Panasonic BN-SW60ANL0 User manual

User's manual
DTL Wireless Link Wireless Unit
Model No. BN-SW60ANL0
Panasonic Corporation Connecter Solutions Company
@ Panasonic Corporation 2018
1-15 Matsuo-cho Kadoma-shi Osaka, JAPAN 571-8504

Features
The DTL Wireless Link(DTLWL) is the system to connect information network
between carriages wirelessly. The DTLWL is integrated in the on-board train
system and enables the ultra-high speed information network over a train.
The DTLWL is capable of handling over 1 Gigabit data rate wirelessly and equips
Ethernet ports as data transmission interface, therefore this is a best solution to
replace from Gigabit Ethernet cable. In addition, since an Ethernet port supports
Power on Ethernet spec (IEEE802.3at), single cable connection is required for
system integration. The DTLWL is designed as dedicated area network with
minimal incoming/outgoing interference, so that there is no interference from a
train system on one truck to the other system on other truck.
Wireless unit has wireless communication function of 60 GHz.
Main Specifications
Center frequency 60.48GHz
Frequency bandwidth 1.76GHz
Transmitt Power 8dBm
Distance coverage 0.9m or less
Data Rate 900Mbps (Typ.)
Interface USB3.0 (Special connector)
Power voltage DC +5.0V (from USB Connector)
Power consumption 2.55W or less
Usage conditions
Storage Temperature : -40 to +80 ℃
Storage Humidity : 5 to 95% no condensation
Operating Temperature : -40 to +50 ℃
Operating Humidity : <75% (in average)
<95% (up to continuous 30 days)
External dimensions 160(W) x 160(H) x 110.3(D) mm
(does not include protrusions)
Body weight About 1.6kg

Outline
Protective Bent
Connector
Cable Ground

Be sue to observe these safety precautions because they are designed to
protect you or Those around you from causing injury and to avoid unnecessary
damege to the property.
Precautions ALWAYS FOLLOW THESE DIRECTIONS
The symbols below indicate the levels of danger or damage that can be caused
if the particular precautions are noto observed.
Warning This symbol indicates that incorrect handling poses a
risk of causing death or serious injury.
Caution This symbol indicates that incorrect handling poses a
risk of causing injury or damage to the product or
property.
The following symbols show specific directions:
Don’t
Do not
Denotes things not to do. (Prohibition)
Denotes the units not to disassemble.
Do
Denotes mandatory instructions (matters that must be
comlied with)
Warning
disassemble
Do not
disassemble
Do not attempt to disassemble or remodel
Fire, burns, injury or electric shock may result.

Warning
Do
When there is abnormality, stop using it immediately.
If smoke comes out, smells, the outside deteriorates, as it is, it may cause injury due to
fire or falling, damage to the equipment.
Do
Install in a place that can withstand the total weight.
If the strength is insufficient, it may cause injury or accident due to falling.
Do
Check regularly.
If the metal fittings and screws rust, it may cause injury or accident due to falling.
Do
Tighten the screws and bolts with the specified torque value.
Falling may cause injury or accident.
Don’t
Do not install other than the specified method.
It may cause accidents such as falling.
Don’t
Do not dangle, do not substitute for footholds.
It may cause accidents such as falling.
Don’t
Do not use outside the rating.
It may cause fire or electric shock.
Do
Please use 20 cm away when using the product
The radio wave may adversely affect the operation of electronic medical equipment.

Please refer to the installation manual for installation.
Before installing and connecting this equipment, check the necessary
peripheral equipment and cables and prepare.
Installation Precautions

RED InformationCE Declaration of Conformity
Hereby, Panasonic declares that this “BN-SW60ANL0” is in compliance with the
essential requirements and other relevant provisions of Directive 2014/53/EU.
The declaration of conformity may be consulted at
http://panasonic.xxx/xxxx/xxxx.pdf.
Declaration of Operation
This equipment has been so constructed that the product complies with the
requirement of with Article 10(2) as it can be operated in at least one Member
State as examined and the product is compliant with Article 10(10) as it has no
restrictions on putting into service in all EU member states.

FCC Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.

FCC Notice
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
