Panasonic CS-A7BKP User manual

1 Features 2
2 Functions 3
3 Product Specifications 6
4 Dimensions 12
5 Refrigeration Cycle Diagram 14
6 Block Diagram 15
7 Wiring Diagram 16
8 Operation Details 17
9 Operating Instructions 33
10 Installation Instructions 38
© 2001 Matsushita Air-Conditioning Corp. Sdn. Bhd.
(183914D). All rights reserved. Unauthorized copying
and distribution is a violation of law.
CS-A7BKP CU-A7BKP5
CS-A7BKP CU-A7BKP6
CS-A9BKP CU-A9BKP5
CS-A9BKP CU-A9BKP6
CS-A12BKP CU-A12BKP5
CS-A12BKP CU-A12BKP6
11 2-way, 3-way Valve 49
12 Servicing Information 62
13 Troubleshooting Guide 66
14 Technical Data 68
15 Exploded View 74
16 Replacement Parts List 75
17 Exploded View 76
18 Replacement Parts List 77
19 Electronic Parts List 78
20 Electronic Circuit Diagram 79
Room Air Conditioner
CONTENTS
Page Page
Order No. MAC0109053C0

• High Efficiency
• Compact Design
• Comfort Environment
− 8 hours of sleep mode operation
− Air filter with function to reduce dust and smoke
− Wider range of horizontal discharge air
• Auto Restart
− Random auto restart after power failure for safety restart
operation
• Removable and Washable Front Panel
• Remote Control Self-illuminating Button
• Catechin Air Purifying Filter
− Trap dust, tobacco smoke and tiny particles
− Prevent the growth of bacteria and viruses trapped
• Solar Refreshing Deodorizing Filter
− Remove unpleasant odour from the air
• Quality Improvement
− Gas leakage protection
− Prevent compressor reverse cycle
− 2-stage OLP to protect compressor
− Noise prevention during soft dry operation.
− Anti-dew Formation Control (Cooling & Soft Dry)
− Compressor Protection Control (Cooling & Soft Dry)
− Overload Protection Control (Heating)
− Outdoor Fan Control
− Compressor High Pressure Control
− Blue Coated Condenser
− High resistance to corrosion.
• Operation Improvement
− Economy mode to reduce electrical power consumption
− Powerful mode to reach the desired room temperature
quickly
• Long Installation Piping
− CS/CU-A7BK, CS/CU-A9BK, long piping up to 10 meter
− CS/CU-A12BK, long piping up to 15 meter
• 24-hour Timer Setting
1 Features
2
CS-A7BKP CU-A7BKP5 / CS-A7BKP CU-A7BKP6 / CS-A9BKP CU-A9BKP5 / CS-A9BKP CU-A9BKP6 / CS-A12BKP CU-A12BKP5 / CS-A12BKP CU-A12BKP6

2 Functions
Remote Control
Operation OFF / ON
OFF / ON I
Room Temperature Setting
TEMP.
Operation Mode Selection
•AUTO Automatic Operation Mode
•HEAT Heating Operation Mode
•COOL Cooling Operation Mode
•DRY Soft Dry Operation Mode
MODE
TIME
Time / Timer Setting
• Hours and minutes setting.
Clock Setting
• Current time setting.
Sleep Mode Operation OFF / ON
SLEEP
Indoor Fan Speed Selection
FAN SPEED
•FAN Low Fan Speed
•FAN Medium Fan Speed
•FAN High Fan Speed
•AUTO Automatic Fan Speed
FAN
Vertical Airflow Direction Control
• 24-hour, OFF / ON Real Timer Setting.
ON-TIMER
OFF-TIMER
Timer Operation Selection
SET
CANCEL
Timer Operation Set / Cancel
• ON Timer and OFF Timer setting and
cancellation.
CLOCK
AIR SWING
•AUTO Automatic Vertical Airflow
Direction Control
•MANUAL Vertical Airflow Direction
Manual Control (5 stages of
adjustment)
Powerful Mode Operation OFF/ON
POWERFUL
Economy Mode Operation OFF/ON
ECONOMY
Heating, Cooling, Soft Dry Operation.
• Temperature Setting (16°C to 30°C)
Automatic Operation
•Operation with 2°C higher than
standard temperature.
