Ozito MBDS-125 User manual

MINI BENCH
DISC SANDER
140W Ø125MM
INSTRUCTION MANUAL
SPECIFICATIONS
Mains Voltage: 230–240V ~ 50Hz
Input Power: 140W (S2 15mins)
Max. n0: 4,000/min
Speed Settings: 6
Disc Size: Ø125mm
Weight: 2.4kg
MBDS-125
STANDARD EQUIPMENT
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: valve adapters
and accessories.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
ozito.com.au
Mini Bench Disc Sander
Angle Guide & 6 x Sanding Sheets
C-Clamp Bracket & Dust Extraction
Adaptor
1219

ONLINE MANUAL
Scan this QR Code with
your mobile device to take
you to the online manual.
Securing The Disc Sander
This mini disc sander can be mounted vertically or horizontally onto
your bench to suit the workpiece being sanded.
1. Unwind the screw on the
C-clamp bracket so that it ts
over your workbench.
2. Position the sander vertically or horizontally on the workbench
and slide the free end of the C-clamp bracket into the appropriate
mounting slot on the tool.
Note: Ensure the free end of the C-clamp is fully inserted into the
slot.
3. Wind up the screw on the
C-clamp to lock the sander
against your workbench.
Note: Ensure the entire surface
of the C-clamp screw is pushed
fully against the workbench.
WARNING! DO NOT TURN ON THE TOOL UNTIL THE
SCREW IS TIGHTENED SUFFICIENTLY SO THAT THE
SANDER IS UNABLE TO MOVE AROUND.
1. Dust Extraction Port
2. Power Cord
3. On/O󰀨 Switch
4. Fence Rail
5. Mitre Fence
6. Mitre Angle Guide
7. Fence Adjustor Screw
8. Tilt Table
9. Table Adjustor Screw
10.Speed Control Dial
11. Vertical Mounting Slot
12.C-Clamp Bracket
13.Clamp Screw
14.Tilt Angle Guide
15.Angle Increment Dial
MINI BENCH DISC SANDER
KNOW YOUR PRODUCT
1. ASSEMBLY
SETUP & PREPARATION
1 2
10
8
1415
3
5
11
4
12
13
9
7 6
WARNING! ENSURE THE TOOL IS TURNED OFF
AND DISCONNECTED FROM THE POWER SUPPLY
BEFORE PERFORMING ANY OF THE FOLLOWING
OPERATIONS.

Installing The Mitre Fence
1. Loosen the fence adjustor
screw.
2. Slide the fence rail into the channel on
the tilt table.
3. Tighten the adjustor screw to
lock it in place.
Dust Extraction
A vacuum hose or dust extractor can be tted to the dust extraction
port to help keep your work area clean while you’re sanding.
1. Align the arrow on the dust
extraction adaptor with the
arrow marking on the sander.
2. Insert the dust extraction
adaptor and turn it clockwise
to lock it in place.
3. A vacuum hose can now be tted to
the other end of the adaptor to remove
sanding dust and debris as you work.
4. To remove the adaptor, rotate it in the port until the arrow markings
align, then pull it out of the slot.
Note: The saw dust will travel
according to the direction of
the wheel rotation. For e󰀩cient
dust extraction, position the
workpiece on the left of the
sanding disc.
WARNING! DUST EXTRACTION SHOULD NOT BE
USED DURING METAL SANDING TO PREVENT HOT
METAL FRAGMENTS FROM ENTERING THE VACUUM
CLEANER OR DUST EXTRACTION SYSTEM.
Sandpaper Selection
Selecting the correct grit of sandpaper is an important step in
achieving optimum results. Coarse grit will remove the most material.
Finer grit will produce a smoother nish. The condition of the
workpiece will determine the grit of the sandpaper to be used. The
higher the grit number, the ner the grade of sandpaper.
If the surface is rough, start with a coarse grit and sand until the
surface is uniform. Medium grit may then be used to remove
scratches left by the coarser grit. Finer grit is then used to nish the
surface. Always continue sanding with each grade of sandpaper until
the surface is uniform.
MATERIAL APPROPRIATE GRIT
Coarse Sanding Fine Sanding
Soft Timbers 60 240
Hardwoods 60 180
Note: If intermediate sanding is required, choose a grit rating
between coarse and ne. The above table is intended as a guide
only. To ensure a satisfactory result, test on a scrap piece of material
to ensure the grit of sandpaper chosen is suitable for the desired
nish.
Replace the sand paper when it becomes worn.
2. FITTING SANDPAPER

