Panasonic KX-TG5471 User manual

– 1 –
5.8 GHz Digital Cordless Answering System
Model No. KX-TG5471
Quick Set-Up Guide
Please read the Operating Instructions for further details.
PQQW13668ZA SM1004SR0
Step 1 Setting Up the Base Unit
•USE ONLY WITH Panasonic AC ADAPTOR PQLV1.
•USE only the telephone line cord included in the unit.
•
Make sure that the AC adaptor and telephone line cords are plugged into the unit properly.
Step 2 Setting Up the Handset
Install the battery.
Insert the battery (1), and
press it down until it snaps
into the compartment (2).
Close the cover.
Charge the battery
for 6 hours before initial use.
•The unit beeps once, the CHARGE indicator
lights and “Charging” is displayed.
•When the battery is fully charged, “Charge
completed” is displayed if there are no new
calls in the Caller List.
Telephone
Line Cord
AC Adaptor
Connect as shown.
Fasten the AC adaptor
cord to prevent it from
being disconnected.
12
CHARGE Indicator
TG5471_QG.fm Page 1 Wednesday, November 24, 2004 5:44 PM

– 2 –
Step 3 Setting Date and Time
1Press [MENU].
2Scroll to “Date and time” by
pressing [d] or [B], then press
the soft key ( ).
31Enter 2 digits each for the
month, day and year.
(Ex. To set June 15, 2005,
enter “06 15 05”.)
2Enter 4 digits for the time
(hour and minute). (Ex. To set
9:30, enter “0930”.)
•To move the cursor, press the soft
key ( ) or ( ).
4Select “AM” or “PM” by pressing [*].
5Press the soft key ( ), then press [OFF].
• To confirm the date and time, repeat steps 1 and 2.
The current date and time are displayed. When finished, press
[OFF].
Step 4 Recording Your Own Greeting (Optional)
You can record a personal greeting message of up to 2 minutes. If you do not record
your own message, one of two pre-recorded greetings will be played for callers.
For details, see pages 22–23 in the Operating Instructions.
Press
[GREETING REC]
twice.
After the long beep,
talk into the MIC.
When finished, press
[GREETING REC] or
[STOP].
• To instruct callers to leave a message in a specific mailbox (Mailbox 1,
Mailbox 2, or Mailbox 3):
You can record a message, such as “Hello, this is (your name and/or number). Sorry,
we cannot take your call. If you have a message, for John press [#] and [1], for Jane
press [#] and [2], for Jack press [#] and [3], before the beep. Or just stay on the line
and leave a message after the beep. Thank you.”
BACK
SELECT
B
Date and time
d
BACK PLAY SELECT
f g
Date: | 12.31.2004
Time:12:00 AM
0-9=Date&Time
@=AM/PM
f g SAVE
Date: | 06.15.2005
Time:09:30 AM
0-9=Date&Time
@=AM/PM
f g SAVE
SAVE
1
2
3
TG5471_QG.fm Page 2 Wednesday, November 24, 2004 5:44 PM

– 3 –
Step 5 Subscription Service
In order to use Caller ID, Call Waiting or Call Waiting Caller ID, you must first
subscribe to the desired service.
For more information, contact your telephone company.
If you want to use the Call Waiting Caller ID feature, but it does not
function at all.
You may need to contact your telephone company to activate this specific service, even
if you already subscribed to both Caller ID and Call Waiting with Caller ID services
(CWID).
If you subscribe to a flat rate bundle service including Caller ID, Call
Waiting, Voice Mail and unlimited local/regional/long distance calls,
please read the following.
a) To use the Voice Mail service provided by the telephone company rather
than the unit’s Answering System, please turn off the Answering System by
pressing [ANSWER ON] on the base unit.
•This unit does not have an indicator to indicate if there are new messages in
your mailbox service.
b) To keep using the Answering System rather than the Voice Mail service
provided by your telephone company, please contact your telephone
company to deactivate the Voice Mail service in your bundle service.
If the telephone company cannot do that, please set the number of rings so
that the telephone answering system can answer calls prior to Voice Mail
service. It is necessary to check the “Number of Rings” required to activate
the Voice Mail service provided by your telephone company before
changing this setting.
As an example to set Number of Rings to “2”:
Press [MENU][0][6][1]. When “Number of rings” is displayed, press
[2] .
(Refer to page 73 in the Operating Instructions, if you need to set to the
different number.)
SAVE
TG5471_QG.fm Page 3 Wednesday, November 24, 2004 5:44 PM

– 4 –
Location of Controls
Base unit
Handset
MAILBOX Buttons:
Press once to playback messages.
[ANSWER ON]
Press to turn on/off
the Answering System.
Navigator Key
[SP-PHONE]
Press to begin or end a hands-free
phone conversation.
[MUTE]
Press to mute a conversation.
[FLASH/CALL WAIT]
Press to answer
another incoming call.
[REDIAL/PAUSE]
REDIAL:
Press to redial.
PAUSE:
Press to insert a
pause during dialing.
[GREETING REC]
(Record)
Press twice to record
a greeting message.
[GREETING CHECK]
Press to check the
greeting message.
Display
[ERASE]
- Individual message:
Press during
playback.
- All messages in the
mailbox:
Press before pressing
the MAILBOX button.
- Greeting:
Press after pressing
[GREETING CHECK].
BACK
[OFF]
Press to end calls or exit
programming/Caller List/
phone book.
[MENU]
Press to enter programming mode.
Navigator Key
[FLASH/CALL WAIT]
Press to answer
another incoming call.
Display
Ringer/Message Alert Indicator
[C](TALK)
Press to make/answer calls.
Soft Keys
[REDIAL]
Press to redial.
Microphone
[s](Speakerphone)
Press to turn on, to begin
a hands-free phone
conversation.
TG5471_QG.fm Page 4 Wednesday, November 24, 2004 5:44 PM