• Operation with standard temperature.
•Operation with 2°C lower than
standard temperature.
Self illuminating
button
3
CS-A7BKP CU-A7BKP5 / CS-A7BKP CU-A7BKP6 / CS-A9BKP CU-A9BKP5 / CS-A9BKP CU-A9BKP6 / CS-A12BKP CU-A12BKP5 / CS-A12BKP CU-A12BKP6

Indoor Unit
Random Auto Restart Control
• Operation is restarted randomly after power
failure at previous setting mode.
Anti-Freezing Control
• Anti-Freezing control for indoor heat
exchanger. (Cooling and Soft Dry)
Sleep Mode Auto Control
• Indoor Fan operates at Low speed.
• Operation stops after 8 hours.
Indoor Fan Speed Control
• High, Medium and Low.
• Automatic Fan Speed Mode
– Heating : Fan speed varies from Me →
SSLo in accordance with
indoor heat exchanger.
– Cooling : Fan rotates at Hi, Me and SLo
speed. Deodorizing control is
available.
– Soft Dry : Fan rotates at SLo speed.
Deodorizing control is
available.
• Automatic air swing and manual adjusted
by remote control for vertical airflow.
•
Manually adjusted by hand for horizontal airflow.
Airflow Direction Control
Automatic Operation Button
• Press for < 5s to operate Automatic
operation mode.
(Used when the remote control cannot be used.)
• Press continuously for 5s or < 10s to
operate Test Run/Pump down. “Beep”
sound will be heard at the 5th second.
(Used when test running or servicing.)
• Press continuously for 10s and above to
omit or resume the remote control signal
receiving sound. “Beep, beep” sound will
be heard at the 10th second.
AUTO
OFF / ON
Operation Indication Lamps (LED)
•POWER (Green) ......... Lights up in operation,
blinks in Automatic
Operation Mode judging.
•SLEEP (Orange) ......... Lights up in Sleep Mode
Operation.
•TIMER (Orange) ......... Lights up in Timer
Setting.
•POWERFUL (Orange) ... Lights up in Powerful
Mode Operation.
•ECONOMY (Green) ...... Lights up in Economy
Mode Operation.
Operation Mode
• Heating, Cooling, Soft Dry and Automatic
Mode.
Powerful Operation
• Reaches the desired room temperature
quickly.
Time Delay Safety Control
• Restarting is inhibited for appro. 3 minutes.
Starting Current Control
Economy Operation
• To reduce electrical power consumption.
7 Minutes Time Save Control
• Cooling Operation only.
Anti-Dew Formation Control
• Anti-Dew Formation Control for indoor unit
discharge area.
• Fan motor is delayed for 1.6 seconds when
compressor starts simultaneously.
30 Minutes Time Save Control
• Heating Operation only.
Hot-Start Control
• At Heating Operation the indoor fan will
operate at SLo speed when indoor heat
exchanger temperature reaches 30°C.
Anti Cold Draft Control
• The indoor fan operates at SSLo when the
indoor heat exchanger temperature is low.
(During Heating mode thermal off)
4
CS-A7BKP CU-A7BKP5 / CS-A7BKP CU-A7BKP6 / CS-A9BKP CU-A9BKP5 / CS-A9BKP CU-A9BKP6 / CS-A12BKP CU-A12BKP5 / CS-A12BKP CU-A12BKP6

Outdoor Unit
• To protect compressor from reverse
rotation when there is a instantaneous
power failure.
60 Secs. Forced Operation Control
• Once the compressor is activated, it
does not stop within the first 60 secs.
However, it stops immediately with
remote control stop signal.
Overload Protector
• 2-Stage OLP to protect the compressor.
Overload Protector will trip when
– Temperature of compressor increases
to 120°C.
– High temperature or high current flows
to compressor.
(Refer circuit diagram for OLP
characteristic)
Compressor Reverse Rotation
Protection Control
Outdoor Fan Operation Control
• Temperature Fuse.
4-Way Valve Control
• When the unit is switched to “OFF”
during Heating Operation, 4-way valve
stays at Heating position for 5 minutes.
Overload Protection Control
• Outdoor fan stops when indoor heat
exchanger temperature rises to 51°C
and above, and restarts when the indoor
heat exchanger temperature drops to
49°C and below.
