FX-301
Digital Fiber Sensor
Superior performance and
advanced user-friendly
multi-functionality
enables expert usage on
the very first day
68
SERIES
Long-range sensing made possible with built-in optical lens Stable long-term sensing Enhanced worksite-friendly installability
For the first time in the industry, an
optical ‘double coupling lens’ has been
incorporated directly into the fiber
sensor itself. This lens maximizes the
light emission efficiency, resulting in a
tremendous improvement in the
sensing range. Sensing ranges with
small diameter fibers and ultra-small
diameter fibers, which have become
very popular in recent years due to the
miniaturization of chip components,
have been increased by 50 % over
previous values achieved with other
amplifiers.
The newly developed four-chemical
emitting element that uses the FX-301
(red LED type) suppresses changes
over long periods of time as much as
possible, so that a stable light emitting
level is maintained. There is very little
element deterioration so that stable
and accurate sensing can be
maintained over long periods.
Our new fiber cutter utilizes a specially
developed two-in-one fiber attachment
that now makes it possible to cut two
fibers simultaneously to exactly the
same length. Also, since the fibers can
be attached to the amplifier while
being fixed in position in the two-in-one
fiber attachment, sensitivity changes
due to variation in the amount of fiber
insertion do not occur.
Selectable response time
We offer 4 selectable levels to
correspond with various applications:
the response time 150 !s FAST mode,
the LONG mode, perfect for adverse
environments, and the S-D mode,
especially made for minute detection.
http://www.fiber-sensor.com
* Passed the UL 991 Environment Test
* UL 61010C-1 compatible, Passed the UL 991 Environment Test based on SEMI S2-0200.
[Category applicable for semiconductor manufacturing: TWW2, Process Equipment]
[Applicable standards: UL 61010C-1]
[Additional test / evaluation standards as per intended use: UL 991, SEMI S2-0200]

69
FX-301
Even beginners can quickly learn how to use the MODE NAVI
MODE NAVI uses six indicators to display the amplifier’s basic operations. The current operating mode can be confirmed at a
glance, so even a first time user can easily operate the amplifier without becoming confused.
Easy maintenance, as main
and sub units are identical
Both main and sub units utilize the same
amplifier body. This feature allows for
easy mounting in the side-by-side
configuration. The main and sub unit
functions are distinguished only by the
proper use of 3-core main cable and the
1-core sub cable. Moreover, by utilizing
the same body for both main and sub
units, inventory management and
maintenance is simplified.
Wiring- and labor-saving design allows side-
by-side configuration for up to sixteen units
Up to sixteen amplifiers can be
connected in a side-by-side configuration.
As the sub cable contains only one output
line, a great amount of wiring and space
can be saved. Also, special ‘sliding’
connectors have been provided for all
main and sub cables, which can be
detached merely by releasing the lock
and pulling directly back, without having
to slide the amplifier body to the side.
Using this connector system, only a
minimal amount of space is required for
regular maintenance.
The use of only two switches makes for very simple operations
Only two switches, the large jog switch and the large MODE key, are required for
operation. Depressing the large MODE key sets the ‘mode selection’ and ‘mode
cancel’ functions. The large jog switch is used to select from the detailed functions
available within each mode, as well as to change numerical values after the mode
has been chosen.
Polyethylene packaging
Environmentally friendly packaging
With regard to effects on the environment,
we only utilize the simplest of packaging
methods greatly contributing to the reduction
in wastes generated by your worksite.
Also, the bags are made of polyethylene, a
substance that doesn’t give off polluting
gases when burned.

70
FX-301
4 types of light sources available
In addition to our red LED (four-chemical
emitting element) type, the blue, green,
and infrared LED types are also provided
to correspond to your specific application.
Easy code input setting
Every function can be directly set merely by the input of a four digit code (numbers) from the code table. This convenient
feature is easy to set up.
In the event that settings are accidentally changed at the operating site, merely entering the correct code can restore the
original settings. This results in easy and quick maintenance.
Equipped with each type of timer
These sensors are equipped with 3
types of timers, ON-delay, OFF-delay,
and ONE SHOT, for compatibility to
variegated environments.
ON-delay timer
This function is useful for sensing only
objects taking a long time travel.
OFF-delay timer
This function is useful when the
connected device has a slow response
time.
ONE SHOT timer
This function is useful when the input
specifications of the connected device
require a signal of fixed width.
Optical communication function lets
multiple sensors be adjusted all at once
The optical communication function
allows the data that is currently set to
be copied and saved all at once for all
amplifiers connected together from the
right side. This greatly reduces
troublesome setup tasks and makes
setup much smoother.
Selectable cable length
Made available are 3 lengths, 1 m 3.281 ft,
2 m 6.562 ft, and 5 m 16.404 ft, to suit
your application requirements. This helps
reduce the waste caused by cutting cables
and lightens the installation workload.
Invertible digital display
The digital display can be inverted as per its orientation once mounted onto the amplifier.

