Panasonic CS-Z25TKEA User manual

© Panasonic Corporation 2018.
Order No: PAPAMY1802076CE
POWERFUL
Indoor Unit Outdoor Unit
CS-Z25TKEA
CS-Z35TKEA
CS-Z42TKEA
CS-Z50TKEA
CS-Z71TKEA
CU-Z25TKEA
CU-Z35TKEA
CU-Z42TKEA
CU-Z50TKEA
CU-Z71TKEA
Destination
Europe
WARNING
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the products dealt with in this service information by anyone else could result in serious injury or death.
IMPORTANT SAFETY NOTICE
There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic
Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced
with manufacturer’s specified parts to prevent shock, fire or other hazards. Do not modify the original design without permission of
manufacturer.
PRECAUTION OF LOW TEMPERATURE
In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.
CAUTION
R32 REFRIGERANT – This Air Conditioner contains and operates with refrigerant R32.
THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED BY QUALIFIED PERSONNEL.
Refer to Commonwealth, State, Territory and local legislation, regulations, codes, installation & operation manuals, before the
installation, maintenance and/or service of this product.

Specifications, designs and contents in this Service Manual are subject to change without notice.
2
TABLE OF CONTENTS
PAGE PAGE
1.Safety Precautions .............................................3
2.Precaution for Using R32 Refrigerant ..............6
3.Specifications ...................................................10
4.Features.............................................................19
5.Location of Controls and Components..........20
5.1Indoor Unit ..................................................20
5.2Outdoor Unit ...............................................20
5.3Remote Control ..........................................20
6.Dimensions .......................................................21
6.1Indoor Unit ..................................................21
6.2Outdoor Unit ...............................................23
7.Refrigeration Cycle Diagram ...........................24
7.1CS-Z25TKEA CU-Z25TKEA
CS-Z35TKEA CU-Z35TKEA
CS-Z42TKEA CU-Z42TKEA.......................24
7.2CS-Z50TKEA CU-Z50TKEA
CS-Z71TKEA CU-Z71TKEA.......................25
8.Block Diagram ..................................................26
8.1CS-Z25TKEA CU-Z25TKEA
CS-Z35TKEA CU-Z35TKEA
CS-Z42TKEA CU-Z42TKEA.......................26
8.2CS-Z50TKEA CU-Z50TKEA
CS-Z71KEA CU-Z71TKEA.........................27
9.Wiring Connection Diagram ............................28
9.1Indoor Unit ..................................................28
9.2Outdoor Unit ...............................................29
10.Electronic Circuit Diagram ..............................31
10.1Indoor Unit ..................................................31
10.2Outdoor Unit ...............................................32
11.Printed Circuit Board .......................................34
11.1Indoor Unit ..................................................34
11.2Outdoor Unit ...............................................36
12.Installation Instruction.....................................37
12.1Select the Best Location.............................37
12.2Indoor Unit ..................................................38
12.3Outdoor Unit ...............................................44
13.Installation and Servicing Air Conditioner
using R32 ..........................................................51
13.1About R32 Refrigerant................................51
13.2Characteristics of R32 Refrigerant .............51
13.3Refrigerant piping installation • Tools used
in services...................................................53
13.4New installation, Relocation, Repairing of
Refrigerant Cycle System The
Procedures .................................................57
13.5Piping installation of R32............................58
13.6Installation, Relocation, and Service ..........59
13.7Repairing of refrigerant cycle / Brazing
point............................................................63
13.8<Reference> Analysis method for no error
code, no cooling / no warming....................69
14.Operation Control.............................................71
14.1Basic Function ............................................71
14.2Indoor Fan Motor Operation .......................72
14.3Outdoor Fan Motor Operation ....................73
14.4Airflow Direction..........................................74
14.5Quiet Operation (Cooling Mode/Cooling
Area of Dry Mode) ......................................76
14.6Quiet Operation (Heating) ..........................76
14.7Powerful Mode Operation...........................76
14.8Timer Control..............................................77
14.9Weekly Timer Setting .................................77
14.10Auto Restart Control...................................78
14.11Indication Panel ..........................................78
15.Protection Control ............................................79
15.1Protection Control for All Operations..........79
15.2Protection Control for Cooling & Soft Dry
Operation....................................................81
15.3Protection Control for Heating Operation ...82
16.Servicing Mode .................................................84
16.1Auto OFF/ON Button ..................................84
17.Troubleshooting Guide....................................85
17.1Refrigeration Cycle System........................85
17.2Breakdown Self Diagnosis Function...........87
17.3Error Codes Table ......................................88
17.4Self-diagnosis Method................................90
18.Disassembly and Assembly Instructions ... 118
18.1CS-Z25TKEA CS-Z35TKEA................... 118
18.2CS-Z42TKEA CS-Z50TKEA
CS-Z71TKEA........................................... 124
18.3Outdoor Electronic Controller Removal
Procedure ................................................ 130
19.Technical Data ............................................... 132
19.1Cool Mode Performance Data................. 132
19.2Heat Mode Performance Data................. 135
20.Service Data ................................................... 136
20.1Cool Mode Outdoor Air Temperature
Characteristic........................................... 136
20.2Heat Mode Outdoor Air Temperature
Characteristic........................................... 141
20.3Piping Length Correction Factor.............. 146
21.Exploded View and Replacement Parts
List .................................................................. 148
21.1Indoor Unit ............................................... 148
21.2Outdoor Unit ............................................ 152

3
1. Safety Precautions
Read the following “SAFETY PRECAUTIONS” carefully before perform any servicing.
Electrical work must be installed or serviced by a licensed electrician. Be sure to use the correct rating of the
power plug and main circuit for the model installed.
The caution items stated here must be followed because these important contents are related to safety. The
meaning of each indication used is as below. Incorrect installation or servicing due to ignoring of the instruction
will cause harm or damage, and the seriousness is classified by the following indications.
WARNING This indication shows the possibility of causing death or serious injury.
CAUTION This indication shows the possibility of causing injury or damage to properties.
The items to be followed are classified by the symbols:
Explanation of symbols displayed on the indoor unit or outdoor unit.
WARNING This symbol shows that this equipment uses a flammable refrigerant.
If the refrigerant is leaked, together with an external ignition source, there is a possibility of ignition.
CAUTION This symbol shows that the Operation Manual should be read carefully.
CAUTION This symbol shows that a service personnel should be handling this equipment with reference to the
Installation Manual.
CAUTION This symbol shows that there is information included in the Operation Manual and/or Installation Manual.
Carry out test run to confirm that no abnormality occurs after the servicing. Then, explain to user the operation,
care and maintenance as stated in instructions. Please remind the customer to keep the operating instructions for
future reference.
WARNING
1. Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. Any
unfit method or using incompatible material may cause product damage, burst and serious injury.
2. Do not install outdoor unit near handrail of veranda. When installing air-conditioner unit on veranda of a high rise building, child
may climb up to outdoor unit and cross over the handrail causing an accident.
3.
Do not use unspecified cord, modified cord, joint cord or extension cord for power supply cord. Do not share the single outlet
with other electrical appliances.
Poor contact, poor insulation or over current will cause electrical shock or fire.
4.
The appliance shall be stored in a well ventilated room with floor area larger than A min (m2) [refer Table A] and without any
continuously operating ignition sources.
Keep away from open flames, any operating gas appliances or any operating electric heater. Else, it may explode and cause
injury or death.
5. Do not tie up the power supply cord into a bundle by band. Abnormal temperature rise on power supply cord may happen.
6. Do not insert your fingers or other objects into the unit, high speed rotating fan may cause injury.
7. Do not sit or step on the unit, you may fall down accidentally.
8.
The appliance shall be installed, and/or operated in a room with floor area larger than A min (m2) [refer Table A] and keep away
from ignition sources, such as heat/sparks/open flame, or, hazardous areas, such as gas appliances, gas cooking, reticulated
gas supply systems, or electric cooking appliances, etc.
9. Keep plastic bag (packaging material) away from small children, it may cling to nose and mouth and prevent breathing.
10.
When installing or relocating air conditioner, do not let any substance other than the specified refrigerant, eg. air etc mix into
refrigeration cycle (piping).
Mixing of air etc. will cause abnormal high pressure in refrigeration cycle and result in explosion, injury etc.
11.
Do not pierce or burn as the appliance is pressurized. Do not expose the appliance to heat, flame, sparks, or other sources of
ignition.
Else, it may explode and cause injury or death.
12. Do not add or replace refrigerant other than specified type. It may cause product damage, burst and injury etc.
This symbol denotes item that is PROHIBITTED from doing.

