Panasonic BB-HNP17A User manual

Operating Instructions
Network Camera Recorder with Viewer Software Ver. 4
Model No. BB-HNP17A
Thank you for purchasing the Panasonic "Network Camera Recorder with Viewer Software Ver. 4"
•Please read this document before using and save this document for future reference.

Introduction
Main Features
Supports H.264
Supports the recording and playback of H.264 cameras.
Supports resolutions of 2048 ´ 1536
Can record and monitor cameras supporting resolution of 2048 ´ 1536.
Supports widescreen displays
Supports 16:9 and other sizes of widescreen displays.
The Multi-monitoring and Multi-playback screens are displayed with the full screen size.
Browsers supported (® Page 132)
By accessing the server for this software with a browser, you can display monitoring and setup pages, etc.
Freedom of layout setup (® Page 103, Page 111)
You can register 64 cameras with this software.*1
Also, you can freely set up the layout of the multi-monitoring window and multi-playback window.
Timer recording with preset designation (® Page 81)
You can specify the display location of timer start/stop times.
Preset Sequence (® Page 48)
Periodically scans and displays the locations registered in the camera presets.
Event Detection Recording
This software can detect and record Motion/Alarm/Sensor/Sound/Shock events.*2
A pop-up is displayed when detection is made (® Page 35)
A pop-up is displayed when the system detects motion or other events.
Time specified color night view (® Page 50)
The start and finish times of color night view can be registered in the schedule.
Multiple Language Support
The default languages are English, Japanese, and Portuguese. (2013/2 present)
Camera connection status notification by E-mail (® Page 43)
The camera's connection status can be sent by E-mail to specified E-mail addresses in cases such as when
the camera and PC become disconnected due to network problems.
Event detection notification by E-mail (® Page 19)
Event detection (Motion Detection, Alarm Detection, Sensor Detection, Sound Detection, and Shock
Detection) notifications can be sent by E-mail to specified E-mail addresses.
2 Operating Instructions
Introduction

Network Video Encoder support (® Page 24)
Network video encoder images can be recorded and played.
*1 This does not indicate the number of cameras that can record at the same time. The number of cameras that can record at the same
time differs depending on factors such as the resolution and frame rate used, and the specifications of your computer. See
Page 167 for details.
*2 Network cameras corresponding to each event are necessary.
Screen shots in this document
Screen shots in this document were taken running this software on Microsoft® Windows® XP.
The screens displayed when using a different operating system may differ slightly.
Trademarks
•Microsoft, Windows, Windows Server, Windows Vista, Internet Explorer, and Windows Media are either
registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
•Intel and Intel Core are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the
United States and other countries.
•Screen shots reprinted with permission from Microsoft Corporation.
•This software is based in part on the work of Independent JPEG Group.
•All other trademarks identified herein are the property of their respective owners.
System Requirements for your PC
The following technical specifications are recommended for this software to work properly with your PC and
network.
Item Description
OS Microsoft® Windows® 8.1
Microsoft® Windows® 8
Microsoft® Windows® 7*1
Microsoft® Windows® Vista*2
Microsoft® Windows® XP
Microsoft® Windows Server® 2012*3
Microsoft® Windows Server® 2008*3
Microsoft® Windows Server® 2003*3
CPU Intel® Core™ 2 Duo 2.1 GHz or higher processor
Memory 4 GB or more
Resolution SXGA (1280 ´ 1024 pixels; 16,770,000 colors)
Web Browser Windows® Internet Explorer® 6 (32-bit English version)
Windows® Internet Explorer® 7 (32-bit English version)
Windows® Internet Explorer® 8 (32-bit English version)
Windows® Internet Explorer® 9 (32-bit English version)
Windows® Internet Explorer® 10 (32-bit English version)
Windows® Internet Explorer® 11 (32-bit English version)
File System NTFS (NT File System)
Operating Instructions 3
Introduction