71
FX-301
Optional units for greater freedom and control when installing
Sensor-PLC connection system
This wire-saving system enables the
collective connection of up to 16 I/O
devices with an MIL connector.
Scattered installation is also possible
with the help of a sensor separate
unit.
SC SERIES Bank selection unit
Without directly manipulating the
sensor itself, you can simultaneously
switch up to 16 fiber sensors’ settings
using an external emitted signal.
(Load and save)
mAlso possible with the FX-301 series’ databank
function
FX-CH SERIES
APPLICATIONS
Workpieces detection
This standard type of FX-301 using red light
has a four-chemical emitting element for
stable sensing over long periods.
Sensing semi-transparent stickers
The blue LED type greatly reduces the
dampening rate, making it ideal for delicate
sensing.
Sensing register marks
The green LED type can accurately
discriminate between red and yellow, that
cannot be easily detected using red LED
type.
Sensing film meandering
Infrared LED type is ideal for sensing
environments with light restrictions, such as
places where light-sensitive film is being
handled. (The emission peak wavelength:
940 nm 0.037 mil.) It includes full-auto
teaching function which allows sensitivity to
be set without stopping the workpiece line.
Detecting chip component
Because of low light intensity fluctuations
when detecting minute moving objects,
decrease the hysteresis in PRO mode and
accurate sensing will be possible in high-
speed mode. This method is optimal for chip
component verification in taping equipment.
Detecting register marks on a
transparent sheet
When detecting registration marks on
transparent film with a thru-beam type, the
S-D (reduced light intensity) mode will
enable minute light intensity fluctuation
sensing.

72
FX-301
ORDER GUIDE
Type Appearance Model No. Emitting element Output
NPN output
PNP output
Digital
FX-301
FX-301B
FX-301G
FX-301H
FX-301P
FX-301BP
FX-301GP
FX-301HP
Red LED
Blue LED
Green LED
Infrared LED
Red LED
Blue LED
Green LED
Infrared LED
Amplifiers
NPN open-collector
transistor
PNP open-collector
transistor
Quick-connection cables
Type Model No. Description
CN-73-C1
CN-73-C2
CN-73-C5
CN-71-C1
CN-71-C2
CN-71-C5
Length: 1 m 3.281 ft
Length: 2 m 6.562 ft
Length: 5 m 16.404 ft
Length: 1 m 3.281 ft
Length: 2 m 6.562 ft
Length: 5 m 16.404 ft
Main cable
Sub cable
0.15 mm
2
3-core cabtyre cable, with connector on one end
Cable outer diameter: "3.0 mm "0.118 in
0.15 mm
2
1-core cabtyre cable, with connector on one end
Cable outer diameter: "3.0 mm "0.118 in
Main cable
• CN-73-C
Sub cable
• CN-71-C
Appearance Model No. Description
MS-DIN-E
When cascading multiple amplifiers, or when it
moves depending on the way it is installed on a
DIN rail, these end plates ensure that all
amplifiers are mounted together in a secure and
fully connected manner.
End plates
Quick-connection cable is not supplied with the amplifier. Please order it separately.
Quick-connection cable is not supplied with the amplifier. Please order it separately.
Two pcs. per set
OPTIONS
Designation Model No. Description
MS-DIN-2
FX-MB1
Mounting bracket for amplifier
10 sets of 2 communication window seals and 1 connector seal
Communication window seal:
It prevents malfunction due to transmission signal from another
amplifier, as well as, prevents effect on another amplifier.
Connector seal:
It prevents contact of any metal, etc., with the pins of the quick-
connection cable.
Amplifier mounting
bracket
Fiber amplifier
protective seal
Amplifier mounting bracket
• MS-DIN-2
Fiber amplifier protective seal
• FX-MB1
End plates are not supplied with the amplifier. Please order separately when the amplifiers are mounted in cascade.

73
FX-301
FT-FM10L
FT-SFM2L
FT-B8
FT-NB8
FT-FM2
FT-FM2S
FT-FM2S4
FT-T80
FT-SFM2
FT-N8
FT-NFM2
FT-NFM2S
FT-NFM2S4
FT-SNFM2
FT-R80
FT-V10
FT-SFM2SV2
FT-V22
FT-V41
140 5.512
R25 mm
R0.984 in
R25 mm
R0.984 in
Fiber
R25 mm
R0.984 in
Sleeve
R25 mm
R0.984 in
R25 mm
R0.984 in
Fiber
R25 mm
R0.984 in
Sleeve
R25 mm
R0.984 in
R25 mm
R0.984 in
R25 mm
R0.984 in
LIST OF FIBERS
2,800
110.236
1,400 55.118
1,000 39.370