Sandpaper Fitment
1. Unwind the left table adjustor
screw completely. Remove
the screw caps and washer
from one end, and pull the
axle out of the slot.
2. Slide the tilt table o󰀨 the tool.
3. Slide the disc fence out and
pull the used sandpaper sheet
o󰀨 the hook & loop backing.
Replace it with a new sheet.
4. Replace the disc fence, then
slide the tilt table back onto
the sander, making sure to
align the angle rails in the
channels on each side of the
tool.
5. Re-insert the table adjustor axle into the slot, ensuring there is a
washer on either end of the axle, and tighten the table adjustor
screws back into place.
WARNING! DO NOT START THE TOOL UNTIL ALL
COMPONENTS ARE COMPLETELY ASSEMBLED.
Adjusting The Tilt Table
1. Loosen the table adjustor
screws slightly.
2. Rotate the angle increment dial
to adjust the table to the desired
angle.
3. Tighten the table adjustor
screws to lock the table in
place.
Adjusting The Mitre Guide
1. Loosen the fence adjustor screw.
2. Rotate and slide the mitre fence to
the desired angle and position.
3. Tighten the fence adjustor screw to
lock the mitre fence in place.
3. ADJUSTING THE SANDER
WARNING! ENSURE THE TOOL IS TURNED OFF
AND DISCONNECTED FROM THE POWER SUPPLY
BEFORE PERFORMING ANY OF THE FOLLOWING
OPERATIONS.
WARNING! ENSURE THE TOOL IS TURNED OFF
AND DISCONNECTED FROM THE POWER SUPPLY
BEFORE PERFORMING ANY OF THE FOLLOWING
OPERATIONS.

Setting The Speed
Rotate the speed control dial to
the desired speed setting.
Use a high speed setting to remove material quickly or a lower setting
for more control.
WARNING! DO NOT ADJUST THE SPEED OF THE
SANDING DISC WHILE SANDING WORKPIECES IS IN
PROGRESS.
Starting The Sander
1. Press the on/o󰀨 switch to the ‘I’
position to turn the sander on.
2. Press the switch to the ‘0’ position
to turn the tool o󰀨.
WARNING! ENSURE THAT THE BENCH DISC
SANDER IS CLAMPED SECURELY BEFORE
SANDING.
Sanding Procedure
The arrow on the top of the sanding
wheel indicates the direction of rotation.
WARNING! DO NOT ATTEMPT TO SAND MATERIAL
ON THE RIGHT HALF OF THE SANDING DISC.
THIS WILL CAUSE THE WORKPIECE TO FLY OFF
THE TOOL AND POTENTIALLY CAUSE PERSONAL
INJURY OR DAMAGE TO BYSTANDERS.
1. Fit the appropriate grit sandpaper to the sanding wheel.
2. Set the sanding speed with
the control dial, plug in the
power cord and switch on the
sander.
3. Allow the sander to reach full
speed and run without load for
a minute.
4. While maintaining a rm grip
on the workpiece, hold the
surface to be sanded against
the sanding sheet.
Note: Move it steadily back and
forth across the sanding disc
to ensure even wear and to
prolong the life of the sandpaper.
WARNING! NEVER USE THE BENCH SANDER
WITHOUT THE TILT TABLE & DISC FENCE IN PLACE.
MBDS-125
4. CONTROLS 5. USAGE
OPERATION
WARNING! THIS PRODUCT IS NOT RECOMMENDED
FOR SANDING DRYWALL OR PLASTER DUE TO THE
ULTRA-FINE SANDING PARTICLES PRODUCED.
DRYWALL SANDERS IN CONJUNCTION WITH DUST
EXTRACTION ARE RECOMMENDED FOR DRYWALL
AND PLASTER SANDING APPLICATIONS.
WARNING! THE TOOL MUST BE USED WITH A
RESIDUAL CURRENT DEVICE WITH A RATED
RESIDUAL CURRENT OF 30mA OR LESS.
WARNING! DO NOT LEAVE THE TOOL UNATTENDED
WHILE THE ON/OFF SWITCH IS IN THE ON
POSITION.