4
WARNING
13.
Do not perform flare connection inside a building or dwelling or room, when joining the heat exchanger of indoor unit with
interconnecting piping. Refrigerant connection inside a building or dwelling or room must be made by brazing or welding. Joint
connection of indoor unit by flaring method can only be made at outdoor or at outside of a building or dwelling or room. Flare
connection may cause gas leak and flammable atmosphere.
14.
For R32 model, use piping, flare nut and tools which is specified for R32 refrigerant. Using of existing (R22) piping, flare nut and
tools may cause abnormally high pressure in the refrigerant cycle (piping), and possibly result in explosion and injury.
Thickness for copper pipes used with R32 must be more than 0.8 mm. Never use copper pipes thinner than 0.8 mm.
It is desirable that the amount of residual oil less than 40 mg/10 m.
15. Engage authorized dealer or specialist for installation and servicing. If installation or servicing done by the user is defective, it will cause
water leakage, electrical shock or fire.
16. For refrigeration system work, Install according to this installation instructions strictly. If installation is defective, it will cause water
leakage, electrical shock or fire.
17. Use the attached accessories parts and specified parts for installation and servicing. Otherwise, it will cause the set to fall, water
leakage, fire or electrical shock.
18. Install at a strong and firm location which is able to withstand weight of the set. If the strength is not enough or installation is not properly
done, the set will drop and cause injury.
19. For electrical work, follow the national regulation, legistration and this installation instructions. An independent circuit and single outlet
must be used. If electrical circuit capacity is not enough or defect found in the electrical work, it will cause electrical shock or fire.
20.
Do not use joint cable for indoor/outdoor connection cable. Use the specified indoor/outdoor connection cable, refer to instruction
CONNECT THE CABLE TO THE INDOOR UNIT and connect tightly for indoor/outdoor connection. Clamp the cable so that no external
force will have impact on the terminal.
If connection or fixing is not perfect, it will cause heat up or fire at the connection.
21. Wire routing must be properly arranged so that control board cover is fixed properly. If control board cover is not fixed perfectly, it will
cause heat-up or fire at connection point of terminal, fire or electrical shock.
22.
This equipment is strongly recommended to be installed with Earth Leakage Circuit Breaker (ELCB) or Residual Current Device (RCD),
with sensitivity of 30mA at 0.1 sec or less. Otherwise, it may cause electrical shock and fire in case of equipment breakdown or
insulation breakdown.
23.
During installation, install the refrigerant piping properly before running the compressor. Operation of compressor without fixing
refrigeration piping and valves at opened position will cause suck-in of air, abnormal high pressure in refrigeration cycle and result in
explosion, injury etc.
24.
During pump down operation, stop the compressor before removing the refrigeration piping. Removal of refrigeration piping while
compressor is operating and valves are opened will cause suck-in of air, abnormal high pressure in refrigeration cycle and result in
explosion, injury etc.
25. Tighten the flare nut with torque wrench according to specified method. If the flare nut is over-tightened, after a long period, the flare
may break and cause refrigerant gas leakage.
26. After completion of installation or service, confirm there is no leakage of refrigerant gas. It may generate toxic gas when the refrigerant
contacts with fire.
27. Ventilate if there is refrigerant gas leakage during operation. It may cause toxic gas when the refrigerant contacts with fire.
28. Be aware that refrigerants may not contain an odour.
29. This equipment must be properly earthed. Earth line must not be connected to gas pipe, water pipe, earth of lightning rod and
telephone. Otherwise, it may cause electrical shock in case of equipment breakdown or insulation breakdown.
30. Do not modify the machine, part, material during repairing service.
31. If wiring unit is supplied as repairing part, do not repair or connect the wire even only partial wire break. Exchange the whole wiring unit.
32. Do not wrench the fasten terminal. Pull it out or insert it straightly.
33. Must not use other parts except original parts describe in catalog and manual.
CAUTION
1. Do not install the unit in a place where leakage of flammable gas may occur. In case gas leaks and accumulates at surrounding
of the unit, it may cause fire.
2. Prevent liquid or vapor from entering sumps or sewers since vapor is heavier than air and may form suffocating atmospheres.
3. Do not release refrigerant during piping work for installation, servicing, reinstallation and during repairing a refrigerant parts.
Take care of the liquid refrigerant, it may cause frostbite.
4. Do not install this appliance in a laundry room or other location where water may drip from the ceiling, etc.

5
CAUTION
5. Do not touch the sharp aluminium fin, sharp parts may cause injury.
6. Carry out drainage piping as mentioned in installation instructions. If drainage is not perfect, water may enter the room and damage the
furniture.
7.
Select an installation location which is easy for maintenance.
Incorrect installation, service or repair of this air conditioner may increase the risk of rupture and this may result in loss damage or injury
and/or property.
8.
Power supply connection to the room air conditioner.
Use power supply cord 3 x 1.5 mm2(1.0 ~ 1.75HP), 3 x 2.5 mm2(2.0 ~ 2.5HP) type designation 60245 IEC 57 or heavier cord.
Connect the power supply cord of the air conditioner to the mains using one of the following method.
Power supply point should be in easily accessible place for power disconnection in case of emergency.
In some countries, permanent connection of this air conditioner to the power supply is prohibited.
1) Power supply connection to the receptacle using power plug.
Use an approved 15/16A (1.0 ~ 1.75HP) or 16A (2.0HP) or 20A (2.5HP), power plug with earth pin for the connection to the socket.
2) Power supply connection to a circuit breaker for the permanent connection.
Use an approved 16A (1.0 ~ 2.0HP) or 20A (2.5HP) circuit breaker for the permanent connection. It must be a double pole switch
with a minimum 3.0 mm contact gap.
9. Installation or servicing work: It may need two people to carry out the installation or servicing work.
10
Pb free solder has a higher melting point than standard solder; typically the melting point is 50°F – 70°F (30°C – 40°C) higher.
Please use a high temperature solder iron. In case of the soldering iron with temperature control, please set it to 700 ± 20°F
(370 ± 10°C).
Pb free solder will tend to splash when heated too high (about 1100°F / 600°C).
11.
Do not touch the sharp aluminum fins or edges of metal parts.
If you are required to handle sharp parts during installation or servicing, please wear hand glove.
Sharp parts may cause injury.
12. Tighten the flare nut with torque wrench according to specified method. If the flare nut is over-tightened, after a long period, the flare may
break and cause refrigerant gas leakage.
13. Do not touch outdoor unit air inlet and aluminium fin. It may cause injury.