Item Description
Audio*4 Audio output feature (Speaker or Headphones)
Audio input feature (Microphone)
*1 Because the PC specifications required for running Windows 7 Starter do not meet the required specifications of this software,
performance cannot be guaranteed for PCs running Windows 7 Starter.
*2 For Windows Vista, set the [Power Options] setting to [High performance]. (Using other power settings may affect timer recording.)
*3 Windows Media® Player must be installed to view recorded images.
Install it with the following procedure (when using Windows Server 2003 or Windows Server 2008):
From the server manager feature displayed in [Start]-[Control Panel]-[Programs and Features]-[Turn Windows features on or off],
click [Add Features], select [Desktop Experience], and install Windows Media Player.
*4 When using a camera that supports audio.
Note
•When Windows Update is set to perform updates automatically, recording may be interrupted during
updates. Therefore, we recommend that updates are performed manually during times that will not
affect recording.
Notice
•The recommended number of cameras that you can register, monitor and record simultaneously differs
depending on the specifications of your computer. See Page 167 for details.
•You can estimate recorded image capacity according to the recording method and the number of
recording days. Using [Record Size (estimate)] (® Page 28) and the file sizes of recorded images
(® Page 17) as guidelines, estimate the hard disk capacity requirement.
•When returning from the power saving mode or the screen saver, this software may not function
correctly. Power saving mode is prevented from operating when this software is being used. Also, do
not use the screen saver when using this software. The settings for the screen saver can configured
from the [Preferences] ® [Basic Settings] screen (® Page 14).
•Certain security software use a lot of TEMP files located in the C drive, which may cause this software
to not function correctly.
Internet connections
When you are setting up the camera over an Internet connection or using remote access, we recommend using
a connection method that provides fast uploading and downloading speeds, such as FTTH (optical fiber).
WV Series Network Camera
The following WV series network cameras and network video encoder are supported by this software (2015/6
present):
•SFN6**/SFR6**L/SFN6**/SFV6**/SPN6**/SPW6** series
•SFN3**/SFR3**/SFV3**/SPW3** series
•SPN5** series
•SF5**/SP5**/SW5**/SW4**/SF4** series, GXE100,500 (Network video encoder)
•SW3**/SC3**/SF3**/SP3**/SW1**/SF1**/SP1** series
•NW502S (version 1.02 or later), NP502 (version 1.02 or later)
Network Camera with feature limitations
The following are cameras whose features are limited when used with this software. (2015/6 present)
•The WV series network cameras listed above.
4 Operating Instructions
Introduction

Note
•When the above network cameras with feature limitations are registered to this software, some of the
specifications will differ to those listed in this model.
See Page 159 for details.
About this document
Model number suffixes are omitted in this document.
Operating Instructions 5
Introduction

Table of Contents
1 Before use .................................................................................................8
1.1 Product Introduction .........................................................................................................8
1.2 Starting or Closing This Software ...................................................................................9
1.2.1 Starting Operation Window ..............................................................................................9
1.2.2 Closing the Operation Window .......................................................................................10
1.2.3 Closing This Software ....................................................................................................10
1.3 Performing License Registration ...................................................................................11
1.3.1 Registering a New License .............................................................................................11
1.4 Changing the displayed language .................................................................................13
1.5 Setting Recording Preferences ......................................................................................14
1.5.1 Setting a Folder to Save Recorded Images ...................................................................14
1.5.2 Setting a Proxy Server ...................................................................................................18
1.5.3 Setting E-mail notification ...............................................................................................19
2 Basic Operations ....................................................................................23
2.1 Registering the Camera ..................................................................................................23
2.2 Setting Cameras ..............................................................................................................28
2.3 Network Camera Recorder Window ..............................................................................53
2.3.1 About the Application Windows ......................................................................................53
2.4 Monitoring Cameras .......................................................................................................69
2.4.1 Multi-Monitoring window .................................................................................................69
2.4.2 Operating the camera .....................................................................................................73
2.5 Recording Images ...........................................................................................................75
2.5.1 Recording Method ..........................................................................................................75
2.5.2 Performing Continuous Recording .................................................................................76
2.5.3 Motion Detection Recording ...........................................................................................77
2.5.4 Alarm Detection Recording ............................................................................................78
2.5.5 Sensor Detection Recording ..........................................................................................79
2.5.6 Sound Detection Recording ...........................................................................................79
2.5.7 Shock Detection Recording ............................................................................................80
2.5.8 Timer Recording .............................................................................................................81
2.6 Playing Recorded Images ..............................................................................................88
2.6.1 Selecting Recorded Images to Play ...............................................................................88
2.6.2 Checking the Playback Screen ......................................................................................93
2.6.3 Playing back Recorded Images on the Multi-Playback window .....................................95
2.7 Changing computers ......................................................................................................99
2.8 Playing back saved recording data on another computer ........................................101
3 Applied Functions ................................................................................103
3.1 Using the Software Windows .......................................................................................103
3.1.1 Selecting Cameras .......................................................................................................103
3.1.2 Multi-Monitoring Page Settings ....................................................................................103
3.1.3 Setting the playback volume ........................................................................................110
3.1.4 Sets the multi-playback screen ....................................................................................111
3.2 Editing Recorded Images .............................................................................................113
3.2.1 Converting Recorded Images .......................................................................................113
3.2.2 Copying Recorded Images ...........................................................................................125
3.2.3 Deleting Recorded Images ...........................................................................................127
3.2.4 Changing the keyword ..................................................................................................128
3.2.5 Copying Display Screens .............................................................................................128
3.2.6 Displaying the Recorded Image Information ................................................................130
3.3 Using Remote Access Functions ................................................................................132
6 Operating Instructions
Table of Contents