• Compressor stop when indoor heat
exchanger temperature reaches 65°C or
above. (Heating Operation Only)
Deice Control
• To prevent frosting at outdoor heat
exchanger. (Only for Heating Operation)
•
Temperature of outdoor heat exchanger
is sensed by TRS (Thermal Reed Switch).
TRS OFF temperature 4°C.
TRS ON temperature -3°C.
Compressor Protection Control
• If the outdoor fan motor is not running
after compressor starts for 50 secs.,
compressor will stop. (Cooling and Soft
Dry Operation only).
5
CS-A7BKP CU-A7BKP5 / CS-A7BKP CU-A7BKP6 / CS-A9BKP CU-A9BKP5 / CS-A9BKP CU-A9BKP6 / CS-A12BKP CU-A12BKP5 / CS-A12BKP CU-A12BKP6

3 Product Specifications
Unit CS-A7BK CU-A7BK
Power Source Phase, Voltage, Cycle (1)
(4)
Single, 220 - 230, 50 Hz
(2) Single, 220 - 240, 50 Hz
Cooling Capacity kW (kcal/h) (1)
(4)
2.00 - 2.05 (1,720 - 1,760)
kW (BTU/h) (2) 2.00 - 2.05 (6,820 - 6,990)
Heating Capacity kW (kcal/h) (1)
(4)
2.20 - 2.25 (1,890 - 1,940)
kW (BTU/h) (2) 2.20 - 2.20 (7,500 - 7,500)
Moisture Removal l/h (Pint/h) 1.3 (2.7)
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Indoor Air (Lo) m3/min (cfm) Cooling; 6.4 (230) - 6.4 (230) —
Heating; 7.0 (250) - 7.0 (250)
Indoor Air (Me) m3/min (cfm) Cooling; 7.6 (270) - 7.6 (270) —
Heating; 7.7 (270) - 7.7 (270)
Indoor Air (Hi) m3/min (cfm) Cooling; 8.5 (300) - 8.5 (300) —
Heating; 9.9 (350) - 9.9 (350)
Indoor Air (SHi) m3/min (cfm) Cooling; 9.9 (350) - 9.9 (350) —
Heating; 9.9 (350) - 9.9 (350)
dB (A) Cooling; High 33-33, Low 26-26 Cooling; High 46 - 47
Heating; High 36-36, Low 28-28 Heating; High 48 - 49
Noise Level
Power level dB Cooling; High 46 - 46 Cooling; High 61 - 62
Heating; High 47 - 47 Heating; High 64 - 65
Electrical Data Input Power W (1)
(4)
Cooling; 580 - 600
Heating, 500 - 525
(2) Cooling; 580 - 630, Heating, 510 - 550
Running Current A (1)
(2)
(4)
Cooling; 2.7 - 2.7, Heating; 2.4 - 2.4
EER W/W (kcal/hW) (1)
(4)
Cooling; 3.45 - 3.42 (2.97 - 2.93)
W/W (BTU/hW) (2) Cooling; 3.44 - 3.25 (11.8 - 11.1)
COP W/W (kcal/hW) (1)
(4)
Heating; 4.40 - 4.29 (3.78 - 3.70)
W/W (BTU/hW) (2) Heating; 4.31 - 4.00 (14.7 - 13.6)
Starting Current A 12.4
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 3/8”
L ; Half Union 1/4”
G ; 3-way valve 3/8”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 3/8”
L ; (liquid side) 1/4”
G ; (gas side) 3/8”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length mm 650 —
Power Cord Length m 1.9 —
Power of core wire 3 (1.0 mm2) —
6
CS-A7BKP CU-A7BKP5 / CS-A7BKP CU-A7BKP6 / CS-A9BKP CU-A9BKP5 / CS-A9BKP CU-A9BKP6 / CS-A12BKP CU-A12BKP5 / CS-A12BKP CU-A12BKP6

Note:
Dimensions Height inch (mm) 10 - 13/16 (275) 21 - 1/4 (540)
Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)
Depth inch (mm) 8 - 9/32 (210) 11 - 3/8 (289)
Net Weight lb (kg) 20 (9.0) 64 (29.0)
Compressor Type —Rotary (1 cylinder)
rolling piston type
Motor Type —Induction (2-poles)
Rated Output W — 550