6
2. Precaution for Using R32 Refrigerant
The basic installation work procedures are the same as conventional refrigerant (R410A, R22) models.
However, pay careful attention to the following points:
WARNING
1.
Since the working pressure is higher than that of refrigerant R22 models, some of the piping and installation and service tools are
special.
(See “2.1. Special tools for R32 (R410A)”.)
Especially, when replacing a refrigerant R22 model with a new refrigerant R32 model, always replace the conventional piping and flare
nuts with the R32 and R410A piping and flare nuts on the outdoor unit side.
For R32 and R410A, the same flare nut on the outdoor unit side and pipe can be used.
2.
Models that use refrigerant R32 and R410A have a different charging port thread diameter to prevent erroneous charging with refrigerant
R22 and for safety.
Therefore, check beforehand. [The charging port thread diameter for R32 and R410A is 12.7 mm (1/2 inch).]
3. Be more careful than R22 so that foreign matter (oil, water, etc.) does not enter the piping.
Also, when storing the piping, securely seal the opening by pinching, taping, etc. (Handling of R32 is similar to R410A.)
CAUTION
1.
Installation (Space)
Must ensure the installation of pipe-work shall be kept to a minimum. Avoid use dented pipe and do not allow acute bending.
Must ensure that pipe-work shall be protected from physical damage.
Must comply with national gas regulations, state municipal rules and legislation. Notify relevant authorities in accordance with all
applicable regulations.
Must ensure mechanical connections be accessible for maintenance purposes.
In cases that require mechanical ventilation, ventilation openings shall be kept clear of obstruction.
When disposal of the product, do follow to the precautions in #12 and comply with national regulations.
Always contact to local municipal offices for proper handling.
Interconnecting refrigerant pipework, i.e. pipework external to the unitary components, should be marked with a Class label (see
Figure 9.1 of Code of Practice) every two metres where the pipework is visible. This includes pipework located in a ceiling space or
any void which a person may access for maintenance or repair work within that space.
2.
Servicing
2-1. Service personnel
Any qualified person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certificate from
an industry-accredited assessment authority, which authorizes their competence to handle refrigerants safely in accordance with an
industry recognised assessment specification.
Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance and repair requiring the
assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of flammable
refrigerants.
Servicing shall be performed only as recommended by the manufacturer.
2-2. Work
Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of
ignition is minimised.
For repair to the refrigerating system, the precautions in #2-2 to #2-8 must be followed before conducting work on the system.
Work shall be undertaken under a controlled procedure so as to minimize the risk of a flammable gas or vapor being present while
the work is being performed.
All maintenance staff and others working in the local area shall be instructed and supervised on the nature of work being carried
out.
Avoid working in confined spaces.
Wear appropriate protective equipment, including respiratory protection, as conditions warrant.
Ensure that the conditions within the area have been made safe by limit of use of any flammable material. Keep all sources of
ignition and hot metal surfaces away.
2-3. Checking for presence of refrigerant
The area shall be checked with an appropriate refrigerant detector prior to and during work, to ensure the technician is aware of
potentially flammable atmospheres.
Ensure that the leak detection equipment being used is suitable for use with flammable refrigerants, i.e. non sparking, adequately
sealed or intrinsically safe.
In case of leakage/spillage happened, immediately ventilate area and stay upwind and away from spill/release.
In case of leakage/spillage happened, do notify persons downwind of the leaking/spill, isolate immediate hazard area and keep
unauthorized personnel out.
2-4. Presence of fire extinguisher
If any hot work is to be conducted on the refrigeration equipment or any associated parts, appropriate fire extinguishing equipment
shall be available at hand.
Have a dry powder or CO2fire extinguisher adjacent to the charging area.

7
CAUTION
2-5. No ignition sources
No person carrying out work in relation to a refrigeration system which involves exposing any pipe work that contains or has
contained flammable refrigerant shall use any sources of ignition in such a manner that it may lead to the risk of fire or explosion.
He/She must not be smoking when carrying out such work.
All possible ignition sources, including cigarette smoking, should be kept sufficiently far away from the site of installation, repairing,
removing and disposal, during which flammable refrigerant can possibly be released to the surrounding space.
Prior to work taking place, the area around the equipment is to be surveyed to make sure that there are no flammable hazards or
ignition risks.
“No Smoking” signs shall be displayed.
2-6. Ventilated area
Ensure that the area is in the open or that it is adequately ventilated before breaking into the system or conducting any hot work.
A degree of ventilation shall continue during the period that the work is carried out.
The ventilation should safely disperse any released refrigerant and preferably expel it externally into the atmosphere.
2-7. Checks to the refrigeration equipment
Where electrical components are being changed, they shall be fit for the purpose and to the correct specification.
At all times the manufacturer’s maintenance and service guidelines shall be followed.
If in doubt consult the manufacturer’s technical department for assistance.
The following checks shall be applied to installations using flammable refrigerants.
- The charge size is in accordance with the room size within which the refrigerant containing parts are installed.
- The ventilation machinery and outlets are operating adequately and are not obstructed.
- If an indirect refrigerating circuit is being used, the secondary circuit shall be checked for the presence of refrigerant.
- Marking to the equipment continues to be visible and legible. Markings and signs that are illegible shall be corrected.
- Refrigeration pipe or components are installed in a position where they are unlikely to be exposed to any substance
which may corrode refrigerant containing components, unless the components are constructed of materials which are
inherently resistant to being corroded or are properly protected against being so corroded.
2-8. Checks to electrical devices
Repair and maintenance to electrical components shall include initial safety checks and component inspection procedures.
Initial safety checks shall include but not limit to:-
- That capacitors are discharged: this shall be done in a safe manner to avoid possibility of sparking.
- That there is no live electrical components and wiring are exposed while charging, recovering or purging the system.
- That there is continuity of earth bonding.
At all times the manufacturer’s maintenance and service guidelines shall be followed.
If in doubt consult the manufacturer’s technical department for assistance.
If a fault exists that could compromise safety, then no electrical supply shall be connected to the circuit until it is satisfactorily dealt
with.
If the fault cannot be corrected immediately but it is necessary to continue operation, an adequate temporary solution shall be used.
The owner of the equipment must be informed or reported so all parties are advised thereinafter.
3.
Repairs to sealed components
During repairs to sealed components, all electrical supplies shall be disconnected from the equipment being worked upon prior to
any removal of sealed covers, etc.
If it is absolutely necessary to have an electrical supply to equipment during servicing, then a permanently operating form of leak
detection shall be located at the most critical point to warn of a potentially hazardous situation.
Particular attention shall be paid to the following to ensure that by working on electrical components, the casing is not altered in
such a way that the level of protection is affected. This shall include damage to cables, excessive number of connections, terminals
not made to original specification, damage to seals, incorrect fitting of glands, etc.
Ensure that apparatus is mounted securely.
Ensure that seals or sealing materials have not degraded such that they no longer serve the purpose of preventing the ingress of
flammable atmospheres.
Replacement parts shall be in accordance with the manufacturer’s specifications.
NOTE: The use of silicon sealant may inhibit the effectiveness of some types of leak detection equipment.
Intrinsically safe components do not have to be isolated prior to working on them.
4.
Repair to intrinsically safe components
Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that this will not exceed the permissible
voltage and current permitted for the equipment in use.
Intrinsically safe components are the only types that can be worked on while live in the presence of a flammable atmosphere.
The test apparatus shall be at the correct rating.
Replace components only with parts specified by the manufacturer. Unspecified parts by manufacturer may result ignition of
refrigerant in the atmosphere from a leak.
5.
Cabling
Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp edges or any other adverse
environmental effects.
The check shall also take into account the effects of aging or continual vibration from sources such as compressors or fans.
6.
Detection of flammable refrigerants
Under no circumstances shall potential sources of ignition be used in the searching or detection of refrigerant leaks.
A halide torch (or any other detector using a naked flame) shall not be used.

