Panasonic FV-0810RS1 User manual

Service Manual
PEG1805014CE
Version:1801
CONTENTS
2.Parts Identification
3.Wiring Diagram
4.Parts List
PAGE
6
Ventilating Fan
2~5
7~8
(North America Market)
WARNING
This service information is designed for experienced repair technicians only and is not designed for use by
the general public. It does not contain warnings or cautions to advise non-technical individuals of potential
dangers in attempting to service a product. Products powered by electricity should be serviced or repaired
only by experienced professional technicians. Any attempt to service or repair the product or products dealt
with in this service information by anyone else could result in serious injury or death.
IMPORTANT SAFETY NOTICE
There are special components used in this equipment which are important for safety. These parts are
marked by in the Schematic Diagrams, Exploded Views and Replacement Parts List. It is essential
that these critical parts should be replaced with manufacturer's specified parts to prevent shock, fire
or other hazards. Do not modify the original design without permission of manufacture.
We suggest to handle such parts after the static electricity prevention.
It is forbidden to touch the PCB parts by bare hands during the repairing process.
FV-0810RS1
1.Specifications 1
FV-0810RSL1

1
1. Specifications

2
2. Parts Identification
Main Body Section
FV-0810RS1
5
C
1
2
3
4
6
7
8
9
10
11
12
13
14
15
A
(2pcs)
A
B
A
D
(6pcs)
E
(4pcs)
F
(2pcs)
A

3
2. Parts Identification
Main Labels
17
18
Packing Section
22
21
16
19
23
24
25
FAN
US
LISTED
E78414
08VSL3082
Not for use in cooking area-See installation
/instructions. Non destiné à la zone de cuisson -Voir
/instructions d’installation. No usar en áreas donde
se cocine - Consulte las instrucciones de instalación.
20
FV-0810RS1

4
2. Parts Identification
Main Body Section
FV-0810RSL1
5
C
1
2
3
4
7
8
9
10
11
12
13
14
15
A
(2pcs)
A
B
A
D
(6pcs)
E
(4pcs)
F
(2pcs)
A
16
17
19
18
D
6

5
2. Parts Identification
FV-0810RSL1
Main Labels
21
22
Packing Section
27
26
20
24
28
29
30
FAN
US
LISTED
E78414
08VSL3082
Not for use in cooking area-See installation
/instructions. Non destiné à la zone de cuisson -Voir
/instructions d’installation. No usar en áreas donde
se cocine - Consulte las instrucciones de instalación.
25
23

6
3. Wiring Diagram
FV-0810RS1
FV-0810RSL1

7
4. Parts List
FV-0810RS1
Main Body Section
No. Part No. Part Name Q'ty Remark
1 FFV5710025S Suspension Bracket 1
2 FFV1600168S Frame Assy 1
3 FFV0000166S Adapter Assy 1
4 FFV2800027S Junction Cover 1
5 FFV3450010S Earth Lead Wire 1
6 FFV0900072S Connector Assy (V) 1
7 FFV0900052S Connector Plate 1
8 FFV3700373S Motor Support Unit 1
9 FFV3700374S Motor Unit 1
10 FFV0400112S Blade 1
11 FFV0400113S Blade Fix Ring 1
12 FFV7010058S Undee Washer 1
13 FFV7020024S Hexagon Nut 1
14 FFV0790128S Casing Unit 1
15 FFV3400159S Louver Assy 1
A FFV7000108S Truss Tap Screw 5
B FFV7000064S Bind Screw 1
C FFV7000203S Earth Screw Assy 1 Include Spring Washer
D FFV7000089S Truss Tap Screw 6
E FFV7000074S Truss Tap Screw 4
F FFV7000080S Plus Bind Screw 2
Main Labels
No. Part No. Part Name Q'ty Remark
16 FFV4020945S Name Plate 1
17 FFV2260003S UL Mark 1
18 FFV0810011S Caution Label 1 1
Packing Section
No. Part No. Part Name Q'ty Remark
19 FFV4710381S Louver Case Assy 1
20 FFV4650016S Poly Cover 1
21 FFV2540231S Installation Instructions 1
22 FFV0010231S Accessory A 1
23 FFV4710431S Right Pad 1
24 FFV4710432S Left Pad 1
25 FFV9001389S Packing Case Assy 1

8
4. Parts List
FV-0810RSL1
Main Body Section
No. Part No. Part Name Q'ty Remark
1 FFV5710025S Suspension Bracket 1
2 FFV1600168S Frame Assy 1
3 FFV0000173S Adapter Assy 1
4 FFV2800027S Junction Cover 1
5 FFV3450010S Earth Lead Wire 1
6 FFV0900069S Connector Assy (L) 1
7 FFV0900072S Connector Assy (V) 1
8 FFV0900074S Connector Plate 1
9 FFV3700373S Motor Support Unit 1
10 FFV3700374S Motor Unit 1
11 FFV0400112S Blade 1
12 FFV0400113S Blade Fix Ring 1
13 FFV7010058S Undee Washer 1
14 FFV7020024S Hexagon Nut 1
15 FFV0790128S Casing Unit 1
16 FFV3400160S Louver Section 1
17 FFV3400161S Louver Unit 1
18 FFV3400148S Led Unit 1
19 FFV2520040S Insulation Plate 1
A FFV7000108S Truss Tap Screw 5
B FFV7000064S Bind Screw 1
C FFV7000203S Earth Screw Assy 1 Include Spring Washer
D FFV7000089S Truss Tap Screw 7
E FFV7000074S Truss Tap Screw 4
F FFV7000080S Plus Bind Screw 2
Main Labels
No. Part No. Part Name Q'ty Remark
20 FFV4020946S Name Plate 1
21 FFV2260003S UL Mark 1
22 FFV0810011S Caution Label 1 1
23 FFV6730109S FCC Label 1
Packing Section
No. Part No. Part Name Q'ty Remark
24 FFV4710381S Louver Case Assy 1
25 FFV4650016S Poly Cover 1
26 FFV2540232S Installation Instructions 1
27 FFV0010231S Accessory A 1
28 FFV4710431S Right Pad 1
29 FFV4710432S Left Pad 1
30 FFV9001390S Packing Case Assy 1
