Panasonic CF-53 User manual

Please read these instructions carefully before using this product, and save this manual for future use.
Contents
Getting Started
Useful Information
Getting StartedUseful InformationTroubleshootingAppendix
Appendix
Troubleshooting
OPERATING INSTRUCTIONS
Personal Computer
Model No. CF-53 series
Introduction.................................................2
Read Me First ..............................................3
(Precautions)
Description of Parts .....................................11
First-time Operation .....................................13
On-screen Manual.......................................18
Handling and Maintenance .............................19
Reinstalling Software....................................21
Troubleshooting (Basic) ................................23
LIMITED USE LICENSE AGREEMENT ..............27
Specifications ............................................28
Standard Limited Warranty.............................32
For further information about the com-
puter, you can refer to the on-screen
manual.
To access the on-screen manual
Îpage 18 “On-screen Manual”
CPE02609ZA_CF-53mk2_7_OI_E.book 1 ページ ２０１２年７月３日 火曜日 午後４時１３分

2
Getting StartedUseful InformationTroubleshootingAppendix
Introduction
Thank you for purchasing this Panasonic product. For optimum performance and safety, please read these instructions
carefully.
Terms and illustrations in these instructions
zSome illustrations are simplified to help your understanding and may look different from the actual unit.
zIf you do not log on as an administrator, you cannot use some functions or cannot display some screens.
zRefer for the latest information about optional products to the catalogs, etc.
zIn these instructions, the names and terms are referred as follows.
• “Genuine Windows®7 Professional 32-bit Service Pack 1” and “Genuine Windows®7 Professional 64-bit Service
Pack 1” as “Windows” or “Windows 7”
• DVD MULTI drive as “CD/DVD drive”
• Circular media including DVD-ROM and CD-ROM as “discs”
Disclaimer
Computer specifications and manuals are subject to change without notice. Panasonic Corporation assumes no liability
for damage incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manu-
als.
Trademarks
Microsoft®, Windows®and the Windows logo are registered trademarks of Microsoft Corporation of the United States
and/or other countries.
Intel, Core, Centrino and PROSet are either registered trademarks or trademarks of Intel Corporation.
SDXC Logo is a trademark of SD-3C, LLC.
Adobe, the Adobe logo and Adobe Reader are either registered trademarks or trademarks of Adobe Systems Incorpo-
rated in the United States and/or other countries.
Bluetooth®is a registered trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed to Panasonic Corporation.
HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other countries.
Roxio Creator is a trademark or registered trademark of Corel Corporation in the United states and/or other countries.
Names of products, brands, etc., appearing in this manual are trademarks or registered trademarks of their respective
own companies.
: Conditions that may result in minor or moderate injury.
: Useful and helpful information.
Enter : Press [Enter] key.
Fn + F5 : Press and hold [Fn] key, and then press [F5] key.
(Start) - [All Programs]: Click (Start), and then click [All Programs].
Î: Page in these Operating Instructions or in the Reference Manual.
: Reference to the on-screen manuals.
CAUTION
NOTE
CPE02609ZA_CF-53mk2_7_OI_E.book 2 ページ ２０１２年７月３日 火曜日 午後４時１３分

3
Getting StartedUseful InformationTroubleshootingAppendix
Read Me First
<Only for model with modem>
When using your telephone equipment, basic safety precau-
tions should always be followed to reduce the risk of fire,
electric shock and injury to persons, including the following:
1. Do not use this product near water, for example, near
a bath tub, wash bowl, kitchen sink or laundry tub, in a
wet basement or near a swimming pool.
2. Avoid using a telephone (other than a cordless type)
during an electrical storm. There may be a remote risk
of electric shock from lightning.
3. Do not use the telephone to report a gas leak in the
vicinity of the leak.
4. Use only the power cord and batteries indicated in this
manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special
disposal instructions.
SAVE THESE INSTRUCTIONS
19-E-1
<Only for model with wireless LAN/Bluetooth>
This product and your Health
This product, like other radio devices, emits radio fre-
quency electromagnetic energy. The level of energy emit-
ted by this product however is far much less than the
electromagnetic energy emitted by wireless devices like
for example mobile phones.
Because this product operates within the guidelines found in
radio frequency safety standards and recommendations, we
believe this product is safe for use by consumers. These
standards and recommendations reflect the consensus of
the scientific community and result from deliberations of
panels and committees of scientists who continually review
and interpret the extensive research literature.
In some situations or environments, the use of this prod-
uct may be restricted by the proprietor of the building or
responsible representatives of the organization. These sit-
uations may for example include:
zUsing this product on board of airplanes, or
zIn any other environment where the risk of interference
to other devices or services is perceived or identified
as harmful.
If you are uncertain of the policy that applies on the use of
wireless devices in a specific organization or environment
(e.g. airports), you are encouraged to ask for authoriza-
tion to use this product prior to turning on the product.
Regulatory Information
We are not responsible for any radio or television interfer-
ence caused by unauthorized modification of this product.
The correction of interference caused by such unautho-
rized modification will be the responsibility of the user. We
and its authorized resellers or distributors are not liable for
damage or violation of government regulations that may
arise from failing to comply with these guidelines.
26-M-1
Important Safety Instructions
Information to the User
CPE02609ZA_CF-53mk2_7_OI_E.book 3 ページ ２０１２年７月３日 火曜日 午後４時１３分