3.3.1 Configuring the Settings ...............................................................................................133
3.4 Other Features ...............................................................................................................145
3.4.1 Audio Transmission ......................................................................................................145
3.4.2 Importing/Exporting the Camera Information ...............................................................145
3.4.3 Copying Camera Images ..............................................................................................147
3.4.4 Deleting a Registered Camera from the List ................................................................148
3.4.5 Deleting Timer Settings ................................................................................................149
3.4.6 Checking the Recording Capacity and Remaining Time ..............................................151
3.4.7 Executing Restore Program and Log Analysis .............................................................154
4 Using WV series network cameras and some BL series network
cameras .................................................................................................159
4.1 Specification Differences .............................................................................................159
4.1.1 Multi-Monitoring screen ................................................................................................159
4.1.2 Image Settings .............................................................................................................160
4.1.3 Motion Detection ..........................................................................................................161
4.1.4 Alarm/Sensor Detection ...............................................................................................162
4.1.5 Other Settings ..............................................................................................................162
4.2 Network Camera Setting Values ..................................................................................164
4.3 Recording Image File Sizes ..........................................................................................165
4.4 Recommended Configuration ......................................................................................166
5 Additional Information .........................................................................167
5.1 Specifications ................................................................................................................167
5.2 Troubleshooting ............................................................................................................169
5.3 Error Message List ........................................................................................................174
5.4 Default Setting List .......................................................................................................185
Operating Instructions 7
Table of Contents

1 Before use
1.1 Product Introduction
You must perform the following steps in order to use this software.
Read the Software End User License Agreement (® attached leaflet)
•You cannot install this software if you disagree.
(The legal agreement is required when installing this software.)
Install this software
(® "Important Information")
Performing License Registration (® Page 11)
•It is necessary to register the license in order to use this software.
•The attached registration code stickers are required.
Setting Recording Preferences (® Page 14, Page 18, Page 19)
•Set a folder to save recorded images.
•Set the proxy server when using one.
•Set the E-mail address to send notifications for event detections and connection disruptions.
Registering the Camera (® Page 23)
•If the camera has security settings enabled (authentication setting), enter the administrator
user name and password for the camera. If you set a general or unregistered user name
and password, this software may not work properly.
Monitoring the Camera (® Page 69, Page 73)
Recording the Image (® Page 75)
Playing the Recorded Images (® Page 88)
8 Operating Instructions
1.1 Product Introduction

1.2 Starting or Closing This Software
This software starts automatically when you boot up the PC.
• is displayed in the notification area while this software is running.
PC screen
Start
notification area
Displayed in the
notification area.
Note
•When using the software on Windows 7 the is not displayed in the notification area.
Click the ( ) in the notification area to display the .
To always display , click the ( ) in the notification area. From the displayed menu select
[Customize] and configure [Show icon and notifications] for the software.
•To not start this software automatically when booting up the PC, right-click and uncheck [Start on
bootup] from the menu.
1.2.1 Starting Operation Window
Double-click on the desktop to start this software.
•Operation window of this software is displayed.
Note
•You can also start the operation window through the following procedures.
–From the [Start] menu, select [All Programs] ® [Network Camera Recorder with Viewer Software
Ver. 4] ® [Network Camera Recorder with Viewer Software Ver. 4].
–Start Explorer and double click the destination [Ncr4] folder [ncr4.exe] where this software will be
installed.
•This software cannot be started multiple times simultaneously.
Operating Instructions 9
1.2.1 Starting Operation Window