Air Circulation Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 20% PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input W 44.8 - 53.5 57.0 - 62.0
Rate Output W 15 29
Fan Speed Low rpm Cooling; 780 - 780 —
Heating; 840 - 840
Medium rpm Cooling; 920 - 920 —
Heating; 920 - 920
High rpm Cooling; 1,030 - 1,030 805 - 820
Heating; 1,190 - 1,190
SuperHigh rpm Cooling; 1,190 - 1,190 —
Heating; 1,190 - 1,190
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Corrugate Fin
Row / Stage (Plate fin configuration, forced draft)
2×15 1×20
FPI 19 17
Size (W × H × L) mm 610 × 315 × 25.4 841 × 508 × 22
Refrigerant Control Device —Capillary Tube
Refrigeration Oil (cm3) — SUNISO 4GDID or ATMOS
M60 (290)
Refrigerant (R-22) g (oz) — 810 (28.6)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — Cooling; 600, Heating; 650
Flow Rate l/min — Cooling; 5.0, Heating; 11.4
Inner Diameter mm — Cooling; 1.1, Heating; 1.5
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 20 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 2.0 µF, 450VAC
• Specifications are subject to change without notice for further improvement.
• (1) — CS-A7BKP/CU-A7BKP5 (Europe).
• (2) — CS-A7BKP-2/CU-A7BKP5-2 (Oceania).
• (4) — CS-A7BKP-6/CU-A7BKP5-6 (Turkey).
7
CS-A7BKP CU-A7BKP5 / CS-A7BKP CU-A7BKP6 / CS-A9BKP CU-A9BKP5 / CS-A9BKP CU-A9BKP6 / CS-A12BKP CU-A12BKP5 / CS-A12BKP CU-A12BKP6

Unit CS-A9BK CU-A9BK
Power Source Phase, Voltage, Cycle (1)
(4)
Single, 220 - 230, 50 Hz
(2) Single, 220 - 240, 50 Hz
(3) Single, 220, 50 Hz
Cooling Capacity kW (kcal/h) (1)
(4)
2.65 - 2.70 (2,280 - 2,320)
kW (BTU/h) (2) 2.65 - 2.65 (9,040 - 9,040)
kW (kcal/h) (3) 2.65 (2,280)
Heating Capacity kW (kcal/h) (1)
(4)
3.00 - 3.05 (2,580 - 2,620)
kW (BTU/h) (2) 3.00 - 3.05 (10,230 - 10,400)
kW (kcal/h) (3) 3.00 (2,580)
Moisture Removal l/h (Pint/h) 1.6 (3.4)
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Indoor Air (Lo) m3/min (cfm) (1)
(2)
(4)
Cooling; 6.8 (240) - 6.8 (240)
Heating; 7.0 (250) - 7.0 (250)
—
(3) Cooling; 6.8 (240)
Heating; 7.0 (250)
—
Indoor Air (Me) m3/min (cfm) (1)
(2)
(4)
Cooling; 8.3 (290) - 8.3 (290)
Heating; 8.0 (280) - 8.0 (280)
—
(3) Cooling; 8.3 (290)
Heating; 8.0 (280)
—
Indoor Air (Hi) m3/min (cfm) (1)
(2)
(4)
Cooling; 9.9 (350) - 9.9 (350)
Heating; 10.2 (360) - 10.2 (360)
—
(3) Cooling; 9.9 (350)
Heating; 10.2 (360)
—
Indoor Air (SHi) m3/min (cfm) (1)
(2)
(4)
Cooling; 10.2 (360) - 10.2 (360)
Heating; 10.2 (360) - 10.2 (360)
—
(3) Cooling; 10.2 (360)
Heating; 10.2 (360)
—
Noise Level dB (A) (1)
(2)
(4)
Cooling; High 36-36, Low 26-26
Heating; High 38-38, Low 28-28
Cooling; High 48 - 49
Heating; High 48 - 49
(3) Cooling; High 36, Low 26
Heating; High 38, Low 28
Cooling; High 48
Heating; High 48
Power level (dB) (1)
(2)
(4)
Cooling; High 49 - 49
Heating; High 49 - 49
Cooling; High 62 - 63
Heating; High 64 - 65
(3) Cooling; High 49
Heating; High 49
Cooling; High 62
Heating; High 64
