Panasonic Zener Diodes MAZSxxx Series User manual

Zener Diodes
1
Publication date: March 2003 SKE00012CED
MAZSxxx Series
Silicon planar type
For constant voltage, constant current, waveform clip-
per and surge absorption circuit
■Features
•SS-Mini type 2-pin package (SSMini2-F1)
•Low noise type
•VZrank classified(VZ=2.4 V to 39 V)
■Absolute Maximum Ratings Ta=25°C
Unit: mm
Parameter Symbol Rating Unit
Repetitive peak forward current IFRM 200 mA
Total power dissipation *Ptot 150 mW
Junction temperature Tj150 °C
Storage temperature Tstg −55 to +150 °C
1: Anode
2: Cathode
EIAJ: SC-79
SSMini2-F1 Package
Note) *: With a printed circuit board
Parameter Symbol Conditions Min Typ Max Unit
Forward voltage VFIF=10 mA 0.9 1.0 V
Zener voltage *2VZIZSpecified value V
Reverse current IRVRSpecified value µA
Zener rise operating resistance RZK IZSpecified value Ω
Zener operating resistance RZIZSpecified value Ω
Temperature coefficient of zener voltage *3SZIZSpecified value mV/°C
■Common Electrical Characteristics Ta=25°C±3°C *1
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7031 measuring methods for diodes.
2. Rated input/output frequency: 5 MHz
3. *1: The VZvalue is for the temperature of 25°C. In other cases, carry out the temperature compensation.
*2: Guaranteed at 20 ms after power application.
*3: Tj=25°C to 150°C
0.80+0.05
–0.03
0.60+0.05
–0.03
0.12+0.05
–0.02
1.20+0.05
–0.03
0+0
–0.05
0.30±0.05
0.01±0.01
1.60±0.05
0.01±0.01
1
2
0.80±0.05(0.80)
(0.60)
(0.15)
(0.60)
5˚
5˚
Internal Connection
1
2
Marking Symbol
Refer to the list of the electrical
characteristics within part numbers
(Example) MAZS082 : 8
MAZS0820L : 8_
MAZS0820M: 8−
MAZS0820H : 8^
Note) L/M/H marked products will be supplied
unless other wise specified
Refer to the list of the
electrical characteristics
within part numbers