200 7.874
100 3.937
65 2.559

110 4.331
55 2.165
40 1.575

100 3.937
50 1.969
35 1.378

70 2.756
35 1.378
24 0.945

66 2.598
33 1.299
22 0.866

24 0.945
12 0.472
8 0.315

44 1.732
22 0.866
16 0.630

200 7.874
100 3.937
65 2.559

40 1.575
20 0.787
14 0.551

26 1.024
13 0.512
8 0.315

14 0.551
7 0.276
5 0.197
2.400
94.488
1,200 47.244
900 35.433
(Note 3) 
155 6.102
77 3.031
55 2.165

100 3.937
50 1.969
30 1.181

90 3.543
45 1.772
28 1.102

50 1.969
25 0.984
18 0.709

45 1.772
22 0.866
17 0.669

16 0.630
8 0.315
5 0.197

32 1.260
16 0.630
12 0.472

150 5.906
75 2.953
40 1.575

30 1.181
15 0.591
12 0.472

44 1.732
22 0.866
15 0.591

10 0.394
5 0.197
3 0.118

"0.4 mm
"0.016 in
opaque object
"0.02 mm
"0.0008 in
opaque object
"0.04 mm
"0.0016 in
opaque object
"0.03 mm
"0.0012 in
opaque object
"0.03 mm
"0.0012 in
opaque object
"0.03 mm
"0.0012 in
opaque object
"0.025 mm
"0.0010 in
opaque object
"0.04 mm
"0.0016 in
opaque object
"0.05 mm
"0.0019 in
opaque object
"0.02 mm
"0.0008 in
opaque object
Standard
Long sensing range
Standard fibers [Thru-beam type (one pair set)]
19,500 767,715
14,000 551.180
3,800 149.606
Type
:LONG
:STD
:FAST
:S-D
Sensing range (mm in ) (Note 1)
Red LED
Blue LED Green LED Infrared LED
Min. sensing object
under the optimum
condition (Note 2)
Allowable
bending
radius
10,000 393.700
580 22.835
400 15.748
360 14.173
280 11.024
250 9.843
150 5.906
800 31.496
140 5.512
125 4.921
60 2.362
100 3.937
1,600 62.992
800 31.496
280 11.024
1,100 43.307
530 20.866
180 7.087
1,000 39.370
480 18.898
168 6.614
780 30.709
400 15.748
130 5.118
700 27.559
360 14.173
126 4.961
530 20.866
230 9.055
80 3.150
2,000 78.740
1,000 39.370
350 13.780
400 15.748
200 7.874
70 2.756
390 15.354
180 7.087
63 2.480
175 6.890
80 3.150
27 1.063
270 10.630
49 1.929
R10 mm
R0.394 in
R10 mm
R0.394 in
Elbow
Side-view
With lens
With lens
Lens mountable
Lens mountable
Lens mountable
Lens mountable
Sleeve 90 mm 3.543 in
Sleeve 40 mm 1.575 in
Sleeve 90 mm 3.543 in
Sleeve 40 mm 1.575 in
Sleeve part cannot be bent.
Sleeve part cannot be bent.
Sleeve part cannot be bent.
Notes: 1) Please take care that the sensing range of the free-cut type fiber may be reduced by 20 % max. depending upon how the fiber is cut. In addition, the infrared
type is easily affected by humidity, so contact our office if using these sensors in environments with high humidity or where humidity levels can fluctuate.
Notes: 2) The minimum sensing object size is the value for red LED type. Please contact our office for information on the minimum sensing object size if using
amplifiers other than red LED type.
The optimum condition is the condition when the sensitivity is set so that the sensing output just changes to light incident operation in the object absent
condition.
Notes: 3) Sensing range for a 2 m 6.562 ft long fiber. A 10 m 32.808 ft long fiber will cause damping of the beam and cannot be used.
Notes: 4) The fiber cutter is not supplied as an accessory with FT-NB8 and FT-N8. Please order it separately.
R25 mm
R0.984 in
Shape of fiber head
(mm in)
1 m
3.281 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
10 m
32.808 ft
2 m
6.562 ft
2 m 6.562 ft
(Note 4)
2 m 6.562 ft
(Note 4)
Model No.
Fiber cable
length
: Free-cut
5,400 212.598
2,700 106.299
1,900 74.803