MAINTENANCE
Cleaning
1. We recommend that you clean the tool immediately after you use it.
2. Keep the device free of dirt and dust as much as possible. Wipe the
equipment with a clean cloth.
Storage
Pull the mains plug out of the socket, switch o󰀨 the tool and make
sure that it is secured in such a way that it cannot be started up again
by any unauthorised person.
Store the tool in a dry location which is not accessible to unauthorised
persons.
Supply Cords
If the supply cord of this power tool is damaged, it must be
replaced by a specially prepared cord available through the service
organisation.
Note: Ozito Industries will not be responsible for any damage or
injuries caused by the repair of the tool by an unauthorised person or
by mishandling of the tool.
WARNING! BEFORE CLEANING OR CARRYING OUT
ANY MAINTENANCE PROCEDURE, MAKE SURE
THAT IT IS DISCONNECTED FROM THE POWER
SUPPLY TO PREVENT ACCIDENTAL STARTING.
Sanding Tips
Never force the material into the sander; allow the sandpaper to do
the work. Applying additional pressure will slow the motor, rapidly
wear the sandpaper, and greatly reduce the sander speed. This will
slow the removal rate and produce an inferior quality surface.
WARNING! EXCESSIVE PRESSURE WILL
OVERLOAD THE MOTOR, CAUSING OVERHEATING
AND POSSIBLE DAMAGE TO THE MOTOR AND/OR
DAMAGE TO THE SURFACE.
Be sure to check your workpiece often. The sander is capable of
removing material rapidly, especially with coarse paper.
Do not sand on one spot for too long. The sander’s rapid action may
remove too much material, creating an uneven surface.
WARNING! WHEN SANDING SOFT METALS, THE
MATERIAL CAN GET HOT. SAND WITH CAUTION
AND IF NECESSARY, COOL THE MATERIAL DOWN
BEFORE RESUMING SANDING OPERATIONS.
WARNING! DUST EXTRACTION SHOULD NOT BE
USED DURING METAL SANDING TO PREVENT
HOT METAL FRAGMENTS FROM ENTERING
THE VACUUM CLEANER OR DUST EXTRACTION
SYSTEM.
WARNING! BEFORE COMMENCING METAL
SANDING, THE SANDER AND WORK AREA MUST BE
CLEANED THOROUGHLY TO REMOVE ANY WOOD
DUST & RESIDUE.

DESCRIPTION OF SYMBOLS
Double insulated
Wear breathing protection Wear eye protection
Warning
Regulatory Compliance Mark
(RCM)
VVolts Hz
W
Hertz
~
n0
/min
Alternating Current Watts
No load speed
Revolutions or reciprocations
per minute
Read Instruction Manual
Power tools that are no longer usable should not be
disposed of with household waste but in an environmentally
friendly way. Please recycle where facilities exist. Check
with your local council authority for recycling advice.
Recycling packaging reduces the need for landll and raw
materials. Reuse of recycled material decreases pollution in
the environment. Please recycle packaging where facilities
exist. Check with your local council authority for recycling
advice.
CARING FOR THE ENVIRONMENT
SPARE PARTS
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]

WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of re, electric shock, personal injury and
material damage.
Read the whole manual carefully and make sure you know how to switch the tool o󰀨 in an emergency,
before operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The charger has been designed for 230V and 240V only. Always check that the power supply corresponds
to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.
This tools charger is double insulated; therefore no earth wire is required.
Note: Double insulation does not take the place of normal safety precautions when operating
this tool. The insulation system is for added protection against injury resulting from a possible
electrical insulation failure within the tool.
If the supply cord of this power tool is damaged, it must be replaced by a specially prepared cord available
through the service organisation.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the
extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead
not suitable for the power input of the tool or which is damaged or defective may result in a risk of re and
electric shock.
The power supply for this products charger should be protected by a residual current device (rated at
30mA or less). A residual current device reduces the risk of electric shock.
WARNING! The appliance is not to be used by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction.
Young children should be supervised to ensure that they do not play with the appliance.
• The tool should always be used with a residual current device with a rated residual current of 30mA
or less.
• Unplug the sander before changing accessories. Accidental start-ups may occur if the sander is
plugged in while changing an accessory.
• Disposing of dust. Be extremely careful of dust disposal, materials in ne particle form may be
explosive. Do not throw sanding dust on an open re. Spontaneous combustion, may in time, result
from a mixture of oil or water with dust particles.
• Always wear eye protection and a dust mask for dusty applications and when sanding overhead.
Sanding particles can be absorbed by your eyes and inhaled easily and may cause health
complications.
• Use special precautions when sanding chemically pressure treated timber, paint that may be
lead based, or any other materials that may contain carcinogens. A suitable breathing respirator
and protective clothing must be worn by all persons entering the work area. Work area should
be sealed by plastic sheeting and persons not protected should be kept out until work area is
thoroughly cleaned.
• Do not ‘wet sand’ with this sander. Liquids entering the motor housing are an electrical shock
hazard.
• Do not use sandpaper intended for larger sanding pads. Larger sandpaper will extend beyond the
sanding pad causing snagging, tearing of the paper. Extra paper extending beyond the sanding
pad can also cause serious lacerations.
• Some dust created by power sanding, sawing, grinding, drilling and other construction activities
contain chemicals known to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
- Lead from lead-based paints;
- Crystalline silica from bricks, cement and other masonry products, and;
- Arsenic and chromium from chemically-treated timber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce
your exposure to these chemicals: work in a well ventilated area and work with approved safety
equipment, such as dust masks that are specially designed to lter out microscopic particles.
• Always hold material rmly against the tilt table.
• Never use the bench sander without the tilt table in place.
• Do not operate the tool until it is completely assembled and installed according to the instructions.
• Always work with adequate lighting.
• Before work, check that the machine is placed on an even surface with su󰀩cient stability. For your
own safety, always mount the machine to a work bench with the provided C-clamp.
• Keep the surrounding area of the machine well maintained and free of loose materials, such as
chips and cut-o󰀨s.
• Always hold the workpiece rmly when sanding.
• Never sand more than one workpiece at a time. Do not stack more than one workpiece on the
machine base at a time.
• Do not sand with the workpiece unsupported. Do not sand pieces of material that are too small to
be safely supported.
• Avoid awkward operations and hand positions where a sudden slip could cause your hand to move
into the sanding belt or disc.
• Avoid kickback by sanding in accordance with directional arrows.
• Always maintain a clearance of 16mm between the worktable and the machine.
• Never stand or have any part of your body in line with the path of the workpiece.
• Machine should never be connected to power supply when you are assembling parts, adjusting, or
when not in use.
• Never leave tool running unattended. Do not leave tool until it comes to a complete stop.
• Never use this belt/disc sander for cut-o󰀨 operations.
• When sanding soft metals, the material can get hot. Sand with caution and if necessary, cool the
material down before resuming sanding operations.
DISC SANDER SAFETY WARNINGS
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings
refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to
lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase
the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
b.Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the o󰀨-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
h. Do not let familiarity gained from frequent use of tools allow you to become complacent and
ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power
tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and o󰀨. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any
other condition that may a󰀨ect the power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations di󰀨erent from those intended could result in a hazardous situation.
h. Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