MAZSxxx Series
SKE00012CED
2
Zener voltage Reverse Zener operating
current resistance
Part Number VZ(V) IR (µA) RZ (Ω)R
ZK (Ω)S Z (mV/°C) Marking symbol
Min Nom Max IZMax VRMax IZMax IZTyp IZ
(mA) (V) (mA) (mA) (mA)
MAZS024 2.28 2.40 2.60 5 120 1.0 100 5 −1.6 5 T
MAZS027 2.50 2.70 2.90 2 or 2_ or 2^
MAZS0270L 2.50 2.60 2.75 5 120 1.0 110 5 −2.0 5 2_
MAZS0270H 2.65 2.80 2.90 2^
MAZS030 2.80 3.00 3.20 3 or 3_ or 3^
MAZS0300L 2.80 2.90 3.05 5 50 1.0 120 5 −2.1 5 3_
MAZS0300H 2.95 3.10 3.20 3^
MAZS033 3.10 3.30 3.50 F or F_ or F^
MAZS0330L 3.10 3.20 3.35 5 20 1.0 130 5 −2.4 5 F_
MAZS0330H 3.25 3.40 3.50 F^
MAZS036 3.40 3.60 3.80 H or H_ or H^
MAZS0360L 3.40 3.50 3.65 5 10 1.0 130 5 −2.4 5 H_
MAZS0360H 3.55 3.70 3.80 H^
MAZS039 3.70 3.90 4.10 K or K_ or K^
MAZS0390L 3.70 3.80 3.97 5 10 1.0 130 5 −2.5 5 K_
MAZS0390H 3.87 4.00 4.10 K^
MAZS043 4.00 4.30 4.60 L or L_ or L−or L^
MAZS0430L 4.03 4.10 4.26 5 10 1.0 130 5 −2.5 5 L_
MAZS0430M 4.17 4.30 4.40 L−
MAZS0430H 4.31 4.40 4.54 L^
MAZS047 4.40 4.70 5.00 N or N_ or N−or N^
MAZS0470L 4.45 4.60 4.69 5 2.0 1.0 80 5 800 1.0 −1.4 5 N_
MAZS0470M 4.59 4.70 4.83 N−
MAZS0470H 4.74 4.90 4.99 N^
MAZS051 4.80 5.10 5.40 5 or 5_ or 5−or 5^
MAZS0510L 4.87 5.00 5.12 5 1.0 2.0 60 5 500 1.0 −0.8 5 5_
MAZS0510M 5.00 5.10 5.26 5−
MAZS0510H 5.14 5.30 5.40 5^
MAZS056 5.30 5.60 6.00 P or P_ or P−or P^
MAZS0560L 5.30 5.40 5.58 5 0.5 2.5 40 5 200 0.5 1.2 5 P_
MAZS0560M 5.48 5.60 5.76 P−
MAZS0560H 5.66 5.80 5.95 P^
MAZS062 5.80 6.20 6.60 6 or 6_ or 6−or 6^
MAZS0620L 5.85 6.00 6.15 5 0.2 4.0 30 5 100 0.5 2.3 5 6_
MAZS0620M 6.05 6.20 6.36 6−
MAZS0620H 6.24 6.40 6.56 6^
MAZS068 6.40 6.80 7.20 R or R_ or R−or R^
MAZS0680L 6.44 6.60 6.77 5 0.1 4.0 20 5 60 0.5 3.0 5 R_
MAZS0680M 6.64 6.80 6.98 R−
MAZS0680H 6.85 7.00 7.20 R^
MAZS075 7.00 7.50 7.90 7 or 7_ or 7−or 7^
MAZS0750L 7.07 7.30 7.43 5 0.1 5.0 20 5 60 0.5 4.0 5 7_
MAZS0750M 7.29 7.50 7.67 7−
MAZS0750H 7.51 7.70 7.89 7^
MAZS082 7.70 8.20 8.70 8 or 8_ or 8−or 8^
MAZS0820L 7.77 7.90 8.17 5 0.1 5.0 20 5 60 0.5 4.6 5 8_
MAZS0820M 8.03 8.20 8.43 8−
MAZS0820H 8.29 8.50 8.70 8^
MAZS091 8.50 9.10 9.60 9 or 9_ or 9- or 9^
MAZS0910L 8.58 8.80 9.02 5 0.1 6.0 20 5 60 0.5 5.5 5 9_
MAZS0910M 8.87 9.10 9.33 9−
MAZS0910H 9.14 9.40 9.60 9^
■Electrical characteristics within part numbers Ta=25°C±3°C
Temperature
coefficient of
zener voltage