•You must register the license to use this software.
[Register the license key.] will be displayed if you start this software without having first registered it.
Follow the steps in Page 11 to register the license.
1.2.2 Closing the Operation Window
Click in the operation window.
Note
• will continue to be displayed in the notification area even after you close the operation window.
While is displayed, the software keeps running so that timer recording can operate as set.
1.2.3 Closing This Software
1. Right-click in the notification area and select [Exit].
2. Click [Yes].
Note
•When you exit this software, will be removed from the notification area.
•When you exit this software, any timers that you have set stop operating.
10 Operating Instructions
1.2.3 Closing This Software

1.3 Performing License Registration
If no license has been registered when the operation window is started, [Register the license key.] will be
displayed.
1.3.1 Registering a New License
1. Click on the multi-monitoring window and select [License Registration] from the menu which is
displayed.
2. Enter the [Registration Code] and [License key], and click [OK].
•The registration code and license key are printed on the attached registration code sticker.
Entries are case-sensitive, so be sure to enter this information exactly as it is printed on the sticker.
3. Click [OK].
Operating Instructions 11
1.3.1 Registering a New License

Note
•[License Registration] will turn gray when you have completed registration.
•If security software is operating, [License Registration] may still be displayed after completing the
license registration and starting the operation screen. In this case, temporarily stop the security
software, or perform settings such as allowing connections to the software. For more information, see
your security software manual.
Notice
•If the following window is displayed, the registration code or license key is incorrect.
Confirm them, and then enter them again.
•Keep the registration code and license key in a safe place where you will not lose them.
Lost codes and keys cannot be reissued.
12 Operating Instructions
1.3.1 Registering a New License

1.4 Changing the displayed language
You can change the displayed language.
1. Click on the multi-monitoring window.
2. Select the language that you want to display.
•In the default setting, you can choose from the following languages. (2015/6 present)
·English ·Japanese ·Portuguese
3. Click [Yes].
•The displayed language will be changed after restarting the software.
Operating Instructions 13
1.4 Changing the displayed language

1.5 Setting Recording Preferences
1.5.1 Setting a Folder to Save Recorded Images
This software records camera images to the hard disk on your PC. The folder can be changed.
After you have changed the destination folder, the recorded images will be saved in the folder that you specified.
•If the destination folder is not specified, the recorded images are saved into the [ncrdata] folder in the folder
where this software is installed.
•You can change the destination folder to another folder or external hard disk drives.
1. Click on the multi-monitoring window.
2. Click [Preferences].
3. Configure the settings on the [Basic Settings] page and click [OK].
Basic Settings Page
Setting Description
Save Destination Folder Specify the destination folder to save recorded images. (® Page 16)
•Due to the operating system specifications (UAC: User Account Control)
of Windows Vista and Windows 7, when [Program Files] of the start-up
drive is specified in the destination folder, recorded images are
automatically saved in separate folders. When this software is installed
to C:\Program Files\Panasonic\NCR4 in Windows Vista and Windows
7, folders are saved to: C:\User\(user name)\AppData\Local
\VirtualStore\Program Files\Panasonic\Ncr4\ncrdata. Do not directly set
the [AppData] folder as the destination folder.
Note that the [AppData] folder is a hidden folder. If the folder is not
displayed, set the folder settings to [Show hidden, files, folders, and
drives] from [Folder Options].*1
14 Operating Instructions
1.5.1 Setting a Folder to Save Recorded Images