8
CAUTION
7.
Leak detection methods
Electronic leak detectors shall be used to detect flammable refrigerants, but the sensitivity may not be adequate, or may need re-
calibration.
(Detection equipment shall be calibrated in a refrigerant-free area.)
Ensure that the detector is not a potential source of ignition and is suitable for the refrigerant used.
Leak detection equipment shall be set at a percentage of the LFL of the refrigerant and shall be calibrated to the refrigerant
employed and the appropriate percentage of gas (25 % maximum) is confirmed.
Leak detection fluids are suitable for use with most refrigerants but the use of detergents containing chlorine shall be avoided as the
chlorine may react with the refrigerant and corrode the copper pipe-work.
If a leak is suspected, all naked flames shall be removed/extinguished.
If a leakage of refrigerant is found which requires brazing, all of the refrigerant shall be recovered from the system, or isolated (by
means of shut off valves) in a part of the system remote from the leak. Oxygen free nitrogen (OFN) shall then be purged through
the system both before and during the brazing process.
8.
Removal and evacuation
When breaking into the refrigerant circuit to make repairs – or for any other purpose – conventional procedures shall be used.
However, it is important that best practice is followed since flammability is a consideration.
The following procedure shall be adhered to:
• remove refrigerant -> • purge the circuit with inert gas -> • evacuate -> • purge again with inert gas ->
• open the circuit by cutting or brazing
The refrigerant charge shall be recovered into the correct recovery cylinders.
The system shall be “flushed” with OFN to render the unit safe.
This process may need to be repeated several times.
Compressed air or oxygen shall not be used for this task.
Flushing shall be achieved by breaking the vacuum in the system with OFN and continuing to fill until the working pressure is
achieved, then venting to atmosphere, and finally pulling down to a vacuum.
This process shall be repeated until no refrigerant is within the system.
When the final OFN charge is used, the system shall be vented down to atmospheric pressure to enable work to take place.
This operation is absolutely vital if brazing operations on the pipe work are to take place.
Ensure that the outlet for the vacuum pump is not close to any ignition sources and there is ventilation available.
9.
Charging procedures
In addition to conventional charging procedures, the following requirements shall be followed.
- Ensure that contamination of different refrigerants does not occur when using charging equipment.
- Hoses or lines shall be as short as possible to minimize the amount of refrigerant contained in them.
- Cylinders shall be kept upright.
- Ensure that the refrigeration system is earthed prior to charging the system with refrigerant.
- Label the system when charging is complete (if not already).
- Extreme care shall be taken not to over fill the refrigeration system.
Prior to recharging the system it shall be pressure tested with OFN (refer to #7).
The system shall be leak tested on completion of charging but prior to commissioning.
A follow up leak test shall be carried out prior to leaving the site.
Electrostatic charge may accumulate and create a hazardous condition when charging and discharging the refrigerant.
To avoid fire or explosion, dissipate static electricity during transfer by grounding and bonding containers and equipment before
charging/discharging.
10.
Decommissioning
Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its details.
It is recommended good practice that all refrigerants are recovered safely.
Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of
reclaimed refrigerant.
It is essential that electrical power is available before the task is commenced.
a) Become familiar with the equipment and its operation.
b) Isolate system electrically.
c) Before attempting the procedure ensure that:
• mechanical handling equipment is available, if required, for handling refrigerant cylinders;
• all personal protective equipment is available and being used correctly;
• the recovery process is supervised at all times by a competent person;
• recovery equipment and cylinders conform to the appropriate standards.
d) Pump down refrigerant system, if possible.
e) If a vacuum is not possible, make a manifold so that refrigerant can be removed from various parts of the system.
f) Make sure that cylinder is situated on the scales before recovery takes place.
g) Start the recovery machine and operate in accordance with manufacturer’s instructions.
h) Do not over fill cylinders. (No more than 80 % volume liquid charge).
i) Do not exceed the maximum working pressure of the cylinder, even temporarily.
j) When the cylinders have been filled correctly and the process completed, make sure that the cylinders and the
equipment are removed from site promptly and all isolation valves on the equipment are closed off.
k) Recovered refrigerant shall not be charged into another refrigeration system unless it has been cleaned and checked.
Electrostatic charge may accumulate and create a hazardous condition when charging or discharging the refrigerant.
To avoid fire or explosion, dissipate static electricity during transfer by grounding and bonding containers and equipment before
charging/discharging.