– 5 –
Handset navigator key
Scrolls up [B]and down [d]the function menu, the Caller List
and the phone book.
Increases [B]or decreases [d]the handset ringer and receiver/
speaker volumes.
Base unit navigator key
Increases [B]or decreases [d]the base unit ringer and
speaker volumes.
Selects the base unit ringer tone [<]and [>].
Repeats [<]or skips [>]recorded messages.
Throughout this guide, the soft keys are indicated by their icons, such as ,
and C.
Throughout this guide, the handset navigator key is indicated by the arrows [d] or [B].
Throughout this guide, the base unit navigator key is indicated by the arrows [d],[B],
[<]or [>].
Listening to Messages
a) Playing Back New Messages
When the ANSWER ON indicator on the base unit and
the mailbox icon(s)
(, and/or ) on the
base unit display FLASH, press the MAILBOX button
([MAILBOX 1], [MAILBOX 2], or [MAILBOX 3]).
b) Playing Back Old Messages
When the mailbox icon(s) (, and/or )
on the base unit display DOES NOT FLASH, press the
MAILBOX button ([MAILBOX 1], [MAILBOX 2], or [MAILBOX 3]).
Handset soft keys
Three soft keys are used to select functions displayed
directly above each key. Functions displayed above each
key will change depending on the state of use.
On this sample display, “ ”, “ ” and “C” are
displayed above the soft keys.
Pressing the right soft key selects the Phone Book “C”.
Pressing the middle soft key selects message playback “ ”.
Pressing the left soft key reviews Caller ID information in the Caller List “ ”.
•When a function name does not appear above a soft key, the soft key has no function.
SP I PRIVACY 1
IN USE
CID PLAY
C
CID PLAY
PLAY
CID
CID PLAY
BOX 1BOX 2BOX 3
BOX 1BOX 2BOX 3
TG5471_QG.fm Page 5 Wednesday, November 24, 2004 5:44 PM

– 6 –
Using Phone Book
a) Storing Names and Numbers
Press the soft keys (C) and ( ), then enter a name and phone
number using dialing buttons (0–9) and the soft keys
( and
) by following the display.
(Refer to page 39 in the Operating Instructions for details.)
b) Dialing from the Phone Book
Press the soft key (C) to search. Search for the desired item by
pressing [d] or [B], then press [C], [s], or the soft key ( ).
(Refer to page 41 in the Operating Instructions for details.)
c) Chain Dial
You can dial a combination of phone book or manual key pad entries while
making a call. This feature can be used, for example, to first automatically
dial a calling card access number that you have stored in the phone book,
then manually or automatically dial your PIN, and then automatically dial the
destination number from the phone book.
Press [MENU], then press [1] to access the phone book, while you are
on a call. Search for the desired item by pressing [d] or [B],
then
press the soft key
().
•If required, repeat steps for any remaining numbers.
(Refer to page 42 in the Operating Instructions for details.)
Using Caller List
Please make sure that you have already subscribed to Caller ID service.
a) Viewing the Caller List
Press the soft key ( ), then press [d] to search the Caller List.
(Refer to pages 34 and 35 in the Operating Instructions for details.)
b) Calling Back from the Caller List
Press [C] or [s] while you are viewing a phone number to call back.
If you need to edit a phone number before calling back, press the soft
key (). You can delete “1” or “1 with area code” by pressing the
soft key ()repeatedly.
(Refer to page 36 in the Operating Instructions for details.)
c) Caller ID Number Auto Edit
Once you call back an edited number (see above), this unit can
automatically edit incoming phone numbers from the same area code in the
Caller List and each time you receive a call.
You need to turn on this feature. (*Factory preset is ON.)
(Refer to page 37 in the Operating Instructions for details.)
ADD
f
g
CALL
CALL
CID
EDIT
EDIT
TG5471_QG.fm Page 6 Wednesday, November 24, 2004 5:44 PM

– 7 –
Using Other Useful Features
a) Message Alert
The Ringer/Message Alert indicator on the handset will flash slowly
when you have new messages in the Answering System.
You need to turn on this feature to use.
(Refer to page 26 in the Operating Instructions for details.)
To turn on Message Alert: Press [MENU][0][#][1] .
b) Talking Caller ID
The handset and base unit will announce the displayed name following
every ring if name-and-number Caller ID is available.
You need to subscribe to Caller ID service to use this feature.
And you need to turn on this feature. (*Factory preset is ON.)
(Refer to pages 33 and 34 in the Operating Instructions for details.)
Other Operation and Information
For information on other functions, refer to the following pages in the
Operating Instructions.
Adjusting Receiver/Speaker Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 28, 30
Selecting Ringer Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 20, 21
Caller ID Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 32–38
Phone Book. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 39–43
Answering System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 22, 56, 58
Changing Number of Rings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 25
Remote Operation from a Touch Tone Phone. . . . . . . . . . . . . . . . . . . . . . . p. 65
Call Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 58
Voice Enhancer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 29
Direct Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 73, 74
SAVE
TG5471_QG.fm Page 7 Wednesday, November 24, 2004 5:44 PM

IMPORTANT!
If your product is not working properly. . .
1. Read this Quick Set-Up Guide or Operating Instructions 2. Visit our website:
http://www.panasonic.com/consumersupport
3. Contact us via the web at:
http://www.panasonic.com/contactinfo
4. Call us at: 1-800-211-PANA(7262) To order battery, 1-800-332-5368 http://www.panasonic.com/batterystore
TG5471_QG.fm Page 8 Wednesday, November 24, 2004 5:44 PM
