank to
avoid spilling fuel. Make sure
fuel cap is secured tightly and
check engine for fuel leaks
before starting engine. Move
generator away from refuelling
area or any spillage before
starting engine. Allow for fuel
expansion. Never refuel with
the engine running.
RISK ASSESSMENTS