9
CAUTION
11.
Labelling
Equipment shall be labelled stating that it has been de-commissioned and emptied of refrigerant.
The label shall be dated and signed.
Ensure that there are labels on the equipment stating the equipment contains flammable refrigerant.
12.
Recovery
When removing refrigerant from a system, either for servicing or decommissioning, it is recommended good practice that all
refrigerants are removed safely.
When transferring refrigerant into cylinders, ensure that only appropriate refrigerant recovery cylinders are employed.
Ensure that the correct number of cylinders for holding the total system charge are available.
All cylinders to be used are designated for the recovered refrigerant and labelled for that refrigerant (i.e. special cylinders for the
recovery of refrigerant).
Cylinders shall be complete with pressure relief valve and associated shut-off valves in good working order.
Recovery cylinders are evacuated and, if possible, cooled before recovery occurs.
The recovery equipment shall be in good working order with a set of instructions concerning the equipment that is at hand and shall
be suitable for the recovery of flammable refrigerants.
In addition, a set of calibrated weighing scales shall be available and in good working order.
Hoses shall be complete with leak-free disconnect couplings and in good condition.
Before using the recovery machine, check that it is in satisfactory working order, has been properly maintained and that any
associated electrical components are sealed to prevent ignition in the event of a refrigerant release.
Consult manufacturer if in doubt.
The recovered refrigerant shall be returned to the refrigerant supplier in the correct recovery cylinder, and the relevant Waste
Transfer Note arranged.
Do not mix refrigerants in recovery units and especially not in cylinders.
If compressors or compressor oils are to be removed, ensure that they have been evacuated to an acceptable level to make certain
that flammable refrigerant does not remain within the lubricant.
The evacuation process shall be carried out prior to returning the compressor to the suppliers.
Only electric heating to the compressor body shall be employed to accelerate this process.
When oil is drained from a system, it shall be carried out safely.

10
3. Specifications
Indoor Model CS-Z25TKEA CS-Z35TKEA
POS (EAN) 5025232873319 5025232873333
Outdoor Model CU-Z25TKEA CU-Z35TKEA
POS (EAN) 5025232873326 5025232873340
Performance Test Condition EUROVENT EUROVENT
Power Supply Phase, Hz Single, 50 Single, 50
V 230 230
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 0.85 2.50 3.00 0.85 3.50 4.00
BTU/h 2900 8530 10200 2900 11900 13600
kcal/h 730 2150 2580 730 3010 3440
Running Current A – 2.45 – – 4.00 –
Input Power W 170 510 700 170 860 1.10k
Annual Consumption – 258 – – 435 –
EER CLASS – A – – A –
EER
W/W 5.00 4.90 4.29 5.00 4.07 3.64
BTU/hW 17.06 16.73 14.57 17.06 13.84 12.36
kcal/hW 4.29 4.22 3.69 4.29 3.50 3.13
ErP
Pdesign kW 2.5 3.5
SEER (W/W) 8.5 8.5
Annual
Consumption kWh 103 144
Class A+++ A+++
Power Factor % – 91 – – 93 –
Indoor Noise (H / L / QLo) dB-A 39 / 25 / 21 42 / 28 / 21
Power Level dB 55 / – / – 58 / – / –
Outdoor Noise (H / L / QLo) dB-A 46 / – / – 48 / – / –
Power Level dB 61 / – / – 63 / – / –
Heating
Capacity
kW 0.85 3.40 5.40 0.85 4.00 6.60
BTU/h 2900 11600 18400 2900 13600 22500
kcal/h 730 2920 4640 730 3440 5680
Running Current A – 3.40 – – 4.20 –
Input Power W 165 700 1.31k 165 920 1.82k
COP CLASS – A – – A –
COP
W/W 5.15 4.86 4.12 5.15 4.35 3.63
BTU/hW 17.58 16.57 14.05 17.58 14.78 12.36
kcal/hW 4.42 4.17 3.54 4.42 3.74 3.12
ErP
Pdesign kW 2.8 3.6
Tbivalent °C -10 -10
SCOP (W/W) 4.5 4.4
Annual
Consumption kWh 871 1145
Class A+ A+
Power Factor % – 90 – – 95 –
Indoor Noise (H / L / QLo) dB-A 41 / 27 / 22 43 / 30 / 22
Power Level dB 58 / – / – 60 / – / –
Outdoor Noise (H / L / QLo) dB-A 48 / – / – 50 / – / –
Power Level dB 63 / – / – 65 / – / –
Low Temp. : Capacity (kW) / I.Power (W) / COP 3.91 / 1.16k / 3.37 4.78 / 1.61k / 2.97
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 3.33 / 1.29k / 2.58 4.07 / 1.70k / 2.39
Max Current (A) / Max Input Power (W) 7.7 / 1.74k 8.3 / 1.82k
Starting Current (A) 3.40 4.20

11
Indoor Model CS-Z25TKEA CS-Z35TKEA
POS (EAN) 5025232873319 5025232873333
Outdoor Model CU-Z25TKEA CU-Z35TKEA
POS (EAN) 5025232873326 5025232873340
Compressor
Type Hermetic Motor / Rotary Hermetic Motor / Rotary
Motor Type Brushless (4-poles) Brushless (4-poles)
Output Power W 900 900
Indoor Fan
Type Cross-flow Fan Cross-flow Fan
Material ASG20K1 ASG20K1
Motor Type DC (8-poles) DC (8-poles)
Input Power W 47.3 47.3
Output Power W 40 40
Speed
QLo Cool rpm 650 640
Heat rpm 670 680
Lo Cool rpm 730 800
Heat rpm 810 880
Me Cool rpm 910 1010
Heat rpm 1010 1140
Hi Cool rpm 1100 1220
Heat rpm 1220 1400
SHi Cool rpm 1200 1270
Heat rpm 1320 1450
Outdoor Fan
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type DC (8-poles) DC (8-poles)
Input Power W – –
Output Power W 40 40
Speed Hi Cool rpm 800 860
Heat rpm 800 890
Moisture Removal L/h (Pt/h) 1.5 (3.2) 2.0 (4.2)
Indoor
Airflow
QLo Cool m3/min (ft3/min) 5.49 (194) 5.22 (184)
Heat m3/min (ft3/min) 5.71 (202) 5.60 (198)
Lo Cool m3/min (ft3/min) 6.36 (225) 6.74 (238)
Heat m3/min (ft3/min) 7.22 (255) 7.50 (265)
Me Cool m3/min (ft3/min) 8.35 (295) 8.73 (308)
Heat m3/min (ft3/min) 9.43 (333) 9.97 (352)
Hi Cool m3/min (ft3/min) 10.40 (365) 10.70 (380)
Heat m3/min (ft3/min) 11.70 (415) 12.40 (440)
SHi Cool m3/min (ft3/min) 11.43 (404) 11.20 (395)
Heat m3/min (ft3/min) 12.73 (450) 12.91 (456)
Outdoor
Airflow Hi Cool m3/min (ft3/min) 32.20 (1135) 34.40 (1215)
Heat m3/min (ft3/min) 32.20 (1135) 35.60 (1255)
Refrigerant
Cycle
Control Device Expansion Valve Expansion Valve
Refrigerant Oil cm3FW50S (450) FW50S (450)
Refrigerant Type g (oz) R32, 960 (33.9) R32, 1000 (35.3)
F-Gas
GWP 675 675
CO2eq (ton)
(Precharged Amount /
Maximum Amount)
0.648 / 0.732 0.675 / 0.759