Electrical Data Input Power W (1)
(4)
Cooling; 800 - 830
Heating; 700 - 740
(2) Cooling; 830 - 870, Heating; 730 - 780
(3) Cooling; 800, Heating; 700
Running Current A (1)
(4)
Cooling; 3.8 - 3.7
Heating; 3.3 - 3.3
(2) Cooling; 3.8 - 3.7, Heating; 3.4 - 3.3
(3) Cooling; 3.8, Heating; 3.3
EER W/W (kcal/hW) (1)
(4)
Cooling; 3.31 - 3.25 (2.85 - 2.80)
W/W (BTU/hW) (2) Cooling; 3.19 - 3.05 (10.9 - 10.4)
W/W (kcal/hW) (3) Cooling; 3.31 (2.85)
COP W/W (kcal/hW) (1)
(4)
Heating; 4.29 - 4.12 (3.69 - 3.54)
W/W (BTU/hW) (2) Heating; 4.11 - 3.91 (14.0 - 13.3)
W/W (kcal/hW) (3) Heating; 4.29 (3.69)
Starting Current A 18.0
8
CS-A7BKP CU-A7BKP5 / CS-A7BKP CU-A7BKP6 / CS-A9BKP CU-A9BKP5 / CS-A9BKP CU-A9BKP6 / CS-A12BKP CU-A12BKP5 / CS-A12BKP CU-A12BKP6

Note:
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 3/8”
L ; Half Union 1/4”
G ; 3-way valve 3/8”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 3/8”
L ; (liquid side) 1/4”
G ; (gas side) 3/8”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length mm 650 —
Power Cord Length m 1.9 —
Number of core-wire (1)
(2)
(4)
3 (1.0 mm2) —
(3) 3 (1.5 mm2) —
Dimensions Height inch (mm) 10 - 13/16 (275) 21 - 1/4 (540)
Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)
Depth inch (mm) 8 - 9/32 (210) 11 - 3/8 (289)
Net Weight lb (kg) 20 (9.0) 73 (33.0)
Compressor Type —Rotary (1 cylinder)
rolling piston type
Motor Type —Induction (2-poles)
Rated Output W — 750
Air Circulation Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 20% PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input W 44.8 - 53.5 57.0 - 62.0
Rate Output W 15 29
Fan Speed Low rpm (1)
(2)
(4)
Cooling; 780 - 780
Heating; 840 - 840
—
(3) Cooling; 780, Heating; 840 —
Medium rpm (1)
(2)
(4)
Cooling; 960 - 960
Heating; 960 - 960
—
(3) Cooling; 960, Heating; 960 —
High rpm (1)
(2)
(4)
Cooling; 1,140 - 1,140
Heating; 1,230 - 1,230
805 - 820
(3) Cooling; 1,140, Heating; 1,230 805
SuperHigh rpm (1)
(2)
(4)
Cooling; 1,230 - 1,230
Heating; 1,230 - 1,230
—
(3) Cooling; 1,230, Heating; 1,230 —
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Corrugate Fin
Row / Stage (Plate fin configuration, forced draft)
2×15 1×20
FPI 19 17
Size (W × H × L) mm 610 × 315 × 25.4 841 × 508 × 22
Refrigerant Control Device —Capillary Tube
Refrigeration Oil (cm3) — SUNISO 4GDID or ATMOS
M60 (350)
Refrigerant (R-22) g (oz) — 920 (32.5)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — Cooling; 982, Heating; 325
Flow Rate l/min — Cooling; 5.4, Heating; 13.4
Inner Diameter mm — Cooling; 1.2, Heating; 1.4
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 30 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 2.0 µF, 450VAC
• Specifications are subject to change without notice for further improvement.
• (1) — CS-A9BKP/CU-A9BKP5 (Europe).
• (2) — CS-A9BKP-2/CU-A9BKP5-2 (Oceania).
• (3) — CS-A9BKP-3/CU-A9BKP5-3 (Argentina).
• (4) — CS-A9BKP-6/CU-A9BKP5-6 (Turkey).