4
Read Me First
Getting StartedUseful InformationTroubleshootingAppendix
<Only for model with wireless WAN>
The following safety precautions must be observed during all phases of the operation, usage, service or repair of any
Personal Computer or Handheld Computer incorporating wireless WAN modem. Manufacturers of the cellular terminal
are advised to convey the following safety information to users and operating personnel and to incorporate these guide-
lines into all manuals supplied with the product. Failure to comply with these precautions violates safety standards of
design, manufacture and intended use of the product. Panasonic assumes no liability for customer failure to comply
with these precautions.
When in a hospital or other health care facility, observe the restrictions on the use of mobiles. Switch Personal
Computer or Handheld Computer incorporating wireless WAN modem off, if instructed to do so by the
guidelines posted in sensitive areas. Medical equipment may be sensitive to RF energy.
The operation of cardiac pacemakers, other implanted medical equipment and hearing aids can be affected by
interference from Personal Computer or Handheld Computer incorporating wireless WAN modem placed close
to the device. If in doubt about potential danger, contact the physician or the manufacturer of the device to verify
that the equipment is properly shielded. Pacemaker patients are advised to keep their Personal Computer or
Handheld Computer incorporating wireless WAN modem away from the pacemaker, while it is on.
Switch off Personal Computer or Handheld Computer incorporating wireless WAN modem before boarding
an aircraft. Make sure it cannot be switched on inadvertently. The operation of wireless appliances in an
aircraft is forbidden to prevent interference with communications systems. Failure to observe these
instructions may lead to the suspension or denial of cellular services to the offender, legal action, or both. For
details on usage of this unit in aircrafts please consult and follow instruction provided by the airline.
Do not operate Personal Computer or Handheld Computer incorporating wireless WAN modem in the
presence of flammable gases or fumes. Switch off the cellular terminal when you are near petrol stations, fuel
depots, chemical plants or where blasting operations are in progress. Operation of any electrical equipment
in potentially explosive atmospheres can constitute a safety hazard.
Your Personal Computer or Handheld Computer incorporating wireless WAN modem receives and transmits
radio frequency energy while switched on. Remember that interference can occur if it is used close to TV
sets, radios, computers or inadequately shielded equipment. Follow any special regulations and always
switch off Personal Computer or Handheld Computer incorporating wireless WAN modem wherever
forbidden, or when you suspect that it may cause interference or danger.
Road safety comes first! Do not use a Personal Computer or Handheld Computer incorporating wireless
WAN modem while driving a vehicle. Do not place the computer with wireless WAN modem in an area where
it could cause personal injury to the driver or passengers. It is recommended to stow the unit in the boot or
secure stowage area while driving.
Do not place the computer with wireless WAN modem in an area over an air bag or in the vicinity where an air
bag may deploy.
Air bags inflate with great force and if the computer with wireless WAN modem is placed in the air bag
deployment area may be propelled with great force and cause serious injury to occupants of the vehicle.
IMPORTANT!
Personal Computer or Handheld Computer incorporating wireless WAN modem operate using radio signals
and cellular networks cannot be guaranteed to connect in all conditions. Therefore, you should never rely
solely upon any wireless device for essential communications, for example emergency calls.
Remember, in order to make or receive calls, Personal Computer or Handheld Computer incorporating
wireless WAN modem must be switched on and in a coverage area with adequate cellular signal strength.
Some networks do not allow for emergency calls if certain network services or phone features are in use (e.g.
lock functions, fixed dialing etc.). You may need to deactivate those features before you can make an
emergency call.
Some networks require that a valid SIM card be properly inserted in Personal Computer or Handheld
Computer incorporating wireless WAN modem.
Safety Precautions
CPE02609ZA_CF-53mk2_7_OI_E.book 4 ページ ２０１２年７月３日 火曜日 午後４時１３分

5
Getting StartedUseful InformationTroubleshootingAppendix
Lithium Battery!
This computer contains a lithium battery to enable the date, time, and other data to be stored. The battery should only
be exchanged by authorized service personnel.
Warning! A risk of explosion from incorrect installation or misapplication may possibly occur.
15-E-1
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
12-E-1
The following label is put on the bottom of the computer.
12-1-1
When using Port Replicator or Car Mounter on which
an external antenna can be installed:
• External antenna for wireless LAN must be professionally installed.
• The gain of external antenna for wireless LAN must not exceed 5dBi.
• The user must maintain minimum of 20 cm spacing between the external antenna and all people (excluding extremi-
ties of hands, wrist and feet) during wireless modes of operation.
41-E-1-1
These symbols on the products, packaging, and/or accompanying documents mean that used electrical
and electronic products and batteries should not be mixed with general household waste.
For proper treatment, recovery and recycling of old products and used batteries, please take them to appli-
cable collection points, in accordance with your national legislation and the Directives 2002/96/EC and
2006/66/EC.
By disposing of these products and batteries correctly, you will help to save valuable resources and pre-
vent any potential negative effects on human health and the environment which could otherwise arise from
inappropriate waste handling.
For more information about collection and recycling of old products and batteries, please contact your
local municipality, your waste disposal service or the point of sale where you purchased the items.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further
information.
[Information on Disposal in other Countries outside the European Union]
These symbols are only valid in the European Union. If you wish to discard this product, please contact
your local authorities or dealer and ask for the correct method of disposal.
Note for the battery symbol (bottom two symbol examples):
This symbol might be used in combination with a chemical symbol. In this case it complies with the
requirement set by the Directive for the chemical involved.
53-E-1
Lithium Battery
CD/DVD Drive Caution
External Antenna
Information for Users on Collection and Disposal of Old Equipment and used
Batteries
CPE02609ZA_CF-53mk2_7_OI_E.book 5 ページ ２０１２年７月３日 火曜日 午後４時１３分

6
Read Me First
Getting StartedUseful InformationTroubleshootingAppendix
<Only for model with a “CE ” mark on the bottom of the computer>
Declaration of Conformity (DoC)
“Hereby, Panasonic declares that this Personal Computer is in compliance with the essential
requirements and other relevant provisions of the Directive 1999/5/EC.”
Hint:
If you want to get a copy of the original DoC of our above mentioned products,
please contact our web address: http://www.doc.panasonic.de
Authorised Representative:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
Network connection of Wired Modem.
The terminal equipment is intended for connection to the following public network;
In all the countries of European Economical Area and Turkey;
- Public Switched Telephony Networks
Technical Features of Wired Modem.
The terminal equipment includes the following features;
- DTMF dialing
- Maximum bitrate receiving mode: 56 kbit/s
- Maximum bitrate sending mode: 33.6 kbit/s
Indication of the countries where WLAN is intended to be used:
AT BE BG CH CY CZ DE DK EE ES
FI FR GB GR HU IE IS IT LT LU
LV MT NL NO PL PT RO SE SI SK TR
18-25-E-1
<Only for model with a “CE” mark on the bottom of the computer>
Declaration of Conformity (DoC)
“Hereby, Panasonic declares that this Personal Computer is in compliance with the essential
requirements and other relevant provisions of the Directive 1999/5/EC.”
Hint:
If you want to get a copy of the original DoC of our above mentioned products,
please contact our web address: http://www.doc.panasonic.de
Authorised Representative:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
Network connection of Wired Modem.
The terminal equipment is intended for connection to the following public network;
In all the countries of European Economical Area and Turkey;
- Public Switched Telephony Networks
Technical Features of Wired Modem.
The terminal equipment includes the following features;
- DTMF dialing
- Maximum bitrate receiving mode: 56 kbit/s
- Maximum bitrate sending mode: 33.6 kbit/s
18-E-1
Models for Europe
CPE02609ZA_CF-53mk2_7_OI_E.book 6 ページ ２０１２年７月３日 火曜日 午後４時１３分

