Panasonic CU-5E36QBU Installation and user guide

Split System Submittal Data
Indoor: CU-5E36QBU
Multi System Outdoor Units
Approval:
Date:
Construction:
Unit#:
Drawing#:
Job Name:
Location:
Engineer:
Submitted to:
Submitted by:
Reference:
General Data
Power (V/P/Hz) 230/208/1/60
Minimum Circuit Ampacity (A) 30
Maximum Overcurrent Protection (A) 45
Compressor DC Twin Rotary
No. Used 1
Output Power (W) 1.3K
Outdoor Unit Cool/Heat
Fan type Propeller
Motor Type DC Motor (8 poles)
Output Power (W) 90
Airflow (CFM) Cooling/Heating 750/740
Coil Type Aluminum (Blue Coated)
Fin Type - Pipe Type Corrugated Fin
Rows - F.P.I. 19
Face Area (sq.ft.) 9.41
Refrigerant R410A
Lbs. - R410a (outdoor unit) 7.5
Control Electronic Expansion Valve
Connection Flare
Line Length, Max (ft.) 82
Elevation Difference, Max (ft.) 49
Line Size (in. O.D. Discharge) 1/4" x 5
Line Size (in. O.D. Suction) 3/8" x 5
Dimensions (HxWxD)
Outdoor Unit (Crated) (in.) 44-3/4 x 42-5/16 x 19-29/32
Outdoor Unit (Uncrated) (in.) 39-11/32 x 37-1/32 x 13-13/32
Weight (lbs.) Indoor
Net 183
Shipping 201
Performance Data @ ARI Standard Conditions (230/208V)
Cooling
Total Capacity (BTU/H) 36,000 (9,900-39,000)
Sensible Capacity (BTU/H) 33,840
Latent Capacity (BTU/H) 2,160
Features
Wireless Remote Controller Standard
Wired Remote Controller
(CZ-RD516C)
Optional
Controls Microprocessor
Remote Controller LCD Wireless Type
Temperature Control IC Thermostat
Air Louver, Horizontal Manual
Air Louver, Vertical Automatic
Power Failure Autmoatic Restart Built-In
Self-Diagnosis Built-In
Air Filter Washable, One-touch
Operating Range Indoor Air Intake Temp Outdoor Air Intake Temp
Cooling (Max) 90F DB/74F WB 115F DB/79F WB
Cooling (Min) 60F DB/52F WB 14F DB/-F WB
Heating (Max) 86F DB/-F WB 75F DB/64F WB
Heating (Min) 60F DB/-F WB 5F DB/3.2F WB
SEER 18.5
Dehumidification (Pints/H) N/A
Amps (A) 17.2/19
Power Inputs (W) 3750 (Max 3860)
Outdoor Sound Rating (dB-A) 55
Heating
Total Capacity (BTU/H) 37,800 (11,600-49,500)
HSPF 10.0
Amps (A) 13.4/14.8
Power Inputs (W) 2,900
Outdoor Sound Rating (dB-A) 55

9
3. Dimensions
Panasonic North America
Air Conditioning Division
1690 Roberts Blvd., NW, Suite 110
Kennesaw, GA 30144
us.panasonic.com/aircon
Outdoor Dimensions