400 15.748
200 7.874
130 5.118

220 8.661
110 4.331
75 2.953

200 7.874
100 3.937
70 2.756

150 5.906
75 2.953
40 1.575

140 5.512
70 2.756
40 1.575

50 1.969
25 0.984
16 0.630

85 3.346
42 1.654
28 1.102

400 15.748
200 7.874
130 5.118

80 3.150
40 1.575
28 1.102

50 1.969
25 0.984
16 0.630

28 1.102
14 0.551
10 0.394


74
FX-301
FT-WV42
FT-Z8H
FT-Z8E
FT-Z8
FT-P80
FT-P60
FT-P40
FT-P2
FT-PS1
FT-W8
FT-WS3
FT-WS8
FT-WZ8H
FT-WZ8E
FT-WZ8
FT-WKV8
FT-WS8L
"0.3 mm
"0.012 in
opaque object
"0.25 mm
"0.010 in
opaque object
FT-WA30
FT-WA8
400 15.748
200 7.874
140 5.512

240 9.449
120 4.724
80 3.150

80 3.150
40 1.575
25 0.984

300 11.811
150 5.906
100 3.937

240 9.449
120 4.724
90 3.543

200 7.874
100 3.937
70 2.756

120 4.724
60 2.362
40 1.575

40 1.575
20 0.787
13 0.512

160 6.299
80 3.150
60 2.362

120 4.724
60 2.362
40 1.575

16 0.630
8 0.315
5 0.197





560 22.047
280 11.024
200 7.874

400 15.748
200 7.874
140 5.512

120 4.724
60 2.362
40 1.575

130 5.118
65 2.559
45 1.772

50 1.969
25 0.984
18 0.709

32 1.260
16 0.630
12 0.472

36 1.417
18 0.709
14 0.551

14 0.551
7 0.276
4 0.157

10 0.394
5 0.197
3 0.118





200 7.874
100 3.937
65 2.559

200 7.874
100 3.937
65 2.559

60 2.362
30 1.181
22 0.866

70 2.756
35 1.378
25 0.984

26 1.024
13 0.512
8 0.315

18 0.709
9 0.354
7 0.276

20 0.787
10 0.394
8 0.315

6 0.236
3 0.118
2 0.079

"0.08 mm
"0.003 in
opaque object
"0.05 mm
"0.0020 in
opaque object
"0.04 mm
"0.0016 in
opaque object
"0.06 mm
"0.0024 in
opaque object
"0.02 mm
"0.0008 in
opaque object
LIST OF FIBERS
Sharp bending
Flexible
Wide beam
Rectangular head
Narrow beam
Long sensing range
Small diameter
Side-view
Rectangular head
Standard
Small diameter Standard
Sharp bending fibers / Flexible fibers [Thru-beam type (one pair set)]
1,100 43.307
850 33.465
500 19.685
240 9.449
600 23.622
420 16.535
200 7.874
55 2.165
30 1.181
1,000 39.370
600 23.622
300 11.811
230 9.055
140 5.512
75 2.953
90 3.543
30 1.181
:LONG
:STD
:FAST
:S-D
Sensing range (mm in) (Note 1)
Red LED
Blue LED Green LED Infrared LED
Allowable
bending
radius
Model No.
3,500 137.795
1,500 59.055
750 29.528
2,500 98.425
1,200 47.244
410 16.142
1,500 59.055
700 27.559
210 8.268
700 27.559
330 12.992
120 4.724
1,700 66.929
700 27.559
300 11.811
1,200 47.244
600 23.622
210 8.268
570 22.441
290 11.417
100 3.937
800 31.496
400 15.748
140 5.512
1,600 62.992
800 31.496
280 11.024
2,700 106.299
1,400 55.118
490 19.291
90 3.543
40 1.575
15 0.591
160 6.299
80 3.150
28 1.102
650 25.591
320 12.598
110 4.331
400 15.748
190 7.480
80 3.150
250 9.843
100 3.937
35 1.378
280 11.024
120 4.724
42 1.654
80 3.150
40 1.575
17 0.669
W5H69D20
W0.197H2.717D0.787
Sensing width
32 mm
1.260 in
W4.2H31D13.5
W0.165H1.220D0.531
Sensing width
11 mm
0.433 in
Easy mounting Top sensing
W3H8D12 W0.118H0.315D0.472
Easy mounting Side sensing
W3H12D8 W0.118H0.472D0.315
Easy mounting Front sensing
Side-view type with small light
dispersion
W8.5H12D3 W0.335H0.472D0.118
Easy mounting  Top sensing
W3H8D12 W0.118H0.315D0.472
Easy mounting Side sensing
W3H12D8 W0.118H0.472D0.315
Easy mounting  Front sensing
W8.5H12D3 W0.335H0.472D0.118
Sleeve part cannot be bent.
Notes: 1) Please take care that the sensing range of the free-cut type fiber may be reduced by 20 % max. depending upon how the fiber is cut. In addition, the infrared
type is easily affected by humidity, so contact our office if using these sensors in environments with high humidity or where humidity levels can fluctuate.
Notes: 2) The minimum sensing object size is the value for red LED type. Please contact our office for information on the minimum sensing object size if using amplifiers other than red LED
type. The optimum condition is the condition when the sensitivity is set so that the sensing output just changes to light incident operation in the object absent co ndition.
Notes: 3) The fiber cable length practically limits the sensing range to 3,500 mm 137.795 in long.
R1 mm
R0.039 in
R1 mm
R0.039 in
R1 mm
R0.039 in
R1 mm
R0.039 in
R1 mm
R0.039 in
R1 mm
R0.039 in
R1 mm
R0.039 in
R1 mm
R0.039 in
R4 mm
R0.157 in
R4 mm
R0.157 in
R4 mm
R0.157 in
Lens mountable
Lens mountable
Lens mountable
With lens  Long sensing range
FT-WS4
FT-W4
Type Shape of fiber head
(mm in)
90 3.543
45 1.772
30 1.181