7
Getting StartedUseful InformationTroubleshootingAppendix
This equipment requires minimum 20 cm spacing from all person’s body (excluding extremities of hands, wrist and feet)
in directions of the back and both sides of the LCD display during wireless modes of operation.
60-E-1
For your safety, please read the following text carefully.
This appliance is supplied with a molded three pin mains plug for your safety and convenience. A 3 ampere fuse is fitted
in this plug.
Should the fuse need to be replaced please ensure that the replacement fuse has a rating of 3 ampere and that it is
approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body of the fuse.
If the plug contains a removable fuse cover you must ensure that it is refitted when the fuse is replaced.
If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover
can be purchased from your local dealer.
If the fitted molded plug is unsuitable for the socket outlet in your home then the fuse should be removed and the plug
cut off and disposed of safely.
There is a danger of severe electrical shock if the cut off plug is inserted into any 13-ampere socket.
How to replace the fuse
The location of the fuse differs according to the type of AC mains plug (figures A and B).
Confirm the AC mains plug fitted and follow the instructions below. Illustrations may differ from actual AC mains plug.
Open the fuse cover with a screwdriver and replace the fuse and close or attach the fuse cover.
8-E-1
Models for UK
A S A
Fuse cover
Figure A Figure B
CPE02609ZA_CF-53mk2_7_OI_E.book 7 ページ ２０１２年７月３日 火曜日 午後４時１３分

8
Read Me First
Getting StartedUseful InformationTroubleshootingAppendix
This computer is not intended for use in medical equip-
ment including life-support systems, air traffic control sys-
tems, or other equipment, devices or systems that are
involved with ensuring human life or safety. Panasonic
cannot be held responsible in any way for any damages
or loss resulting from the use of this unit in these types of
equipment, devices or systems, etc.
This computer has been designed so as to minimize
shock to the LCD and hard disk drive, the leakage of liq-
uid (e.g., water) on to the keyboard, etc., but no warranty
is provided against such trouble. Therefore, as a precision
instrument, be extremely careful in the handling.
If a Malfunction or Trouble Occurs, Immediately Stop Use
If a Malfunction Occurs, Immediately Unplug the AC Plug
and the Battery Pack
• This product is damaged
• Foreign object inside this product
• Smoke emitted
• Unusual smell emitted
• Unusually hot
Continuing to use this product while any of the above con-
ditions are present may result in fire or electric shock.
• If a malfunction or trouble occurs, immediately turn the power
off and unplug the AC plug, and then remove the battery
pack. Then contact your technical support office for repair.
Do Not Touch This Product In a Thunderstorm If Connected
with the AC Cable or Any Other Cables
Electric shock may result.
Do Not Connect the AC Adaptor to a Power Source Other
Than a Standard Household AC Outlet
Otherwise, a fire due to overheating may result. Connect-
ing to a DC/AC converter (inverter) may damage the AC
adaptor. On an airplane, only connect the AC adaptor/
charger to an AC outlet specifically approved for such use.
Do Not Do Anything That May Damage the AC Cord, the AC
Plug, or the AC Adaptor
Do not damage or modify the cord, place it near hot tools,
bend, twist, or pull it forcefully, place heavy objects on it,
or bundle it tightly.
Continuing to use a damaged cord may result in fire, short
circuit, or electric shock.
Do Not Pull or Insert the AC Plug If Your Hands Are Wet
Electric shock may result.
Clean Dust and Other Debris of the AC Plug Regularly
If dust or other debris accumulates on the plug, humidity, etc.
may cause a defect in the insulation, which may result in a fire.
• Pull the plug, and wipe it with a dry cloth.
Pull the plug if the computer is not being used for a long
period of time.
Insert the AC Plug Completely
If the plug is not inserted completely, fire due to overheat-
ing or electric shock may result.
• Do not use a damaged plug or loose AC outlet.
Do Not Place Containers of Liquid or Metal Objects on Top
of This Product
If water or other liquid spills, or if paper clips, coins, or foreign
matter get inside this product, fire or electric shock may result.
• If foreign matter has found its way inside, immediately
turn the power off and unplug the AC plug and remove the
battery pack. Then contact your technical support office.
Do Not Disassemble This Product
You may receive an electric shock, or foreign matter may
enter and result in a fire.
Keep SD Memory Cards Away from Infants and Small Children
Accidental swallowing will result in bodily injury.
• In the event of accidental swallowing, see a doctor immediately.
Do Not Place This Product on Unstable Surfaces
If balance is lost, this product may fall over or drop, result-
ing in an injury.
Avoid Stacking
If balance is lost, this product may fall over or drop, result-
ing in an injury.
Do Not Leave This Product in High Temperature Environ-
ment for a Long Period of Time
Leaving this product where it will be exposed to extremely
high temperatures such as near fire or in direct sunlight
may deform the cabinet and/or cause trouble in the inter-
nal parts. Continued use in such a resulting condition may
lead to short-circuiting or insulation defects, etc. which
may in turn lead to a fire or electric shocks.
Do Not Block the Ventilation Hole (Exhaust)
Using this product wrapped in cloth or on top of bedding
or a blanket can block the ventilation hole and cause heat
to build up inside, possibly resulting in a fire.
Hold the Plug When Unplugging the AC Plug
Pulling on the cord may damage the cord, resulting in a
fire or electric shock.
Do Not Move This Product While the AC Plug Is Connected
The AC cord may be damaged, resulting in fire or electric shock.
• If the AC cord is damaged, unplug the AC plug immediately.
Use Only the Specified AC Adaptor With This Product
Using an AC adaptor other than the one supplied (sup-
plied with the unit or one sold separately as an accessory)
may result in a fire.
Precautions
THIS PRODUCT IS NOT INTENDED FOR USE AS,
OR AS PART OF, NUCLEAR EQUIPMENT/SYSTEMS,
AIR TRAFFIC CONTROL EQUIPMENT/SYSTEMS,
AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS*1,
MEDICAL DEVICES OR ACCESSORIES*2, LIFE
SUPPORT SYSTEMS OR OTHER EQUIPMENTS/
DEVICES/SYSTEMS THAT ARE INVOLVED WITH
ENSURING HUMAN LIFE OR SAFETY. PANASONIC
WILL NOT BE RESPONSIBLE FOR ANY LIABILITY
RESULTING FROM THE USE OF THIS PRODUCT
ARISING OUT OF THE FOREGOING USES.
*1
AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include Class2
Electrical Flight Bag (EFB) Systems and Class1 EFB Systems
when used during critical phases of flight (e.g., during take-off and
landing) and/or mounted on to the aircraft. Class1 EFB Systems
and 2 EFB Systems are defined by FAA: AC (Advisory Circular)
120-76A or JAA: JAA TGL (Temporary Guidance Leaflets) No.36.
*2 As defined by the European Medical Device Directive (MDD) 93/
42/EEC.
Panasonic cannot guarantee any specifications, tech-
nologies, reliability, safety (e.g. Flammability/Smoke/
Toxicity/Radio Frequency Emission, etc) requirements
related to aviation standards and medical equipment
standards that differ from the specifications of our
COTS (Commercial-Off-The-Shelf) products.
CPE02609ZA_CF-53mk2_7_OI_E.book 8 ページ ２０１２年７月３日 火曜日 午後４時１３分

