PACH & COMPANY QUANTUM QVOiP SERIES User manual

•24 Months warranty for complete system
•6 Months warranty for Printed Circuit Board
Exit program, cancel call
23
Lock-out Count
Save program
24
Alarm
0= disable
1= local beep for 60
seconds
2= disable system for 60
seconds with no beep
3= call directory (0-9)
00
Change master code (0000
is default)
25
Keypad beep
0= disable (default)
1=enable
01
Add new forwarding tenant’s
directory
26
Door beep
0= disable
1= enable (default)
02
Edit existing tenant’s
directory
27
Talk time (060-240
second). Default=60
second
03
Delete existing tenant’s
directory
28
Unlock relay1 time
(12-99 second).
Default= 12 second
04
Clear all forwarding tenant’s
directory
29
Unlock relay2 time
(12-99 second).
Default= 12 second
05
Enable/Disable Call
33
Temporary code
06
New access code
34
Special code
07
Delete access code
35
Temporary card
08
Clear all access code
36
Special card
09
Access code digit (4-8 digit).
Default is 4-digit
38
System acknowledge
(0-9). Default= 3
10
Add new card
39
Remote access
0= disable
1=enable (default)
11
Delete card
40
DTMF relay 1 (0-9).
Default=9
12
Clear all card
41
DTMF relay 2 (0-9).
Default=8
13
Set time
42
Relay 2 Mode
1= door control (default)
2= relay 2 trigger
simultaneously as relay
1
3= enable if function
code 24 is enabled
4= turn relay 2 on and
off
On=7, Off=6
14
Set date
43
DND: do not disturb time
zone (0-9)
15
Initializing event recording
44
Disable Time zone relay
1, 2 or both
16
AUS= auto unlock schedule
(0-9 schedule)
45
Relay 1 and 2 unlock
timer
17
TMZ= time zone. 20 TMZ,
00-20.
46
Firmware version
18
HLD= holiday zone. 20 HLD,
1-20
48
PBX enable. Default=
disable
19
Directory digit (2-4 digit).
Default is 2-digit
49
Edit Access code
20
AUXIN1
0= disable (default)
1= enable control by relay 1
open interval
2= relay 1 control by AuxIn2
50
Erase the memory to
factory default
21
AUXIN2
0= disable (default)
1= enable control by relay 2
open interval
2= relay 2 control by AuxIn2
51
Welcome screen
22
Do not disturb
0= disable (default),
1= enable
Log on to programming:
Press simultaneously then
release, the welcome message will
stop scrolling (repeat if screen still
scrolling) enter 4-digit “MASTER
CODE” (0000 is default), the screen
will show as below:
Select the “Function Code” from
the table
OPERATION
Two ways to call tenant
1. Press to scroll name from A-Z or to scroll name
from Z-A then press to call name selected.
2. Press wait for dial tone then press the directory
number
Opening the door remotely press (relay 1) or
(relay 2)
Open the door with the access code press (display
screen will stop scrolling) then press a valid 4-digit access
code.
Extend talk time tenant must press from the phone
after the time out warning beep.
Call into the system:
1. Enable function code 39 and function code 38 must be
set 1-9
2. Call the system phone number, hear one beep if the
system
answering the call.
3. Press then 4-digit master code, hear one short
beep
4. Press to establish two ways communication
5. Press or to release the door.
.
QWCM BROWSER DEFAULT IP
IP: 192.168.1.230
SUBNET: 255.255.255.0
GATEWAY: 192.168.1.1
DNS: 192.168.1.1
USERNAME: Administrator
PASSWORD: pach or 8888
QUANTUM QVOIP SERIES
PACH AND COMPANY INC. QUICK GUIDE

1. INPUT POWER 12VAC 40VA SUPPLIED (voltage measurement must be (12.5-14.0 VAC)
OR 12VDC 2A adjustable power supply (voltage measurement must be 13.5-14.0 VDC)
2. 12 VDC 4Ahr BATTERY BACK-UP (OPTIONAL) WARNING: THIS IS NOT INPUT POWER
3. DOOR 2 DRY CONTACT RELAY, MUST USE SEPARATE POWER FOR DOOR STRIKE
4. DOOR 1 DRY CONTACT RELAY, MUST USE SEPARATE POWER FOR DOOR STRIKE
5. TELEPHONE OUT LOOP TO NEXT QC SYSTEM, IF TELEPHONE LINE IS SHARED
6. TELEPHONE INPUT ANALOG DIAL TONE “ONLY”
7. AUX 1 AND AUX 2 FOR EXIT SWITCH, LOOP DETECTOR OR ANY INPUT DEVICE WITH DRY CONTACT OUTPUT.
8. DOORS1 AND DOORS 2 SENSOR. WARNING: THESE ARE NOT DOOR CONTACTS
9. RS-485 PORT, CONNECT TO SLAVE UNITS (USCR, UCRM, USKP AND USKPR) UP TO 8 UNITS
10. 26-WIEGAND INPUT. PROPRIETARY CARD READER IS BUILT-IN ON THE QC SERIES. DISCONNECT THE BUILT-IN READER IF YOU
ARE USING YOUR OWN CARD READER.
11. FACTORY USE “ONLY” TO POWER THE QWCM IP MODULE AND FAN. WARNING: “DO NOT USE THE +12VDC POWER TO POWER
ANY OTHER DEVICES”.
12. AATA2 INPUT POWER 5VDC 3.0A (SUPPLIED)
13. AATA2 INTERNET CONNECT TO ROUTER OR SWITCH
14. AATA2 LAN CONNECT TO QWCM (#17)
15. AATA2 PHONE 1 ANALOG DIAL TONE.
16. QWCM POWER AND COMMUNICATION CONNECT TO (#11 12VDC POWER) AND (#18 RS-232). DO NOT UPLUG THIS CONNECTOR
WITH POWER ON FACTORY PREWIRED
17. QWCM ETHERNET PORT CONECT TO ROUTER OR SWITCH.
DO NOT CONNECT TO AATA2 NO. 14
18. RS-232 CONNECT TO (#16 ON QWCM) FACTORY PREWIRED
Technical Support is available
Monday-Friday 7:00 am-4:00 pm PST at 1-888-678-7224
Technical Info and complete manual are available online
www.pach-co.com
AATA2 ACTIVATION
www.ooma.com/activate
Nominal monthly fees and taxes required
based on zip code.
TURN OFF THE SYSTEM’S POWER
BEFORE CONNECTING OR
DISCONNECTING ANY DEVICES