56 2.205
28 1.102
20 0.787

180 7.087
90 3.543
65 2.559

100 3.937
50 1.969
30 1.181

36 1.417
18 0.709
12 0.472

150 5.906
75 2.953
45 1.772

110 4.331
55 2.165
35 1.378

8 0.315
4 0.157
2.5 0.098





180 7.087
90 3.543
65 2.559

140 5.512
70 2.756
50 1.969

46 1.811
23 0.906
16 0.630

56 2.205
28 1.102
20 0.787

20 0.787
10 0.394
7 0.276

14 0.551
7 0.276
5 0.197

18 0.709
9 0.354
7 0.276

14 0.551
7 0.276
4 0.157

600 23.622
300 11.811
220 8.661

300 11.811
150 5.906
110 4.331

220 8.661
110 4.331
80 3.150

2,400 94.488
1,200 47.244
700 27.559

1,200 47.244
600 23.622
350 13.780

800 31.496
400 15.748
240 9.449

42 1.654
21 0.827
15 0.591

"0.03 mm
"0.0012 in
opaque object
"0.05 mm
"0.0020 in
opaque object
"0.03 mm
"0.0012 in
opaque object
"0.02 mm
"0.0008 in
opaque object
"0.02 mm
"0.0008 in
opaque object
"0.03 mm
"0.0012 in
opaque object
"0.04 mm
"0.0016 in
opaque object
"0.02 mm
"0.0008 in
opaque object
1 m
3.281 ft
500 mm
19.685 in
Wide area sensing
Wide area sensing
Min. sensing object
under the optimum
condition (Note 2)
3,500 137.795
3,500 137.795
3,500 137.795
3,500 137.795
(Note 3)
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
Fiber cable
length
: Free-cut

75
FX-301
R25 mm
R0.984 in
R25 mm
R0.984 in
600 23.622
300 11.811
220 8.661

120 4.724
60 2.362
40 1.575

120 4.724
60 2.362
40 1.575

80 3.150
35 1.378
10 0.394

3 0.118
2 0.079
1 0.039

14 0.551
7 0.276
4 0.157

130 5.118
64 2.520
45 1.772

300 11.811
150 5.906
110 4.331

60 2.362
30 1.181
20 0.787

60 2.362
30 1.181
20 0.787





1 0.039



6 0.236
3 0.118
2 0.079

64 2.520
32 1.260
22 0.866

"0.25 mm
"0.010 in
opaque object
Horizontal:
"0.025 mm
"0.0010 in
opaque object
Vertical:
"0.45 mm
"0.018 in
opaque object
"0.06 mm
"0.0024 in
opaque object
"0.02 mm
"0.0008 in
opaque object
"0.02 mm
"0.0008 in
opaque object
"0.05 mm
"0.0020 in
opaque object
LIST OF FIBERS
Special use
Wide beam
Array
Narrow beam
Ultra-small diameter
Tough flexible
FT-A8
FT-AFM2
FT-AFM2E
FT-K8
FT-KV8
FT-KV1
FT-E12
FT-E22
FT-P81X
Special use fibers [Thru-beam type (one pair set)]
1,100 43.307
220 8.661
200 7.874
800 31.496
8 0.315
36 1.417
230 9.055
:LONG
:STD
:FAST
:S-D
Sensing range (mm in) (Note 1)
Red LED
Blue LED Green LED Infrared LED
Allowable
bending
radius
Model No.
3,500 137.795
1,500 59.055
750 29.528
650 25.591
330 12.992
115 4.528
590 23.228
290 11.417
100 3.937
2,000 78.740
1,000 39.370
350 13.780
18 0.709
10 0.394
3 0.118
180 7.087
500 19.685
250 9.843
100 3.937
80 3.150
50 1.969
15 0.591
650 25.591
320 12.598
110 4.331
220 8.661
110 4.331
80 3.150

