INTRODUCTION
The Palintest Scanning Analyzer is a precision instrument used with unique
pre-calibrated disposable sensors. It offers a simple method of analyzing
for lead or copper.
The instrument is lightweight and portable for field or laboratory use. It is
extremely simple to use, with a large, clear, backlit results display.
Once linked to a PC through the USB interface, a stored log of up to 500
tests may be accessed.
Diagram of Kit, Instrument and Sensor
Use of Sensor
The sensor is designed for single use only. The surface of the sensor is highly
sensitive. It should only be handled bythe edges or through the foil packaging.
Power Key
to switch ON or
OFF
OK/Return
Key
Sliding Catch
Cursor Keys
to Select Options
Sensitive Surface –
DO NOT HANDLE
Connecting
Tracks
Calibration
Chip
Crushing
Rods
Tablets and
Sensors
Sample
Vessels

4
INSTRUMENT OPERATION
The Scanning Analyzer automatically engages with the computer when
connected to it via its USB port. This allows the user to view the log of results
on their PC.
To perform a test the unit should be battery powered and not connected to a
PC.
Testing the Sample
Instrument Start Up
1
Press and hold the power button until the
title screen is displayed.
2
When the instrument passes all internal
functional checks on start up, the screen
displays the current calibration code and
prompts the user to insert a sensor.
Ensure the calibration code shown on
screen matches with the number on the
box of sensors in use.
When the instrument is first turned on, the
test that is currently selected is displayed
on the screen, eg Lead in Water.
To enter a new calibration code, see Page
8 for further instructions.
To change the test, see Page 9 for further
instructions.
If start up fails, an error message is displayed.
Insert
Sensor
Lead in Water
113-753-22
Palintest
SCANNING ANALYZER
SA1100

5
Performing a Test
1
Slide the front catch all the way to the right,
and open the instrument case fully.
2
Rinse the sample vessel and then fill to the
5 ml line with the sample. Place the sample
vessel in its position within the instrument.
3
Add one Soluprep SP-A tablet to the sample,
crush with the crushing rod and stir to dissolve.
When the tablet is dissolved the sample is
preparedforthetest.
4
Tear open the foil along the indicating marks, in
themannershown. Holdingthesensorthrough
thefoilpack,exposetheconnectingtracks.
5
Press the blue lever to open the jaws of the
sensor connector. Insert the exposed end of
the sensor, connecting tracks uppermost, into
the slot, and release the lever. The jaws will
close tohold thesensor inplace. Slidethe foil
pouch off to expose the sensor.
6
Gently close the instrument lid to immerse
the sensor in the sample. The test starts
automatically. Do not disturb the instrument
duringthetest.
7
After threeminutes, thelead or copper result will
be displayed. If the concentration of copper is
>500 µg/L, the result will be displayed after 30
seconds. Pressthedownarrowtoscrollthrough
‘Date and Time and Sample Number’. All results
areautomaticallystoredtotheinstrumentlog.

5 ml
Fill with sample
to 5 ml mark.
µg/L Lead
36
Read Sample
Place sample
vessel in holder.

6
8
After completion of the test DO NOT OPEN
THE INSTRUMENT. The sensor must be
released into the sample vessel while the
instrument lid is closed - push up on the lever
located within the left-hand side of the
instrument - accessible without opening the lid.
Once the sensor has been released, open the
instrument lid and cap the sample vessel with
theused sensorstillinside.
Do not leave water within the instrument on
completion ofthetest.
The sensor contains mercury and therefore
must be disposed of as per state or
national/regionallaws.
9
Press key to carry out a new test or new
calibration.
If no key is pressed within five minutes, the
instrument automatically switches off to
save power.
10
To scroll through all the previous readings,
use the left/right keys when on the results
screen.
11
The following symbols will appear if the
result is out of range :-
> Higher than test range
< Lower than limit of detection
Stored Samples
Stored samples are usuallytreated with nitric acid (to 0.15%) to ensure metals
remain in solution.
If samples have been acidified, they should be neutralized before analysis.
A Neutralisation Pack (PT 429) is available as an optional extra.
Using forefinger on left-
hand, push lever upwards
to release sensor into
the sample vessel.