Setting Description
Limit the recording capacity Place a check mark in [Limit the recording capacity] when there are
limitations on the recording capacity where you will be saving recordings
and set the [Capacity Limit]. (1 GB (default))
When no recording capacity limit is set, the recording will stop when the free
disk space of the chosen save file destination is under 10%.
Operation when the capacity
reached the limit
Sets operation when the limit has been reached. ([Stop recording] (default),
[Delete old files and keep recording])
Screen Saver By placing a mark in [Stop the screen saver during operations for this
product], the computer's screen saver will be stopped when this software is
being used.
•When returning from the screen saver, this software may not function
correctly.
We recommend placing a check mark in [Stop the screen saver during
operations for this product] to deactivate the screen saver.
Automatic settings for the
camera
The optimal settings for the WV series network cameras and some of the
BB series network cameras can automatically be set when the camera is
registered.
See 4.2 Network Camera Setting Values for more details on the
automatically set parameters.
*1 Use the following procedure to display hidden folders:
1. With the explorer view displayed, click the [ALT] key and select [Folder options...] from the [Tools] menu.
2. Select [View] from the [Folder Options] window.
3. From the [Advanced settings] menu select [Show hidden, files, folders, and drives] and click [Apply].
Note
•You can also specify the destination folder for individual cameras. (® Page 24)
•Starting from 1 GB, [Capacity Limit] has a maximum limit of 90% of the capacity of the save destination
drive. For stable operations, we recommend setting the limit to within 70% of the capacity of the save
destination drive.
An error window will be displayed if you make a setting in excess of 90% of capacity.
•If you select [Delete old files and keep recording] and the recording capacity is set to less than the
amount already recorded, the difference will be deleted starting from the oldest recorded images.
(For example: If you change the recording capacity to 2 GB when there are already 3 GB of recorded
images, 1 GB of the older recorded images will be deleted.)
•It is recommended that you use the built-in hard disk as your save file destination.
When using an external hard disk as your save file destination, use a hard disk with an access speed
as fast as possible. Issues such as the loss of recorded images, a decrease in operation response,
etc., may occur depending on the access speed of the hard disk.
•You can also limit the recording capacity of individual cameras. (® Page 31)
However, when the [Limit the recording capacity] is set on the [Camera Settings] page, the following
Operating Instructions 15
1.5.1 Setting a Folder to Save Recorded Images

window is displayed. Clicking the [OK] button cancels the [Limit the recording capacity] setting on the
[Camera Settings] page.
Change the destination folder
1. Click [Browse] under [Save Destination Folder] in the [Basic Settings] page.
2. Select the destination folder, and click [OK].
•Create the folder in advance.
Notice
•The drive containing the destination folder must have a capacity of 1.2 GB or more, and have 10% of
free space or more.
•Do not move, change, or delete the files and folders in the destination folder. Doing so can cause this
software to behave unexpectedly.
•Select a destination folder with a path less than 128 characters.
e.g.
under 128 characters
D:/HNP17/2010
16 Operating Instructions
1.5.1 Setting a Folder to Save Recorded Images

Note
•When you change a setting, a mark is displayed on the icon for the item that you changed. The setting
is applied when you click [OK] or [Apply].
See Page 63 for details on the settings icons.
File sizes of recorded images
Note
•The maximum file size is shown.
•See Page 165 for details on WV series network cameras and some BL series network cameras file
sizes.
1 frame size (Image only)
Data format: JPEG
Resolution
File Size (KB)
Favor Clarity Standard Favor Motion
1280 ´ 1024 100 77 60
1280 ´ 960 120 77 60
640 ´ 480 50 35 27
320 ´ 240 25 16 10
192 ´ 144 10 7 5
160 ´ 120 7 5 3
•Recording capacity can be calculated by Size (KB) ´ Frame Rate (images per second) ´ time (second).
e.g. 640 ´ 480 resolution, Favor Clarity and 5 images per second for one hour:
50 (KB) ´ 5 (images/s) ´ 3,600 (s) = 900,000 KB (About 879 MB).
If the audio is attached, add 4 KB per second.
900,000 (KB) + 4 (KB) ´ 3,600 (s) = 914,400 KB (About 893 MB).
Data size for 1 second of motion (Image only)
Data format: MPEG-4/H.264
MPEG-4/H.264 bit rate (kbps) Data size/hour (KB)
2,048 921,600
1,536 691,200
1,024 460,800
768 345,600
512 230,400
384 172,800
256 115,200
192 86,400
•MPEG-4 recording capacity can be calculated by MPEG-4 bit rate*1 (Kbps) divided by 8 bits, times by time
(seconds).
Example: for a 640 x 480 dot resolution with 768 Kbps MPEG-4 bit rate, the calculation is 768 Kbps divided
by 8 bits, times by 3,600 seconds (1 hour) = 345,600 KB (About 337.5 MB).
Operating Instructions 17
1.5.1 Setting a Folder to Save Recorded Images