9
Getting StartedUseful InformationTroubleshootingAppendix
Do Not Subject the AC Adaptor to Any Strong Impact
Using the AC adaptor after a strong impact such as being
dropped may result in electric shock, short circuit, or fire.
Take a Break of 10-15 Minutes Every Hour
Using this product for long periods of time may have detri-
mental health effects on the eyes or hands.
Do Not Look into the CD/DVD Drive
Looking directly at the internal laser light source may
result in damage to eyesight.
Do Not Use Discs That Are Cracked or Deformed
Because the discs rotate at high speeds, damaged discs
may break apart causing injury.
• Discs that are not round and discs that have been
repaired using adhesives are similarly dangerous, and
so should not be used.
Do Not Turn the Volume Up to Loud When Using Head-
phones
Listening at high volumes that overstimulate the ear for
long periods of time may result in loss of hearing.
Do Not Connect a Telephone Line, or a Network Cable Other
Than the One Specified, into the LAN Port
If the LAN port is connected to a network such as the
ones listed below, a fire or electric shock may result.
• Networks other than 1000BASE-T, 100BASE-TX or 10BASE-T
• Phone lines (IP phone (Internet Protocol Telephone), Tele-
phone lines, internal phone lines (on-premise switches), digital
public phones, etc.)
Do Not Use With Exposing the Skin to This Product For a
Long Period of Time
Using this product with exposing the skin to the heat
source of this product or AC adaptor for a long period of
time can cause a low-temperature burn.
Do Not Expose Yourself to the Hot Wind from the Ventilation
Hole (Exhaust) for a Long Period of Time.
Low-temperature burns may result.
Covering the ventilation hole (exhaust) with your hand or other
object can cause heat to build up inside, possibly resulting in
burns.
Do Not Expose the Skin To This Product When Using the Prod-
uct In A Hot Or Cold Environment.
Burns, low-temperature burns, or frostbite may result.
• When it is necessary to expose the skin to this product such as to
scan a fingerprint, perform the operation in the shortest time pos-
sible.
<Only for model with modem>
Use the Modem With a Regular Telephone Line
Connection to an internal phone line (on-premise switches) of a
company or business office, etc. or to a digital public phone or
use in a country or area not supported by the computer may
result in a fire or electric shocks.
zDo not place the computer near a television or radio
receiver.
zKeep the computer away from magnets. Data stored
on the hard disk may be lost.
zThis computer is not intended for the display of images
for use in medical diagnosis.
zThis computer is not intended for a use with connec-
tion of medical equipment for the purpose of medical
diagnosis.
zPanasonic shall not be liable for loss of data or other
incidental or consequential damages resulting from the
use of this product.
Interface Cable
Use of an interface cable longer than
3 m is not recommended.
11-E-1
CPE02609ZA_CF-53mk2_7_OI_E.book 9 ページ ２０１２年７月３日 火曜日 午後４時１３分