48 1.890
24 0.945
18 0.709

48 1.890
24 0.945
18 0.709





4 0.157
2 0.079
1.5 0.059

10 0.394
5 0.197
3 0.118

130 5.118
64 2.520
45 1.772

Sensing width
32 mm
1.260 in
W5H69D20
W0.197H2.717D0.787
Sensing width
11 mm
0.433 in
W4.2H31D13.5
W0.165H1.220D0.531
Top sensing
W5H15D15 W0.197H0.591D0.591
Side sensing
W5H15D15 W0.197H0.591D0.591
Side-view
Beam diameter: "0.125 mm "0.005 in
Notes: 1) Please take care that the sensing range of the free-cut type fiber may be reduced by 20 % max. depending upon how the fiber is cut. In addition, the
infrared type is easily affected by humidity, so contact our office if using these sensors in environments with high humidity or where humidity levels can
fluctuate.
Notes: 2) The minimum sensing object size is the value for red LED type. Please contact our office for information on the minimum sensing object size if using
amplifiers other than red LED type.
The optimum condition is the condition when the sensitivity is set so that the sensing output just changes to light incident operation in the object absent
condition.
Notes: 3) The fiber cable length practically limits the sensing range to 3,500 mm 137.795 in long.
R5 mm
R0.197 in
R10 mm
R0.394 in
R10 mm
R0.394 in
R10 mm
R0.394 in
R10 mm
R0.394 in
Sleeve part cannot be bent.
Beam diameter: "0.25 mm "0.010 in
Sleeve part cannot be bent.
Lens mountable
Type Shape of fiber head
(mm in)
500 mm
19.685 in
1 m
3.281 ft
1 m
3.281 ft
Min. sensing object
under the optimum
condition (Note 2)
3,500 137.795
3,500 137.795
3,500 137.795
3,500 137.795
(Note 3)
2,400 94.488
1,200 47.244
700 27.559

1,200 47.244
600 23.622
350 13.780

800 31.496
400 15.748
240 9.449

400 15.748
200 7.874
130 5.118

200 7.874
100 3.937
65 2.559

150 5.906
75 2.953
40 1.575

"0.3 mm
"0.012 in
opaque object FT-A30
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
Side-view
W2H1.5D20 W0.079H0.059D0.787
Fiber cable
length
: Free-cut

76
FX-301
100 3.937
50 1.969
35 1.378

44 1.732
22 0.866
14 0.551

100 3.937
50 1.969
35 1.378

72 2.835
36 1.417
26 1.024

320 12.598
160 6.299
120 4.724

160 6.299
80 3.150
50 1.969

120 4.724
60 2.362
35 1.378

100 3.937
50 1.969
30 1.181

36 1.417
18 0.709
12 0.472

50 1.969
25 0.984
18 0.709

22 0.866
11 0.433
7 0.276

50 1.969
25 0.984
18 0.709

32 1.260
16 0.630
10 0.394

160 6.299
80 3.150
60 2.362

160 6.299
80 3.150
50 1.969

80 3.150
40 1.575
25 0.984

46 1.811
23 0.906
16 0.630

18 0.709
9 0.354
6 0.236

"0.04 mm
"0.0016 in
opaque object
"0.02 mm
"0.0008 in
opaque object
"0.04 mm
"0.0016 in
opaque object
"0.06 mm
"0.0024 in
opaque object
"4 mm
"0.157 in
opaque object
"0.08 mm
"0.003 in
opaque object
"0.02 mm
"0.0008 in
opaque object
LIST OF FIBERS
Environment resistant
Heat-resistant
Vacuum Chemical-resistant
Environment resistant fibers [Thru-beam type (one pair set)]
:LONG
:STD
:FAST
:S-D
Sensing range (mm in) (Note 1)
Red LED
Blue LED Green LED Infrared LED
550 21.654
280 11.024
200 7.874
100 3.937
200 7.874
300 11.811
1,000 39.370
1,000 39.370
280 11.024
165 6.496
75 2.953
90 3.543
310 12.205
140 5.512
50 1.969
880 34.646
440 17.323
155 6.102
550 21.654
280 11.024
90 3.543
3,500 137.795
1,500 59.055
530 20.866
470 18.504
230 9.055
80 3.150
220 8.661
100 3.937
35 1.378
800 31.496
400 15.748
140 5.512
3,500 137.795
1,500 59.055
530 20.866
420 16.535
210 8.268
160 6.299