12
Indoor Model CS-Z25TKEA CS-Z35TKEA
POS (EAN) 5025232873319 5025232873333
Outdoor
Model CU-Z25TKEA CU-Z35TKEA
POS (EAN) 5025232873326 5025232873340
Dimension Unit
Height
(I/D / O/D) mm (inch) 295 (11-5/8) / 619 (24-3/8) 295 (11-5/8) / 619 (24-3/8)
Width
(I/D / O/D) mm (inch) 919 (36-3/16) / 824 (32-15/32) 919 (36-3/16) / 824 (32-15/32)
Depth
(I/D / O/D) mm (inch) 194 (7-21/32) / 299 (11-25/32) 194 (7-21/32) / 299 (11-25/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) / 37 (82) 10 (22) / 38 (84)
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 9.52 (3/8)
Standard Length m (ft) 5.0 (16.4) 5.0 (16.4)
Length Range (min – max) m (ft) 3 (9.8) ~ 20 (65.6) 3 (9.8) ~ 20 (65.6)
I/D & O/D Height Different m (ft) 15.0 (49.2) 15.0 (49.2)
Additional Gas Amount g/m (oz/ft) 10 (0.1) 10 (0.1)
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Drain Hose Inner Diameter mm 16.7 16.7
Length mm 650 650
Indoor
Heat
Exchanger
Fin Material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Slit Fin Slit Fin
Row × Stage × FPI 2 × 15 × 21 2 × 15 × 21
Size (W × H × L) mm 610 × 315 × 25.4 610 × 315 × 25.4
Outdoor
Heat
Exchanger
Fin Material Aluminium Aluminium
Fin Type Corrugated Fin (Pre Coat) Corrugated Fin (Pre Coat)
Row × Stage × FPI 2 × 28 × 17 2 × 28 × 17
Size (W × H × L) mm 36.4 × 588 × 781.3:752.7 36.4 × 588 × 856.3:827.7
Air Filter Material Polypropelene Polypropelene
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord Nil Nil
Thermostat Electronic Contol Electronic Contol
Protection Device Electronic Contol Electronic Contol
Dry Bulb Wet Bulb Dry Bulb Wet Bulb
Indoor Operation
Range
Cooling Maximum °C (°F) 32 (89.6) 23 (73.4) 32 (89.6) 23 (73.4)
Minimum °C (°F) 16 (60.8) 11 (51.8) 16 (60.8) 11 (51.8)
Heating Maximum °C (°F) 30 (86.0) – 30 (86.0) –
Minimum °C (°F) 16 (60.8) – 16 (60.8) –
Outdoor Operation
Range
Cooling Maximum °C (°F) 43 (109.4) 26 (78.8) 43 (109.4) 26 (78.8)
Minimum °C (°F) -20 (-40) – -20 (-40) –
Heating Maximum °C (°F) 24 (75.2) 18 (64.4) 24 (75.2) 18 (64.4)
Minimum °C (°F) -15 (5.0) – -15 (5.0) –
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C DRY BULB (95°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb).
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor air temperature of 7°C Dry Bulb (44.6°F
Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb).
3. Heating low temperature capacity, Input Power and COP measured at 230 V, indoor temperature 20°C, outdoor 2/1°C.
4. Heating extreme low temperature capacity, Input Power and COP measured at 230 V, indoor temperature 20°C, outdoor -7/-8°C.
5. Standby power consumption ≤10.0w (when switched OFF by remote control, except under self protection control).
6. Specifications are subjected to change without prior notice for further improvement.

13
Indoor Model CS-Z42TKEA CS-Z50TKEA
POS (EAN) 5025232873357 5025232873364
Outdoor Model CU-Z42TKEA CU-Z50TKEA
POS (EAN) 5025232873388 5025232873395
Performance Test Condition EUROVENT EUROVENT
Power Supply Phase, Hz Single, 50 Single, 50
V 230 230
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 0.98 4.20 5.00 0.98 5.00 6.00
BTU/h 3340 14300 17100 3340 17100 20500
kcal/h 840 3610 4300 840 4300 5160
Running Current A – 5.00 – – 6.30 –
Input Power W 200 1.10k 1.54k 280 1.39k 1.94k
Annual Consumption – 550 – – 695 –
EER CLASS – A – – A –
EER
W/W 4.90 3.82 3.25 3.50 3.60 3.09
BTU/hW 16.70 13.00 11.10 11.93 12.30 10.57
kcal/hW 4.20 3.28 2.79 3.00 3.09 2.66
ErP
Pdesign kW 4.2 5.0
SEER (W/W) 8.5 8.5
Annual
Consumption kWh 173 206
Class A+++ A+++
Power Factor % – 96 – – 96 –
Indoor Noise (H / L / QLo) dB-A 43 / 32 / 29 44 / 37 / 30
Power Level dB 59 / – / – 60 / – / –
Outdoor Noise (H / L / QLo) dB-A 48 / – / – 48 / – / –
Power Level dB 63 / – / – 63 / – / –
Heating
Capacity
kW 0.98 5.40 7.25 0.98 5.80 8.00
BTU/h 3340 18400 24700 3340 19800 27300
kcal/h 840 4640 6240 840 4990 6880
Running Current A – 6.10 – – 6.50 –
Input Power W 220 1.35k 2.15k 340 1.44k 2.50k
COP CLASS – A – – A –
COP
W/W 4.45 4.00 3.37 2.88 4.03 3.20
BTU/hW 15.18 13.63 11.49 9.82 13.75 10.92
kcal/hW 3.82 3.44 2.90 2.47 3.47 2.75
ErP
Pdesign kW 3.8 4.4
Tbivalent °C -10 -10
SCOP (W/W) 4.3 4.4
Annual
Consumption kWh 1237 1400
Class A+ A+
Power Factor % – 96 – – 96 –
Indoor Noise (H / L / QLo) dB-A 44 / 35 / 29 44 / 37 / 30
Power Level dB 60 / – / – 60 / – / –
Outdoor Noise (H / L / QLo) dB-A 50 / – / – 50 / – / –
Power Level dB 65 / – / – 65 / – / –
Low Temp. : Capacity (kW) / I.Power (W) / COP 5.25 / 1.90k / 2.76 5.80 / 2.21k / 2.62
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 4.30 / 1.95k / 2.21 5.00 / 2.25k / 2.22
Max Current (A) / Max Input Power (W) 9.4 / 2.15k 11.1 / 2.53k
Starting Current (A) 6.10 6.50