MAZSxxx Series
SKE00012CED 3
Zener voltage Reverse Zener operating
current resistance
Part Number VZ(V) IR (µA) RZ (Ω)R
ZK (Ω)S Z (mV/°C) Marking symbol
Min Nom Max IZMax VRMax IZMax IZTyp IZ
(mA) (V) (mA) (mA) (mA)
MAZS100 9.40 10.00 10.60 10 or 10_ or 10−or 10^
MAZS1000L 9.44 9.70 9.92 5 0.05 7.0 30 5 60 0.5 6.4 5 10_
MAZS1000M 9.75 10.00 10.25 10−
MAZS1000H 10.07 10.30 10.59 10^
MAZS110 10.40 11.00 11.60 11 or 11_ or 11−or 11^
MAZS1100L 10.40 10.70 10.94 5 0.05 8.0 30 5 60 0.5 7.4 5 11_
MAZS1100M 10.73 11.00 11.28 11−
MAZS1100H 11.05 11.30 11.60 11^
MAZS120 11.40 12.00 12.70 12 or 12_ or 12−or 12^
MAZS1200L 11.40 11.70 11.96 5 0.05 9.0 30 5 80 0.5 8.4 5 12_
MAZS1200M 11.73 12.00 12.33 12−
MAZS1200H 12.06 12.30 12.68 12^
MAZS130 12.40 13.00 14.10 13 or 13_ or 13−or 13^
MAZS1300L 12.40 12.70 12.99 5 0.05 10.0 35 5 80 0.5 9.4 5 13_
MAZS1300M 12.73 13.00 13.40 13−
MAZS1300H 13.25 13.70 14.08 13^
MAZS150 13.90 15.00 15.60 15 or 15_ or 15−or 15^
MAZS1500L 13.90 14.30 14.76 5 0.05 11.0 40 5 80 0.5 11.4 5 15_
MAZS1500M 14.60 15.00 15.35 15−
MAZS1500H 14.95 15.30 15.60 15^
MAZS160 15.30 16.00 17.10 16 or 16_ or 16−or 16^
MAZS1600L 15.30 15.70 16.09 5 0.05 12.0 50 5 80 0.5 12.4 5 16_
MAZS1600M 15.70 16.00 16.50 16−
MAZS1600H 16.26 16.70 17.10 16^
MAZS180 16.90 18.00 19.10 18 or 18_ or 18−or 18^
MAZS1800L 16.90 17.30 17.76 5 0.05 13.0 60 5 80 0.5 14.4 5 18_
MAZS1800M 17.55 18.00 18.45 18−
MAZS1800H 18.20 18.70 19.10 18^
MAZS200 18.80 20.00 21.20 20 or 20_ or 20−- or 20^
MAZS2000L 18.85 19.30 19.81 5 0.05 15.0 80 5 100 0.5 16.4 5 20_
MAZS2000M 19.50 20.00 20.50 20−
MAZS2000H 20.15 20.70 21.19 20^
MAZS220 20.80 22.00 23.30 22 or 22_ or 22−or 22^
MAZS2200L 20.80 21.30 21.86 5 0.05 17.0 80 5 100 0.5 18.4 5 22_
MAZS2200M 21.45 22.00 22.55 22−
MAZS2200H 22.10 22.70 23.24 22^
MAZS240 22.80 24.00 25.60 24 or 24_ or 24−or 24^
MAZS2400L 22.80 23.30 23.97 5 0.05 19.0 100 5 120 0.5 20.4 5 24_
MAZS2400M 23.50 24.00 24.70 24−
MAZS2400H 24.35 25.00 25.60 24^
MAZS270 25.10 27.00 28.90 27 or 27_ or 27−or 27^
MAZS2700L 25.30 26.00 26.70 2 0.05 21.0 120 2 120 0.5 23.4 2 27_
MAZS2700M 26.30 27.00 27.70 27−
MAZS2700H 27.30 28.00 28.70 27^
MAZS300 28.00 30.00 32.00 30 or 30_ or 30−or 30^
MAZS3000L 28.30 29.00 29.70 2 0.05 23.0 160 2 160 0.5 26.6 2 30_
MAZS3000M 29.30 30.00 30.80 30−
MAZS3000H 30.20 31.00 31.80 30^
MAZS330 31.00 33.00 35.00 33 or 33_ or 33−or 33^
MAZS3300L 31.20 32.00 32.80 2 0.05 25.0 200 2 200 0.5 29.7 2 33_
MAZS3300M 32.20 33.00 33.80 33−
MAZS3300H 33.20 34.00 34.90 33^
■Electrical characteristics within part numbers (continued) Ta=25°C±3°C
Temperature
coefficient of
zener voltage

MAZSxxx Series
SKE00012CED
4
Zener voltage Reverse Zener operating
current resistance
Part Number VZ(V) IR (µA) RZ (Ω)R
ZK (Ω)S Z (mV/°C) Marking symbol
Min Nom Max IZMax VRMax IZMax IZTyp IZ
(mA) (V) (mA) (mA) (mA)
MAZS360 34.00 36.00 38.00 36 or 36_ or 36−or 36^
MAZS3600L 34.10 35.00 35.90 2 0.05 27.0 250 2 250 0.5 33.0 2 36_
MAZS3600M 35.10 36.00 36.90 36−
MAZS3600H 36.10 37.00 37.90 36^
MAZS390 37.00 39.00 41.00 39 or 39_ or 39−or 39^
MAZS3900L 37.10 38.00 39.00 2 0.05 30.0 300 2 300 0.5 35.6 2 39_
MAZS3900M 38.00 39.00 40.00 39−
MAZS3900H 39.00 40.00 41.00 39^
■Electrical characteristics within part numbers (continued) Ta=25°C±3°C
Temperature
coefficient of
zener voltage