220 8.661
110 4.331
70 2.756

420 16.535
210 8.268
160 6.299

70 2.756
35 1.378
25 0.984

320 12.598
160 6.299
120 4.724

400 15.748
200 7.874
150 5.906

75 2.953
38 1.496
24 0.945

70 2.756
35 1.378
22 0.866

28 1.102
14 0.551
10 0.394

Notes: 1) Please take care that the sensing range of the free-cut type fiber may be reduced by 20 % max. depending upon how the fiber is cut. In addition, the infrared
type is easily affected by humidity, so contact our office if using these sensors in environments with high humidity or where humidity levels can fluctuate.
Notes: 2) The minimum sensing object size is the value for red LED type. Please contact our office for information on the minimum sensing object size if using amplifiers other than red
LED type. The optimum condition is the condition when the sensitivity is set so that the sensing output just changes to light incident operation in the object absent
condition.
Notes: 3) The allowable cutting range is 500 mm 19.685 in from the end that the amplifier inserted.
Lens mountable
Side-view
350 C 662 F
Lens mountable
200 C 392 F
Lens mountable
130 C 266 F
Lens mountable
Easy mounting  Rectangular head
SEMI S2 compliant
W7H15D13
W0.276H0.591D0.512
350 C 662 F
Sleeve 60 mm 2.362 in
Allows flexible wiring
200 C 392 F
Lens mountable
R25 mm
R0.984 in
R25 mm
R0 .984 in
R25 mm
R 0.984 in
R30 mm
R1.181 in
R200 mm
R7.874 in
R30 mm
R1.181 in
FT-H35-M2
FT-H35-M2S6
FT-H20W-M1
FT-H20W-M2
FT-H20-M1
FT-H13-FM2
FT-L8Y
FT-V8Y
FT-6V
FT-60V
Allowable
bending
radius
Model No.
R10 mm
R0.394 in
R10 mm
R0.394 in
FT-Z802Y
The vacuum type fiber must be used with the following products as a set.
FT-J6: Fiber at atmospheric side (one pair set) FV-BR1: Photo-terminal (one pair set)
Semi-standard fibers (Custom made per order)
The fiber cable length or sleeve length of the standard fibers can be modified at your request. Select the fiber cable length (symbol ) or the sleeve length
(symbol f) from the table below.
FT-FM 
FT-FM -S f
FT-FM L
FT-NFM2-S f
FT-WA30- 
FT-WA8- 
FT-A30- 
FT-A8- 
FT-H20-M 
FT-H35-M 
FT-Z80 Y
3 9.843, 4 13.123, 5 16.404, 10 32.808,
15 49.213, 20 65.617,25 82.021, 30 98.425
2 6.562 (Note), 3 9.843, 4 13.123, 5 16.404,
10 32.808, 15 49.213, 20 65.617, 25 82.021, 30 98.425
20 65.617, 30 98.425
5 16.404
2 6.562, 3 9.843
3 9.843
5 16.404, 7 22.966
Standard threaded
head (free-cut)
With sleeve
With large diameter lens
Small diameter threaded
head with sleeve (free-cut)
Wide beam
200C 392F heat-resistant
350C 662Fheat-resistant
Chemical-resistant
Correlation between sensing
range attenuation coefficient and
fiber cable length
The longer the fiber cable, the shorter the
sensing range.
1 0.394, 2 0.787, 3 1.181, 4 1.575, 5 1.969, 6 2.362,
7 2.756, 8 3.150, 9 3.543, 10 3.937, 11 4.331, 12
4.724
1 0.394, 2 0.787, 3 1.181, 4 1.575, 5 1.969, 6 2.362,
7 2.756, 8 3.150, 9 3.543, 10 3.937, 11 4.331, 12
4.724
Note: The standard fiber has a 2 m 6.562 ft fiber cable length and a 4 cm 1.575 in or 9 cm 3.543 in sleeve length.
Fiber
R25 mm
R0.984 in
Sleeve
Type Shape of fiber head
(mm in)
2 m
6.562 ft
1 m
3.281 ft
2 m
6.562 ft
1 m
3.281 ft
1 m
3.281 ft
Type Fiber cable length
(Unit: m ft)
fSleeve length
(Unit: cm in)
Min. sensing object
under the optimum
condition (Note 2)
Basic model No.
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
(Note 3)
Fiber cable
length
: Free-cut

77
FX-301
FD-B8
FD-5
FD-FM2
FD-FM2S
FD-FM2S4
FD-T80
FD-T40
FD-S80
FD-N8
FD-N4
FD-NFM2
FD-NFM2S
FD-NFM2S4
FD-SNFM2
FD-R80
FD-SFM2SV2
FD-V41
80 3.150
40 1.575
26 1.024