7
Getting the Best Results
1 Handle the sensors with care.
2 Place the instrument on a flat surface free from vibration.
3 Do not disturb the instrument or sample during the test.
4 The sensor response is most accurate and precise when sample temperature
is intherange of 20 –25°C.
5 Use a fresh sample vessel and clean crushing rod for each test.
6 Ensure the correct Soluprep tablet is used for the test and is completely
dissolved before starting the test.

8
Entry of New Calibration Code
1
Slide the front catch to the right, and open
the instrument case fully.
2
Press the blue lever, and insert the contacts
of the calibration chip fully into the slot
revealed. Release the blue lever.
3
Close the instrument lid and view the display.
Check the new calibration code displayed on
screen matches the number on the sensor
box. A test can now be performed.
4
If the calibration procedure was unsuccessful,
an errormessage will be displayed. Steps 1 –3
should be repeated, if the chip will still not
calibrate, contact Palintest technical enquiries
forfurtherinformation.
5
Remove the calibration chip.
NB:Theinstrumentstores separatecalibration
values for each type of sensor. If a Copper in
Water calibration chip is inserted while the
instrument is set to read Lead in Water, then
the instrument will store this value to use for
Copper inWater tests, but will continue to use
the previously stored calibration for Lead in
Water.

Lead in Water
Failed
113-753-22
Lead in Water
113-753-22

9
Optional Settings and Data Handling
Enter SET-UP Mode
1
To engage the system menu, turn the unit
on and press the left hand side arrow on
the front of the unit.
2
Scroll through the menu of options using
the keys and press to select.
3
To exit the system menu, select the left
hand side arrow when the system menu
screen is displayed.
Selectable Options
Choose a Test
There are two tests available on the SA1100:
Press to show the tests.
Scroll to highlight the required test.
Press to select and return to the options list.
Language
Press to show the available languages. Scroll to highlight the
required language. Press to select and return to the options list.
Clear Log
Press to select. Use keys to highlight [Yes] or [No].
Press to perform the action and return to the options list.
Sample Number
Press to select the sample number option. Use keys to highlight
[On] or [Off].
Choose a Test
Language
Clear Log
Sample Number

Lead in Water
Copper in Water

10
Selecting ‘On’ will mean the sample number screen is displayed to the user
before the test starts, allowing the user the option to manually adjust the
sample number.
Press to perform the action and return to the options list.
Sample Increment
Press to select the sample increment option. Use keys to highlight
[On] or [Off].
Selecting ‘On’ will mean the sample number is automatically allocated as
the next sequential number in the data log.
Press to perform the action and return to the options list.
Set Time
Press to edit the displayed time. Use keys to increment/decrement
the highlighted number. Use the keys to move the highlight to different
numbers.
Press to accept the new time and return to the options list.
Set Date
Press to editthe displayeddate.Usethe keystoincrement/decrement
the highlighted number. Use the keys to move the highlight to different
numbers.
Press to accept the new date and return to the options list.
Date Format
Press to select UK or US date format. Use the keys to highlight
either DD/MM/YYYY or MM/DD/YYYY.
Press to select and return to options list.
Serial Number
Press to view the instrument serial number.
Press to return to the options list.