To calculate the recording capacity for images with audio, add 4 KB for each second of recording.
345,600 KB plus 4 KB times 3,600 seconds (1 hour) = 360,000 KB (About 352 MB)
*1 Perform calculations with the maximum values of the [MPEG-4 Bit Rate] of the [Video Streaming] set for the camera.
•H.264 recording capacity can be calculated by H.264 bit rate*1 (Kbps) divided by 8 bits times by time
(seconds).
Example: for a 640 x 480 dot resolution with 1,536 Kbps H.264 bit rate, the calculation is 1,536 Kbps divided
by 8 bits, times by 3,600 seconds (1 hour) = 691,200 KB (About 675 MB).
To calculate the recording capacity for images with audio, add 8 KB for each second of recording.
691,200 KB plus 8 KB times 3,600 seconds (1 hour) = 720,000 KB (About 704 MB)
*1 Perform calculations with the maximum values of the [H.264 Bit Rate] of the [Video Streaming] set for the camera.
1.5.2 Setting a Proxy Server
When viewing a camera over the Internet using a proxy server, set [Used] on the [Camera Settings] page for
each camera after setting the proxy server. (® Page 24)
The following settings are not necessary when not using a proxy server.
1. Click on the multi-monitoring window.
2. Click [Proxy Server] under [Preferences].
3. Set the parameters and click [OK].
Proxy Server page
18 Operating Instructions
1.5.2 Setting a Proxy Server

Setting Description
Server Address/Port Enter the IP address of proxy server and port number.
Enter them after asking your network administrator.
•Enter the alphanumeric characters. (Enter only numeric characters for
the port number.)
•Proxy servers are not supported in IPv6 connections.
Enter the IPv4 address or the URL which is registered with the IPv4
domain name service.
User Name/Password Enter the user name and password for the proxy server, if required.
Enter them after asking your network administrator.
•Enter the alphanumeric characters.
1.5.3 Setting E-mail notification
You can configure the software to send event detection (Motion Detection, Alarm Detection, Sensor
Detection, Sound Detection, and Shock Detection) notifications and camera connection status information to
PC and mobile phone addresses.
Detected camera images (JPEG) can be sent as E-mail attachments.
1. Click on the multi-monitoring window.
2. Click [E-mail Settings] under [Preferences].
3. Set the parameters and click [OK].
E-mail Settings Page
Operating Instructions 19
1.5.3 Setting E-mail notification

Setting Description
IP Address or Host Name Enter the Mail Sending Server (SMTP) IP address or host name. (Up to 255
alphanumeric characters.)
•Symbols can also be entered (up to 255 alphanumeric characters).
However, [Space], ["], ['], [&], [<], [>], [0.0.0.0], and [255.255.255.255]
cannot be entered.
•IPv6 addresses can also be used.
–When entering IPv6 addresses, divide the 8 groups of hexadecimal
digits with [:].
–Consecutive [0] are displayed as [::].
–To distinguish IPv4 addresses, set these in brackets [ ].
Example: [2001:2:3:4::5]
Port Enter the Mail Sending Server (SMTP) port number (1-65535). Port 25 is
normally used.
Sender Enter the sender's E-mail address.
•Enter the E-mail address assigned by the provider specified in Mail
Sending Server (SMTP).
•["] cannot be entered in E-mail addresses.
Destination E-mail Address 1/
Destination E-mail Address 2/
Destination E-mail Address 3
Enter the destination E-mail addresses.
•Up to 3 destination addresses can be set. (It is not necessary to enter
all 3 destination addresses.)
•["] cannot be entered in E-mail addresses.
20 Operating Instructions
1.5.3 Setting E-mail notification