46 1.811
23 0.906
15 0.591

46 1.811
23 0.906
15 0.591

46 1.811
23 0.906
15 0.591

46 1.811
23 0.906
15 0.591

16 0.630
8 0.315
5 0.197

46 1.811
23 0.906
15 0.591

46 1.811
23 0.906
15 0.591

16 0.630
8 0.315
5 0.197

16 0.630
8 0.315
5 0.197

32 1.260
16 0.630
10 0.394

14 0.551
7 0.276
40.157

6 0.236
3 0.118


42 1.654
21 0.827
14 0.551

24 0.945
12 0.472
8 0.315

24 0.945
12 0.472
8 0.315

24 0.945
12 0.472
8 0.315

24 0.945
12 0.472
80.315

8 0.315
4 0.157
2 0.079

24 0.945
12 0.472
8 0.315

24 0.945
12 0.472
8 0.315

8 0.315
4 0.157
2 0.079

8 0.315
4 0.157
2 0.079

16 0.630
8 0.315
5 0.197

7 0.276
3.5 0.138


3 0.118



"0.02 mm
"0.0008 in
gold wire
"0.02 mm
"0.0008 in
gold wire
"0.02 mm
"0.0008 in
gold wire
"0.02 mm
"0.0008 in
gold wire
"0.02 mm
"0.0008 in
gold wire
"0.02 mm
"0.0008 in
gold wire
"0.02 mm
"0.0008 in
gold wire
"0.02 mm
"0.0008 in
gold wire
LIST OF FIBERS
Standard
Long sensing range
Side-view Elbow
Standard fibers (Reflective type)
:LONG
:STD
:FAST
:S-D
Sensing range (mm in ) (Note 1, 2)
Red LED
Blue LED Green LED Infrared LED
270 10.630
110 4.331
39 1.535
90 3.543
45 1.772
16 0.630
270 10.630
110 4.331
39 1.535
270 10.630
110 4.331
39 1.535
310 12.205
140 5.512
47 1.850
480 18.898
220 8.661
160 6.299
100 3.937
310 12.205
140 5.512
47 1.850
100 3.937
85 3.346
85 3.346
35 1.378
85 3.346
85 3.346
28 1.102
35 1.378
17 0.669
32 1.260
60 2.362
75 2.953
75 2.953
38 1.496
13 0.512
90 3.543
45 1.772
16 0.630
185 7.283
85 3.346
30 1.181
100 3.937
45 1.772
16 0.630
55 2.165
25 0.984
9 0.354
260 10.236
120 4.724
42 1.654
26 1.654
13 0.827
90.551

90 3.543
45 1.772
30 1.181

20 0.787
10 0.394
7 0.276

20 0.787
10 0.394
7 0.276

20 0.787
10 0.394
7 0.276

6 0.236
3 0.118
2 0.079

20 0.787
10 0.394
7 0.276

20 0.787
10 0.394
7 0.276

4 0.157
2 0.079
1.5 0.059

6 0.236
3 0.118
2 0.079

10 0.472
5 0.197
3 0.118

4 0.157







Notes: 1) The sensing range is specified for white non-glossy paper (FD-B8, FD-5, FD-FM2, FD-FM2S, FD-FM2S4, FD-N8, FD-T80, FD-S80 and FD-R80:
400400 mm 15.74815.748 in, FD-T40, FD-N4, FD-NFM2, FD-NFM2S, FD-NFM2S4,FD-SNFM2, FD-SFM2SV2 and FD-V41: 200200 mm
7.8747.874 in) as the object.
Notes: 2) Please take care that the sensing range of the free-cut type fiber may be reduced by 20 % max. depending upon how the fiber is cut. In addition, the
infrared type is easily affected by humidity, so contact our office if using these sensors in environments with high humidity or where humidity levels can
fluctuate.
Notes: 3) The minimum sensing object size is the value for red LED type at maximum sensitivity. Please contact our office for information on the minimum sensing
object size if using amplifiers other than red LED type.
Also, note that the corresponding setting distance is different from the rated sensing distance.
Notes: 4) The fiber cutter is not supplied as an accessory with FD-N8 and FD-N4. Please order it separately.
Coaxial
Sleeve 90 mm 3.543 in
Sleeve 40 mm 1.575 in
Sleeve 90 mm 3.543 in
Sleeve 40 mm 1.575 in
Small diameter
Small diameter
R25 mm
R0.984 in
Fiber
R25 mm
R0.984 in
Sleeve
R25 mm
R0.984 in
R25 mm
R 0.984 in
R25 mm
R0.984 in
Fiber
R25 mm
R0.984 in
Sleeve
R25 mm
R0.984 in
R25 mm
R0.984 in
R25 mm
R0.984 in
Allowable
bending
radius
Model No.
R10 mm
R0.394 in
R10 mm
R0.394 in
Sleeve part cannot be bent.
Sleeve part cannot be bent.
Type Shape of fiber head
(mm in)
500 mm
19.685 in
Min. sensing object
at the maximum
sensitivity (Note 3)
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
2 m
6.562 ft
(Note 4)
Fiber cable
length
: Free-cut