14
Indoor Model CS-Z42TKEA CS-Z50TKEA
POS (EAN) 5025232873357 5025232873364
Outdoor Model CU-Z42TKEA CU-Z50TKEA
POS (EAN) 5025232873388 5025232873395
Compressor
Type Hermetic Motor / Rotary Hermetic Motor / Rotary
Motor Type Brushless (4-poles) Brushless (4-poles)
Output Power W 900 900
Indoor Fan
Type Cross-flow Fan Cross-flow Fan
Material ASG33 ASG33
Motor Type DC (8-poles) DC (8-poles)
Input Power W 89.0 89.0
Output Power W 40 40
Speed
QLo Cool rpm 700 730
Heat rpm 720 760
Lo Cool rpm 760 900
Heat rpm 880 950
Me Cool rpm 900 1000
Heat rpm 1010 1080
Hi Cool rpm 1050 1100
Heat rpm 1150 1210
SHi Cool rpm 1100 1150
Heat rpm 1200 1260
Outdoor Fan
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type DC (8-poles) DC (8-poles)
Input Power W – –
Output Power W 40 40
Speed Hi Cool rpm 860 720
Heat rpm 890 700
Moisture Removal L/h (Pt/h) 2.4 (5.1) 2.8 (5.9)
Indoor
Airflow
QLo Cool m3/min (ft3/min) 11.30 (400) 11.89 (420)
Heat m3/min (ft3/min) 11.70 (413) 12.48 (441)
Lo Cool m3/min (ft3/min) 12.48 (441) 15.24 (538)
Heat m3/min (ft3/min) 14.85 (524) 16.23 (573)
Me Cool m3/min (ft3/min) 15.34 (542) 17.21 (608)
Heat m3/min (ft3/min) 17.51 (618) 18.79 (664)
Hi Cool m3/min (ft3/min) 18.20 (640) 19.20 (680)
Heat m3/min (ft3/min) 20.20 (715) 21.30 (750)
SHi Cool m3/min (ft3/min) 19.18 (677) 20.17 (712)
Heat m3/min (ft3/min) 21.15 (747) 22.33 (789)
Outdoor
Airflow Hi Cool m3/min (ft3/min) 34.40 (1215) 39.70 (1400)
Heat m3/min (ft3/min) 35.60 (1255) 38.60 (1365)
Refrigerant
Cycle
Control Device Expansion Valve Expansion Valve
Refrigerant Oil cm3FW50S (450) FW50S (450)
Refrigerant Type g (oz) R32, 1.08k (38.1) R32, 1.15k (40.6)
F-Gas
GWP 675 675
CO2eq (ton)
(Precharged Amount /
Maximum Amount)
0.729 / 0.856 0.776 / 1.004

15
Indoor Model CS-Z42TKEA CS-Z50TKEA
POS (EAN) 5025232873357 5025232873364
Outdoor
Model CU-Z42TKEA CU-Z50TKEA
POS (EAN) 5025232873388 5025232873395
Dimension Unit
Height
(I/D / O/D) mm (inch) 302 (11-29/32) / 619 (24-3/8) 302 (11-29/32) / 695 (27-3/8)
Width
(I/D / O/D) mm (inch) 1120 (44-1/8) / 824 (32-15/32) 1120 (44-1/8) / 875 (34-15/32)
Depth
(I/D / O/D) mm (inch) 236 (9-5/16) / 299 (11-25/32) 236 (9-5/16) / 320 (12-5/8)
Weight Net (I/D / O/D) kg (lb) 12 (26) / 38 (84) 12 (26) / 43 (95)
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.70 (1/2) 6.35 (1/4) / 12.70 (1/2)
Standard Length m (ft) 5.0 (16.4) 5.0 (16.4)
Length Range (min – max) m (ft) 3 (9.8) ~ 20 (65.6) 3 (9.8) ~ 30 (98.4)
I/D & O/D Height Different m (ft) 15.0 (49.2) 15.0 (49.2)
Additional Gas Amount g/m (oz/ft) 10 (0.1) 15 (0.2)
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Drain Hose Inner Diameter mm 16.7 16.7
Length mm 650 650
Indoor
Heat
Exchanger
Fin Material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Slit Fin Slit Fin
Row × Stage × FPI 2 × 17 × 21 2 × 17 × 21
Size (W × H × L) mm 836.5 × 357 × 25.4 836.5 × 357 × 25.4
Outdoor
Heat
Exchanger
Fin Material Aluminium Aluminium
Fin Type Corrugated Fin (Pre Coat) Corrugated Fin (Pre Coat)
Row × Stage × FPI 2 × 28 × 17 2 × 31 × 19
Size (W × H × L) mm 36.4 × 588 × 856.3:827.7 36.4 × 651 × 854.5:824.5
Air Filter Material Polypropelene Polypropelene
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord Nil Nil
Thermostat Electronic Contol Electronic Contol
Protection Device Electronic Contol Electronic Contol
Dry Bulb Wet Bulb Dry Bulb Wet Bulb
Indoor Operation
Range
Cooling Maximum °C (°F) 32 (89.6) 23 (73.4) 32 (89.6) 23 (73.4)
Minimum °C (°F) 16 (60.8) 11 (51.8) 16 (60.8) 11 (51.8)
Heating Maximum °C (°F) 30 (86.0) – 30 (86.0) –
Minimum °C (°F) 16 (60.8) – 16 (60.8) –
Outdoor Operation
Range
Cooling Maximum °C (°F) 43 (109.4) 26 (78.8) 43 (109.4) 26 (78.8)
Minimum °C (°F) -20 (-40) – -20 (-40) –
Heating Maximum °C (°F) 24 (75.2) 18 (64.4) 24 (75.2) 18 (64.4)
Minimum °C (°F) -15 (5.0) – -15 (5.0) –
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C DRY BULB (95°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb).
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor air temperature of 7°C Dry Bulb (44.6°F
Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb).
3. Heating low temperature capacity, Input Power and COP measured at 230 V, indoor temperature 20°C, outdoor 2/1°C.
4. Heating extreme low temperature capacity, Input Power and COP measured at 230 V, indoor temperature 20°C, outdoor -7/-8°C.
5. Standby power consumption ≤10.0w (when switched OFF by remote control, except under self protection control).
6. Specifications are subjected to change without prior notice for further improvement.

16
Indoor Model CS-Z71TKEA
POS (EAN) 5025232873371
Outdoor Model CU-Z71TKEA
POS (EAN) 5025232873401
Performance Test Condition EUROVENT
Power Supply Phase, Hz Single, 50
V 230
Min. Mid. Max.
Cooling
Capacity
kW 0.98 7.10 8.10
BTU/h 3340 24200 27600
kcal/h 840 6110 6970
Running Current A – 9.90 –
Input Power W 420 2.24k 2.67k
Annual Consumption – 1120 –
EER CLASS – B –
EER
W/W 2.33 3.17 3.03
BTU/hW 7.95 10.80 10.34
kcal/hW 2.00 2.73 2.61
ErP
Pdesign kW 7.1
SEER (W/W) 6.1
Annual
Consumption kWh 407
Class A++
Power Factor % – 98 –
Indoor Noise (H / L / QLo) dB-A 47 / 38 / 35
Power Level dB 63 / – / –
Outdoor Noise (H / L / QLo) dB-A 52 / – / –
Power Level dB 66 / – / –
Heating
Capacity
kW 0.98 8.60 9.90
BTU/h 3340 29300 33800
kcal/h 840 7400 8510
Running Current A – 10.90 –
Input Power W 400 2.45k 2.85k
COP CLASS – B –
COP
W/W 2.45 3.51 3.47
BTU/hW 8.35 11.96 11.86
kcal/hW 2.10 3.02 2.99
ErP
Pdesign kW 5.5
Tbivalent °C -10
SCOP (W/W) 4.0
Annual
Consumption kWh 1925
Class A+
Power Factor % – 98 –
Indoor Noise (H / L / QLo) dB-A 47 / 38 / 35
Power Level dB 63 / – / –
Outdoor Noise (H / L / QLo) dB-A 54 / – / –
Power Level dB 68 / – / –
Low Temp. : Capacity (kW) / I.Power (W) / COP 7.17 / 2.52k / 2.85
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 6.13 / 2.48k / 2.47
Max Current (A) / Max Input Power (W) 14.8 / 3.22k
Starting Current (A) 10.90