9
CS-A7BKP CU-A7BKP5 / CS-A7BKP CU-A7BKP6 / CS-A9BKP CU-A9BKP5 / CS-A9BKP CU-A9BKP6 / CS-A12BKP CU-A12BKP5 / CS-A12BKP CU-A12BKP6

Unit CS-A12BK CU-A12BK
Power Source Phase, Voltage, Cycle (1)
(4)
Single, 220 - 230, 50 Hz
(2) Single, 220 - 240, 50 Hz
(3) Single, 220, 50 Hz
Cooling Capacity kW (kcal/h) (1)
(4)
3.52 - 3.60 (3,030 - 3,100)
kW (BTU/h) (2) 3.52 - 3.57 (12,000 - 12,170)
kW (kcal/h) (3) 3.52 (3,030)
Heating Capacity kW (kcal/h) (1)
(4)
3.90 - 4.07 (3,350 - 3,500)
kW (BTU/h) (2) 3.90 - 4.00 (13,300 - 13,640)
kW (kcal/h) (3) 3.90 (3,350)
Moisture Removal l/h (Pint/h) 2.1 (4.4)
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Indoor Air (Lo) m3/min (cfm) (1)
(2)
(4)
Cooling; 7.3 (260) - 7.3 (260)
Heating; 7.8 (270) - 7.8 (270)
—
(3) Cooling; 7.3 (260)
Heating; 7.8 (270)
—
Indoor Air (Me) m3/min (cfm) (1)
(2)
(4)
Cooling; 9.1 (320) - 9.1 (320)
Heating; 9.1 (320) - 9.1 (320)
—
(3) Cooling; 9.1 (320)
Heating; 9.1 (320)
—
Indoor Air (Hi) m3/min (cfm) (1)
(2)
(4)
Cooling; 10.2 (360) - 10.2 (360)
Heating; 10.6 (370) - 10.6 (370)
—
(3) Cooling; 10.2 (360)
Heating; 10.6 (370)
—
Indoor Air (SHi) m3/min (cfm) (1)
(2)
(4)
Cooling; 10.6 (370) - 10.6 (370)
Heating; 10.6 (370) - 10.6 (370)
—
(3) Cooling; 10.6 (370)
Heating; 10.6 (370)
—
Noise Level dB (A) (1)
(2)
(4)
Cooling; High 39-39, Low 29-29
Heating; High 40-40, Low 29-29
Cooling; High 48 - 49
Heating; High 48 - 49
(3) Cooling; High 39, Low 29
Heating; High 40, Low 29
Cooling; High 48
Heating; High 48
Power level (dB) (1)
(2)
(4)
Cooling; High 52 - 52
Heating; High 52 - 52
Cooling; High 62 - 63
Heating; High 64 - 65
(3) Cooling; High 52
Heating; High 52
Cooling; High 62
Heating; High 64
Electrical Data Input Power kW (1)
(4)
Cooling; 1.08 - 1.12
Heating; 1.07 - 1.10
(2) Cooling; 1.12 - 1.17, Heating; 1.07 - 1.11
(3) Cooling; 1.08, Heating; 1.07
Running Current A (1)
(4)
Cooling; 5.1 - 5.0
Heating; 5.0 - 4.8
(2) Cooling; 5.1 - 4.9, Heating; 5.0 - 4.8
(3) Cooling; 5.1, Heating; 5.0
EER W/W (kcal/hW) (1)
(4)
Cooling; 3.26 - 3.21 (2.80 - 2.77)
W/W (BTU/hW) (2) Cooling; 3.14 - 3.05 (10.7 - 10.4)
W/W (kcal/hW) (3) Cooling; 3.26 (2.80)
COP W/W (kcal//hW) (1)
(4)
Heating; 3.64 - 3.70 (3.13 - 3.18)
W/W (BTU/hW) (2) Heating; 3.48 - 3.60 (11.9 - 12.3)
W/W (kcal/hW) (3) Heating; 3.64 (3.13)
Starting Current A 16.9
10
CS-A7BKP CU-A7BKP5 / CS-A7BKP CU-A7BKP6 / CS-A9BKP CU-A9BKP5 / CS-A9BKP CU-A9BKP6 / CS-A12BKP CU-A12BKP5 / CS-A12BKP CU-A12BKP6