10
Read Me First
Getting StartedUseful InformationTroubleshootingAppendix
Do Not Use With Any Other Product
The battery pack is rechargeable and was intended for
the specified product. If it is used with a product other
than the one for which it was designed, electrolyte leak-
age, generation of heat, ignition or rupture may result.
Do Not Charge the Battery Using Methods Other Than
Those Specified
If the battery is not charged using one of the specified
methods, electrolyte leakage, generation of heat, ignition
or rupture may result.
Do Not Throw the Battery Pack into a Fire or Expose It
to Excessive Heat
Generation of heat, ignition or rupture may result.
Avoid Extreme Heat (Near the Fire, in Direct Sunlight,
for Example)
Electrolyte leakage, generation of heat, ignition or rupture
may result.
Do Not Insert Sharp Objects into the Battery Pack,
Expose It to Bumps or Shocks, Disassemble, or Mod-
ify It
Electrolyte leakage, generation of heat, ignition or rupture
may result.
• If this product is subjected to a strong impact, stop using
it immediately.
Do Not Short the Positive (+) and Negative (-) Con-
tacts
Generation of heat, ignition or rupture may result.
• Do not place the battery pack together with articles such
as necklaces or hairpins when carrying or storing.
Do Not Use This Product With a Battery Pack Other
Than the One Specified
Use only the specified battery pack (Îpage 12) with your
product. Use of battery packs other than those manufac-
tured and supplied by Panasonic may present a safety
hazard (generation of heat, ignition or rupture).
When the battery pack has deteriorated, replace it
with a new one
Continued use of a damaged battery pack may result in
heat generation, ignition or battery rupture.
zDo not touch the terminals on the battery pack. The
battery pack may no longer function properly if the
contacts are dirty or damaged.
zDo not expose the battery pack to water, or allow it to
become wet.
zIf the battery pack will not be used for a long period of
time (a month or more), charge or discharge (use) the
battery pack until the remaining battery level becomes
30% to 40% and store it in a cool, dry place.
zThis computer prevents overcharging of the battery by
recharging only when the remaining power is less than
approx. 95% of capacity.
zThe battery pack is not charged when the computer is
first purchased. Be sure to charge it before using it for
the first time. When the AC adaptor is connected to the
computer, charging begins automatically.
zShould the battery leak and the fluid get into your
eyes, do not rub your eyes. Immediately flush your
eyes with clear water and see a doctor for medical
treatment as soon as possible.
NOTE
zThe battery pack may become warm during recharging
or normal use. This is completely normal.
zRecharging will not commence if internal temperature
of the battery pack is outside of the allowable tempera-
ture range (0 °C to 50 °C) (ÎReference Manual
“Battery Power”). Once the allowable range require-
ment is satisfied, charging begins automatically. Note
that the recharging time varies based on the usage
conditions. (Recharging takes longer than usual when
the temperature is 10 °C or below.)
zIf the temperature is low, the operating time is short-
ened. Only use the computer within the allowable tem-
perature range.
zThis computer has a high temperature mode function
that prevents the degradation of the battery in high
temperature environments. (ÎReference Manual
“Battery Power”) A level corresponding to a 100%
charge for high temperature mode is approximately
equivalent to an 80% charge level for normal tempera-
ture mode.
zThe battery pack is a consumable item. If the amount
of time the computer can be run by using a particular
battery pack becomes dramatically shorter and
repeated recharging does not restore its performance,
the battery pack should be replaced with a new one.
zWhen transporting a spare battery inside a package,
briefcase, etc., it is recommended that it be placed in a
plastic bag so that its contacts are protected.
zAlways power off the computer when it is not in use.
Leaving the computer on when the AC adaptor is not
connected will exhaust the remaining battery capacity
(ÎReference Manual “LAN”).
Precautions (Battery Pack)
CAUTION:
Risk of Explosion if Battery is replaced by an Incorrect Type.
Dispose of Used Batteries According to the Instructions.
58-E-1
CPE02609ZA_CF-53mk2_7_OI_E.book 10 ページ ２０１２年７月３日 火曜日 午後４時１３分

11
Getting StartedUseful InformationTroubleshootingAppendix
Description of Parts
A : Wireless WAN antenna
<Only for model with wireless WAN>
ÎReference Manual “Wireless WAN”
B : Bluetooth antenna
<Only for model with Bluetooth>
ÎReference Manual “Bluetooth”
C : Speaker
ÎReference Manual “Key Combinations”
D : Smart Card slot
<Only for model with Smart Card slot>
ÎReference Manual “Smart Card”
E : CD/DVD Drive
ÎReference Manual “CD/DVD Drive”
F : Wireless LAN antenna
<Only for model with wireless LAN>
ÎReference Manual “Wireless LAN”
G : Wireless LAN antenna
<Only for model with wireless LAN and without GPS>
ÎReference Manual “Wireless LAN”
GPS antenna
<Only for model with GPS>
H : Camera
<Only for model with Camera>
ÎReference Manual “Camera”
I : LCD
<Only for model with touchscreen>
ÎReference Manual “Touchscreen”
J : Power switch
K : Function key
ÎReference Manual “Key Combinations”
L : Wireless LAN antenna
<Only for model with wireless LAN and GPS>
ÎReference Manual “Wireless LAN”
M : Fingerprint Reader
<Only for model with Fingerprint Reader>
ÎReference Manual “Fingerprint Reader”
N : Keyboard
O : LED indicator
: Caps lock
: Numeric key (NumLk)
: Scroll lock (ScrLk)
: Drive status
: SD Memory Card status
(Blinking: During access or a password is
requested)
ÎReference Manual “SD Memory Card”
: Wireless ready
This indicator lights when Wireless LAN, Blue-
tooth, and/or Wireless WAN are connected and
ready. It does not necessarily indicate the On/Off
condition of the wireless connection.
ÎReference Manual “Disabling/Enabling
Wireless Communication” “Wireless LAN” “Blue-
tooth” “Wireless WAN”
: Battery status
ÎReference Manual “Battery Power”
: Power status
(Off: Power off/Hibernation, Green: Power on,
Blinking green: Sleep, Blinking green rapidly:
Cannot power on or resume due to low tempera-
ture.)
P : Microphone jack
A condenser microphone can be used. If other types
of microphones are used, audio input may not be pos-
sible, or malfunctions may occur as a result.
Q : Headphone jack
You can connect headphones or amplified speakers.
When they are connected, audio from the internal
speakers is not heard.
R : Stylus Holder
<Only for model with touchscreen>
S : RFID Reader
<Only for model with RFID Reader>
ÎReference Manual “RFID Reader”
T : Carrying handle
U : Touch pad
B
C
D
E
A
G
A
I
C
M
L
N
O
P
Q
R
S
T
R
U
K
J
F
H
CPE02609ZA_CF-53mk2_7_OI_E.book 11 ページ ２０１２年７月３日 火曜日 午後４時１３分

