Intel, the Intel logo, Intel Atom, and Intel Atom Inside are trademarks of Intel Corporation in the Australia. *Please consult your reseller or Panasonic representative for availability. Toughbook notebook PCs are covered by a
3-year limited warranty, parts and labour. Please consult your Panasonic representative prior to purchase. Panasonic is constantly enhancing product specifications and accessories. Specifications subject to change without
notice. ©2008 Panasonic Corporation of Australia. All rights reserved. U1-10/08
cF-u1 sPecs
Operating system
• Genuine Windows Vista®Business
(with XP downgrade option)
CpU
• Intel®AtomTM Processor Z520 1.33GHz,
512KB L2 cache, 533MHz FSB
stOrage & memOry
• 1024MB SDRAM (DDR2)
• 16GB solid state removable drive
(32GB optional)
DispLay
• 5.6”widescreen 1024 x 600 WSVGA
sunlight-viewable TFT active matrix LCD
– Anti-glare, anti-reflective screen treatments
– LED backlighting
DUraBiLity FeatUres
• MIL-STD-810F- and IP54-compliant
• 1.2 metre drop approved
• Magnesium alloy cage chassis
• Removable solid state drive
• Sealed all-weather design
• Rain-, spill-, dust- and vibration-resistant
• Rotating hand strap
KeyBOarD & inpUt
• Touchscreen LCD–zoom, scroll and
4 user-defined programmable buttons
• 61-key with dedicated Windows®key
expansiOn sLOts
• SD card
• Magnetic stripe reader (with expansion module)
• SmartCard reader (with expansion module)
interFaCe
• Headphones/speaker Mini-jack stereo
• Microphone/line in Mini-jack
• Expansion module Dedicated 19-pin connector
• USB 2.0 (x 1) 4-pin
• Ethernet (RJ-45) With expansion module
• Serial With expansion module
WireLess
• Optional integrated 3G mobile broadband
(WWAN)
• Intel® Wireless Wi-Fi Link 5100
802.11a/b/g/draft-n
• Bluetooth® v2.0 + EDR
pOWer sUppLy
• Twin hot-swappable lithium ion battery
packs (7.2V, 2900mAh each)
• Battery operation: 9 hours
• AC Adapter: AC 100V-240V 50/60Hz
Warranty
• 3-year limited warranty, parts and labor
DimensiOns & WeigHt
• 150mm (L) x 184mm (W) x 57mm (H)
• 1.06Kg
integrateD OptiOns
• Choice of 1D, 2D barcode or RFID reader*
• Mobile Broadband Solutions
– 3G
• 2.0MP camera with dual LED light
• 32GB SSD
• Global positioning system (GPS) receiver
• Fingerprint scanner
• Magnetic Stripe Reader Expansion Module
• Serial/Ethernet/SmartCard Expansion Module
• AC Adapter (3-pin)
• 4-bay Battery Charger
• Lithium Ion Battery Pack
• Touchscreen Replacement Stylus
• External USB Combo Drive
• External USB Floppy Drive
• Desktop Cradle / Spare 2-Bay Battery Charger
• Vehicle Dock
• 5.6" LCD Protector Film
cF-u1 accessories
Panasonic recommends Windows Vista®Business.
introducing Panasonic toughbook cF-u1
the new ruggedised ultra mobile Pc