11
Error Messages
The Scanning Analyzer features an error detection system to guide the
user. After correcting each error, press key to reset the instrument.
Always use a fresh portion of sample if a sensor has been immersed in the
water sample.
Error
Action
Unable to read:
Sensor damaged
Remove sensor and discard
before trying a new sensor.
Unable to read:
Check sensors and
contacts
1) Remove and discard wet
sensor. Dry the contacts
(see below)
2) Remove calibration chip.
Error: Sensor
disconnected
Remove sensor and discard
before trying a new sensor.
Lid opened during
test
Remove the sensor.
Press key and start again
with fresh sample and sensor.
F01, F02…F30, etc
These errors are indicating a
fundamental error with the
electronic check chip.
Ensure the ship is inserted
correctly and re-try. If this still
fails, contact the Palintest
technical department.
The instrument is fitted with integral electrical connectors for insertion of the
sensors. If the contacts accidentally become wet, open the jaws with the
blue lever and insert a Palintest Contact Drying Stick (CS 160). Wait a few
seconds until it absorbs the water, then remove and insert the opposite end
to check the contacts are dry. A dry ‘Contact Drying Stick’ may also be
used to clean the contacts.

12
COMPUTER INTERFACE
The Scanning Analyzer USB port, once connected to a PC, can be used to
access data stored in the instrument log, or to upgrade the instrument
software.
When the Scanning Analyzer is connected to a PC, it behaves like a
removable hard drive or USB memory stick.
Data Access
1 Connect the Scanning Analyzer to a PC using a USB cable.
2 Press and hold the key until the title screen appears then release.
3 On the PC, open the hard drive window. Three files will be seen :-
4 Results are stored in the Log file, SCAN_LOG.TXT.
5 Copy the file to the PC to view and handle the data.
6 Open this file. Results appear as a text file. Each result appears on one
line with spacing to allow easy opening in a spreadsheet program :-

13
7 Theresultsstored intheinstrumentmemorycanbedeleted ineitherof two
ways –either delete the log file on the hard drive window that is shown by
the PC, or use the instrument Set-Up mode as shown on Page 8.
8 Note that for security of the audit trail, it is not possible to save files to
the log file stored in the instrument.
Software Upgrade
When new software is made available byPalintest,the Scanning Analyzer may
be upgraded. Files will be available by e-mail or on the Palintest website :-
1 Connect the Scanning Analyzer to a PC using a USB cable.
2 Press and hold the key until the title screen appears. Release the .
key.
3 On the PC, open the hard drive window.
4 Drag and drop the software upgrade (PLE.) file onto the hard drive window.
5 The new software will be programmed into the Scanning Analyzer. The
instrument will re-start to run the new software.
6 When upgrading the PLB. file, the instrument should be turned off and
then back on again in order for the new software to take effect.
Any logged data will be retained during this upgrade.

14
TECHNICAL INFORMATION
Operating Principle
The Palintest Scanning Analyzer is an electro-chemical device that utilises the
analytical technique of anodic stripping voltammetry. It can be divided into the
plating phaseand the scanning phase.
The plating phase begins as soon as the electrode is immersed in the
sample. A voltage is applied to the electrode that induces a small electric
current to pass through the sample. The dissolved metal ions are deposited
onto the electrode surface. Once the plating phase is complete, the scanning
phase commences. The Scanning Analyzer applies an increasing reverse
voltage to the electrode to strip off the deposited metals. Each metal is
stripped from the electrode in a defined order and at a precisely known
voltage, thus metals are separated and identified.
The Scanning Analyzer controls the voltage cycle, and captures and collates
thousands of signal readings. The processor interprets these readings to
identify the specified metal and determines its exact concentration. The
instrument display gives a direct reading of the test result.
No user calibration is required because each electrode batch is meticulously
checked during manufacture and assigned a calibration code. This code is
used to construct a calibration curve that exactly matches the sensor batch.
A pre-programmed, plug-in calibration chip is provided with each pack of
sensors to automatically enter the calibration code into the instrument.
System Performance Characteristics
LEAD
COPPER
Analysis Time
3 minutes
30s or 3 minutes
Precision Range
2 –100 µg/l
50 –2000 µg/l
Resolution
1 µg/l
1 µg/l
Sample Temperature
15 - 30°C
15 - 30°C
Unit Conversions
To convert µg/l (parts per billion, ppb) into mg/l (parts per million, ppm) :-
Result in µg/l /1000 = Result in mg/l