12
Description of Parts
Getting StartedUseful InformationTroubleshootingAppendix
A : Battery pack
Specified Battery pack: CF-VZSU71U
B : ExpressCard slot*1 / PC Card slot*2
ÎReference Manual “PC Card / ExpressCard”
*1 Only for model with ExpressCard slot
*2 Only for model without ExpressCard slot
C : PC Card slot
ÎReference Manual “PC Card / ExpressCard”
D : SD Memory Card slot
ÎReference Manual “SD Memory Card”
E : Wireless switch
Î
Reference Manual “Disabling/Enabling Wireless
Communication” “Wireless LAN” “Bluetooth” “Wireless WAN”
F : USB 3.0 port
ÎReference Manual “USB Devices”
G : DC-IN jack
H : LAN port
ÎReference Manual “LAN”
I : USB 2.0 port
ÎReference Manual “USB Devices”
J : HDMI Port
ÎReference Manual “External Display”
K : VGA port
ÎReference Manual “External Display”
L : Ventilation hole (Exhaust)
M : Security lock
A Kensington cable can be connected.
For further information, read the manual that comes
with the cable.
N : SIM Card slot
<Only for model with Wireless WAN>
ÎReference Manual “Wireless WAN”
O : 2nd LAN Port*3 / Modem Port*4 / IEEE 1394 Inter-
face Connector*5 / Rugged USB 2.0 Port*6
*3 Only for model with 2nd LAN
ÎReference Manual “LAN”
*4 Only for model with Modem
ÎReference Manual “Modem”
*5 Only for model with IEEE 1394
ÎReference Manual “IEEE 1394 Devices”
*6 Only for model with Rugged USB 2.0 Port
P : Serial port
Q : Expansion bus connector
ÎReference Manual “Port Replicator”
R : RAM module slot
ÎReference Manual “RAM Module”
S : Battery latch
T : Hard disk drive
ÎReference Manual “Hard Disk Drive”
NOTE
zWhen you open the covers on
the right side or the rear side,
push down and pull the covers.
zThis computer contains a
magnet and magnetic prod-
ucts at the locations circled in
the illustration at right. Avoid
leaving metallic object or mag-
netic media in contact with
these areas.
ABC D EF G
Q
R
S
T
HI JK L OPMN
Right side
Rear side Bottom
(Example: rear side)
CPE02609ZA_CF-53mk2_7_OI_E.book 12 ページ ２０１２年７月３日 火曜日 午後４時１３分

13
Getting StartedUseful InformationTroubleshootingAppendix
First-time Operation
Preparation
ACheck and identify the supplied accessories.
If you do not find the described accessories, contact Panasonic Technical Support.
B
Read the LIMITED USE LICENSE AGREEMENT before breaking the seal on the computer’s packaging (Îpage 27).
Inserting the Battery Pack
AReverse the computer, then press and hold the mark part (A).
BSlide and remove the cover.
CInsert the battery pack (B) until it securely fits the connector.
DSlide the cover back.
To remove the battery pack
In step C above, slide and hold the latch (C), and pull the tab (D) of the battery pack.
CAUTION
zMake sure the cover is securely attached. Otherwise the battery pack may fall
when you carry the computer.
NOTE
zNote that the computer consumes electricity even when the computer power is
off. If the battery pack is fully charged, the battery will fully discharge in the fol-
lowing period of time:
• When power is off: Approx. 9 weeks
• In sleep: Approx. 3.5 days
• In hibernation: Approx. 9 days
zWhen the DC plug is not connected to the computer, disconnect the AC cord
from your AC wall outlet. Power is consumed simply by having the AC adaptor
plugged into an electrical outlet.
Attaching the stylus to the computer
• AC Adaptor . . . . . . . . . . . . . 1
Model No: CF-AA5713A
• AC Cord . . . . . . . . . . . . . . . 1 • Battery Pack . . . . . . . . . . . . 1
Model No: CF-VZSU71U
• OPERATING INSTRUCTIONS (This book). . . . . . . . . . . . . . . . . . . . . . . . . 1
<Only for model with touchscreen>
• Soft Cloth . . . . . . . . . . . . . . 1 • Stylus . . . . . . . . . . . . . . . . 1 • Tether . . . . . . . . . . . . . . . . 1
(ÎReference Manual “Touchscreen”)
2
1
3
4
D
C
B
A
<Only for model with touchscreen> Use the tether to attach the stylus to the computer so you will not lose it.
There are holes (A) to attach it.
CAUTION
zDo not pull the tether with excessive force. The digitizer pen may hit the com-
puter, person’s body or other objects when released.
A
1 2 3 4
CPE02609ZA_CF-53mk2_7_OI_E.book 13 ページ ２０１２年７月３日 火曜日 午後４時１３分

14
First-time Operation
Getting StartedUseful InformationTroubleshootingAppendix
Opening the Display
Setting up the computer
zDo not touch the terminals of the battery pack and the computer. Doing so can
make the terminals dirty or damaged, and may cause malfunction of the battery
pack and the computer.
zBe sure to attach the cover for use.
The battery charging starts automatically.
CAUTION
zDo not disconnect the AC adaptor and do not switch the wireless switch to on
until the first-time operation procedure is completed.
zWhen using the computer for the first time, do not connect any peripheral device
except the battery pack and AC adaptor.
zHandling the AC adaptor
Problems such as sudden voltage drops may arise during periods of thunder and
lightning. Since this could adversely affect your computer, an uninterruptible
power source (UPS) is highly recommended unless running from the battery
pack alone.
AConfirm the wireless switch (Îpage 12) is OFF.
BPress and hold the power switch (Îpage 11) until the power indicator
(Îpage 11) lights.
CAUTION
zDo not press the power switch repeatedly.
zThe computer will be forcibly turned off if you press and hold the power switch for
four seconds or longer.
zOnce you turn off the computer, wait for ten seconds or more before you turn on
the computer again.
zDo not perform the following operation until the drive indicator turns off.
• Connecting or disconnecting the AC adaptor
• Pressing the power switch
• Touching the keyboard, touch pad, touchscreen <only for model with touch-
screen> or external mouse
• Closing the display
• Turn on/off the wireless switch
zWhen the CPU temperature is high, the computer may not start up to prevent
overheating of the CPU. Wait until the computer cools down, and then turn the
power on again. If the computer does not power on even after cooling down,
contact Panasonic Technical Support.
APush the top of the latch (A) to release it.
BLift up the display to open.
A
1
2
1 Insert the battery pack. (Îpage 13)
2 Connect your computer to a power outlet.
3 Turn on the computer.
CPE02609ZA_CF-53mk2_7_OI_E.book 14 ページ ２０１２年７月３日 火曜日 午後４時１３分