17
Indoor Model CS-Z71TKEA
POS (EAN) 5025232873371
Outdoor Model CU-Z71TKEA
POS (EAN) 5025232873401
Compressor
Type Hermetic Motor / Rotary
Motor Type Brushless (4-poles)
Output Power W 1.70k
Indoor Fan
Type Cross-flow Fan
Material ASG33
Motor Type DC (8-poles)
Input Power W 105.0
Output Power W 40
Speed
QLo Cool rpm 800
Heat rpm 860
Lo Cool rpm 850
Heat rpm 960
Me Cool rpm 1020
Heat rpm 1100
Hi Cool rpm 1200
Heat rpm 1240
SHi Cool rpm 1250
Heat rpm 1290
Outdoor Fan
Type Propeller Fan
Material PP
Motor Type DC (8-poles)
Input Power W –
Output Power W 40
Speed Hi Cool rpm 820
Heat rpm 820
Moisture Removal L/h (Pt/h) 4.1 (8.7)
Indoor
Airflow
QLo Cool m3/min (ft3/min) 12.63 (446)
Heat m3/min (ft3/min) 13.76 (486)
Lo Cool m3/min (ft3/min) 13.57 (479)
Heat m3/min (ft3/min) 15.65 (553)
Me Cool m3/min (ft3/min) 16.79 (592)
Heat m3/min (ft3/min) 18.30 (646)
Hi Cool m3/min (ft3/min) 20.20 (715)
Heat m3/min (ft3/min) 21.00 (740)
SHi Cool m3/min (ft3/min) 21.13 (746)
Heat m3/min (ft3/min) 21.89 (773)
Outdoor
Airflow Hi Cool m3/min (ft3/min) 44.70 (1580)
Heat m3/min (ft3/min) 44.70 (1580)
Refrigerant
Cycle
Control Device Expansion Valve
Refrigerant Oil cm3FW50S (800)
Refrigerant Type g (oz) R32, 1.32k (46.6)
F-Gas
GWP 675
CO2eq (ton)
(Precharged Amount /
Maximum Amount)
0.891 / 1.229

18
Indoor Model CS-Z71TKEA
POS (EAN) 5025232873371
Outdoor
Model CU-Z71TKEA
POS (EAN) 5025232873401
Dimension Unit
Height
(I/D / O/D) mm (inch) 302 (11-29/32) / 695 (27-3/8)
Width
(I/D / O/D) mm (inch) 1120 (44-1/8) / 875 (34-15/32)
Depth
(I/D / O/D) mm (inch) 236 (9-5/16) / 320 (12-5/8)
Weight Net (I/D / O/D) kg (lb) 13 (29) / 49 (108)
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 15.88 (5/8)
Standard Length m (ft) 5.0 (16.4)
Length Range (min – max) m (ft) 3 (9.8) ~ 30 (98.4)
I/D & O/D Height Different m (ft) 20.0 (65.6)
Additional Gas Amount g/m (oz/ft) 25 (0.3)
Length for Additional Gas m (ft) 10 (32.8)
Drain Hose Inner Diameter mm 16.7
Length mm 650
Indoor
Heat
Exchanger
Fin Material Aluminium (Pre Coat)
Fin Type Slit Fin
Row × Stage × FPI 2 × 17 × 21
Size (W × H × L) mm 836.5 × 357 × 25.4
Outdoor
Heat
Exchanger
Fin Material Aluminium
Fin Type Corrugated Fin (Pre Coat)
Row × Stage × FPI 2 × 31 × 19
Size (W × H × L) mm 36.4 × 651 × 904.5:874.5
Air Filter Material Polypropelene
Type One-touch
Power Supply Indoor
Power Supply Cord Nil
Thermostat Electronic Contol
Protection Device Electronic Contol
Dry Bulb Wet Bulb
Indoor Operation
Range
Cooling Maximum °C (°F) 32 (89.6) 23 (73.4)
Minimum °C (°F) 16 (60.8) 11 (51.8)
Heating Maximum °C (°F) 30 (86.0) –
Minimum °C (°F) 16 (60.8) –
Outdoor Operation
Range
Cooling Maximum °C (°F) 43 (109.4) 26 (78.8)
Minimum °C (°F) -20 (-40) –
Heating Maximum °C (°F) 24 (75.2) 18 (64.4)
Minimum °C (°F) -15 (5.0) –
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C DRY BULB (95°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb).
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor air temperature of 7°C Dry Bulb (44.6°F
Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb).
3. Heating low temperature capacity, Input Power and COP measured at 230 V, indoor temperature 20°C, outdoor 2/1°C.
4. Heating extreme low temperature capacity, Input Power and COP measured at 230 V, indoor temperature 20°C, outdoor -7/-8°C.
5. Standby power consumption ≤10.0w (when switched OFF by remote control, except under self protection control).
6. Specifications are subjected to change without prior notice for further improvement.

19
4. Features
Inverter Technology
oWider output power range
oEnergy saving
oQuick Cooling
oQuick Heating
oMore precise temperature control
Environment Protection
oNon-ozone depletion substances refrigerant (R32)
Long Installation Piping
oLong piping up to 20 meters (Z25~42TKEA) and 30 meters (Z50/71TKEA) during single split connection only
Easy to use remote control
Quality Improvement
oRandom auto restart after power failure for safety restart operation
oGas leakage protection
oPrevent compressor reverse cycle
oInner protector to protect compressor
oNoise prevention during soft dry operation
Operation Improvement
oQuiet mode to reduce the indoor unit operating sound
oPowerful mode to reach the desired room temperature quickly
o24-hour timer setting
Serviceability Feature
oBreakdown Self Diagnosis function

20
5. Location of Controls and Components
5.1 Indoor Unit
POWERFUL
Front panel
Air Filters
Auto OFF/ON button
Use when remote control is misplaced
or a malfunction occurs.
Vertical airflow direction louver
Manually adjustable.
Horizontal airflow direction louver
Do not adjust by hand.
Aluminium fin
Sunlight Sensor and
Remote Control Receiver
Indicator
POWER
TIMER
QUIET
POWERFUL
5.2 Outdoor Unit
5.3 Remote Control
Operation Mode Selection
Indicator
OFF Indicator
Timer/Clock Setting Display
Check Button
Fan Speed Display
Temperature Setting Display
Powerful Operation Indicator
Quiet Operation Indicator
OFF/ON Button
Operation Mode Button
Temperature Setting Button
Fan Speed Button
Quiet/Powerful Operation Button
Remote Control Reset Button
Air Conditioner Reset Button
System Error Display
Operation LED
Timer Setting Button Group