15
GENERAL INFORMATION
Tehnical Specification –Instrument
Instrument Type Fixed voltage potentiostat
Display Backlit, graphical LCD (42 x 22 mm), with six
language options and direct-reading of results in
µg/l
User Selectable Options Set time and date, date format, display language
and reset sample number
Data Logging Stores 500 previous readings and offers prompts
when 40 and20 left
Interface Waterproof USB connection to PC
Power 4 x 1.5v ‘AA’ alkaline batteries. Battery power
saving system with auto switch-off after five minutes.
PoweredviaUSBportwhenconnectedtocomputer
Size Instrument only 170 x 126 x 116 mm
Weight 975g
Technical Specification –Sensors
Sensor Type Disposable, single-use sensor
Calibration Pre-calibrated during manufacture
Packaging Individually packed in sealed foil
Storage Life 18 months
Storage Temperature 2°C –30°C (35°F –86°F)
Calibration Check Standards
For help with the preparation of standard solutions in order to enable full
testing of the instrument, please contact Palintest Technical Queries
Department.
To use the electronic check standards, please follow the instructions included
in the kit.

16
Power Supply
The Scanning Analyzer is designed to operate on alkaline batteries. If the
batteries require replacement a ‘Low Battery’ warning message appears. The
message canbe cleared bypressing . The instrumentcontinuestofunction
correctly for several tests, but the batteries should be replaced as soon as
possible. Whenthepowersuppliedbythebatteries isinsufficienttocarryout a
test, the instrument displays the warning message continually and will not
carry out a test.
The battery compartment, in the base of the instrument, is secured by four
screws. To replace the batteries, remove the cover and battery pack to
access the old batteries. Replace all four batteries at once with new batteries,
observing the correct polarity as marked in the battery holder.
Insert the battery pack into the base of the instrument, replace the battery
compartment cover. Tighten the screws in diagonal pairs to ensure water-
proof fit.
Use 4 x 1.5v ‘AA’ alkaline cells (type MN1500, LR6, E91 and AM3 or
equivalent).
To avoid corrosion damage through leakage, remove batteries from the
instrument if it is to be stored or left unused for a long period of time.
CARE AND MAINTENANCE
The Scanning Analyzer is designed to give long and trouble-free operation.
The instrument is suitable for both laboratory and field use.
On no account should solvents or abrasive materials be used to clean the
instrument.
Guarantee
The Palintest Scanning Analyzer is guaranteed for a period of two years
from the date of purchase, excluding accidental damage or damage caused
by unauthorised repair or misuse. Should repair be necessary, contact our
Technical Services Department quoting the serial number shown on the
instrument label. This guarantee does not affect statutory rights.

17
Reordering Information
Part Code
Product Description
PT 435
Lead Sensors x10
PT 436
Copper Sensors x10
PT 429
Neutralisation Pack
CS 160
Contact Drying Sticks
CS 640
Instrument Check Chip

18
CONTACT INFORMATION
Palintest Limited
Palintest House, Kingsway, Team Valley, Gateshead, Tyne &Wear, NE11 0NS, England
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
Website: www.palintest.com
Palintest USA
1455 Jamike Avenue (Suite 100), Erlanger, Kentucky, 41018 USA
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Website: www.palintestusa.com
Palintest Australia
Unit 1/53, Lorraine Street, Peakhurst, NSW 2210, Australia
Tel: [phone]
Priority Tel: [phone]
Fax: [phone]
Priority Fax: [phone]
E-mail: [e-mail]
Website: www.palintest.com.au
Palintest China
Room 1711, Fanli Mansion, 22 Chaowai Street, Chaoyang District, Beijing 100020 PRC
电话：86-10-51261868-809
传真：86-10-82626620
E-mail: chi[email protected]
Website: www.palintest.cn
V2- 07/14