15
Getting StartedUseful InformationTroubleshootingAppendix
NOTE
zThe message "Reinstall" is displayed, but language and OS (32-bit or 64-bit)
will be prepared by the following steps.
AClick [Reinstall Windows] and click [Next].
The License Agreement screen appears.
BClick [Yes, I agree to the provisions above and wish to continue!] and click
[Next].
CClick [Reinstall Windows to the whole Hard Disk to factory default.] and click
[Next].
DAt the confirmation message, click [YES].
ESelect language and OS (32bit or 64bit) on "Select OS" screen and click
[OK].
The language setting will start by clicking [OK] on the confirmation screen.
You can return to the "Select OS" screen by clicking [Cancel].
The language and OS setting will be completed in about 15 minutes.
FWhen termination screen is displayed, click [OK] to turn off the computer.
GTurn on the computer.
CAUTION
zCarefully choose your language because you cannot change it later. If you set a
wrong language, you need to reinstall Windows.
AFollow the on-screen instructions.
zThe computer restarts several times. Do not touch the keyboard or touch
pad, and wait until the drive indicator
has turned off.
zAfter the computer is turned on, the screen remains black or unchanged for
a while, but this is not a malfunction. Wait for a moment until the Windows
setup screen appears.
zDuring setup of Windows, use the touch pad and clicking to move the cursor
and to click an item.
zSetup of Windows will take approximately 20 minutes.
Go to the next step, confirming each message on the display.
z“Join a wireless network” screen may not appear.
You can set the Wireless Network after the setup of Windows is complete.
CAUTION
zWait until the drive indicator has turned off.
zYou can change the user name, password, image and Wireless Networks after
setup of Windows.
zDo not use the following words and characters for user name: CON, PRN,
AUX, CLOCK$, NUL, COM1 to COM9, LPT1 to LPT9, @
, &, space . In particu-
lar, if you create a user name (account name) that includes the “@” mark, a
password will be requested at the log-on screen, even if no password has been
set. If you try to log on without entering a password, “The user name or pass-
word is incorrect.” may be displayed and you will not be able to log on to Win-
dows (Îpage 24).
zUse standard characters as a computer name: numbers 0 through 9, upper-
case and lowercase letters from A to Z, and the hyphen (-) character.
If the error message “The computer name is not valid” appears, check if char-
acters other than the above are not entered. If the error message still remains
on the display, set the key entry mode to English (“EN”) and enter characters.
4 <For MUI OS model>
Select language and OS (32-bit or 64-bit).
5 Setup Windows.
CPE02609ZA_CF-53mk2_7_OI_E.book 15 ページ ２０１２年７月３日 火曜日 午後４時１３分

16
First-time Operation
Getting StartedUseful InformationTroubleshootingAppendix
z The wallpaper for the first logon user has already been set on “ 5 Setup Windows.”.
When using this computer under the Sun, the screen becomes easily viewable
by changing the wallpaper to the white wallpaper.
ARight-click on the desktop, and click [Personalize] - [Desktop Background].
BSelect [Solid Colors] at [Picture Location].
CSelect the white wallpaper and click [Save changes].
<For MUI OS model>
zWhen setting up the keyboard, choose the appropriate one to your computer.
Otherwise, input by the keyboard may become unavailable.
zBefore performing the calibration, close Tablet PC Input Panel.
NOTE
zAt first, log on to Windows as an administrator and perform this calibration.
zAlternatively, you can perform the calibration from Dashboard for Panasonic PC.
(ÎReference Manual
“Dashboard for Panasonic PC” )
A Click (Start) - [Control Panel] - [Hardware and Sound] - [Tablet PC Setting].
BClick [Calibrate].
C
Using the stylus, touch each of the “+” target marks one by one, and then click [Yes].
DClick [OK].
NOTE
zPerform the following calibration for each user.
zAlternatively, you can perform the calibration from Dashboard for Panasonic PC.
(ÎReference Manual
“Dashboard for Panasonic PC” )
A Click (Start) - [Control Panel] - [Hardware and Sound] - [Tablet PC Setting].
BClick [Calibrate].
C
Using the stylus, touch each of the “+” target marks one by one, and then click [Yes].
DClick [OK].
zPerform the calibration for the orientation to be used.
NOTE
zPC Information Viewer
This computer periodically records the management information of the hard disk, etc. The maximum data volume for each
record is 1024 bytes. This information is only used for estimating the cause when the hard disk goes down by any possibil-
ity. They are never sent to outside via network nor used for any other purpose except for the purpose described the above.
To disable the function, add the check mark for [Disable the automatic save function for management information
history] in [Hard Disk Status] of PC Information Viewer, and click [OK].
(ÎReference Manual “Checking the Computer’s Usage Status”)
When Starting Up/Shutting Down
Do not do the following
• Connecting or disconnecting the AC adaptor
• Pressing the power switch
• Touching the keyboard, touch pad, touchscreen (only for model with touchscreen) or external mouse
• Closing the display
• Turn on/off the wireless switch
NOTE
zTo conserve power, the following power saving methods are set at the time of purchase.
• The screen automatically turns off after 10 minutes of inactivity.
• The computer automatically enters sleep*1 after 20 minutes of inactivity.
*1 Refer to Reference Manual “Sleep and Hibernation Functions” about resuming from sleep
6 <Only for model with touchscreen>
Perform the touchscreen calibration.
CPE02609ZA_CF-53mk2_7_OI_E.book 16 ページ ２０１２年７月３日 火曜日 午後４時１３分

17
Getting StartedUseful InformationTroubleshootingAppendix
To change the partition structure
You can shrink a part of an existing partition to create unallocated disk space, from which you can create a new partition.
This computer has a single partition as default setting.
AClick (Start) and right-click [Computer], then click [Manage].
zA standard user needs to enter an administrator password.
BClick [Disk Management].
CRight-click the partition for Windows (“c” drive in the default setting), and click [Shrink Volume].
zThe partition size depends on the computer specifications.
DInput the size in [Enter the amount of space to shrink in MB] and click [Shrink].
zYou cannot input a larger number than the displayed size.
zTo select [Reinstall to the first 3 partitions.] in reinstalling Windows 7 (Îpage 22), 30000 MB*2 or more is nec-
essary for [Total size after shrink in MB].
ERight-click [Unallocated] (the shrunk space in the step D) and click [New Simple Volume].
FFollow the on-screen instructions to make the settings, and click [Finish].
Wait until formatting is completed.
*2 For MUI OS model, 60000 MB or more is necessary.
NOTE
zYou can create an additional partition using remaining unallocated space or newly creating unallocated space.
zTo delete a partition, right-click the partition and click [Delete Volume] in the step C.
CPE02609ZA_CF-53mk2_7_OI_E.book 17 ページ ２０１２年７月３日 火曜日 午後４時１３分