MAZSxxx Series
SKE00012CED 5
0
0 2001601208040
50
100
150
200
250
Ambient temperature Ta(°C)
Total power dissipation P
tot
(mW)
Heat sink
Copper foil
0.8 mm × 0.8 mm
0.001
024681012
0.01
0.1
1
10
100
Zener voltage V
Z
(V)
Zener current I
Z
(mA)
T
a = 25°C
Static
charac-
teristics
MAZS062
MAZS068
MAZS075
MAZS082
MAZS091
MAZS100
MAZS024
MAZS039
MAZS047
MAZS051
MAZS043
MAZS056
0.001
0 102030405060
0.01
0.1
1
10
100
Zener voltage VZ(V)
Zener current IZ(mA)
T
a = 25°C
Static
charac-
teristics
MAZS160
MAZS200
MAZS240
MAZS360
MAZS390
MAZS110
MAZS130
Ptot TaIZVZIZVZ
0.001
024681012
0.01
0.1
1
10
100
Tj=25°C
Dynamic
charac-
teristics
MAZS100
MAZS091
MAZS082 MAZS075 MAZS068 MAZS062 MAZS056 MAZS051 MAZS047 MAZS043 MAZS039 MAZS033 MAZS027 MAZS024
Zener voltage V
Z
(V)
Zener current I
Z
(mA)
0.001
0 102030405060
0.01
0.1
1
10
100
T
j = 25°C
Dynamic
charac-
teristics
MAZS110 MAZS130 MAZS160 MAZS200 MAZS240 MAZS360 MAZS390
Zener voltage V
Z
(V)
Zener current I
Z
(mA)
1
10
100
1
000
0.1 1 10010 1
000
Zener operating resistance R
Z
(Ω)
Zener current I
Z
(mA)
T
a = 25°C
MAZS047
MAZS039
MAZS051
MAZS056
MAZS062
MAZS068
MAZS160
MAZS390
MAZS024
MAZS100
MAZS082
MAZS043
0.01
0 0.2 0.4 0.6 1.00.8 1.2
0.1
1
10
100
Forward voltage V
F
(V)
Forward current I
F
(mA)
T
a = 25°C
15
5
−5
20
25
0
10
01020 405030
Zener current IZ(mA)
Temperature coefficient of zener voltage SZ(mV/°C)
MAZS240
MAZS160
MAZS100
MAZS068
MAZS039
MAZS024
IZVZIZVZRZIZ
IFVFSZIZ

MAZSxxx Series
SKE00012CED
6
1
10
100
0.1
1001010.10.01
Pulse width tW(ms)
Non-repetitive reverse P
ZSM
(W)
surge power dissipation
MAZS039
MAZS075
T
a = 25°C
t
W
Non repetitive
P
ZSM
0.1
1
10
0.01
1001010.10.01
Pulse width tW(s)
Thermal impedance Zth (°C/mW)
With heat sink (Typ. value)
Without heat sink (Typ. value)
Heat sink
Copper foil 0.8 mm × 0.8 mm
PZSM tWZth tW

Request for your special attention and precautions in using the technical information and
semiconductors described in this book
(1)If any of the products or technical information described in this book is to be exported or provided to non-residents, the laws and
regulations of the exporting country, especially, those with regard to security export control, must be observed.
(2)The technical information described in this book is intended only to show the main characteristics and application circuit examples
of the products, and no license is granted under any intellectual property right or other right owned by our company or any other
company. Therefore, no responsibility is assumed by our company as to the infringement upon any such right owned by any other
company which may arise as a result of the use of technical information described in this book.
(3)The products described in this book are intended to be used for standard applications or general electronic equipment (such as office
equipment, communications equipment, measuring instruments and household appliances).
Consult our sales staff in advance for information on the following applications:
–Special applications (such as for airplanes, aerospace, automobiles, traffic control equipment, combustion equipment, life support
systems and safety devices) in which exceptional quality and reliability are required, or if the failure or malfunction of the prod-
ucts may directly jeopardize life or harm the human body.
–Any applications other than the standard applications intended.
(4)The products and product specifications described in this book are subject to change without notice for modification and/or im-
provement. At the final stage of your design, purchasing, or use of the products, therefore, ask for the most up-to-date Product
Standards in advance to make sure that the latest specifications satisfy your requirements.
(5)When designing your equipment, comply with the range of absolute maximum rating and the guaranteed operating conditions
(operating power supply voltage and operating environment etc.). Especially, please be careful not to exceed the range of absolute
maximum rating on the transient state, such as power-on, power-off and mode-switching. Otherwise, we will not be liable for any
defect which may arise later in your equipment.
 Even when the products are used within the guaranteed values, take into the consideration of incidence of break down and failure
mode, possible to occur to semiconductor products. Measures on the systems such as redundant design, arresting the spread of fire
or preventing glitch are recommended in order to prevent physical injury, fire, social damages, for example, by using the products.
(6)Comply with the instructions for use in order to prevent breakdown and characteristics change due to external factors (ESD, EOS,
thermal stress and mechanical stress) at the time of handling, mounting or at customer's process. When using products for which
damp-proof packing is required, satisfy the conditions, such as shelf life and the elapsed time since first opening the packages.
(7)This book may be not reprinted or reproduced whether wholly or partially, without the prior written permission of Matsushita
Electric Industrial Co., Ltd.