18
Getting StartedUseful InformationTroubleshootingAppendix
On-screen Manual
You can access the following manuals on the computer screen.
Reference Manual
The Reference Manual contains the practical information to help you fully enjoy the computer’s performance.
To access the Reference Manual:
Double-click on the desktop.
zAlternatively click (Start) - [All Programs] - [Panasonic] - [On-Line Manuals] - [Reference Manual].
Important Tips
The Important Tips will provide you with the battery information so that you can use the battery pack in the optimum
condition to obtain longer operation time.
To access the Important Tips:
Double-click on the desktop.
zAlternatively click (Start) - [All Programs] - [Panasonic] - [On-Line Manuals] - [Important Tips].
CPE02609ZA_CF-53mk2_7_OI_E.book 18 ページ ２０１２年７月３日 火曜日 午後４時１３分

19
Getting StartedUseful InformationTroubleshootingAppendix
Handling and Maintenance
zPlace the computer on a flat stable surface not subject to shock, vibration, and danger of dropping. Do not place the
computer upright or turn it over. If the computer is exposed to an extremely strong impact, it may become damaged.
zTemperature: Operation : <Model without HDD heater> 0 °C to 50 °C (IEC60068-2-1, 2)*1
<Model with HDD heater> -10 °C to 50 °C (IEC60068-2-1, 2)*1
Storage : -20 °C to 60 °C
Humidity: Operation : 30% to 80% RH (No condensation)
Storage : 30% to 90% RH (No condensation)
Even within the above temperature/humidity ranges, operation for a long time in extreme environments, smoking
nearby, or operation in places where oil is used or where there is a lot of dust will result in the product deterioration
and will shorten the product life.
*1 Do not expose the skin to this product when using the product in a hot or cold environment. (Îpage 9)
If the computer is wet in temperatures of 0 °C or below, freeze damage may occur. Make sure to dry off the computer in such tem-
peratures.
zDo not place the computer in the following areas, otherwise the computer may be damaged.
• Near electronic equipment. Image distortion or noise may occur.
• In extremely high or low temperature.
zAs the computer can become hot during operation, keep it away from items that are sensitive to heat.
This computer is designed to minimize shock to parts such as the LCD and the hard disk drive and equipped with a drip-
proof keyboard, but no warranty is provided against any trouble caused by shock. Be extremely careful when handling
the computer.
zWhen carrying the computer:
• Turn off the computer.
• Remove all external devices, cables, PC Cards and other protruding objects.
• Remove a disc in the CD/DVD drive.
• Do not drop or hit the computer against solid objects.
• Do not leave the display open.
• Do not grip the display part.
zDo not put anything (e.g., a piece of paper) between the display and keyboard.
zWhen you board an airplane, take the computer with you and never put it in your checked luggage. When using the
computer on airplane, follow the airline’s instructions.
zWhen carrying a spare battery, put it in a plastic bag to protect its terminals.
zThe touch pad is designed to be used by finger tip. Do not place any object on its surface and do not press down
strongly with sharp-pointed or hard objects that may leave marks (e.g., nails, pencils and ball point pens).
zAvoid any harmful substances such as oil from getting into the touch pad. The cursor may not work correctly.
zBe careful not to get injured by dropping or getting hit when carrying the computer.
<Only for model with touchscreen>
zUse only the included stylus to touch the touchscreen. Do not place any object on its surface and do not press down
strongly with sharp-pointed or hard objects that may leave marks (e.g., nails, pencils and ball point pens).
zDo not use the touchscreen when dust or dirt (e.g., oil) is on the screen. Otherwise foreign particles on the screen/
stylus can scratch the screen surface or obstruct the stylus operation.
zUse the stylus only for touching the screen. Using it for any other purpose may damage the stylus and result in
scratches on the screen.
When using peripheral devices
Follow these instructions and the Reference Manual to avoid any damage to the devices. Carefully read the instruction
manuals of the peripheral devices.
zUse the peripheral devices conforming to the computer’s specifications.
zConnect to the connectors in the correct direction.
zIf it is hard to insert, do not try forcibly but check the connector’s shape, direction, alignment of pins, etc.
zIf screws are included, fasten them securely.
zRemove the cables when you carry the computer. Do not pull the cables forcibly.
Preventing your computer from unauthorized use via wireless LAN/Bluetooth/Wireless WAN
<Only for model with wireless LAN/Bluetooth/Wireless WAN>
z
Before using wireless LAN/Bluetooth/Wireless WAN, make the appropriate security settings such as data encryption.
Operation Environment
Handling Cautions
CPE02609ZA_CF-53mk2_7_OI_E.book 19 ページ ２０１２年７月３日 火曜日 午後４時１３分

20
Handling and Maintenance
Getting StartedUseful InformationTroubleshootingAppendix
Battery Recalibration
z
The battery recalibration may take a long time due to the large battery capacity. This is not a malfunction.
• Full charge: Approximately 2 hours
• Complete discharge: Approximately 2 hours
If drops of water or other stains get on the surface of the LCD panel, wipe them off immediately. Failure to do so may
result in staining.
To clean the LCD panel
<Only for model with touchscreen>
Use the soft cloth included with the computer. (For further information, refer to “Suggestions About Cleaning the LCD
Surface” ÎReference Manual “Touchscreen”.)
<Only for model without touchscreen>
Wipe with a soft dry cloth such as gauze.
To clean areas other than the LCD panel
Wipe with a soft dry cloth such as gauze. When using detergent, dip a soft cloth in water-diluted detergent and wring it
thoroughly.
CAUTION
zDo not use benzene, thinner, or rubbing alcohol since it may adversely affect the surface causing discoloration, etc.
Do not use commercially-available household cleaners and cosmetics, as they may contain components harmful to
the surface.
zDo not apply water or detergent directly to the computer, since liquid may enter inside of the computer and cause
malfunction or damage.
Maintenance
CPE02609ZA_CF-53mk2_7_OI_E.book 20 ページ ２０１２年７月３日 火曜日 午後４時１３分
